3. Product Introduction

3.1 Technical Specifications

Product Type
Battery Capacity
Max.recommended DOD
Max Charge Power
Max Disharge Power
Voltage
Nominal Voltage
Nominal Charging Current
Nominal Discharging Current
Max Charging Current
Max Discharging Current
Max. Charge Voltage
Weight
Dimension(mm)(L*W*H)
Operating Condition
Charge Temperature
Discharge Temperature
Humidity
Over Voltage Category
Cooling Type
Case Material
Installation
IP rating
Max. Connection Number
Communication
Protection Mode
Battery Protection
Safety
Hazardous Material
classification
Transportation
Product Warranty
＜60%(No condensed water)
Wall mounting/Ground Installation/Rack Installation
Over-current/Over-voltage/Short circuit/ Under-voltage/Over temperature
10 years warranty, 6000 cycles life
All information contained in this document is subject to change without notice
1)For better battery life cycles,we suggest charge in 50A(0.5C @25°C)
2)For better battery life cycles,we suggest discharge in 50A(0.5C @25°C)
3)Peak Current excludes repeated short duration (less than 100ms) of current pattern
5
RT5120
50Ah+50Ah
93%
5.12kW
7.68kW
48~56Vd.c
51.2Vd.c
80A
100A
100A
150A (1.5c)
55.6Vd.c
46kg
530*480*165mm
Indoor
From 0~50℃
From -10~55℃
II
Natural cooling
Metal
IP 20
16P
CAN/ RS485
Dual hardware protection
Cell UL 1973
CE/TUV
9
UN 38.3
