- Page 1 INSTRUCTION MANUAL 2 DOOR SIDE BY SIDE FRIDGE FREEZER THSBS1791PW THSBS1791PX THSBS1791PBIX...
- Page 2 We thank you for the confidence you have shown by purchasing our appliance which is designed to simplify your life. To make the use of the product easier, we have supplied detailed instructions for use. The instructions should allow you to learn about your new appliance as quickly as possible. We wish you find a lot of pleasure in its use.
-
Page 3: Table Of Contents
CONTENTS 4 IMPORTANT NOTES AND PRECAUTIONS 11 INSTALLING YOUR NEW APPLIANCE 13 APPLIANCE DESCRIPTION 14 OPERATING THE APPLIANCE 17 USING YOUR APPLIANCE 21 HELPFUL HINTS AND TIPS 22 CLEANING AND CARE 23 TROUBLESHOOTING 25 DISPOSAL OF THE APPLIANCE... -
Page 4: Important Notes And Precautions
IMPORTANT NOTES AND PRECAUTIONS SAFETY AND WARNING INFORMATION For your safety and correct usage, before installing and first using the appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents, it is important to make sure that all people using the appliance are thoroughly familiar with its operation and safety features. - Page 5 According to IEC standard This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. •...
- Page 6 • WARNING — Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance. • WARNING — If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. •...
- Page 7 flammable. During transportation and installation of the appliance, ensure that none of the components of the refrigerant circuit becomes damaged. The refrigerant (R600a) is flammable. • WARNING — Refrigerators contain refrigerant andgases in the insulation. Refrigerant and gases must be disposed of professionally as they may cause eye injuries or ignition.
- Page 8 • You must not operate the appliance without the interior lighting lamp cover. • The fridge is only applied with power supply of single phase alternating current of 220~240V/50Hz. If fluctuation of voltage in the district of user is so large that the voltage exceeds the above scope, for safety sake, be sure to apply A.C.
- Page 9 • Keep buring candles,lamps and other items with naked flames away from the appliance so that do not set the appliance on fire. • The appliance is intended for keeping food stuff and/ or beverages in normal household as explained in this instruction booklet The appliance is heavy.Care should be taken when moving it.
- Page 10 Installation Important! • For electrical connection carefully, follow the instructions given in this manual. • Unpack the appliance and check if there are damages on it. Do not connect the appliance if it is damaged. Report possible damages immediately to the place you bought it.
-
Page 11: Installing Your New Appliance
INSTALLING YOUR NEW APPLIANCE • Before using the appliance for the first time, you should review the following tips. Ventilation of appliance In order to improve efficiency of the cooling system and save energy, it is necessary to maintain good ventilation around the appliance for the dissipation of heat. - Page 12 Class Temperature from +10 °C to +32 °C from +16 °C to +32 °C from +16 °C to +38 °C from +16 °C to +43 °C • Stand you appliance in a dry place to avoid damage moisure. • Keep the appliance out of direct sunlight, rain or frost. Stand the appliance away from heat sources such as stoves, fires or heaters.
-
Page 13: Appliance Description
APPLIANCE DESCRIPTION 1. Freezer zone LED light 11. Fresh door Rack 2. Freezer door Rack 12. Wind channel cover in fresh 3. Freezer door seal 13. Carbon filter (air purifier). 4. Wind channel cover in freezer 14. Fresh shelf 5. Freezer shelf 15.Bottle rack 6. -
Page 14: Operating The Appliance
OPERATING THE APPLIANCE Use your appliance according to the following control regulations, your appliance has the corresponding functions and modes as the control panels showed in the pictures below. TEMPERATURE SETTING When the appliance is powered on for the first time, the backlighting of the icons on display panel starts working. - Page 15 Mode Selection You can select ( ), ( ), ( ) three modes by pressing the ( ) button in the unlock sate. And it will be selected after 10 seconds no pressing any button. 1. Super Freeze ( Super Freeze will quickly lower the temperature within the freezer so food will freeze faster.
- Page 16 Door Alarm • If the door of fridge or freezer is open for over 1 minutes, the door alarm will sound. The buzzer will automatically stop alarming 10 minutes later. • To save energy, please avoid keeping the door open for a long time when using the appliance.
-
Page 17: Using Your Appliance
USING YOUR APPLIANCE This section tells you how to use most of the useful features. We recommend that you read through them carefully besfore using the appliance. 1. Adjust the door When you find the doors are not at the same level, you can use the screwdriver to adjust the door. - Page 18 3. Using your freezer compartment The freezer compartment is suitable for storage of foods required to be frozen, such as meat, ice cream and others item. Caution! Ensure that bottles are not left in the freezer for longer than needed as freezing may cause the bootles to break.
- Page 19 Order Compartments Target storage Appropriate food TYPE temp.[°C] Fridge Eggs, cooked food, packaged food, fruits and vegetables, dairy products, cakes, Drinks and other foods which are not suitable for freezing. ≤ –18 (***)* – Seafood (fish, shrimp, shellfish), Freezer freshwater aquatic products and meat products (recommended time is 3 months –...
- Page 20 Chill –2 Fresh/frozen pork, beef, chicken, freshwater aquatic products, etc. (7 days below 0 °C and above 0 °C is recommended for consumption within that day, preferably no more than 2 days). Seafood (less than 0 for 15 days, it is not recommended to store above 0 °C) Fresh Food Fresh pork, beef, fish, chicken,...
-
Page 21: Helpful Hints And Tips
HELPFUL HINTS AND TIPS Energy saving tips We recommend that you follow the tips below to save energy. • Try to avoid keeping the door open for long periods. • Ensure the appliance is away from any sources of heat (Direct sunlight, electric oven or cooker etc.) •... -
Page 22: Cleaning And Care
CLEANING AND CARE For hygienic reasons the appliance (including exterior and interior accessories) should be cleaned regularly (at least every two months). Warning! The appliance must not be connected to the mains during cleaning. Danger of electrical shock! Before cleaning switch the appliance off and remove the plug from the mains socket. -
Page 23: Troubleshooting
TROUBLESHOOTING If you experience a problem with your appliance or are concerned that the appliance is not functioning correctly, you can carry out some easy checks before calling for service, please see below. You can carry out some easy checks according to this section before calling for service. Warning! Don't try to repair the appliance yourself. - Page 24 Problem: Possible cause & Solution It is normal to frequently hear the sound of the motor, it will need to run more during following circumstances: • Temperature setting is set colder than necessary. The motor runs • Large quantity of warm food has recently been continuously stored within the appliance.
-
Page 25: Disposal Of The Appliance
DISPOSAL OF THE APPLIANCE It is prohibited to dispose of this appliance as household waste. Packaging materials Packaging materials with the recycle symbol are recyclable. Dispose of the packaging into a suitable waste collection container to recycle it. Before disposal of the appliance 1. - Page 26 We, Teknix, undertake that if within 24 months of the date of purchase this appliance or any part thereof is proven to be defective by reason of mechanical or electrical failure we will at our discretion repair or replace the same free of any charge for labour, materials or carriage on condition that: ·...
- Page 28 Your Teknix appliance comes with a 2 year parts and labour guarantee Please REGISTER your appliance on line at www.teknixwarranty.co.uk You also have the option to EXTEND YOUR WARRANTY To 5 years parts and labour To register your appliance or extend your warranty...
