Summary of Contents for Hover-1 STEALTH H1-STH
- Page 1 ELECTRIC FOLDING SCOOTER O P E RATI O N M A N U A L H 1- S T H...
- Page 2 HELMETS SAVE LIVES! Always wear a properly tted helmet that complies with CPSC or CE safety standards when you ride your E-Scooter. Correct Fit: Make sure your helmet covers your forehead. Incorrect Fit: Forehead is exposed and vulnerable to serious injury.
- Page 3 WARNING As with all mechanical components, the Hover-1 Stealth is subject to wear and high stresses. Di erent materials and components may react to wear or fatigue in di erent ways. If the design life of a component has been exceeded, it may suddenly fail, possibly causing injuries to the rider.
- Page 4 Hover-1 can not be held liable. ATTENTION 1. Only use the supplied charger from Hover-1 with this E-Scooter. 2. The operating temperature range of the Stealth is 32°F - 104°F (0°C - 40°C). 3. The operating temperature range of the charger is 32°F - 104°F (0°C - 40°C).
- Page 5 LOW TEMPERATURE WARNING Low temperatures will affect the lubrication of moving parts inside the Stealth, increasing internal resistance. Additonally, the discharge capacity and capacity of the battery will be significantly decreased. Use caution when riding the Stealth in cold temperatures (below 40°F/4°C).
- Page 6 E-Scooter platform. Record the serial number in the designated area of the “WARRANTY” section of this manual in the event that your Hover-1 Stealth is lost or stolen. WARNING! WARNING: Prolonged exposure to UV rays, rain and the elements...
-
Page 7: Safety Precautions
• Hover-1 is not liable for tickets or violations given to riders who do not follow local laws and regulations. • For your safety, always wear a helmet that meets CPSC or CE safety standards. - Page 8 • Obey all local traffic laws. Obey red and green lights, one-way streets, stop signs, pedestrian crosswalks, etc. • Ride with traffic, not against it. • Ride defensively; expect the unexpected. • Give pedestrians the right-of-way. • Do not ride too close to pedestrians. Alert them if you intend to pass them from behind.
- Page 9 • Do not try to open or modify your Stealth. Doing so voids the manufacturer warranty and may cause your Stealth to fail, resulting in injury or death. • Do not use the Stealth in a manner that would put people or property in danger.
- Page 10 WARNING Proper use of your brake is vital to ensure safe, e icient stopping. To avoid misuse and potential injury, do not apply sudden or excessive force to your brakes. Apply your brakes gradually and give yourself enough room to come to a complete stop safely.
- Page 11 • Do not ride the Stealth in dark or poorly lit areas. • Do not ride the Stealth near or over potholes, cracks, or uneven pavement or surfaces. • Do not operate your Stealth off-road. • Do not turn sharply, especially at high speeds. •...
-
Page 12: Care And Maintenance
• Do not let the Stealth fall from high places, as doing so may damage the internal circuitry. • Do not attempt to disassemble the Stealth. • Only use the charger provided by Hover-1. • Only use the manufacturer’s authorized replacement parts. WARNING Avoid using water or other liquids for cleaning. -
Page 13: Battery Care / Maintenance
E-Scooter. • When charging the E-Scooter, only use the enclosed 1-pin charging cable provided by Hover-1. Use of any other charger or cable may lead to damage to the E-Scooter, overheating, and risk of fire. Use of any other charger or cable voids the manufacturer warranty. - Page 14 • Do not attempt to modify, change, or replace your battery. • Do not use your device if the battery begins to emit odor, overheats, or begins to leak. • Do not touch any leaking materials or breathe fumes emitted. •...
-
Page 15: Specifications
SPECIFICATIONS Model: H1-STH Net Weight: 40 lbs (18 kg) Max Supported Weight: 220 lbs (100 kg) Max Speed: Up to 20 mph (32 km/h) Max Range: Up to 30 miles (48 km) Battery Type: Lithium-ion Motor Power: 500W Brushless Motor Battery Voltage: Battery Capacity: 13Ah... - Page 16 HOVER-1 STEALTH DIAGRAM FEATURES/PARTS 1. LCD Display 9. Removable Battery 2. Bell 10. Steering Column 3. Brake Handle 11. Charging Port 4. Handlebar (L) 12. Folding Lock 5. Power Button 13. Kickstand 6. Handlebar (R) 14. Footdeck 7. Throttle 15. Fender Hook 8.
-
Page 17: Lcd Display
HOVER-1 STEALTH DIAGRAM Handbrake Bell Mode Button Power Button Speed Throttle Battery Level Speed Mode LCD DISPLAY SPEEDOMETER Displays your current speed HIGH TEMPERATURE ALERT ICON When the temperature of the device’s control board is too high, this icon will flash on your display. -
Page 18: Settings Menu
SETTINGS MENU MODE BUTTON POWER BUTTON Menu Navigation 1. Press and hold the power button and the mode button at the same time to enter the settings menu 2. Press the mode button to cycle through settings (from P0 to P2) 3. - Page 19 • If the E-Scooter is not used for an extended period of time, you may need to recharge the battery every 2 months to maintain the battery life. CAUTION Only use the included charging cable and charger to charge your Hover-1 Stealth. Using any other unauthorized charger may damage your Hover-1 Stealth.
- Page 20 ASSEMBLING YOUR STEALTH PLEASE READ THE FOLLOWING INSTRUCTIONS CAREFULLY ATTACHING THE HANDLEBAR ASSEMBLY 1. Make sure the wiring in the steering column is connected, then attach the handlebar assembly to the top of the steering column. 2. Screw the 5 Torx screws into the holes pictured below. There are two holes on each side of the steering column and one hole under the headlight.
-
Page 21: Pinch Points
PINCH POINTS Some parts of your Stealth can injure you if mishandled. Moving and folding parts can cut skin. Clamps and pivoting parts such as brake levers can pinch. When folding and unfolding your Stealth, please watch for pinch points where injury may be sustained. Do not leave your hand in these areas during the folding or unfolding process. -
Page 22: Folding And Unfolding
FOLDING & UNFOLDING FOLDING & UNFOLDING YOUR STEALTH To fold your Stealth, use your thumb to push the twist lock counter-clockwise until it is no longer in front of the folding lock. Grab the folding lock with one hand and hold the steering column with the other. -
Page 23: Cruise Control
KICK TO START For safety reasons, the Stealth will not accelerate unless it is already moving at least 1.8 mph (3 km/h). You must first kick off the ground to get a rolling start and then press the throttle in order to ride the Stealth. Kick to start can be disabled in the settings menu. - Page 24 PRE-RIDE CHECKLIST Ensure that your Stealth is in proper working order each time you ride. If a part of the Stealth does not function correctly, please contact our Customer Support Center. • Ensure the battery is fully charged before riding your E-Scooter. •...
- Page 25 WARNING Do not turn sharply or at high speeds. Do not turn or ride quickly along slopes, as it may cause injury. SPEED AND WEIGHT LIMITATIONS Speed and weight limits are set for your own safety. Please abide by the limits listed here in the manual. •...
-
Page 26: Safety Alerts
WARNING Proper use of your brake is vital to ensure safe, e icient stopping. To avoid misuse and potential injury, do not apply sudden or excessive force to your brake. Apply the brake gradually and give yourself enough room to come to a complete stop safely. -
Page 27: Warranty
WARRANTY For warranty information, please visit us at www.hover-1.com Error code EA - controller / instrument communication failure, the controller needs to be replaced Error code EB - accelerator failure, the accelerator needs to be replaced Error code EC - motor failure, check the wiring of the motor hall communication line. - Page 28 @RideHover1 @RideHover1 @RideHover1 www.Hover-1.com...
