- Page 1 AUTOOL HTS705 Dry Ice Blasting Machine User Manual www.autooltech.com...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Copyright Information..................2 Copyright......................2 Trademark ....................... 2 Cautions ......................3 Warning ......................3 Product Introduction ..................4 Overview ......................4 Applicable industry field .................. 4 Function features .................... 4 Technical parameters ..................5 Product Structure ....................6 Machine structure.................... -
Page 4: Copyright Information
COPYRIGHT INFORMATION Copyright ● All rights reserved by AUTOOL TECH. CO., LTD. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written permission of AUTOOL. -
Page 5: Cautions
CAUTIONS Warning Before using the instrument, please read this manual careful- ly for proper operation. If cleaning moving objects, firstly be sure to turn off the drive power of the objects to be cleaned. The temperature of dry ice is -78.5 degrees, and gloves must be worn for long-term contact with dry ice to prevent burns. -
Page 6: Product Introduction
PRODUCT INTRODUCTION Overview Dry ice cleaning uses compressed air as power to spray dry ice particles to the surface of the cleaned object at supersonic speed. However, it does not rely solely on the kinetic energy of dry ice particles, but uses the ultra-low temperature performance of dry ice to achieve the purpose of decontamination. -
Page 7: Technical Parameters
personnel. ● Quickly remove all kinds of intractable dirt. The use of dry ice blaster can thoroughly remove the attached dirt and protect the equipment to avoid affecting the operation and use of the equipment during cleaning. Technical Power Supply 110V/220V parameters Dry Ice Volume... -
Page 8: Product Structure
PRODUCT STRUCTURE Machine structure Hanger of spray gun pipe Power cord Dry ice tank Control panel Dry ice gun interface Air source interface Ice spray gun Caster... -
Page 9: Control Panel Introduction
Control panel introduction Dry ice volume Pressure gauge adjustment controller Start / Cleaning controller Power indicator light Fuse Power switch... -
Page 10: Operations Instruction
OPERATIONS INSTRUCTION Equipment ● Connect the host to the external air source and external power debugging supply. Check whether the data of the air pressure indicator is normal and whether the power connection is normal (make sure the power supply is grounded normally). ●... -
Page 11: Common Problems And Troubleshooting
COMMON PROBLEMS AND TROUBLESHOOTING Common The ice is blocked in the ice hopper in the dry ice box. faults ● Stop the operation, open the cover, and check if there is exces- sive dry ice filled. If so, remove some dry ice, and then contin- ue the operation. - Page 12 Common The cleaning effect is not perfect, carbon deposits and faults other intractable stains are not cleaned thoroughly. ● If the cleaning is not complete, first check whether the air pressure and flow of the external air source are insufficient. The working pressure of the dry ice machine is not less than Analysis and 6bar and the flow rate is not less than 1m³/min.
-
Page 13: Maintenance Service
MAINTENANCE SERVICE Our products are made of long-lasting and durable materials, and we insist on perfect production process. Each product leaves the factory after 35 procedures and 12 times of testing and inspec- tion work, which ensures that each product has excellent quality and performance. -
Page 14: Warranty
Disclaimer All information, illustrations, and specifications contained in this manual, AUTOOL resumes the right of modify this manual and the machine itself with no prior notice. The physical appearance and color may differ from what is shown in the manual, please refer to the actual product. -
Page 15: Return & Exchange Service
RETURN & EXCHANGE SERVICE ● If you are an AUTOOL user and are not satisfied with the Return & AUTOOL products purchased from the online authorized Exchange shopping platform and offline authorized dealers, you can return the products within seven days from the date of receipt;...
