ZyXEL Communications Dimension ES-3124F Support Notes

ZyXEL Communications Dimension ES-3124F Support Notes

Rstp and mvr (rapid spanning tree protocol + mvr) ring work as the aggregation layer zynos 3.7
Hide thumbs Also See for Dimension ES-3124F:

Advertisement

Quick Links

Download this manual See also: User Manual
RSTP and MVR
(Rapid Spanning Tree Protocol + MVR)
Ring work as the Aggregation Layer
Ethernet Switch
ZyNOS 3.7

Support Notes

Version 3.70
December 2006

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dimension ES-3124F and is the answer not in the manual?

Questions and answers

Related Manuals for ZyXEL Communications Dimension ES-3124F

Summary of Contents for ZyXEL Communications Dimension ES-3124F

  • Page 1: Support Notes

    RSTP and MVR (Rapid Spanning Tree Protocol + MVR) Ring work as the Aggregation Layer Ethernet Switch ZyNOS 3.7 Support Notes Version 3.70 December 2006...

  • Page 2: Overview Of Mvr

    (R)STP -compliant switches in your network in order to ensure that only one path exists between any two stations on the network. Note: "STP" refers to both STP and RSTP on ZyXEL Management Switch. Overview of MVR Multicast VLAN Registration (MVR) is designed for applications (such as Media-on-Demand (MoD)) that use multicast traffic across an Ethernet ring-based service provider network.
  • Page 3 In the following section, we will provide an example to illustrate how to create a multicast network with IGMP Router (IGMP L3 Switch), IGMP Snooping L2 Switch on a ring using RSTP, and MVR L2 Switch with IGMP Snooping Enabled. In this scenario, the Video Servers are located in VLAN200. Thus, the Multicast VLAN is going to be VLAN200.
  • Page 4 7. First of all, the IP domain of the video servers is 192.168.10.1/24. The video servers will be put under VLAN200, so we will need to create VLAN200 as well as the IP domain on the Switch first. To do so, click All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 5 VID (200 in our case). Since the Video Servers are connected to port 10 through another L2 VLAN unaware Switch, we need to take away the “Tx Tagging” and let the Switch to take away the VLAN tag during Egress. Port 12 should be joined to the VLAN200 since it is used to connect to the first MVR L2 Switch.
  • Page 6 This Switch should apply the VID200 tag to all those packets in order for them to go into VLAN 200. Click “Apply” to apply your changes. All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II...
  • Page 7 13. Since we will give the same IP domain as the video server, use 192.168.10.1 /24 again, and again, make it belong to VLAN 200. Click “Add” to add this VLAN. All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II...
  • Page 8 14. Now, the last step is to activate IGMP Route V2 in our newly created IP Domain. To do so we click “IP Application” 15. First, tick the check box and assign “IGMP v2” to the IP domain 192.168.10.1/24. All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II “IGMP”.
  • Page 9 RSTP and MVR Support Note II 16. Finally, in the upper right corner, click “Save” to write all the changes to the memory. At this point everything is done on this Switch. All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 10 6. After successful login you will see a screen similar to the one on the screenshot below. 7. First, we are going to create the multicast VLAN 200 on this switch. Also, RSTP is needed in our case to build the Aggregation layer ring (3x IGMP L2 Switches) for case of physical wire being disconnected.
  • Page 11 9. To configure RSTP, check “Active” to enable this feature first. Since this switch is going to be the root switch in our ring, we will give it the highest spanning tree priority 0 (The lower the number, the higher the priority).
  • Page 12 10. Now we are going to create the multicast VLAN 200 on the ports within the ring (port 11 and port 12) and also the uplink port (port 9). Port 9 is connected to the L3 IGMP Switch. All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 13 VLAN200) and its VLAN ID, 200. Also, we set the port 11 and the port 12 as “Fixed” with Tagging since these two ports are in the ring. Finally, click “Add” to create this VLAN. All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II...
  • Page 14 RSTP and MVR Support Note II 13. Now we need to configure all the multicast related settings. To do so, click “Advanced Application” “Multicast”. All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 15 16. Finally, in the top right corner, click “Save” to write all the changes to the memory. At this point everything is done on this Switch. All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II...
  • Page 16 RSTP and MVR Support Note II All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 17 Moreover, RSTP is needed to build the aggregation network (3x IGMP L2 Switches) as a ring for the case of physical wire disconnection. To enable the RSTP, click “Advanced Application” Protocol” All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II http://192.168.0.1 “Spanning Tree...
  • Page 18 9. To configure RSTP, tick “Active” to enable this feature first. Ports 11 and 12 will be the ports used to form the ring so we need to tick the corresponding the check box. All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II...
  • Page 19 10. Now we are going to create a VLAN 200 for the multicast on the ports within the ring (port 11 and port 12) and port 6 (port 6 is connected to the access layer MVR Switch). To do so, click “Advanced Application” “VLAN”. All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 20 VLAN200) and its VLAN ID, 200. Also, we set port 6, port 11 and port 12 as “Fixed” with Tagging. Finally, click “Add” to create this VLAN. All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II...
  • Page 21 RSTP and MVR Support Note II 13. Now we need to configure all the multicast related settings. To do so, click “Advanced Application” “Multicast”. All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 22 16. Finally, in the top right corner, click “Save” to write all the changes to the memory. At this point everything is done on this Switch. All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II...
  • Page 23 RSTP and MVR Support Note II All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 24 (3x IGMP L2 Switches) as a ring for a case of physical wire being disconnected. To enable the RSTP, we can click “Advanced Application” “Spanning Tree Protocol”. All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II http://192.168.0.1...
  • Page 25 9. To configure RSTP, check “Active” to enable this feature. Ports 11 and 12 will be the ports used in our ring so we need to tick the corresponding check box. All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II...
  • Page 26 10. Now we are going to create a VLAN 200 for the multicast on the ports within the ring (port 11 and port 12) and port 6 (port 6 is connected to the access layer MVR Switch). To do so, click “Advanced Application” “VLAN”. All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 27 VLAN200) and its VLAN ID, 200. Also, we set port 6, port 11 and port12 as “Fixed” with Tagging. Finally, click “Add” to create this VLAN. All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II...
  • Page 28 RSTP and MVR Support Note II 13. Now we need to configure all the multicast-related settings. To do so, click “Advanced Application” “Multicast”. All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 29 Ring, we pick “Fixed” as the IGMP Querier Mode. For the downlink port (port 6), we pick “Edge” as the IGMP Querier Mode. All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II...
  • Page 30 RSTP and MVR Support Note II 16. Finally, in the top right corner, click “Save” to write all the changes to the memory. At this point everything is done on this Switch. All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 31 7. Now we are going to create the customer VLAN on both the downlink port (port 6) and the uplink port (port 9). To do so, we click “Advanced Application” “VLAN”. All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II http://192.168.1.1...
  • Page 32 “Fixed”. Port 9 should be tagged during Egress and port 6 should be untagged since it is connected to the user’s “VLAN unaware CPE”. Finally, click “Add” to create this VLAN. All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II...
  • Page 33 10. As for the VLAN we need to modify the PVID of port 6 from 1 to 5. To do so, go back to the VLAN Status page and click “VLAN Port Setting”. 11. Put 5 into the PVID box of port 6. All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 34 12. Now we need to configure all the multicast related settings. To do so, click “Advanced Application” 13. First of all, we need to active IGMP snooping since MVR needs it. Click “Multicast Setting”. All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II “Multicast”.
  • Page 35 Click “Apply” to activate these settings. 15. Now we can configure MVR after IGMP Snooping has been activated. To do so click “MVR” on the top. All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II...
  • Page 36 Traffic may be sent out through this port. For the uplink port (port 9), please make it “Source Port” and allow “Tagging” during Egress. 17. Now we need to tell the switch what number of group (Multicast channel) belongs to the MVR. To do so we click “Group Configuration”...
  • Page 37 Give this range a name and click “Add” to add it. 19. Finally, in the top right corner, click “Save” to write all the changes to the memory. At this point everything is done on this Switch. All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 38 7. Now we are going to create the customer VLAN on both the downlink port (port 6) and the uplink port (port 9). To do so, click “Advanced Application” “VLAN” All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II http://192.168.1.1 on the...
  • Page 39 “Fixed”. Port 9 should be Tagged during Egress and port 6 should be Untagged since it is connected to the user’s “VLAN unaware CPE”. Finally, click “Add” to create this VLAN. All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II...
  • Page 40 10. For the VLAN we need to modify the PVID of port 6 from 1 to 10. To do so go back to the VLAN Status page and click “VLAN Port Setting”. 11. Put 10 into the PVID box of port 6. All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 41 12. Now we need to configure all the multicast-related settings. To do so, click “Advanced Application” 13. First of all, we need to activate IGMP snooping since MVR needs it. Click “Multicast Setting”. All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II “Multicast”.
  • Page 42 And for the client port (port 6), we pick “Edge” as the IGMP Querier Mode. Click “Apply” to activate these settings. 15. Now we can configure MVR after IGMP Snooping has been activated. Click “MVR” on the top. All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II...
  • Page 43 Traffic may be sent out through this port. As for the uplink port (port 9), make it “Source Port” and make it “Tagging” during Egress. 17. Now we need to tell the Switch what number of Group (Multicast channel) belongs to the MVR. To do so we click “Group Configuration”...
  • Page 44 Also, assign this range a name and click “Add” to add it. 19. Finally, in the right corner, click “Save” to write all the changes to the memory. At this point everything is done on this Switch. All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 45 Configuration using CLI - ZyXEL L3 Management Switch Connect the Switch Console port with your PC or Notebook. Open your Terminal program (E.g. Hyper Terminal in Windows System). Make sure that your port settings are bps:9600 Data bits:8 Parity: None...
  • Page 46 RSTP and MVR Support Note II ip igmp v2 exit ip address 192.168.0.1 255.255.255.0 To save the configuration while in privileged mode (or so called Enable Mode): Switch#write mem All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 47 Parity: None Stop bits:1 Flow control: None: OR you can telnet / SSH the IP of the Switch Management Interface For In-band interface, the default management is 192.168.1.1 (VLAN 1) For out-band interface, the default management is 192.168.0.1. 4. After you have connected successfully, enter the correct administrator user name and the password.
  • Page 48 192.168.0.1 255.255.255.0 spanning-tree spanning-tree priority 0 spanning-tree 11 spanning-tree 12 To save the configuration while in privileged mode (or so called Enable Mode): Switch#write mem All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II...
  • Page 49 Parity: None Stop bits:1 Flow control: None: OR you can telnet / SSH the IP of the Switch Management Interface For In-band interface, the default management is 192.168.1.1 (VLAN 1). For out-band interface, the default management is 192.168.0.1. 4. After you have connected successfully, enter the correct administrator user name and the password.
  • Page 50 192.168.0.1 255.255.255.0 spanning-tree spanning-tree 11 spanning-tree 12 To save the configuration in the privileged mode (or so called Enable Mode): Switch#write mem All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II...
  • Page 51 Parity: None Stop bits:1 Flow control: None: OR you can telnet / SSH the IP of the Switch Management Interface For In-band interface, the default management is 192.168.1.1 (VLAN 1) For out-band interface, the default management is 192.168.0.1 4. After you have connected successfully, enter the correct administrator user name and the password.
  • Page 52 RSTP and MVR Support Note II interface port-channel 12 igmp-querier-mode fixed exit ip address 192.168.0.1 255.255.255.0 spanning-tree spanning-tree 11 spanning-tree 12 To save the configuration while in privileged mode (or so called Enable Mode): Switch#write mem All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 53 Configuration using CLI - ZyXEL MVR L2 Management Switch [The bottom L2 Switch located on the left] 1. Connect the Switch Console port with your PC or Notebook. 2. Open your Terminal program.(E.g. Hyper Terminal in Windows System) 3. Make sure that your port settings are...
  • Page 54 MVR200 tagged 9 group Multicast start-address 224.1.1.1 end-address 225.10.10.10 exit To save the configuration while in privileged mode (or so called Enable Mode): Switch#write mem All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II...
  • Page 55 Configuration using CLI - ZyXEL MVR L2 Management Switch [The bottom L2 Switch located on the right] 1. Connect the Switch Console port with your PC or Notebook. 2. Open your Terminal program.(E.g. Hyper Terminal in Windows System) 3. Make sure that your port settings are...
  • Page 56 MVR200 tagged 9 group Multicast start-address 224.1.1.1 end-address 225.10.10.10 exit To save the configuration while in privileged mode (or so called Enable Mode): Switch#write mem All contents copyright (c) 2006 ZyXEL Communications Corporation. RSTP and MVR Support Note II...
