- Page 1 UPPER ARM AUTOMATIC DIGITAL BLOOD PRESSURE MONITOR INSTRUCTION MANUAL Model: UAM-720C...
- Page 2 PARTS AND COMPONENTS 10.Batteries 11.Storage bag...
- Page 3 SYMBOLS Symbols Meaning Manufacturer Authorized Representative in the European community Symbol for the marking of electrical and electronics devices according to Directive 2012/19/EU. The device, accessories and the packaging have to be disposed of waste correctly at the end of the usage. Please follow Local Ordinances or Regulations for disposal.
-
Page 4: Table Of Contents
TABLE OF CONTENT 1. GENERAL - PRINCIPLE OF OPERATION - NEW TECHNOLOGIES USED 2. IMPORTANT SAFETY INSTRUCTIONS 3. PREPARATION - BATTERY INSTALLATION - USE AC POWER ADAPTER 4. USE THE DEVICE - CORRECT POSTURE - INSTRUCTION FOR CUFF USE - CARRY OUT A MEASUREMENT - FUNCTION OF MEMORY - WHO CLASSIFICATION INDICATION - IRREGULAR HEARTBEAT DETECTOR... -
Page 5: General
This instruction manual is intended to assist the user for safe and efficient operation of the automatic digital blood pressure monitor (hereinafter: device) model UAM-720C. The device must be used in accordance with the procedures described in the manual. It is important to read and understand the entire manual, especially the section <... -
Page 6: Important Safety Instructions
accuracy of measurement. Software version: V1.1 IMPORTANT SAFETY INSTRUCTIONS It is necessary to know that arterial blood pressure is subjected to sharp fluctuations. The level of the arterial blood pressure depends on many factors. Generally arterial blood pressure is lower in summer and higher in winter. Arterial blood pressure changes with atmospheric pressure and is affected considerably by many factors, e.g. - Page 7 changed with pregnancy. • Do not service or maintain the cuff while in use with patient. • Do not use this blood pressure monitor on any arm where intravascular access or therapy (such as an intravenous drip or a blood transfusion), or an arteriovenous shunt (A-V shunt) is present.
- Page 8 sion may produce significantly different results, because too frequent and consecutive measurements could cause disturbanc- es in blood circulation and injuries. Cautions • Use this device under the right environmental conditions as indicated in this user manual. If not, this could affect the perfor- mance, lifetime of the device and measurement results.
- Page 9 cause injury. • This device is not intended for use on extremities other than the arm or for functions other than obtaining a blood pressure measurement. • Do not attach the cuff on the same arm on which other monitoring medical electrical equipment is attached simultaneously, because this could cause temporary loss of function of those simultaneous- ly-used monitoring medical electrical equipment.
- Page 10 ters, microwave ovens. • If this device was stored in low temperature, leave it in room temperature for at least 1 hour. • Repeated measurements with an interval of 3 minutes are recommended, so you can calculate the average to get a more accurate measurement.
-
Page 11: Preparation
BATTERY INSTALLATION 1.Open the battery cover and install four ‘AAA’ type batteries into the battery compartment as indicated. Make sure that the polarity is correct; 2.Close the battery compartment cover. • Replace the batteries when the replacement indication “ ”ap- pears in the display or nothing after “... -
Page 12: Use The Device
• To avoid possible damage of the monitor, use only the exclusive AC adapter that can be purchased from authorized dealers. Other adapter may damage the blood pressure monitor. • The AC adapter is used as an isolating means, the AC adapter plug shall insert into the outlet nearby the operator, make it easy to disconnection the device from the outlet. -
Page 13: Correct Posture
• Make sure, you are in a comfortable, relaxed position with leg-uncrossed, feet flat on the floor, back and arm supported, middle of the cuff at the level of the right atrium of the heart and do not move or constrict your muscles and talk during measure- ment. -
Page 14: Instruction For Cuff Use
INSTRUCTION FOR CUFF USE 1. Put the cuff on the left upper arm with the tube pointing to the direction of palm. If measurement on your left arm is difficult, you can use right arm for measurement. In this case, it is necessary to know that the readings may differ about 5-10 mmHg between left arm and right arm. -
Page 15: Carry Out A Measurement
6. If your clothes restrict the blood circulation of your upper arm, or you roll your sleeve up so as to result in such restriction. Please take off your shirt to get an accurate measurement if necessary. Caution: If you experience discomfort during a measurement, such as pain in the upper arm or other complaints, press the ‘... - Page 16 sufficient to determine measurement result. 5.Then the pump stops and pressure begins to decrease gradually,and the heart symbol start to flash every heart beat once pulse is detected as Fig.4. 6.After the measurement,the 'M1' or 'M2' will flash to remind the user to record the reading,and systol- ic pressure, diastolic pressure, pulse rate as Fig.5.Press bution 'M1' or 'M2' to record the reading in corresponding...
-
Page 17: Function Of Memory
FUNCTION OF MEMORY MEMORY RECALL 1.UAM-720C can store 90 sets of readings each in 'M1' and ‘M2',and automatically calculate the average value of the latest 3 readings. When the memory is full (90 sets of readings are stored), the oldest reading will be replaced by new one automatically. -
Page 18: Who Classification Indication
WHO CLASSIFICATION INDICATION Standards for assessment of high or low blood pressure, regard- less of age, have been established by World Health Organization (WHO) as show in the chart as below： Severe Hypertension Modreate Hypertension Mild Hypertension High-normal Normal Optimal The indicator displays a segment, based on the current data, corresponding to the WHO classification. -
Page 19: Irregular Heartbeat Detector
IRREGULAR HEARTBEAT DETECTOR Model UAM-720C digital blood pressure monitor provides a blood pressure and pulse rate measurement even when an irregular heartbeat occurs. When the device detects the irregular heartbeat or any excessive body movement during measurement, the ‘ ’... -
Page 20: Troubleshooting
TROUBLESHOOTING SYMPTOM CHECK POINT REMEDY The batteries have run Replace all the batteries No display down. The polarity of with new ones. when battery is wrong. The Install the batteries connect the contact of battery correctly. Clean the battery power. compartment is polluted. -
Page 21: Care,Storing,Repair And Recycling
CARE,STORING,REPAIR AND RECYCLING 1. It’s necessary to protect this device against high moisture, direct sunlight, shock, solvent, alcohol and gasoline. 2. Remove the batteries if the device is being stored for a long time, and keep the batteries far away from children. 3. - Page 22 Caution: Generally, we recommend the device should be inspected every 2 years and utilize the manometer mode to verify the accuracy of the manometer at least at 50mmHg and 200mmHg after mainte- nance and repair. Please contact your dealer for maintenance.
-
Page 23: Specifications
SPECIFICATIONS Model UAM-720C Size 127(L)×96(W)×69(H)mm Weight Approximately 225g without batteries Measuring method Oscillometry 40 to 180mmHa(DIA) Measuring range 60 to 260mmHg(SYS) 40 to 160 beats/minute (pulse rate) ±3 mmHg for static pressure Measuring accuracy ±5% of the reading for the pulse rate... - Page 24 Main body, cuff, 4xAAA batteries, Complete kit adapter (optional), gift box, instruction manual Overvoltage category Category II...
-
Page 25: Manufacturer's Declaration
MANUFACTURER’S DECLARATION Compliance information for each EMC test Electromagnetic Emission(Home Healthcare Environment) Emission test(IEC60601-1-2:2014) Compliance Conducted and radiated CLSPR 11 Group 1 Class B RF emissions Harmonic emissions Class A IEC 61000-3-2 Voltage fluctuations/flicker emissions Complies IEC 61000-3-3 Compliance information for each EMC test Declaration-Electromagnetic Immunity(Home Healthcare Environment) Immunity test Compliance level... - Page 26 Voltage dips, 0% U 0.5 Cycle at 0 0% U , 0.5 Cycle at 0 short interruptions ,180 , 225 , 270 , 315 ,180 , 225 , 270 , 315 0% U 1 Cycle and and voltage 0% U , 1 Cycle and 70% U variations on...
-
Page 27: Lifetime Warranty
(US and Canada only) at 1-888-993-3592 for appropriate shipping and insurance costs. In lieu of return of the product, Zewa offers a free of charge warranty repair service on all defective subassemblies, provided the product fails to perform due to faulty workmanship or faulty materials. - Page 28 In no event will Zewa be liable for indirect, exemplary, incidental special or consequential punitive or similar damages, including without limitation, any damages...
-
Page 29: Periodic Safety Checks
Zewa. For any questions regarding this warranty, please contact us By Phone Toll Free 1-888-993-3592 By E-Mail warranty@zewa.com PERIODIC SAFETY CHECKS If you use the device with power adapter, preventive inspection and mainte- nance to be performed including the frequency of such maintenance. - Page 30 Manufactured for Zewa, Inc. 12960 Commerce Lakes Drive # 29 Fort Myers, FL 33913 USA www.zewa.com Toll Free Customer Senvice 1-888 993 3592 warranty@zewa.com...
