ELECTRIC FOLDING SCOOTER
O P E RATI O N M A N U A L
H 1- JV E

Advertisement

Table of Contents
loading

Summary of Contents for Hover-1 JIVE

  • Page 1 ELECTRIC FOLDING SCOOTER O P E RATI O N M A N U A L H 1- JV E...
  • Page 2 HELMETS SAVE LIVES! Always wear a properly tted helmet that complies with CPSC or CE safety standards when you ride your scooter. Correct Fitting: Make sure your helmet covers your forehead. Incorrect Fitting: Forehead is exposed and vulnerable to serious injury.
  • Page 3 In this manual, the WARNING sign indicates a hazardous situation which, if not avoided, can cause death or serious injury. WARNING Great care should be taken with the Hover-1 Jive when folding or unfolding. If you do not understand how to operate the levers, please visit www.Hover-1.com DO NOT RIDE YOUR HOVER-1 JIVE WITHOUT ALL RELEASES SECURELY LOCKED.
  • Page 4 This manual applies to the Hover-1 Jive. • In order to avoid dangers that are caused by collisions, falls, and loss of control, please learn how to ride the Jive safely. • You can learn operating skills by reading the product manual and watching videos.
  • Page 5 LOW TEMPERATURE WARNING Low temperature will affect the lubrication of moving parts inside the Jive, increasing internal resistance. At the same time, in low temperatures, the discharge capacity and the capacity itself of the battery will be significantly decreased. Use caution when riding the Jive in cold temperatures (below 40 degrees F).
  • Page 6 • Do not operate, or allow others to operate, the Hover-1 Jive, until the user understands all instructions, warnings and safety features described in this manual. • Check with your doctor if you have a medical condition that could affect your ability to use the Hover-1 Jive.
  • Page 7: Safety Precautions

    • You should check with local officials to ensure you are complying with local traffic law requirements. • Hover-1 is not liable for tickets or violations given to riders who do not follow local laws and regulations. • For your safety, always wear a helmet that meets CPSC or CE safety standards.
  • Page 8 • Do not ride with pets. • Before stepping on your Jive, make sure it is placed flat on level ground and the power is on.
  • Page 9 • Do not try to open or modify your Jive scooter. Doing so, voids the manufacturer warranty and may cause your Jive to fail, resulting in injury or death. • Do not use the Jive in a manner that would put people or property in danger.
  • Page 10 • Do not ride your Jive near motor vehicles or on public roads. • Do not travel up or down steep hills. • The Jive is intended for use by a single individual, DO NOT attempt to operate the Jive with two or more people.
  • Page 11 • Do not attempt any stunts or tricks with your Jive scooter. • Do not ride the Jive in dark or poorly lit areas. • Do not ride the Jive near or over potholes, cracks or uneven pavement or surfaces.
  • Page 12: Care And Maintenance

    WARNING Avoid using water or other liquids for cleaning. If water or other liquids enter the Jive, it will cause permanent damage to the internal components. WARNING Users who disassemble the Jive scooter without...
  • Page 13: Battery Care / Maintenance

    BATTERY CARE / MAINTENANCE BATTERY SPECIFICATIONS Battery Type: Rechargeable lithium-ion battery Charge Time: Up to 5 hours Battery Voltage: 36V Battery Capacity: 6 Ah Working Temperature: 32°F - 104°F Charging Temperature: 32°F - 104°F Storage Time: 1 year Storage Temperature: -4°F - 104°F Storage Humidity: 5% - 95% BATTERY MAINTENANCE The lithium-ion battery is built into the device.
  • Page 14 • The battery contains dangerous substances, do not open the battery, or insert anything into the battery. • Please only use the charger provided by Hover-1. • Do not attempt to charge the device if the battery has discharge or emits any substances. In that case, immediately distance yourself from the battery in case of fire or explosion.
  • Page 15: Specifications

    SPECIFICATIONS Model: H1-JVE Net Weight: 26.0 lbs (11.8 kg) Max Supported Weight: 264 lbs (120 kg) Min Supported Weight: 44 lbs (20 kg) Max Speed: Up to 16 mph (25 km/h) Max Distance Range Up to 16 miles (25 km) Battery Type: Lithium-ion Motor Power:...
  • Page 16 HOVER-1 JIVE DIAGRAM FEATURES/PARTS 1. LED Display 9. Steering Column 2. Bell 10. Folding Lock 3. Brake Handle 11. Scooter Platform 4. Handlebars(L) 12. Kickstand 5. Handlebars(R) 13. Folding Hook 6. Throttle 14. Brake Light 7. Power Button 8. Folding Clip...
  • Page 17: Led Display

    HOVER-1 JIVE DIAGRAM BRAKE HANDLE THROTTLE FOLDING LED DISPLAY CLIP POWER BUTTON LED DISPLAY SPEEDOMETER Displays your current speed in Mph. Ensure it is power on, Press twice to switch low speed /Mid speed/ high speed mode: Eco- Low speed mode...
  • Page 18 RED, indicating that your device is now being charged. • When the RED indicator light on your charger turns to GREEN, then your device is fully charged. • After fully charging your Jive Scooter, unplug the charger from your device and from the power outlet. CAUTION Only use the included charging cable and charger to charge your Hover-1 Jive.
  • Page 19: Pinch Points

    4 screws into place. PINCH POINTS Some parts of your Hover-1 Jive can injure you if mishandled. Moving and folding parts can cut skin. Clamps and pivoting parts such as brake levers can pinch. When folding and unfolding your Hover-1 Jive, Please watch for pinch points where possible injury may be sustained.
  • Page 20: Folding And Unfolding

    FOLDING & UNFOLDING FOLDING & UNFOLDING YOUR JIVE SCOOTER. To unfold your Jive, press down on the folding clip and pull the steering column up. Raise the safety lock up and push it into place to secure the steering column. You will hear a “click”, indicating the steering column is locked.
  • Page 21: Before Riding

    Customer Support Center. • Ensure the battery is fully charged before riding your scooter. • If the Jive scooter is not used for an extended period of time, you may need to recharge the battery every 2 months to maintain the battery life.
  • Page 22 OPERATING YOUR DEVICE Make sure the device is fully charged before the first initial use. Before turning on your Jive scooter, ride it like a normal kick scooter to get comfortable with the device before using it with the motor.
  • Page 23: Safety Alerts

    SUBSTANCE THAT IS EMITTED FROM THE BATTERY. SAFETY ALERTS While riding your Jive Scooter, if there is a system error or illegal operation performed the device will prompt the user in a variety of ways. The following are common occurrences where you will see Safety Alerts.
  • Page 24: Fcc Statement

    • Battery voltage is too low. • The device is still charging. • Overheating, or motor temperature is too high. • When the b attery is about to run out of power, the battery icon will flash. • If any or both tires are blocked, the device will stop after 10 seconds.
  • Page 25: Warranty

    WARRANTY For warranty information, Please visit us at: www.hover-1.com Error E1- Motor Hall failure Error E2 - MOS tube failure Error code E3 - Brake failure Error E4/MOS - Accelerator failure Error codes Error E5 - low-Overvoltage failure Error E6 - Controller/instrument communication failure...
  • Page 26 @RideHover1 @RideHover1 @RideHover1 www.Hover-1.com...

This manual is also suitable for:

H1-jve
