Summary of Contents for ZyXEL Communications M-202
-
Page 1: Quick Start Guide
ZyXEL M-202 XtremeMIMO 802.11b/g Wireless USB Adapter Quick Start Guide Version 1.0 February 2006... - Page 2 Procedure to View a Product's Certification(s) 1. Go to www.us.zyxel.com 2. Select your product from the drop-down list box on the ZyXEL home page to go to that product's page. 3. Select the certification you wish to view from this page.
-
Page 3: About Your Zyxel M-202
About Your ZyXEL M-202 The ZyXEL M-202 is an IEEE 802.11 b/g compliant wireless LAN USB stick that fits into any USB slot. With the ZyXEL M-202, you can enjoy the wireless mobility within the coverage area. The ZyXEL XtremeMIMO technology provides greater range and offers transmission rate at up to 54 Mbps. - Page 4 ZyXEL M-202 Quick Start Guide the Z icon in the system tray) Install the driver only. In this case, you must connect the ZyXEL M-202 first. 2. ZyXEL Utility and Hardware Installation The installation procedures are similar for all supported Windows versions.
- Page 5 ZyXEL M-202 Quick Start Guide 3. A Welcome screen displays. Click Next. 4. To install ZyXEL Utility, select Utility and Driver checkbox. Click Next to accept the default file location or click Browse to select an alternate folder.
- Page 6 6. Click Finish to restart the computer. 7. Insert your ZyXEL M-202 into an available USB port on the computer by using the provided USB cable. 8. The LEDs will turn on if the ZyXEL M-202 is properly inserted.
-
Page 7: Driver Installation For Windows Xp
10. Double click the Z icon to configure your wireless adapter. 3. Driver Installation for Windows XP 1. Insert the ZyXEL M-202 to an available USB port on the computer. The LINK LED turns on if the ZyXEL M-202 is properly inserted. - Page 8 3. Insert the included CD into your CD-ROM drive, select Search removable media (floppy, CD- ROM…) and then click Next. 4. After the driver has been installed successfully, click Finish to complete the installation. Refer to the User’s Guide to configure the ZyXEL M-202.
-
Page 9: Led Display
ZyXEL M-202 Quick Start Guide 4. LED Display Right Antenna LED Center Antenna LED Left Antenna LED Link LED The following table describes the LEDs on the ZyXEL M-202. LED / COLOR Right Antenna Green Center Antenna Green Left Antenna... - Page 10 ZyXEL M-202 Quick Start Guide LED / COLOR LINK LINK Green LEDS BEHAVIOR The M-202 is powered or M-202 is wirelessly associated with an AP/Router Wireless connection is not associated Blinking with any AP/Router Slowly Blinking The M-202 is receiving or sending data...
-
Page 11: Troubleshooting
ZyXEL M-202 Quick Start Guide 5. Troubleshooting PROBLEM Windows does not Make sure the ZyXEL M-202 is properly connected via the USB auto-detect the slot and then restart your computer. Once the computer has ZyXEL M-202. restarted, check the status of the LEDs on the ZyXEL M-202. -
Page 12: Customer Support
• Warranty Information • Date that you received or purchased your device • Brief description of the problem including any steps that you have taken before contacting the ZyXEL Customer Support Representative SUPPORT E-MAIL support@zyxel.com TELEPHONE +1-800-978-7222 www.us.zyxel.com WEB SITE...
