Echo PB-5810 H Operator's Manual

Power blower
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PB-5810 H/T
Power Blower
The engine exhaust from this product contains chemicals
known to the State of California to cause cancer, birth defects,
or other reproductive harm.
Read and understand all provided literature before
use. Failure to do so could result in serious injury.
Note: This product complies with CAN ICES-2/NMB-2.
X7501210000
© 04/24 ECHO Incorporated
Operator's
Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PB-5810 H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Echo PB-5810 H

Summary of Contents for Echo PB-5810 H

  • Page 1 State of California to cause cancer, birth defects, or other reproductive harm. Read and understand all provided literature before use. Failure to do so could result in serious injury. Note: This product complies with CAN ICES-2/NMB-2. X7501210000 © 04/24 ECHO Incorporated...

  • Page 2: Table Of Contents

    Introduction ....................3 Servicing Information .................. 4 Parts and Serial Number..............4 Service ....................4 ECHO Consumer Product Support ............4 Product Registration ................4 Additional Literature ................4 Safety ......................5 Manual Safety Symbols and Important Information ......5 International Symbols ................

  • Page 3: Introduction

    Scan QR codes for more information. For additional literature, including safety manuals where applicable, or questions regarding terms used in this manual, visit: https://www.echo-usa.com/manuals https://www.shindaiwa-usa.com/manuals X7501210000 © 04/24 ECHO Incorporated...

  • Page 4: Servicing Information

    Register your ECHO equipment online at www.echo-usa.com or by filling out the product registration sheet included in this manual. Registering your product confirms warranty coverage and provides a direct link to ECHO if we find it necessary to contact you.

  • Page 5: Safety

    Note: This enclosed message provides tips for use, care and maintenance of the unit. CIRCLE AND SLASH SYMBOL This symbol means the specific action shown is prohibited. Ignoring these prohibitions can result in serious or fatal injury. X7501210000 © 04/24 ECHO Incorporated...

  • Page 6: International Symbols

    Protection Low Speed Mixture Safety/Alert Stop Switch STOP Fuel and Oil Hot Surface Mixture Idle speed Fast speed Finger severing Purge Bulb DO NOT Allow Ignition Ignition Flames or Sparks ON / OFF Near Fuel X7501210000 © 04/24 ECHO Incorporated...
  • Page 7 Position (Choke Closed) Choke Control Wear Slip “RUN” Position Resistant (Choke Open) Footwear Beware of thrown objects Keep Bystanders and Helpers Away 15 m (50 ft.). Note: Not all symbols will appear on your unit. X7501210000 © 04/24 ECHO Incorporated...

  • Page 8: Personal Condition And Safety Equipment

    Eye protection that meets ANSI Z87.1 or CE requirements  must be worn whenever you operate the unit. For additional safety, a full-face shield can be worn over  safety glasses or goggles to provide protection from sharp branches or flying debris. X7501210000 © 04/24 ECHO Incorporated...
  • Page 9 Gloves also provide protection against cuts and scratches, cold environments, and reduce the transmission of machine vibration to your hands. Hearing and Ear Protection ECHO recommends wearing personal protective equipment whenever unit is used. Breathing Protection Operators who are sensitive to dust or other common airborne allergens may need to wear a dust mask to prevent inhaling these materials while operating unit.
  • Page 10 To reduce the risk of serious or fatal injury, persons with pacemakers should consult with their physician and the pacemaker manufacturer before operating this machine. In the absence of such information, ECHO does not recommend the use of this machine by anyone who has a pacemaker.
  • Page 11 Never touch wires directly or indirectly, otherwise serious injury or death can result. Do not operate gas-powered products indoors or in inadequately ventilated areas. Engine exhaust contains poisonous emissions and can cause serious injury or death. X7501210000 © 04/24 ECHO Incorporated...
  • Page 12 Do not work in odd positions or on ladders. Do not over reach. Avoid Hot Surfaces • Keep exhaust area clear of flammable debris. Avoid contact during and immediately after operation. X7501210000 © 04/24 ECHO Incorporated...

  • Page 13: Equipment

    Incorporated will not be responsible for the failure of cutting devices, attachments or accessories which have not been tested and approved by ECHO. Read and comply with all safety instructions listed in this manual. Do not attempt to modify this product. Serious injury can ...

  • Page 14: Emission Control (Exhaust & Evaporative)

    The 50 or 300 hour emission compliance period is the time span selected by the manufacturer certifying the engine emissions output meets applicable emissions regulations, provided that approved maintenance procedures are followed as listed in the Maintenance Section of this manual. X7501210000 © 04/24 ECHO Incorporated...

  • Page 15: Description

    Locate the safety decal(s) or etching(s) on your unit. Make sure they are legible, and that you understand and follow the instructions. If any cannot be read, replacements can be ordered from your ECHO dealer. Images shown below are for example only. Those on your unit might appear slightly different.
  • Page 16 Safety decal / etching Stick handle Blower pipes Flexible pipe Spark arrester muffler or spark arrester muffler with catalyst 10. Fuel tank 11. Fuel tank cap 12. Spark plug 13. Choke 14. Recoil starter handle 15. Purge bulb X7501210000 © 04/24 ECHO Incorporated...
  • Page 17 Locate the safety decal(s) or etching(s) on your unit. Make sure they are legible, and that you understand and follow the instructions. If any cannot be read, replacements can be ordered from your ECHO dealer. Images shown below are for example only. Those on your unit might appear slightly different.
  • Page 18 Throttle position lever Throttle trigger Blower pipes Flexible pipe Spark arrester muffler or spark arrester muffler with catalyst 10. Fuel tank 11. Fuel tank cap 12. Spark plug 13. Choke 14. Recoil starter handle 15. Purge bulb X7501210000 © 04/24 ECHO Incorporated...

  • Page 19: Contents

    Due to packaging restrictions, some assembly may be necessary. After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts. PB-5810H Power head...

  • Page 20: Assembly

    Assemble swivel pipe (C) into flexible pipe (B). Assemble flexible pipe (B) to elbow (D) on blower and tighten clamps (A). Note: A light lubricant may be used to ease assembly of flexible pipe to blower elbow. X7501210000 © 04/24 ECHO Incorporated...
  • Page 21 (J) the same as in step 8. Note: Blower use will eventually loosen pipe connections. Exclusive positive locking system allows pipes to be tightened. If loosening occurs, remove two pipes and install according to steps 8 and 9. X7501210000 © 04/24 ECHO Incorporated...

  • Page 22: Install Blower Pipes

    (D) on blower. Position clamp with cable guide loop (G) on outside of flexible pipe and tighten clamp. Note: Hang handle freely from blower to assure throttle cable is not twisted before installing handle (E). X7501210000 © 04/24 ECHO Incorporated...
  • Page 23 9. Note: Blower use will eventually loosen pipe connections. Exclusive positive locking system allows pipes to be tightened. If loosening occurs, remove two straight pipes and install according to steps 9 and 10. X7501210000 © 04/24 ECHO Incorporated...

  • Page 24: Operation

    Always be alert for changes in operation of unit.  Always shut engine off before transporting unit to new  location. Always secure the unit during transportation to prevent  turnover, fuel spillage, and damage to the unit. X7501210000 © 04/24 ECHO Incorporated...

  • Page 25: Fuel

    NOT approved. Use of ECHO branded fuel is recommended to extend engine life in all air-cooled 2-stroke and 2/4-stroke hybrid engines. Two Stroke Oil - A two-stroke engine oil, such as ECHO branded 2-stroke oils, meeting ISO-L-EGD (ISO/CD 13738) and J.A.S.O. FD Standards must be used.
  • Page 26 AVOID inhaling oil mists or vapors.  ECHO branded 2-stroke oils may be mixed at 50:1 ratio for application in all ECHO engines sold in the past regardless of ratio specified in those manuals. Handling Fuel Fuel is VERY flammable. Use extreme care when mixing, storing or handling, or serious personal injury will result.
  • Page 27 • Empty the fuel tank prior to storing the unit. Return unused fuel to an approved fuel storage container. Stored two-stroke fuel can separate. ALWAYS shake fuel container thoroughly before each use. X7501210000 © 04/24 ECHO Incorporated...

  • Page 28: Starting Cold Engine

    Move throttle lever (A) to IDLE position. Choke PB-5810H Rotate choke (B) to COLD START position. Purge Bulb Pump purge bulb (C) until fuel is visible. Pump bulb an additional 4 or 5 times. PB-5810T X7501210000 © 04/24 ECHO Incorporated...
  • Page 29 COLD START position, and repeat steps 3- 6. Allow engine to warm up for several minutes before use. Throttle Lever After engine warm-up, move throttle lever gradually to increase engine RPM to desired operating speed. X7501210000 © 04/24 ECHO Incorporated...

  • Page 30: Starting Warm Engine

    Pump bulb an additional 4 or 5 times. PB-5810T Recoil Starter Pull recoil starter handle (D) and engine should start. Do not use choke (B). Note: If engine does not start after 5 pulls, use cold start procedures. X7501210000 © 04/24 ECHO Incorporated...

  • Page 31: Stopping Engine

    Engine exhaust IS HOT, and contains Carbon Monoxide (CO), a poison gas. Breathing CO can cause unconsciousness, serious injury, or death. Exhaust can cause serious burns. ALWAYS position unit so that exhaust is directed away from your face and body. X7501210000 © 04/24 ECHO Incorporated...
  • Page 32 To reduce sound levels, limit the number of pieces of equipment used at any one time. Allow the engine to warm up at a fast idle for a few minutes. X7501210000 © 04/24 ECHO Incorporated...
  • Page 33 Always stop unit using stop engine procedure. Note: Never use a higher speed setting than necessary to perform a task. Remember, the higher the engine speed, the louder the blower noise. X7501210000 © 04/24 ECHO Incorporated...
  • Page 34 This product should not be used in temperatures below 15° F (-9° C) otherwise damage to the fuel lines may occur. Remove clips from back cushion. Remove back cushion (A) from frame. Install cold weather insert (B) on frame over air intake.. X7501210000 © 04/24 ECHO Incorporated...

  • Page 35: Maintenance

    Servicing Dealer for maintenance. To help you decide whether you want to do it yourself or have the Dealer do it, each maintenance task has been graded. If the task is not listed, see your Dealer for repairs. X7501210000 © 04/24 ECHO Incorporated...

  • Page 36: Skill Levels

    Skill Levels Level 1 = Easy to do. Common tools may be required. Level 2 = Moderate difficulty. Some specialized tools may be required. Level 3 = See your dealer. Click HERE or go to http://www.echo-usa.com/products/maintenance-kit HERE https://www.shindaiwa-usa.com/you-can.aspx Maintenance Intervals SKILL...

  • Page 37: Air Filter

    • If filter can be reused, be certain it fits tightly in the air filter cavity, and is installed with the original side out. Assemble components in reverse order. X7501210000 © 04/24 ECHO Incorporated...

  • Page 38: Fuel Filter

    2012 and later equipment, only fuel supply hoses certified by EPA can be used to replace the original equipment supply hose. Fines up to $37,500 may be enforced for using an un-certified replacement part. X7501210000 © 04/24 ECHO Incorporated...

  • Page 39: Spark Plug

    • Air intakes are blocked, preventing cooling air from reaching the cylinder. • Dust and grass build up on the outside of the cylinder. This build up insulates the engine and prevents the heat from leaving. X7501210000 © 04/24 ECHO Incorporated...
  • Page 40 Cleaning Cylinder Fins Remove engine cover. Disconnect spark plug lead from spark plug. Clean cylinder fins (A) to allow cooling air to pass freely. Connect spark plug lead. Install engine cover. X7501210000 © 04/24 ECHO Incorporated...

  • Page 41: Exhaust System

    Exhaust Port Cleaning Level 2. Parts required: Muffler Gasket (as required). Remove engine cover and remove spark plug lead from spark plug. Place piston at top dead center. Remove muffler (A) and muffler gasket (B). X7501210000 © 04/24 ECHO Incorporated...

  • Page 42: Carburetor Adjustment

    New engines must be operated a minimum duration of two tanks of fuel break-in before carburetor adjustments can be made. During the break-in period your engine performance will increase and exhaust emissions will stabilize. Idle speed can be adjusted as required. X7501210000 © 04/24 ECHO Incorporated...
  • Page 43 • Spark arrester screen and muffler are free of carbon. • Blower pipes are installed. Start engine, run at idle for one minute. Complete warm up by running at full throttle for 5 minutes, operating choke twice to clear air from carburetor chambers. X7501210000 © 04/24 ECHO Incorporated...

  • Page 44: Throttle Cable Adjustment (Pb-5810T Only)

    If engine idle speed changes when blower pipe is moved, or engine will not reach full wide open throttle speed, adjust throttle cable. Loosen handle adjustment knob (C) and tilt tube throttle handle forward to expose adjustment screw (D). X7501210000 © 04/24 ECHO Incorporated...

  • Page 45: Troubleshooting

    Carburetor See your dealer cylinder starts hard or OPEN choke Engine Fuel at Clean or replace does not cylinder Muffler wet Fuel mixture air filter start with fuel too rich Adjust carburetor See your dealer X7501210000 © 04/24 ECHO Incorporated...
  • Page 46 Cooling system dirty ation in dirty or Clean system or plugged dusty locations properly Spark Spark arrester arrester Normal wear Replace screen screen plugged Engine Internal engine does not See your dealer problem crank X7501210000 © 04/24 ECHO Incorporated...

  • Page 47: Storage

    10. Install the spark plug. Connect the spark plug lead to the spark plug. 11. Remove blower pipe assembly from unit. X7501210000 © 04/24 ECHO Incorporated...

  • Page 48: Specifications

    1.28 L (43.2 US fl. oz.) Starter System Automatic recoil starter, centrifugal type Idle Speed 2,700 RPM Wide Open Throttle 6,600 RPM Speed Air Force 27 N Maximum Air Speed 89.4 m/sec (200 mph) (with pipes) X7501210000 © 04/24 ECHO Incorporated...
  • Page 49 PB-5810 H/T SPECIFICATIONS MODEL PB-5810H PB-5810T Air Volume 19.8 m /min. (700 ft. /min.) Sound Level at 15.25 m (50 ft.) dB(A) scale per 75 dB(A) ANSI B175.2 X7501210000 © 04/24 ECHO Incorporated...

  • Page 50: Product Registration

    Please go to http://www.echo-usa.com/Warranty/Register-Your-ECHO to register your new product on-line. It's FAST and EASY! NOTE: your information will never be sold or misused by ECHO, Incorporated. Registering your purchase enables us to contact you in the unlikely event of a service update or product recall, and verifies your ownership for warranty consideration.
  • Page 51 PB-5810 H/T PRODUCT REGISTRATION X7501210000 © 04/24 ECHO Incorporated...
  • Page 52 P61212001001 - P61212999999 P61312001001 - P61312999999 P61413001001 - P61413999999 P61513001001 - P61513999999 ECHO INCORPORATED 400 Oakwood Road Lake Zurich, IL 60047 www.echo-usa.com...
