Page 1 OWNER’S MANUAL & SERVICE BOOKLET • Keep With Vehicle At All Times • Contains Warranty policy and Important Information On Safety, Operation & Maintenance Part No. 99011M64M14-74E September, 2021...
Page 2 Earth’s may be discrepancies between informa- manual carefully before operating your natural resources. tion in this manual and your vehicle. new MARUTI SUZUKI and review the To that end, we encourage every vehicle MARUTI SUZUKI INDIA LIMITED manual from time to time.
Page 3 • Words like car, model/variant are invari- ing in vehicle performance problems. could result in minor or moderate ably used in this manual to denote the Consult your Maruti Suzuki authorised injury. “Vehicle”. workshop or qualified service techni- • Pictorial representations used in this cian for advice on installing such manual are for reference purposes only.
Page 4 “WARNING” Vehicle may break-down , meet with an Avoid driving into or starting the vehicle in a accident catch fire due to heavily water logged area. Vehicle may break- down or engine may fail due to 1. Installation of 1. Water entry into the engine (which may lead to hydrostatic lock). - High wattage bulbs - Non genuine lamps / horns 2.
Page 5 “CAUTION” 1. Retro-fitment of LPG / CNG kit may deteriorate vehicle performance, reduce engine & engine related component’s life and also warranty will be null and void for such vehicles. 2. Do not use domestic LPG/LPG cylinder for your factory fitted LPG vehicles. 3.
Page 6 Spare For any assistance with regard to our product, please contact General Manager/Works Manager at any of our Maruti Suzuki authorised Nexa dealer / Maruti Suzuki authorised workshop. For additional enquiry you may contact our Regional Office or Service Department. The...
Page 7 Paid inspection service - 120000 KM / 144 Months Paid inspection service - 130000 KM / 156 Months Maruti Suzuki Network can be viewed by installing below Mobile Apps: Maruti Suzuki Rewards app ensures a hassle free car ownership experience. Get easy access to all the services and information you...
Page 8 1ST. FREE INSPECTION COUPON 1ST. FREE INSPECTION COUPON 1ST. FREE INSPECTION COUPON (Customer’s copy) (1,000 KM or 1 MONTH) (Selling dealer copy) (1,000 KM or 1 MONTH) (Servicing W/S copy) (1,000 KM or 1 MONTH) Model Name Model Name Model Name Model Code* Model Code* Model Code*...
Page 9 MSIL on monthly basis. monthly basis. monthly basis. FOR BAR CODE FOR BAR CODE FOR BAR CODE Service Division Service Division Service Division Maruti Suzuki India Limited Maruti Suzuki India Limited Maruti Suzuki India Limited...
Page 10 2ND. FREE INSPECTION COUPON 2ND. FREE INSPECTION COUPON 2ND. FREE INSPECTION COUPON (Customer’s copy) (5,000 KM or 6 MONTHS) (Selling dealer copy) (5,000 KM or 6 MONTHS) (Servicing W/S copy (5,000 KM or 6 MONTHS) Model Name Model Name Model Name Model Code* Model Code* Model Code*...
Page 11 MSIL on monthly basis. monthly basis. monthly basis. FOR BAR CODE FOR BAR CODE FOR BAR CODE Service Division Service Division Service Division Maruti Suzuki India Limited Maruti Suzuki India Limited Maruti Suzuki India Limited...
Page 12 3RD. FREE INSPECTION COUPON 3RD. FREE INSPECTION COUPON 3RD. FREE INSPECTION COUPON (Customer’s copy) (10,000 KM or 12 MONTHS) (Selling dealer copy) (10,000 KM or 12 MONTHS) (Servicing W/S copy) (10,000 KM or 12 MONTHS) Model Name Model Name Model Name Model Code* Model Code* Model Code*...
Page 13 MSIL on monthly basis. monthly basis. monthly basis. FOR BAR CODE FOR BAR CODE FOR BAR CODE Service Division Service Division Service Division Maruti Suzuki India Limited Maruti Suzuki India Limited Maruti Suzuki India Limited...
Page 14 (3) Maruti Suzuki Warranty Obligation: cants/ oil/ coolant/ fluids used other than those specified in If any defect(s) should be found in a Maruti Suzuki vehicle within the Owner’s Manual. the term stipulated above, Maruti Suzuki’s only obligation is to...
Page 15 This warranty is the entire written warranty given by Maruti Suzuki (m) Any damage or deterioration caused by airborne fallout, for Maruti Suzuki vehicles and no dealer or its or his agent or industrial fallout, acid rain, hail or hail storm, wind storm,...
Page 16 (7) Owner’s Warranty Obligations: (8) Disclaimer of Consequential Damage: Maruti Suzuki assumes no responsibility for loss of vehicle, loss of time, inconvenience or any other indirect incidental or consequen- NOTICE tial damage resulting from the vehicle not being available to the The owner shall not use the vehicle in a damaged condi- owner because of any defect covered by this warranty.
Page 17 EMISSION WARRANTY POLICY 3. The method of examination for deciding the warranty of the parts will be at the sole discretion of Maruti Suzuki and Maruti Suzuki authorised workshop and results of the examination will Maruti Suzuki offers the Emission Warranty on all Maruti Suzuki be final and binding.
Page 18 8. Fuel Tank and Filler Cap. 1. In the absence of valid PUC certificate. 9. PCV (Positive Crankcase Ventilation) Valve. 2. Vehicle not serviced from Maruti Suzuki authorised workshop 10. Oil Filler Cap. as per the schedule specified in the Owner’s Manual.
Page 20: Table Of Contents
TABLE OF CONTENTS FUEL RECOMMENDATION BEFORE DRIVING OPERATING YOUR VEHICLE DRIVING TIPS OTHER CONTROLS AND EQUIPMENT VEHICLE LOADING AND TOWING INSPECTION AND MAINTENANCE EMERGENCY SERVICE APPEARANCE CARE GENERAL INFORMATION SPECIFICATIONS SERVICE NETWORK...
Page 22 FUEL RECOMMENDATION FUEL RECOMMENDATION Fuel Recommendation ............1-1 64MM01000 64MS0-74E...
Page 23 FUEL RECOMMENDATION Fuel Recommendation NOTICE To avoid damaging catalytic converter, you CAUTION must use unleaded petrol with an octane Be careful not to spill fuel containing Use of spurious, low quality, adulter- number (RON) of 90 or higher. alcohol while refueling. If fuel is ated fuel can cause damage to the spilled on the vehicle body, wipe it up Petrol/Ethanol blends...
Page 24: Before Driving
BEFORE DRIVING BEFORE DRIVING Keys ..................2-1 Door Locks ................2-2 Keyless Push Start System Remote Controller/ Keyless Entry System Transmitter (if equipped) ....2-5 Security System (if equipped) ..........2-14 Windows ................2-16 Mirrors .................. 2-18 Front Seats ................2-22 Rear Seats ................
Page 25: Keys
Immobilizer System message may be shown on the information something wrong with your key or with the This system is designed to help prevent display. immobilizer system. Ask a Maruti Suzuki vehicle theft by electronically disabling the engine starting system. 64MS0-74E...
Page 26: Door Locks
BEFORE DRIVING authorised workshop to have the system Ignition Key Reminder (if equipped) To unlock a front door from outside the inspected. vehicle, insert the key and turn the top of A buzzer sounds intermittently to remind the key toward the front of the vehicle. you to remove the ignition key if it is in the The immobilizer/keyless push start system ignition switch when the driver’s door is...
Page 27 BEFORE DRIVING Central Door Locking System NOTE: You can switch the function that unlocks all EXAMPLE doors from twice operations to once opera- tion, and vice versa, via the setting mode of the information display. For details on how to use the information display, refer to “Information Display”...
Page 28 BEFORE DRIVING Child-Proof Locks (rear door) Tailgate Vehicle with keyless push start system You can lock or unlock the tailgate by pushing the request switch (2), when the keyless push start system remote control- WARNING ler is within the switch’s operating range. Always make sure that the tailgate is For details refer to “Keyless Push Start closed and latched securely.
Page 29: Keyless Push Start System Remote Controller/Keyless Entry System Transmitter (If Equipped)
If the tailgate cannot be unlatched by push- Suzuki authorised workshop. 64MM02004 ing the unlatch switch (1), have the vehicle inspected by a Maruti Suzuki authorised Your vehicle is equipped with either a key- workshop. less push start system remote controller...
Page 30 BEFORE DRIVING Keyless Push Start System Remote Central door locking system Car locator function • To lock all doors, push the LOCK button This function helps in locating the vehicle. Controller (Type A) (1) once. Push both of the LOCK button (1) and The remote controller enables the follow- •...
Page 31 • If you lose one of the remote controllers, the siren will sound once when the doors times to remind you. If this happens, ask a Maruti Suzuki authorised work- are locked. check whether your vehicle has been shop as soon as possible for a replace- broken into while you were away from it.
Page 32 BEFORE DRIVING mation display, refer to “Information When the remote controller is within Display” in this section. approximately 80 cm (2 1/2 feet) from a NOTICE front door handle or the tailgate switch, you NOTE: The remote controller is a sensitive can lock or unlock the doors by pushing •...
Page 33 • If you lose one of the remote controllers, With the ignition mode changed to “LOCK” ask a Maruti Suzuki authorised work- (OFF) by pressing the engine switch, bring shop as soon as possible for a replace- out the remote controller if it is inside the ment.
Page 34 BEFORE DRIVING returned to an area of the vehicle other Battery replacement than the rear luggage area. If the remote controller becomes unreli- EXAMPLE able, replace the battery. If the remote controller is left in the vehicle and you lock the driver’s door or front pas- NOTICE senger’s door as described below, the door When replacing the battery, do not...
Page 35 BEFORE DRIVING Keyless Entry System Transmitter how to use the information display, refer to NOTICE “Information Display” in this section. (Type B) • The remote controller is a sensitive The turn signal lights will flash once and EXAMPLE the siren (if your vehicle is equipped with electronic instrument.
Page 36 • If you lose one of the transmitters, ask a NOTE: into while you were away from it. Maruti Suzuki authorised workshop as The car locator function will not activate • Once you push both of the LOCK button soon as possible for a replacement. Be...
Page 37 Used batteries must be disposed properly about disposing of or recycling the used 6) Close the transmitter and install it into according to applicable rules or regulations battery, consult a Maruti Suzuki authorised the transmitter holder. and must not be disposed with ordinary workshop.
Page 38: Security System (If Equipped)
To set you should still be careful to guard • To prevent the alarm from being acci- the shock sensor, ask a Maruti Suzuki against theft. Do not leave money or dentally triggered, avoid arming it while authorised workshop or use the setting things of value in the vehicle.
Page 39 Ask a Maruti Suzuki doors, tailgate or engine hood is opened, • If the shock sensor is in enabled state...
Page 40: Windows
BEFORE DRIVING Windows Passenger’s door The driver’s window has AUTO-DOWN and AUTO-UP features for added conve- EXAMPLE EXAMPLE Electric Window Controls nience (at toll booths or drive-through restaurants, for example). This means the The electric windows can only be operated driver can open or close the window with- when the ignition switch is in the “ON”...
Page 41 BEFORE DRIVING Pinching Prevention Function NOTE: WARNING Even if you cannot close the window by the The driver’s window is equipped with the AUTO-UP feature because there may be pinching prevention function. The function • You should always lock the pas- something wrong with the pinching preven- detects a foreign object caught in the win- senger’s window operation when...
Page 42: Mirrors
EXAMPLE work after initialization, there might be something wrong with the pinching preven- tion function. Have your vehicle inspected CAUTION by a Maruti Suzuki authorised workshop. Do not modify the inside rearview Mirrors mirror or install a non-genuine wide 68LMT0206 mirror.
Page 43 BEFORE DRIVING Auto Dimming Rearview Mirror NOTICE (if equipped) Do not hook anything heavy on the EXAMPLE mirror, or the mirror may break under the weight. NOTE: Auto dimming system may not work in any of the following cases: • Light from the rear is not directly focused to the sensor (3).
Page 44 BEFORE DRIVING Outside Rearview Mirrors Folding NOTICE Switch (if equipped) EXAMPLE • The electric type outside rearview NOTICE mirror operates even though the ignition switch is in the ACC posi- Do not fold the electrical foldable out- tion. However, to prevent unneces- side rearview mirror by hand.
Page 45 BEFORE DRIVING CAUTION Moving mirrors can pinch and injure a hand. Do not allow any one’s hand to get near the mirrors when folding and unfolding the mirrors. NOTE: • If you press the folding switch to open the outside rearview mirrors and simulta- neously start the engine, then the out- side rearview mirrors may get stuck during that moment.
Page 46: Front Seats
BEFORE DRIVING Front Seats CAUTION Seat Adjustment Do not place any object under the front seat. If an object gets stuck WARNING under the front seat, the seat shall Never attempt to adjust the driver’s not be latched properly and may seat or seatback while driving.
Page 47 BEFORE DRIVING Seat position adjustment lever (1) Pull the lever up and slide the seat. EXAMPLE Seatback angle adjustment lever (2) Pull the lever up and move the seatback. Seat height adjustment lever (3) (if equipped) Pull the lever up to raise the seat. Push the lever down to lower the seat.
Page 48 BEFORE DRIVING Head Restraints Front EXAMPLE EXAMPLE 80J001 64MS163 Head restraints are designed to help To raise the front head restraint, pull reduce the risk of neck injuries in the case upward on the restraint until it clicks. To of an accident. Adjust the head restraint to lower the restraint, push down the restraint the position which places the center of the while holding in the lock lever.
Page 49: Rear Seats
BEFORE DRIVING Rear Seats EXAMPLE Seat Adjustment WARNING To avoid excessive seat belt slack, which reduces the effectiveness of the seat belts as a safety device, make sure that the seats are adjusted LOCK before the seat belts are fastened. WARNING All seatbacks should always be in an upright position when driving, or seat...
Page 50 BEFORE DRIVING Seatback angle adjustment lever (1) Rear (if equipped) EXAMPLE EXAMPLE Pull the lever up and move the seatback. After adjustment, try to move the seatback forward and rearward to ensure that it is securely latched. CAUTION After securing the rear seatback, make sure that it is locked securely.
Page 51 BEFORE DRIVING To return the seat to the normal position, EXAMPLE follow the procedure below. NOTICE • When returning the rear seatback CAUTION to the normal position, do not allow When returning the rear seatback to any foreign material to enter the the normal position, be careful that lock opening.
Page 52: Seat Belts And Child Restraint Systems
BEFORE DRIVING Seat Belts and Child Restraint WARNING EXAMPLE Systems • Never allow persons to ride in the cargo area of a vehicle. In the event EXAMPLE of an accident, there is a much greater risk of injury for persons who are not riding in a seat with Above the pelvis their seat belt securely fastened.
Page 53 BEFORE DRIVING WARNING EXAMPLE EXAMPLE (Continued) • Never use the same seat belt on more than one occupant and never attach a seat belt over an infant or as low as possible child being held on an occupant’s across the hips Across the pelvis lap.
Page 54 BEFORE DRIVING Lap-Shoulder Belt EXAMPLE WARNING Emergency Locking Retractor (ELR) (Continued) The seat belt has an emergency locking Low on hips • For children, if the shoulder belt retractor (ELR), which is designed to lock irritates the neck or face, move the the seat belt only during a sudden stop or child closer to the center of the impact.
Page 55 BEFORE DRIVING All Seat Belts Except Rear Center All seat belts except rear center are the EXAMPLE TO TIGHTEN lap-shoulder belt. EXAMPLE Low on hips EXAMPLE 60A039 80JS028 To unfasten the seat belt, push the button on the buckle and retract the belt slowly To tighten the belt, pull the free end of the 60A036 while attaching a hand to the belt or/and...
Page 56 BEFORE DRIVING refitted into the buckle and the belt tight- Driver’s Seat Belt Warning Light / ened as previously described. WARNING Front Passenger’s Seat Belt Warn- To unfasten the belt, press the release but- ing Light It is absolutely essential that the ton on the buckle catch.
Page 57 (2) The sensor of the front passenger’s NOTE: Immediately wipe it dry with a soft seat belt reminder Maruti Suzuki recommends use of Maruti cloth when spilled. Suzuki Genuine accessory of “Seat cover”. The seat belt reminder sensor (2) detects (Continued) whether a person is sitting in the front seat.
Page 58 BEFORE DRIVING Shoulder Anchor Height Adjuster Seat Belt Inspection Child Restraint Systems EXAMPLE EXAMPLE EXAMPLE 65D209S 64J198 Periodically inspect the seat belts to make 60G332S sure they work properly and are not dam- Adjust the shoulder anchor height so that aged.
Page 59 80JC008 MARUTI SUZUKI highly recommends that you use a child restraint system to restrain infants and small children. Many different types of child restraint systems are avail- able;...
Page 60 BEFORE DRIVING Installation with Lap-Shoulder Seat ELR type belt WARNING Belts EXAMPLE Children could be endangered in a NOTICE crash if their child restraint systems are not properly secured in the vehi- If you can adjust the position of rear cle.
Page 61 BEFORE DRIVING Installation with ISOFIX type Install the ISOFIX type child restraint sys- CAUTION tem according to the instructions provided anchorages by the child restraint system manufacturer. (Continued) After installation, try moving the child However, if a booster cushion not restraint system in all directions especially equipped with the head restraint is forward to check that connecting bars are...
Page 62 BEFORE DRIVING 1) Place the child restraint in the rear seat, 3) Push the child restraint toward the anchor- inserting the connecting bars to the ages so that the connecting bar tips are NOTICE anchorages between the seat cushion partially hooked to the anchorages. Use When installing a child restraint sys- and the seatback.
Page 63 BEFORE DRIVING Installation of child restraint with above for securing a restraint system EXAMPLE that does not require a top tether strap. top tether 4) Hook the top tether strap to the top tether anchorage bracket and tighten Front CAUTION the top tether strap according to the instructions provided by the child Adjust the height of the rear head...
Page 64 When installing a child restraint sys- tem to the rear seat, adjust the front seat position so that the front seat does not interfere with the child restraint system. NOTE: Maruti Suzuki recommends use of Maruti Suzuki Genuine accessory of “Child seat, ISOFIX”. 2-40 64MS0-74E...
Page 65 BEFORE DRIVING Child Restraint System for India Child Restraint The suitability of each passenger’s seat position for carriage of children and fitting of child restraint system is shown in the table below. Whenever you carry children up to 12 years of age, properly use the child restraints which conform to AIS 072, the standard for child restraints, referring to the table.
Page 66 BEFORE DRIVING Seat Belt Pretensioner System Read this section and the “Supplemental Sit fully back in the seat; sit up straight; do Restraint System (airbags)” section to not lean forward or sideways. Adjust the EXAMPLE learn more about the pretensioner system. belt so the lap portion of the belt is worn and/or low across the pelvis, not across the waist.
Page 67 Have both systems inspected by a Maruti Suzuki authorised workshop as soon as possible. Service on or around the pretensioner sys- tem components or wiring must be per- formed only by a Maruti Suzuki authorised workshop specially trained. Improper service could result in unin- tended activation of pretensioners or could render the pretensioner inoperative.
Page 68: Supplemental Restraint System (Airbags)
BEFORE DRIVING Supplemental Restraint System EXAMPLE (airbags) WARNING This section of the owner’s manual describes the protection provided by your Vehicle’s supplemental restraint system (airbags). Please read and follow all these instructions carefully to minimize your risk of severe injury or death in the event of a collision.
Page 69 (if equipped) may not work ALWAYS WEAR YOUR SEAT BELTS. Be properly. Have airbag system aware that no system can prevent all pos- inspected by a Maruti Suzuki authorised sible injuries that may occur in an accident. workshop as soon as possible. 2-45 64MS0-74E...
Page 70 If the airbag location is damaged or cracked, the airbag system may not work properly, which could result in serious injury in the event of a colli- sion. Have your vehicle inspected by a Maruti Suzuki authorised work- shop. EXAMPLE 61M0020 Front passenger’s front airbag...
Page 71 BEFORE DRIVING Conditions of front airbags deployment Conditions when front airbags may (inflation) inflate EXAMPLE Receiving a strong impact to the lower EXAMPLE body of your vehicle, the front airbags may inflate. EXAMPLE 80J101 • Landing hard or falling. 80J097 •...
Page 72 BEFORE DRIVING • Frontal collision to a stopped vehicle at Front airbags do not inflate EXAMPLE less than about 50 km/h. Front airbags do not inflate in rear impacts, side impacts or rollovers, etc. However, EXAMPLE these might inflate in a strong impact. EXAMPLE 80J105E •...
Page 73 BEFORE DRIVING How the System Works A seat belt helps keep you in the proper EXAMPLE In a frontal collision, the crash sensors will position for maximum protection when an detect rapid deceleration, and if the control- airbag inflates. Adjust your seat as far back ler judges that the deceleration represents as possible while still maintaining control of a severe frontal crash, the controller will...
Page 74 For that reason, navigation systems. Do not stand wheel or dashboard. Do not place only a Maruti Suzuki authorised workshop umbrellas or similar in front of air- any objects between the airbag and should be allowed to service or replace bags.
Page 75 BEFORE DRIVING To prevent damage or unintended inflation of the airbag system, be sure the battery is disconnected and the ignition switch has been in the “LOCK” position or the ignition mode has been “LOCK” (OFF) for at least 90 seconds before performing any electri- cal service work on your vehicle.
Page 76: Instrument Cluster
BEFORE DRIVING Instrument Cluster 1. Speedometer 2. Tachometer 3. Fuel gauge 4. Temperature gauge 5. Information display 6. Warning and indicator lights EXAMPLE 64MM02017 2-52 64MS0-74E...
Page 77: Speedometer
BEFORE DRIVING Speedometer Fuel Gauge NOTE: The indicator moves a little depending on The speedometer indicates vehicle speed. road conditions (for example, slope or EXAMPLE Speed Alert System curve) and driving conditions because of The speed alert system gives audible fuel moving in the tank.
Page 78: Temperature Gauge
BEFORE DRIVING Temperature Gauge Brightness Control To reduce the brightness of the instrument panel lights, turn the indicator selector knob (1) counterclockwise. EXAMPLE EXAMPLE WARNING If you attempt to adjust the bright- ness of the instrument panel lights while driving, you could lose control of the vehicle.
Page 79: Information Display
BEFORE DRIVING Information Display The information display shows the follow- illustration will appear on the display for ing information. several seconds. The information display is shown when the Some warning and indicator messages ignition switch is in the “ON” position or the Display (A) may appear on the display when the igni- ignition mode is “ON”.
Page 80 BEFORE DRIVING Driving Range / Average Speed / Total idling stop time / Total idling fuel (a) Instantaneous fuel consumption (b) Average fuel consumption saved / Energy flow indicator (c) Driving range When there are no warning or indicator messages on the display (C), you can select one (d) Average speed of the following indications to appear on the display: instantaneous fuel consumption, (e) Total idling stop time...
Page 81 BEFORE DRIVING Instantaneous fuel consumption Average fuel consumption NOTE: The display shows instantaneous fuel con- If you selected average fuel consumption If you add only a small amount of fuel sumption with a bar graph only when the the last time you drove the vehicle, the dis- when you select “Reset after refuel”, the vehicle is moving.
Page 82 BEFORE DRIVING NOTE: Total idling stop time Energy flow indicator • If you refuel when the ignition switch is in The display shows the total length (in Refer to “ENG A-STOP system (engine hours, minutes and seconds) of engine the “ON” position or the ignition mode is auto stop start system)”...
Page 83 BEFORE DRIVING Eco-driving Driving Selector Position (for automatic • The total amount of fuel conservation by When you turn the ignition switch to transaxle vehicles) / Gearshift Indi- the ENG A-STOP system and total idling “LOCK” position or press the engine switch cator (for manual transaxle vehi- stop time can be displayed in the infor- to change the ignition mode to LOCK...
Page 84 BEFORE DRIVING Setting Mode NOTE: Temperature • If you push and hold the indicator selec- When the ignition switch is in the “ON” (Temperature units setting) tor knob (2) to enter the setting mode position or the ignition mode is “ON” and You can change the units that temperature when the display (D) shows average fuel the vehicle is stationary, you can enter the...
Page 85 BEFORE DRIVING Clock setting Door Lock (Door lock setting) • Alarm • To change the hour indication, turn the • Door Unlock You can turn off or on the siren sound indicator selector knob (2) left or right – All Doors: when the door(s) is (are) locked or repeatedly when the hour indication Unlock all doors by turning the key, or...
Page 86 BEFORE DRIVING • When “Comfort” is selected, engine auto Warning and Indicator Messages (Idling disp setting) stop condition becomes severe, com- The display shows warning and indicator You can switch whether the information pared with “Standard”. Engine auto stop messages to let you know about certain display shows the Eco-driving display condition will occur less frequently, the vehicle problems.
Page 87 BEFORE DRIVING Warning and indicator messages Warning and Indicator Master Warning Sound Cause and Remedy Message Indicator Light Blinks Beep (one time from inte- A door or tailgate is not properly closed. Stop in a (only while vehicle rior buzzer; only while safe place and close the door or tailgate properly.
Page 88 Also, the vehicle battery voltage may be decreased. If this message is displayed even if you start the engine with normal voltage of the vehicle battery, have your vehicle inspected by a Maruti Suzuki authorised workshop. 61MM0A168 2-64 64MS0-74E...
Page 89 BEFORE DRIVING Warning and Indicator Master Warning Sound Cause and Remedy Message Indicator Light Keyless Push Start System Blinks Series of beeps under cer- The remote controller may be outside the tain conditions (for about 2 vehicle or its battery may have become dis- seconds from exterior and/or charged.
Page 90 BEFORE DRIVING Warning and Indicator Master Warning Sound Cause and Remedy Message Indicator Light Blinks Continuous beep (from inte- The headlights and/or the position lights are rior buzzer) left on. Turn them off. 61MM0A172 Keyless Push Start System This message is displayed when the ON position is selected as the power supply position.
Page 91 BEFORE DRIVING Warning and Indicator Master Warning Sound Cause and Remedy Message Indicator Light The road may be icy. Drive very carefully. (#1) 61MM0A176 Keyless Push Start System Blinks Beep (one time from interior The remote controller battery is about to buzzer) become flat.
Page 92 BEFORE DRIVING Warning and Indicator Master Warning Sound Cause and Remedy Message Indicator Light Automatic transaxle The engine switch is pressed with the gear- shift lever in a position other than “P” or “N” and depressing the brake pedal. Try again as instructed by message.
Page 93 Beep (one time from interior If this message is displayed, have your vehi- buzzer) cle inspected by a Maruti Suzuki authorised workshop. 61MM0A180 (#1) This message will disappear for a while even if the problem that caused the message to appear is not corrected.
Page 94: Warning And Indicator Lights
“ON”. dealer for repairs or have the vehicle periodic maintenance. 3) The light comes on when under either towed to the nearest Maruti Suzuki or both of above two conditions. NOTE: authorised workshop for repairs. (Parking Brake Reminder Buzzer)
Page 95 ABS system. Suzuki authorised workshop before you drive the vehicle again. If one of these happens, have the system inspected by a Maruti Suzuki authorised NOTICE workshop. If the ABS becomes inoperative, the brake • If you operate the engine with this...
Page 96 Bring the vehicle to a Maruti Suzuki switch is turned to the “ON” position the passenger sits upright, leaning...
Page 97 If you do not fill the fuel, a ding sounds with normal voltage of the vehicle battery, Maruti Suzuki authorised workshop. every time when the ignition switch is ask a Maruti Suzuki authorised workshop to have the system inspected. turned to the “ON” position or the engine NOTE:...
Page 98 If any abnormality of the turn signals is observed, such as fast blinking, there may be malfunction in the turn signal system. 64MM02015 Ask your Maruti Suzuki authorised work- When the cruise control system is on, this shop to inspect the system. light will be on.
Page 99 A-STOP” system, this light comes on. For with the LED headlight. Park the vehicle in details, refer to “ENG A-STOP System a safe place and consult a Maruti Suzuki (Engine Auto Stop Start System)” in the authorised workshop to have the problem “OPERATING YOUR VEHICLE”...
Page 100: Lighting Control Lever
“RE-GEN” Indicator Light (if steering wheel. lem with the hill hold control system. Have equipped) your vehicle inspected by a Maruti Suzuki authorised workshop. For details, refer to “Hill Hold Control Sys- tem” in the “OPERATING YOUR VEHI- CLE” section.
Page 101 BEFORE DRIVING Lighting Operation Automatic Lights Operation EXAMPLE (if equipped) EXAMPLE EXAMPLE 60MK012 With the headlights on, push the lever for- ward to switch to the high beams (main 60MK011 64MS059 beams) or pull the lever toward you to To turn the lights on or off, twist the knob switch to the low beams.
Page 102 BEFORE DRIVING ON: Lights ON To turn the lights on or off, twist the knob LIGHT: When it is light around the light sensor (5). on the end of the lever. There are four DARK: When it is dark around the light sensor (5). positions: OFF (1) Ignition mode...
Page 103 The following settings of the automatic Front position lights, tail lights, license light function can be customized to your plate light, instrument lights and headlights EXAMPLE preference. Please contact a Maruti Suzuki are on. authorised workshop if you want the func- 64MS062 tion reprogrammed.
Page 104: Front Fog Light Switch (If Equipped)
BEFORE DRIVING Rain-triggered automatic lighting oper- Daytime Running Light (D.R.L.) Front Fog Light Switch ation System (if equipped) (if equipped) The setting of the auto-on headlight sys- When the engine is started, the daytime tem can be changed to make it turn on the running lights are turned on by this system.
Page 105: Headlight Leveling Switch (If Equipped)
BEFORE DRIVING Headlight Leveling Switch Turn Signal Control Lever Turn Signal Operation With the ignition switch in the “ON” position (if equipped) or the ignition mode “ON”, move the lever EXAMPLE up or down to activate the right or left turn signals.
Page 106: Hazard Warning Switch
To turn off the and its indicator (1 to 4 times). Please ask WARNING lights, push the switch again. a Maruti Suzuki authorised workshop for To avoid possible injury, do not oper- Use the hazard warning lights to warn the customization.
Page 107 BEFORE DRIVING Windshield Wipers automatically operate when the wiper sys- EXAMPLE tem senses rain or snow. In the “LO” posi- tion, the wipers operate at a steady low EXAMPLE speed. In the “HI” position, the wipers operate at a steady high speed. To turn off the wipers, move the lever back to the “OFF”...
Page 108 (Use a position other than following conditions, have “AUTO” under these conditions.) inspected by a Maruti Suzuki authorised – Rain or snow does not hit the rain sen- workshop. sor area of the windshield, or the snow – Rainfall/snowfall rate varies but the is not of a type that is able to be wiping interval remains constant.
Page 109 BEFORE DRIVING Intermittent wiping Rear Window Wiper/Washer Switch The wipers operate only in the intermittent NOTICE (if equipped) wiping mode. The wiping interval can be To help prevent damage to the wind- changed with the knob on the control lever. EXAMPLE Wiper shield wiper and washer system...
Page 110: Tilt/Telescoping (If Equipped) Steering Lock Lever
BEFORE DRIVING Tilt/Telescoping (if equipped) Horn WARNING Steering Lock Lever EXAMPLE Never attempt to adjust the steering wheel while the vehicle is moving or EXAMPLE you could lose control of the vehicle. 68LM240 61MM0A085 Press the horn button of the steering wheel (1) LOCK to sound the horn.
Page 111: Heated Rear Window Switch (If Equipped)
BEFORE DRIVING Heated Rear Window Switch When the rear window is misted, push this switch (1) to clear the mist from the win- (if equipped) dow. Type A An indicator light will be lit when the defog- ger is on. The defogger will work only EXAMPLE when the engine is running.
Page 112: Operating Your Vehicle
OPERATING YOUR VEHICLE OPERATING YOUR VEHICLE Exhaust Gas Warning ............3-1 Daily Inspection Checklist ..........3-2 Engine Oil Consumption ............ 3-3 Ignition Switch (Vehicle without Keyless Push Start System) ....3-3 Engine Switch (Vehicle with Keyless Push Start System)......3-5 Keyless Push Start System (if equipped) ......
Page 113: Exhaust Gas Warning
OPERATING YOUR VEHICLE Exhaust Gas Warning WARNING WARNING EXAMPLE (Continued) Avoid breathing exhaust gases • Avoid operating the vehicle with Exhaust gases contain carbon monox- ide, a potentially lethal gas that is col- the tailgate open. If it is necessary orless and odorless.
Page 114: Daily Inspection Checklist
OPERATING YOUR VEHICLE Daily Inspection Checklist 4) Make sure the hood is fully closed and ing for proper latch operation. See the latched. item “All latches, hinges and locks” of Before Driving 5) Check the headlights, turn signal lights, “chassis and body” in the “Periodic brake lights and horn for proper opera- Maintenance Schedule”...
Page 115: Engine Oil Consumption
OPERATING YOUR VEHICLE Engine Oil Consumption You should also be aware that the diluting Ignition Switch ingredients evaporate out when the vehicle (Vehicle without Keyless It is normal for the engine to consume is subsequently driven at high speeds, some engine oil during normal vehicle Push Start System) such as on an expressway, making it operation.
Page 116 OPERATING YOUR VEHICLE Manual Transaxle vehicles EXAMPLE You must push in the key to turn it to “LOCK” position. It locks the ignition, and prevents normal use of the steering wheel after the key is removed. To release the steering lock, insert the key and turn it clockwise to one of the other positions.
Page 117: Engine Switch
OPERATING YOUR VEHICLE Engine Switch WARNING • With the engine off (Vehicle with Keyless Push You can use such electric equipment as (Continued) Start System) the power windows and wipers with the There is also a danger that children engine off. When this ignition mode is may injure themselves by playing selected by pressing the engine switch, with the power windows or other...
Page 118: Keyless Push Start System (If Equipped)
OPERATING YOUR VEHICLE NOTE: Unreleased Steering Lock Warning Keyless Push Start System You do not need to keep the engine switch If the steering lock remains engaged when (if equipped) pressed until the engine starts. you press the engine switch to change the Provided the keyless push start system ignition mode to “ON”, the information dis- remote controller is within the “interior...
Page 119 OPERATING YOUR VEHICLE Engine Switch Illumination • A period of 15 minutes has elapsed after Manual transaxle opening the driver’s door. The engine switch is illuminated (lit) in the following situations: Selection of Ignition Modes • When the engine is off and the driver’s Press the engine switch to select the door is open or for 15 seconds after the “ACC”...
Page 120 “ACC” or “ON” by pressing the engine warning. To incorporate this customiza- switch. tion, please contact a Maruti Suzuki authorised workshop. • If the battery of the remote controller is about to become completely discharged,...
Page 121 OPERATING YOUR VEHICLE (1) Immobilizer/keyless push start sys- Interior Workable Area for Engine – The remote controller is in stowage tem warning light (blinks) like the glove box or a door pocket. Starting, Ignition Mode Selection (2) Master warning indicator light (blinks) –...
Page 122: Parking Brake Lever
OPERATING YOUR VEHICLE Parking Brake Lever “P” when you are ready to drive the vehi- cle. WARNING EXAMPLE When preparing to drive the vehicle, move When parking vehicle the gearshift lever out of P position before extremely cold weather, the following releasing the parking brake.
Page 123: Pedal
OPERATING YOUR VEHICLE Parking Brake Reminder Buzzer Pedal WARNING A buzzer sounds intermittently to remind Manual Transaxle you to release the parking brake if you start Do not drive with your foot resting on the vehicle without releasing the parking EXAMPLE the clutch pedal.
Page 124: Starting The Engine (Vehicle Without Keyless Push Start System)
OPERATING YOUR VEHICLE Starting the Engine Starting a Cold and Warm Engine WARNING (Vehicle without Keyless Push With your foot taken off the accelerator Do not apply brakes continuously or pedal, crank the engine by turning the igni- Start System) rest your foot on the brake pedal.
Page 125: Starting The Engine (Vehicle Without Keyless Push Start System)
OPERATING YOUR VEHICLE Starting the Engine NOTICE EXAMPLE (Vehicle with Keyless Push Start (Continued) System) • If the engine does not respond when you try to start it with the Before Starting the Engine engine switch or if the engine switch repeats cycling through the “LOCK”...
Page 126 If you are unable to start the engine using shift it to “P”. Hold the brake pedal fully • If the engine remains stopped for while this procedure, consult a Maruti Suzuki depressed. after it was stopped unexpectedly or was authorised workshop.
Page 127 (including less push start system remote controller warning. Please contact a Maruti Suzuki the tailgate) is opened or closed, the inte- cannot be used to lock them.) authorised workshop for the customiza- rior buzzer will warn you of this condition •...
Page 128: Using The Transaxle
OPERATING YOUR VEHICLE Using the Transaxle Shifting All forward gears are synchronized, which WARNING Manual Transaxle provides for quiet, and easy shifting. • Reduce your speed and downshift Always depress the clutch pedal all the WARNING to a lower gear before going down way to the floor before shifting gears.
Page 129 OPERATING YOUR VEHICLE The 3-speed mode is suitable for the fol- EXAMPLE NOTICE lowing driving conditions: • To help avoid clutch damage, do • Driving on hilly, winding roads not use the clutch pedal as a foot- – You can drive more smoothly with less rest while driving or use the clutch frequent gear changing to keep the vehicle stationary on a...
Page 130 OPERATING YOUR VEHICLE could move and the gear could be 2 (Low 2) WARNING changed unexpectedly. Use this position to provide extra power when climbing hills, or to provide engine Use the gearshift lever positions as Always depress the brake pedal braking when going down hills.
Page 131 OPERATING YOUR VEHICLE If You Cannot Shift Automatic Tran- CAUTION NOTICE saxle Gearshift Lever Out of “P” (Continued) (PARK) • Do not shift the gearshift lever into When starting the engine, press the “R” while moving forward, or the engine switch firmly. Also, make sure EXAMPLE transaxle may be damaged.
Page 132: Gearshift Indicator (If Equipped)
OPERATING YOUR VEHICLE 4) With the release button (1) pushed, which gear position is optimal for your driv- NOTE: push the knob button (2) and shift the ing with the indication on the display. • The gearshift indicator is not indicated gearshift lever to the desired position.
Page 133: Smart Hybrid
OPERATING YOUR VEHICLE Example of the gearshift indicator Smart Hybrid Smart Hybrid has an Integrated Starter Indication Description Generator (ISG) instead of conventional generator to get a better fuel consumption. Lower gear position is selected for the vehicle speed and/or engine revolution.
Page 134 OPERATING YOUR VEHICLE While decelerating your vehicle, decelera- tion. This reduces engine loads and Starter Motor Function tion energy regenerating function will be improves fuel consumption. After the engine auto stop by the ENG A- activated when the following conditions are While the vehicle is running with the STOP system, the engine will be restarted satisfied.
Page 135: Eng A-Stop System (Engine Auto Stop Start System)
You should have the system inspected by indicator give an approximate indication of or leaving the vehicle, properly apply the a Maruti Suzuki authorised workshop. the charge of the lithium-ion battery. The parking brake and stop the engine with the number of segments that appear in the ignition switch or engine switch.
Page 136 – Automatic transaxle vehicle – If tery may die prematurely. the driver’s seat belt is unfas- • When replacing the lead-acid bat- tened, even if the brake pedal is tery, use a MARUTI SUZUKI genu- 64MM03019 pressed down, or the driver’s battery specified...
Page 137 • Do not dismount or disassemble posal in accordance with the applicable the lithium-ion battery. laws. Maruti Suzuki will not take any • Do not let the lithium-ion battery responsibility for consequences such as come in contact with water or other accidents or damages arising due to the liquids.
Page 138 OPERATING YOUR VEHICLE • During the automatic engine stop, the control mode) to keep the cabin air-con- Automatic transaxle vehicle engine may shut down, accompanied ditioned for a longer time. 1) With the brake pedal depressed, decel- by an interior buzzer or restarted, to erate the vehicle.
Page 139 OPERATING YOUR VEHICLE • During the automatic engine stop, the NOTE: engine may shut down, accompanied EXAMPLE When the engine is restarted automati- by an interior buzzer or restarted, to cally, the following conditions may be ensure safety. found as the hill hold control system is acti- For details, refer to the section, vated, but this is not a malfunction.
Page 140 OPERATING YOUR VEHICLE Points to note during the automatic Actuation conditions for ENG engine was stopped, the lead-acid bat- tery may have discharged and it may engine stop A-STOP system take some time before the standby When the following operations are per- Standby conditions mode is achieved.
Page 141 OPERATING YOUR VEHICLE Automatic engine restart conditions • The driver releases the seat belt (for EXAMPLE If one of the following operations is per- automatic transaxle vehicle) (#). formed or the vehicle enters one of the fol- • The driver’s door is opened (for auto- lowing modes during the automatic engine matic transaxle vehicle) (#).
Page 142: Cruise Control (If Equipped)
Have the pery or winding roads, or on steep EXAMPLE system inspected by a Maruti Suzuki downgrades. authorised workshop. – There may be something wrong with the ENG A-STOP system or the Smart Hybrid system.
Page 143 OPERATING YOUR VEHICLE To Set Cruising Speed To Change Speed Temporarily To Change Cruising Speed 1) Turn on the cruise control system by When the cruising speed is maintained, Using the accelerator pedal pushing the “CRUISE” switch (1). When you can temporarily accelerate or deceler- To reset at a faster cruising speed, accel- the cruise indicator light (5) comes on, ate.
Page 144: Parking Sensors
OPERATING YOUR VEHICLE Cancellation of the Cruise Control Parking Sensors • The parking sensor function can be used when the ignition switch is turned to the The “SET” indicator light will go off and the “ON” position or the engine switch is cruise control will be canceled temporarily EXAMPLE pressed to change the ignition mode to...
Page 145 • If the bumper hits a hard object, the sensors on it may not work prop- erly. If this occurs, have the sen- sors inspected by a Maruti Suzuki authorised workshop. 64MS170 (1) Rear center sensors (2 places)
Page 146 OPERATING YOUR VEHICLE Working sensors Approximate areas where obstacles can be detected The sensors that work depends on the position of the gearshift lever as follows: EXAMPLE Manual transaxle Automatic transaxle Gearshift lever position N, 1st – 5th N, D, 2 or L Center Rear sensors Corner...
Page 147 OPERATING YOUR VEHICLE Obstacle Indication by Parking Sen- WARNING WARNING (Continued) EXAMPLE – Obstacles are too close to the • Under the following conditions, the sensors. parking sensor system may not – Sensors are at an angle to a work normally because the sensors cannot detect obstacles correctly.
Page 148 OPERATING YOUR VEHICLE Upon detecting an obstacle, the parking sensor causes an interior buzzer to sound and a Set Sensors symbol representing the obstacle appears on the information display in the instrument You can select either the normal or trailer cluster.
Page 149: Rearview Camera (If Equipped)
OPERATING YOUR VEHICLE Warning and Indicator Messages Rearview Camera If there is a problem or warning regarding the parking sensor system, a message is dis- (if equipped) played on the information display in the instrument cluster and a symbol blinks. If a mes- When the gearshift lever is shifted to the sage is displayed, follow its instruction.
Page 150 OPERATING YOUR VEHICLE How to Use Rearview Camera NOTICE NOTICE 1) Turn the ignition switch to the “ON” position or press the engine switch to If you use the rearview camera for a The rearview camera is a precision change the ignition mode to “ON”. long time when the ignition switch is instrument.
Page 151 OPERATING YOUR VEHICLE Display Range of Rearview Camera NOTE: Rearview camera screen indication • Images shown on the display from the The distance viewed in the rearview cam- The rearview camera display shows the rearview camera are reversed images era may differ from the actual distance area behind the rear end of the tailgate.
Page 152: Braking
OPERATING YOUR VEHICLE Downhill Incline behind the vehicle If the rear view from the rearview cam- Braking era is not shown or there is a poor image EXAMPLE • If the rear view from the rearview camera is not shown. –...
Page 153 OPERATING YOUR VEHICLE Power-Assisted Brakes Anti-Lock Brake System (ABS) WARNING Your vehicle has power-assisted brakes. If ABS will help you avoid skidding by elec- power assistance is lost due to a stalled tronically controlling braking pressure. It • On some types of loose surfaces engine or other failures, the system is still will also help you maintain steering control (such as gravel, snow-covered...
Page 154 WARNING hard braking even on a dry paved WARNING road. Ask your Maruti Suzuki • If the ABS warning light (1) on the The ABS may not work properly if authorised workshop to inspect the...
Page 155 Have your vehicle hill. 3) The vehicle is on an upward incline. inspected by a Maruti Suzuki authorised (Continued) workshop. On models equipped with the ENG A- The hill hold control system will not acti- STOP system, the hill hold control system vate while this message is displayed.
Page 156: Driving Tips
DRIVING TIPS DRIVING TIPS Running-in ................4-1 Catalytic Converter ............. 4-1 Improving Fuel Economy ........... 4-2 Highway Driving ..............4-3 Driving on Hills ..............4-3 Driving on Slippery Roads ..........4-4 Driving on Wet Roads ............4-5 Off-road Driving ..............4-6 When Encountering a Flooded Area .........
Page 157: Running-In
DRIVING TIPS Running-in Catalytic converter EXAMPLE EXAMPLE NOTICE The future performance and reliabil- ity of the engine depends on the care and restraint exercised during its early life. It is especially important to observe the following precautions during the first 960 km of vehicle operation.
Page 158: Improving Fuel Economy
DRIVING TIPS Improving fuel economy EXAMPLE NOTICE NOTE: Fuel economy (mileage) of the vehicle may To minimize the possibility of cata- vary due to several factors i.e., driving lytic converter or other vehicle dam- habits - gear change pattern, usage of A.C, age: Air pressure in the tyres, wind speed, traf- •...
Page 159: Highway Driving
DRIVING TIPS Highway driving Driving on hills Keep the air cleaner clean When driving at highway speeds, pay EXAMPLE attention to the following: EXAMPLE • Stopping distance progressively increases with vehicle speed. Apply the brakes far enough ahead of the stopping point to allow for the extra stopping dis- tance.
Page 160: Driving On Slippery Roads
DRIVING TIPS While moving uphill/gradient from a Driving on slippery roads Tire chains stand still condition - For manual Tire chains should only be used if they are transaxle needed to increase traction or are required EXAMPLE by law. Check that the chains you use are •...
Page 161: Driving On Wet Roads
2) If your vehicle remains stuck after a few overheating or transaxle damage. minutes of rocking, we recommend you NOTICE to consult your Maruti Suzuki autho- • When driving on wet roads, avoid rised workshop or a roadside assis- driving through large amount of tance service.
Page 162: Off-Road Driving
Then, ask a Maruti Suzuki applying the brakes while driving authorised workshop to check the follow- slowly...
Page 163: Do's And Dont's For Safe Driving
DRIVING TIPS Do’s and Dont’s for safe 3) Before moving, look around your vehi- 5) When overtaking other vehicles, watch cle to confirm safety. out for oncoming vehicles and carefully driving 4) Don’t accelerate suddenly, since it is ensure safety. Exercise care in handling your vehicle.
Page 164 DRIVING TIPS Braking Night Time Driving EXAMPLE EXAMPLE EXAMPLE 64MM04010 64MM04007 1) Drive at lower speeds during the night Use foot brake in three stages than in the daytime, as the visual range 1. Warn the vehicle behind you. is restricted at night. 2.
Page 165: Margin For Safety
DRIVING TIPS Margin for safety EXAMPLE It is important to allow yourself a margin for safety during driving so that you can cope with erroneous or unexpected driving of other drivers. For that, observe the follow- ing. • Drive at a safe speed. •...
Page 166: Other Controls And Equipment
OTHER CONTROLS AND EQUIPMENT OTHER CONTROLS AND EQUIPMENT Fuel Filler Cap ..............5-1 Engine Hood ................ 5-2 Sun Visor ................5-4 Interior Light ................ 5-5 Accessory Socket ............... 5-7 Assist Grips ................. 5-8 Glove Box ................5-9 Overhead Console (if equipped) ........5-9 Cup Holder and Storage Area ..........
Page 167: Fuel Filler Cap
OTHER CONTROLS AND EQUIPMENT Fuel Filler Cap EXAMPLE EXAMPLE Close Open (2 (2) EXAMPLE 57L51093 61MM0B104 To remove the fuel filler cap: 1) Open the fuel filler lid. 64MS137 EXAMPLE 2) Remove the cap by turning it counter- clockwise. EXAMPLE CAUTION Remove the fuel filler cap slowly.
Page 168: Engine Hood
OTHER CONTROLS AND EQUIPMENT To reinstall the fuel filler cap: Engine Hood EXAMPLE 1) Turn the cap clockwise until you hear several clicks. 2) Close the fuel filler lid. WARNING Fuel is extremely flammable. Do not smoke when refueling, and make sure there are no open flames or sparks in the area.
Page 169 OTHER CONTROLS AND EQUIPMENT To close the engine hood: EXAMPLE 1) Lift the hood up slightly and remove the CAUTION prop rod from the hole. Put the prop rod To avoid injury, be sure no part of the back to the holding clip. occupant’s body such as hands or head is in the path of the hood when EXAMPLE...
Page 170: Sun Visor
OTHER CONTROLS AND EQUIPMENT Sun Visor Card holder (if equipped) NOTICE Type A EXAMPLE When you park your vehicle outdoors in direct sunlight or in hot weather, do not leave plastic cards in the holder. The heat may distort them. Vanity mirror (if equipped) EXAMPLE 67LH064...
Page 171: Interior Light
OTHER CONTROLS AND EQUIPMENT Interior Light EXAMPLE WARNING EXAMPLE • Do not use the vanity mirror while driving otherwise you could lose control of the vehicle. • When using the vanity mirror, do not move too close to a front air bag location or lean against it.
Page 172 OTHER CONTROLS AND EQUIPMENT Glove Box Light (if equipped) (1) Front (with overhead console) (5) ON (a) • The light comes on and stays on regard- Refer to “Glove Box” in this section. EXAMPLE less of whether the door is open or Footwell Lights (if equipped) (2) closed.
Page 173: Accessory Socket
OTHER CONTROLS AND EQUIPMENT start system remote controller, power remains off regardless of whether the tail- Accessory Socket door locking switch or request switch. gate is open or close. Front armrest console box (if equipped) OFF (c) NOTICE EXAMPLE The light remains off even when the door is opened.
Page 174: Assist Grips
OTHER CONTROLS AND EQUIPMENT Center console (if equipped) Assist Grips NOTICE EXAMPLE • To prevent the fuse from being blown, when using sockets at the same time, do not exceed the total combined power capacity of 12 volt/120 watt/10 ampere. •...
Page 175: Glove Box
OTHER CONTROLS AND EQUIPMENT Glove Box You can open the lid (1) by pressing the EXAMPLE raised portion on it. EXAMPLE WARNING • Do not drive with the overhead con- sole lid open, or the articles stowed inside may fall down during brak- ing, acceleration or in the event of a collision.
Page 176: Cup Holder And Storage Area
OTHER CONTROLS AND EQUIPMENT Cup Holder and Storage Area Instrument Panel Pocket (1) / Driver’s Pocket (9) EXAMPLE WARNING Do not place any objects which may fall out from the pocket when the vehicle is moving. Failure to take the precaution may result in an object interfering with the pedals and causing a loss of vehicle control or an accident.
Page 177 Always place the bottle with its cap closed lid while keeping the lever (1) up. in the bottle holder. EXAMPLE NOTE: Maruti Suzuki recommends to use maxi- mum 1 liter capacity of bottle. Front Armrest with Console Box (if equipped) (4) NOTICE...
Page 178 OTHER CONTROLS AND EQUIPMENT Front Seat Back Pocket (5) Rear Armrest with Cup Holders Luggage Compartment Pocket (8) (if equipped) (7) EXAMPLE EXAMPLE 61MM0B034 EXAMPLE To open the lid, slide the lever (1) and pull 64MS158 64MS083 the lid. (1) Cup holders This pocket is provided for holding light and soft things such as gloves, newspa- The rear armrest is stowed in the center of...
Page 179: Footrest (If Equipped)
OTHER CONTROLS AND EQUIPMENT Footrest (if equipped) Floor Mats WARNING EXAMPLE EXAMPLE Failure to take the following precau- tions may result in the driver’s side floor mat interfering with the pedals and causing a loss of vehicle control or an accident. •...
Page 180: Luggage Compartment Hooks
OTHER CONTROLS AND EQUIPMENT Luggage Compartment Hooks Luggage Compartment Cover (if equipped) NOTICE Shopping Hook To avoid damaging the luggage com- EXAMPLE EXAMPLE partment cover: • Do not push down on it or lean on • Handle it carefully when installing or removing.
Page 181: Luggage Compartment Board
OTHER CONTROLS AND EQUIPMENT Luggage Compartment Board Roof Rails or Roof Rack CAUTION Anchors (if equipped) EXAMPLE If you are not careful when handling Roof rails the luggage board, you could be injured. EXAMPLE Handle the luggage board carefully when removing or installing it. 64MS088 Your vehicle is equipped with the luggage 64MM05005...
Page 182: Frame Hooks
OTHER CONTROLS AND EQUIPMENT which is available at your Maruti Suzuki • Check periodically to make sure the roof Frame Hooks authorised workshop. If you use a roof rack is securely installed and free from It is not recommended to use the frame rack, observe the instructions and precau- damage.
Page 183 OTHER CONTROLS AND EQUIPMENT Front 1) Pick up the towing hook (1), jack handle (A) and wheel brace (B) stowed in the EXAMPLE luggage compartment. EXAMPLE EXAMPLE 64MM05008 64MM05006 3) Screw the towing hook (1) by hand. The towing hook (1) is provided on the NOTE: 64MM05007 front of the vehicle for use in emergency...
Page 184 OTHER CONTROLS AND EQUIPMENT 4) To tighten the towing hook (1), turn it clockwise by using a wheel brace (B) NOTICE until the hook (1) is securely installed. When you use the frame hook (2), To remove the towing hook (1), reverse the avoid driving that gives significant procedure used to install the towing hook.
Page 185: Heating And Air Conditioning System
OTHER CONTROLS AND EQUIPMENT Heating and Air Conditioning System Side outlet EXAMPLE There are two types of heating and air conditioning systems as follows: • Manual Heating and Air Conditioning System • Automatic Heating and Air Conditioning System (Climate Control) Air Outlet EXAMPLE 60M0014...
Page 186: Manual Heating And Air Conditioning System
OTHER CONTROLS AND EQUIPMENT Center outlet Manual Heating and Air Conditioning System EXAMPLE Description of Controls EXAMPLE 61MM0B047 Move the knob (1) vertically or horizontally to adjust the direction of airflow as desired. CAUTION Prolonged exposure to hot air from the heater or air conditioner could result in low temperature burns.
Page 187 OTHER CONTROLS AND EQUIPMENT Temperature selector (1) VENTILATION (a) HEAT (c) This is used to select the temperature by turning the selector. Blower speed selector (2) This is used to turn on the blower and to select blower speed by turning the selec- tor.
Page 188 OTHER CONTROLS AND EQUIPMENT DEFROST (e) RECIRCULATED AIR (g) The mark of “USE WITH” (6) To clear fog on the windshield and/or the side windows When this mode is selected, the indicator quickly, set the air flow selector (3) to light will come on, outside air is shut out HEAT &...
Page 189 OTHER CONTROLS AND EQUIPMENT System Operating Instructions Head cooled/Feet warmed heating Therefore, should occasionally Select the BI-LEVEL and FRESH AIR, the select the FRESH AIR. Natural ventilation • If your vehicle has been left in the sun temperature selector to the desired tem- Select the VENTILATION and FRESH AIR, with the windows closed, it will cool perature position, and the blower speed...
Page 190 OTHER CONTROLS AND EQUIPMENT During operation of ENG A-STOP sys- NOTE: EXAMPLE Your vehicle uses the air conditioning • If the air conditioning performance can refrigerant HFC-134a, commonly called no longer perform at a sufficient level “R-134a”. R-134a replaced R-12 around automatically stopping 1993 for automotive applications.
Page 191: Automatic Heating And Air Conditioning System (Climate Control)
OTHER CONTROLS AND EQUIPMENT Automatic Heating and Air Conditioning System Temperature selector (1) EXAMPLE (Climate Control) Description of Controls EXAMPLE 64MS051 Turn the temperature selector (1) to adjust the temperature. The display (9) shows the selected temperature. NOTE: If you turn the temperature selector (1) until “HI”...
Page 192 OTHER CONTROLS AND EQUIPMENT Blower speed selector (2) Push the air intake selector (3) to change Air flow selector (“MODE”) switch (4) between the following modes. EXAMPLE EXAMPLE If the “AUTO” switch (8) is pushed, the air intake will vary automatically as the climate control system maintains the selected tem- perature.
Page 193 OTHER CONTROLS AND EQUIPMENT VENTILATION (c) HEAT (e) Defrost switch (5) EXAMPLE EXAMPLE 61M0100 61M0102 Temperature-controlled air comes out of Temperature-controlled air comes out of the center and side outlets. the floor outlets, also comes out of the EXAMPLE windshield defroster outlets and also BI-LEVEL (d) comes slightly out of the side defroster out- 64MS038...
Page 194 System Operating Instructions selected and the air conditioning switch will conditioning system. You should have the automatically turn on (“A/C” will appear on system inspected by a Maruti Suzuki Automatic operation the display). In cold weather, air flows out authorised workshop.
Page 195 Set the selectors to the If your air conditioner is equipped with air desired positions. filters, clean or replace them as specified in the “Maintenance Schedule” in the “INSPECTION AND MAINTENANCE” sec- tion. Have this job done by a Maruti Suzuki 5-29 64MS0-74E...
Page 196: Radio Antenna
Frequency Transmitters EXAMPLE NOTE: We recommend that you always ask a Your vehicle uses the air conditioning Maruti Suzuki authorised workshop about refrigerant HFC-134a, commonly called frequency band, output power, “R-134a”. R-134a replaced R-12 around antenna position at vehicle and specific 1993 for automotive applications.
Page 197: Audio System (If Equipped)
OTHER CONTROLS AND EQUIPMENT Audio System (if equipped) EXAMPLE 64MS186 AM/FM CD PLAYER NOTE: For vehicle equipped with SMARTPLAY INFOTAINMENT SYSTEM, refer to the audio manual available with the vehicle. Remote controller is not provided with the vehicles equipped with SMARTPLAY INFOTAINMENT SYSYTEM. 5-31 64MS0-74E...
Page 198 Please bring the unit to a Maruti Suzuki sets. authorised workshop. • Set the sound volume to a level...
Page 199 OTHER CONTROLS AND EQUIPMENT remove the roughness (C) from the edges of the disc before inserting it into the unit. EXAMPLE EXAMPLE EXAMPLE To remove fingermarks and dust, use a soft cloth, and wipe in a straight line from Do not use compact discs that have large the center of the compact disc to the cir- scratches, are misshaped, or cracked, etc.
Page 200 OTHER CONTROLS AND EQUIPMENT ® NOTE: (If equipped) • Do not use commercially available CD ® The Bluetooth word mark and logo are protection sheets or discs equipped with registered trademarks and are owned by stabilizers, etc. the Bluetooth SIG, Ink. These may get caught in the internal ®...
Page 201 OTHER CONTROLS AND EQUIPMENT Basic Operations Turning power on/off Press the VOL PUSH POWER knob (1). EXAMPLE The unit starts in the function mode it was in when the power was turned off last. Adjusting the volume Turn the VOL PUSH POWER knob (1). Turning it clockwise increases the volume;...
Page 202 OTHER CONTROLS AND EQUIPMENT Mute Adjusting the AVC (Auto volume con- Press the MUTE button (3) to mute the trol) sound. To cancel the mute, press the The Auto Volume Control (AVC) function OFF (FLAT) MUTE button (3) again. automatically adjusts (increases/ decreases) the sound volume in accor-...
Page 203 OTHER CONTROLS AND EQUIPMENT Listening to the Radio Display EXAMPLE (1) FM button (2) AM button (3) Up button (4) Down button (5) TUNE FOLDER PUSH SOUND knob (6) Preset buttons ([1] to [6]) (7) AST button (A) Band (B) Frequency (4) (3) 64MS188 5-37...
Page 204 OTHER CONTROLS AND EQUIPMENT Selecting the FM band Auto store Radio Reception Press the FM button (1). Hold down the AST button (7) for 2 sec- Radio reception can be affected by envi- Each time the button is pressed, the recep- onds or longer.
Page 205 OTHER CONTROLS AND EQUIPMENT Listening to a CD Display EXAMPLE (1) Insertion slot (2) Eject button (3) CD button (4) Up button (5) Down button (6) RPT button (7) RDM button (8) DISP button (A) Track number (B) Play time NOTE: This product does not support 8 cm CD (sometimes called as “mini single CD”, “3-...
Page 206 OTHER CONTROLS AND EQUIPMENT 15 seconds or longer will automatically be EXAMPLE NOTICE drawn inside the unit. (Auto reload func- tion) • Never insert your finger or hand The backup eject function: into the CD insertion slot. Never This function allows you to eject a CD by insert foreign objects.
Page 207 OTHER CONTROLS AND EQUIPMENT Fast forwarding/Rewinding a track Repeat playback NOTE: • Hold down the Up button (4) to fast for- Press the RPT button (6). • “NO TITLE” will be displayed when there ward the track. Each time the button is pressed, the mode is no text information in the disc currently •...
Page 208 OTHER CONTROLS AND EQUIPMENT Listening to an MP3/WMA/AAC Disc Display EXAMPLE (1) TUNE FOLDER PUSH SOUND knob (2) Up button (3) Down button (4) RPT button (5) RDM button (6) DISP button (A) Folder number (B) Track number (C) Play time (D) DISC type (3) (2) 64MS190...
Page 209 OTHER CONTROLS AND EQUIPMENT Selecting a folder Repeat playback NOTE: Turn the TUNE FOLDER PUSH SOUND Press the RPT button (4). • “NO TITLE” will be displayed when there knob (1) to select a folder. Each time the button is pressed, the mode is no text information in the disc currently will change as follows: being played.
Page 210 OTHER CONTROLS AND EQUIPMENT What is AAC? Recording MP3/WMA/AAC files on a CD Compression formats • An abbreviation of “Advanced Audio media Coding,” AAC is an audio compression • It is recommended not to write both CD- • Bit rate: MPEG1 Audio Layer III: 32 k - 320 kbps format used by MPEG2 and MPEG4.
Page 211 OTHER CONTROLS AND EQUIPMENT Listening to files stored in a USB device (if equipped) Display EXAMPLE (1) USB button (2) TUNE FOLDER PUSH SOUND knob (3) Up button (4) Down button (5) RPT button (6) RDM button (7) DISP button (A) Folder number (B) Track number (C) Play time...
Page 212 OTHER CONTROLS AND EQUIPMENT Selecting a USB device mode • ALL RANDOM Display change Press the USB button (1). The random indicator “RDM” will light. Press the DISP button (7). The tracks in the connected USB device Each time the button is pressed, display Selecting a folder will be played in random order.
Page 213 OTHER CONTROLS AND EQUIPMENT Notes on USB device Recording MP3/WMA/AAC files on a Maximum number of files/folders USB device • Maximum number of files: 2500 Compatible USB devices • Playback or display may not be possible (files + folders) • USB Mass Storage Class depending on the type of USB device in •...
Page 214 OTHER CONTROLS AND EQUIPMENT ® Listening to an iPod (if equipped) Display EXAMPLE (1) USB button (2) TUNE FOLDER PUSH SOUND knob (3) Up button (4) Down button (5) RPT button (6) RDM button (7) DISP button (8) Preset buttons ([1] to [6]) (A) Track title (B) Track number (C) Play time...
Page 215 OTHER CONTROLS AND EQUIPMENT ® Selecting an iPod mode Repeat playback NOTE: Press the USB button (1). Press the RPT button (5). If text data contains more than 12 charac- Each time the button is pressed, the mode ters, the “>” mark will appear at the right Selecting a track will change as follows: end.
Page 216 OTHER CONTROLS AND EQUIPMENT ® ® Notes on iPod iPod connection ® ® • Make sure to detach the iPod after Supported iPod ® pressing the engine switch to change the • iPod touch (5th generation) ® ignition mode to “LOCK” (OFF) or the •...
Page 217 OTHER CONTROLS AND EQUIPMENT AUX Function AUX connection To listen to auxiliary audio sources (sold EXAMPLE separately) through the unit, follow the instruction below. 1) Connect the auxiliary audio source to AUX/USB socket (separately attached) with an AUX cable. 2) Press the CD button (1). Each time the button is pressed, the mode will change as follows: ®...
Page 218 OTHER CONTROLS AND EQUIPMENT ® NOTE: Bluetooth Hands-Free (if equipped) • Please consult your place of purchase EXAMPLE for details about whether a given auxil- iary audio source can be connected and the proper auxiliary cord to use. • The volume and tone controls of the auxiliary audio source can be adjusted on the unit.
Page 219 OTHER CONTROLS AND EQUIPMENT Steering switch Phone registration 4) Select “CAR AUDIO” from the Blue- ® tooth menu of the phone and establish EXAMPLE the pairing. To use the hands-free function with this Refer to the manual of the phone in use unit, it is required to register the phone for further information.
Page 220 OTHER CONTROLS AND EQUIPMENT Receiving a call Adjusting the call or ringtone volume Selecting the Ringtone Press the Off Hook button (5) to receive a Follow the instructions below to adjust the Follow the instructions below to select a call. call or ringtone volume.
Page 221 OTHER CONTROLS AND EQUIPMENT Dialing using Missed/Incoming/ • Pressing “Confirm” after selecting NOTE: Outgoing Calls “Delete” can delete the selected number When selecting “Go Back”, the previous Follow the instructions below to dial to the from the call history. menu will be displayed. last dialed number again.
Page 222 OTHER CONTROLS AND EQUIPMENT 7) Transfer contacts from the phone. Making a call by Phonebook Deletion of registered data (Delete When the registration is completed, the Follow the instructions below to dial a num- Entry) “Setup Phonebook” will be displayed. ber registered in Phonebook.
Page 223 OTHER CONTROLS AND EQUIPMENT Registration in speed dial When the assignment is completed, the Deletion of speed dial (Del Speed Dial) Follow the instructions below to assign a “Setup Phonebook” will be displayed. To delete a number assigned for the speed number to one of the Preset buttons to use dial, follow the instructions below.
Page 224 OTHER CONTROLS AND EQUIPMENT Display of device data (Device Name) Reset to the factory defaults List of phones (List Phones) Follow the instructions below to display the Follow the instructions below to reset all Follow the instructions below to display the ®...
Page 225 OTHER CONTROLS AND EQUIPMENT Re-connecting already registered phone Passkey setting (Set Passkey) NOTE: (Select Phone) Follow the instructions below to set the When selecting “Go Back”, the previous Follow the instructions below to select a security number (Passkey). menu will be displayed. ®...
Page 226 OTHER CONTROLS AND EQUIPMENT ® NOTE: Bluetooth audio (if equipped) When selecting “Go Back”, the previous menu will be displayed. EXAMPLE BT function on/off (BT Power) Follow the instructions below to turn on/off ® the Bluetooth function. ® 1) Press the Bluetooth setup button (4).
Page 227 OTHER CONTROLS AND EQUIPMENT Steering switch Registration of audio devices Refer to the manual of the audio player in use for further information. EXAMPLE 5) Enter the Passkey displayed on the unit ® To use Bluetooth ready audio devices to the audio player. with this unit, it is required to register the devices.
Page 228 OTHER CONTROLS AND EQUIPMENT ® Fast forwarding/Rewinding a track Disclaimer for Bluetooth function Remote Audio Controls • Hold down the Up button (3) to fast for- • Depending on the mobile phone models, (if equipped) ward the track. some phones may not be compatible Controlling of basic functions of the audio •...
Page 229 OTHER CONTROLS AND EQUIPMENT Selecting the radio station (FM1, FM2, AM mode) FM1 (Radio) • To select the next preset station, press “ ” of the switch (4) only for a moment. FM2 (Radio) • To select the previous preset station, press “...
Page 230 OTHER CONTROLS AND EQUIPMENT Anti-Theft Feature The anti-theft function is intended to dis- courage thefts, such as that the audio sys- tem becomes inoperable when it is EXAMPLE installed on other vehicles. This function works by entering a Personal Identification Number (PIN). When the unit is disconnected from its power source, such as when the audio system is removed or the battery is discon-...
Page 231 OTHER CONTROLS AND EQUIPMENT Canceling the anti-theft feature Confirming the Personal Identification To cancel the anti-theft function, delete the Number (PIN) registered PIN. When the main power source is discon- 1) Press the VOL PUSH POWER knob (1) nected such as when the battery is to power off.
Page 232 OTHER CONTROLS AND EQUIPMENT Battery Installation WARNING Install a lithium battery (CR2025) with the poles facing the correct direction. • Do not expose the battery to flame. EXAMPLE Do not short circuit, disassemble, or heat the battery. • Do not charge the battery. •...
Page 233 OTHER CONTROLS AND EQUIPMENT • When the vehicle is parked in an area exposed to direct sunlight, Ensure the remote controller is placed in an area not exposed to direct sunlight. For example: Glove box. Under direct sunlight, signal reception from the remote controller weakens.
Page 234 OTHER CONTROLS AND EQUIPMENT Remote Controller (if equipped) Common operations POWER button Power ON / OFF VOLUME button Press to adjust volume. (including at AUX mode) TUNE FOLDER UP/DOWN button In Sound Mode Press to adjust the sound.(bass/treble/balance/fader) In Preset-EQ Mode The Preset-EQ setting switches as follows: MUTE button OFF (FLAT)
Page 235 OTHER CONTROLS AND EQUIPMENT Radio operations AS button Press to return to the last received frequency in the previous auto store mode. Press it for 2 seconds or longer. It selects the stations with the stronger signals and stores them in order. VOL - TUNE VOL +...
Page 236 OTHER CONTROLS AND EQUIPMENT CD operations SEEK TRACK UP/DOWN button Press to skip to the next/previous track. Press it for 1 second or longer to fast-forward/fast- RDM (5) button rewind the track. Press to play the current track randomly. Press it again to cancel. VOL - TUNE VOL +...
Page 237 OTHER CONTROLS AND EQUIPMENT MP3/WMA/AAC Disc operations SEEK TRACK UP/DOWN button Press to skip to the next/previous track. Press it for 1 second or longer to fast-forward /fast-rewind the track. TUNE FOLDER UP/DOWN button Press to skip to the next/previous folder. DISP (6) button The display switches as follows: RPT (4) button...
Page 238 OTHER CONTROLS AND EQUIPMENT USB operations SEEK TRACK UP/DOWN button Press to skip to the next/previous file. Press it for 1 second or longer to fast-forward/fast rewind the file. TUNE FOLDER UP/DOWN button Press to skip to the next/previous folder. DISP (6) button The display switches as follows: RPT (4) button...
Page 239 OTHER CONTROLS AND EQUIPMENT ® iPod operations SEEK TRACK UP/DOWN button ENT button Press to skip to the next/previous file. Press it for 1 second or longer to fast-forward/fast- ® While displaying iPod menu, press to select the rewind the file. desired item and display the list.
Page 240 OTHER CONTROLS AND EQUIPMENT Troubleshooting When encountered a problem, check and follow the instructions as described below. If the described suggestions do not solve the problem, it is recommended to take the unit to your Maruti Suzuki authorised workshop. Problem Possible cause...
Page 241 OTHER CONTROLS AND EQUIPMENT Problem Possible cause Possible solution MP3/WMA/AAC The disc contains unsupported formatted No playback Check the file format. data. Sound skipping may occur when playing Sound skips or noise produced It is not recommended to play VBR files. VBR (Variable Bit Rate) files.
Page 242 ERROR 1 The disc cannot be read. When ERROR 1 does not disappear even when a nor- mal disc is inserted, contact your Maruti Suzuki autho- rised workshop. When the CD is in the unit, press the CD eject button to The player developed an error of an remove the disc.
Page 243 OTHER CONTROLS AND EQUIPMENT Display Possible cause Possible solution ® Bluetooth ® Disconnect the Bluetooth ready device and connect it The player developed an error of an again. ERROR 1 unidentified cause. When ERROR 1 does not disappear, contact your Maruti Suzuki authorised workshop.
Page 244: Vehicle Loading And Towing
VEHICLE LOADING AND TOWING VEHICLE LOADING AND TOWING Vehicle Loading ..............6-1 Trailer Towing ..............6-1 54G215 64MS0-74E...
Page 245 VEHICLE LOADING AND TOWING Vehicle Loading Trailer Towing WARNING Your vehicle was designed for specific EXAMPLE weight capacities. The weight capacities of Never overload your vehicle. The your vehicle are indicated by the Gross gross vehicle weight (sum of the Vehicle Weight Rating (GVWR) and the weights of the vehicle, all the occu- Permissible maximum Axle Weight (PAW,...
Page 246: Inspection And Maintenance
INSPECTION AND MAINTENANCE INSPECTION AND MAINTENANCE Maintenance Schedule ............7-2 Periodic Maintenance Schedule ........7-2 Drive Belt ................7-6 Engine Oil and Filter ............7-6 Engine Coolant ..............7-10 Air Cleaner ................7-11 Spark Plugs ................. 7-11 Gear Oil ................7-13 Clutch Pedal ................
Page 247 INSPECTION AND MAINTENANCE EXAMPLE WARNING WARNING (Continued) (Continued) • To prevent damage or unintended • Do not touch ignition wires or other ignition system parts when start- activation of the air bag system be ing the engine or when the engine sure the lead-acid battery is dis- is running, or you could receive an connected and the ignition switch...
Page 248: Maintenance Schedule
MARUTI SUZUKI recommends that NOTE: maintenance on your vehicle should This table includes services as scheduled be performed by a Maruti Suzuki up to 80,000 km mileage. Beyond 80,000 authorised workshop. km, carry out the same services at the same intervals respectively.
Page 249 INSPECTION AND MAINTENANCE FREE INSPECTION PERIODIC MAINTENANCE AT COST Interval: This interval should be judged by odometer reading or months, whichever comes first. km (x1000) months ENGINE 1-1. ISG Belt – – 1-2. Engine Coolant (Level, Leakage) 1-3. Engine oil, engine oil filter and drain plug gasket (Level, Leakage) 1-4.
Page 250 INSPECTION AND MAINTENANCE FREE INSPECTION PERIODIC MAINTENANCE AT COST Interval: This interval should be judged by odometer reading or months, whichever comes first. km (x1000) months BRAKE 6-1. Brake fluid (Level, Leakage) 6-2. Brake pedal (Pedal - floor carpet clearance) 6-3.
Page 251 INSPECTION AND MAINTENANCE FREE INSPECTION PERIODIC MAINTENANCE AT COST Interval: This interval should be judged by odometer reading or months, whichever comes first. km (x1000) months BODY 11-1. All chassis bolts and nuts (Tighten) 11-2. All latches, hinges and locks (Function) I&L I&L I&L...
Page 252: Drive Belt
Check that the engine oil you use comes If you need to replace or adjust the belt under the quality classification of SN. have it done by a Maruti Suzuki authorised Select the appropriate oil viscosity accord- workshop. ing to the above chart.
Page 253 INSPECTION AND MAINTENANCE the vehicle on a level surface. The oil level Refilling Changing Engine Oil and Filter indication may be inaccurate if the vehicle Drain the engine oil while the engine is still is on a slope. The oil level should be EXAMPLE warm.
Page 254 INSPECTION AND MAINTENANCE Oil Filter Replacement WARNING EXAMPLE 1) Using an oil filter wrench, turn the oil fil- (Continued) ter counterclockwise and remove it. • Recycle or properly dispose of 2) Using a clean rag, wipe off the mount- used oil and oil filters. ing surface on the engine where the new filter will be seated.
Page 255 Run the engine at various speeds for at cle inspected by a Maruti Suzuki (1) Oil filter least 5 minutes. authorised workshop.
Page 256: Engine Coolant
INSPECTION AND MAINTENANCE Engine Coolant NOTICE WARNING Selection of Coolant (Continued) (Continued) To maintain optimum performance and • Do not use straight coolant nor • Avoid inhaling coolant mist or hot plain water. durability of your engine, use MARUTI vapors. If inhaled, remove to a •...
Page 257: Air Cleaner
Coolant Replacement wires, couplers, sealing rubber of air Since special procedures are required, we cleaner assembly and washers, are cor- recommend you take your vehicle to your rectly returned in place. Maruti Suzuki authorised workshop for coolant replacement. 7-11 64MS0-74E...
Page 258 INSPECTION AND MAINTENANCE EXAMPLE EXAMPLE EXAMPLE Loosen 0.95 – 1.05mm Wrong (0.037 – 0.041 in.) Tighten Correct 64MM07034 64MM07036 64MM07035 NOTICE NOTICE NOTICE • When installing the spark plugs, • When replacing spark plugs, you • When pulling out the ignition coils, screw them in with your fingers to should only use the brand and type do not pull on the cable.
Page 259: Gear Oil
4) If the oil level is low, add gear oil Since special procedures, materials and through the oil filler and level plug hole tools are required, ask a Maruti Suzuki (1) until the oil level reaches the bottom authorised workshop for this job.
Page 260: Clutch Pedal
(2) Fuel inlet hose engine coolant temperature light (blue Maruti Suzuki authorised workshop. If the (3) Fuel outlet hose color) goes off. clutch fluid level is near the “MIN” line, fill it Replace the fuel filter 2) Then drive for ten more minutes.
Page 261 Then move it tools are required to change the automatic should be between the two marks in hot back to “P” (Park) position. transaxle oil, ask a Maruti Suzuki autho- range on the dipstick. rised workshop for this job. 7-15...
Page 262: Brakes
Solution can be poisonous Should the light come on, immedi- to animals. Keep out of the reach of ately ask your Maruti Suzuki autho- children and animals. rised workshop to inspect the brake system. NOTE: •...
Page 263 • Excessive pedal travel released, have the parking brake inspected If the pedal to floor carpet distance as • Brake dragging and/or adjusted by a Maruti Suzuki autho- measured above is less than the minimum • Excessive noise rised workshop.
Page 264: Steering
If the amount of free play is not as specified or you find anything else to be wrong, an 52KM110 inspection must be performed by your (1) Tread wear indicator Maruti Suzuki authorised workshop. (2) Indicator location mark 7-18 64MS0-74E...
Page 265 1.6 mm (0.06 in.). WARNING 5-tire rotation To help you check this, the tires have • Your MARUTI SUZUKI vehicle is molded-in tread wear indicators in the EXAMPLE equipped with tires which are all grooves. When the indicators appear the same type and size.
Page 266: Lead-Acid Battery
Maruti Suzuki authorised Workshop. or rim bent. Damaged wheel must not Never smoke when working in the Tubeless Tires (If equipped) be used.
Page 267 INSPECTION AND MAINTENANCE Replacement of the lead-acid battery EXAMPLE WARNING EXAMPLE If the lead-acid battery is used with lead-acid battery level being less than the lower level line (2), it may cause reduced lead-acid battery life, an exothermic heat, or an explosion by hydrogen gas occurring from the lead-acid battery.
Page 268: Fuses
INSPECTION AND MAINTENANCE NOTE: Fuses • When the lead-acid battery is discon- NOTICE Your vehicle has three types of fuses, as nected, some of the vehicle’s functions described below: Do not use regular battery in ISG will be initialized and/or deactivated. vehicle.
Page 269 INSPECTION AND MAINTENANCE NOTE: Main fuse box 80 A • “Blank” indicates that fuse is not applica- ble in the variant, even though name of 100 A fuse might be available on cover of fuse- 200 A box of your vehicle. •...
Page 270 If the main fuse or a primary fuse (34) 10 A MTR2 (meter 2) blows, have your vehicle inspected by a Maruti Suzuki authorised work- (35) 30 A SUB BAT (sub battery) shop. Always use a Maruti genuine part. Never use a substitute such as a...
Page 271 INSPECTION AND MAINTENANCE Type A (Keyless push start model) (31) 10 A TAIL (tail lamp) (11) 10 A (hazard warning light) (32) 20 A D/L (door lock) (12) 7.5 A (33) 7.5 A CRUISE (cruise control) (13) 15 A IG COIL (ignition coil) (34) 10 A MTR (meter)
Page 272 INSPECTION AND MAINTENANCE Type B (Ignition switch model) INDIVIDUAL FUSE WARNING 15 A IG COIL (ignition coil) Always be sure to replace a blown fuse with a fuse of the correct amper- 7.5 A ST SIG (starting signal) (15) age. Never use a substitute such as (21) (16) 15 A...
Page 273: Headlight Aiming
The oils from your skin may cause a there is water leakage inside the lamp, halogen bulb to overheat and burst contact a Maruti Suzuki authorised work- when the lights are on. Grasp a new shop. bulb with a clean cloth.
Page 274 INSPECTION AND MAINTENANCE (1) Headlight (Low beam) bulb (5). Install a new bulb in the (2) Headlight (High beam) reverse order of removal. EXAMPLE EXAMPLE EXAMPLE 76MH0A007 2) Turn the bulb holder (2) clockwise and 64MM07021 pull it out from the light housing. NOTE: 61MM0B074 You can see the position of retaining spring...
Page 275 (2), simply pull out or push in the bulb. For DRL replacement, we recommend you to take your vehicle to the authorised Maruti Suzuki workshop as special proce- dure for the same is required. 61MM0B077 1) Open the engine hood. To remove the...
Page 276 INSPECTION AND MAINTENANCE Front Fog Light (if equipped) 3) Remove the clips (2) by prying it off with Rear Combination Light a flat blade screwdriver as shown in the 1) Start the engine. Turn the steering wheel to rotate the tires to the opposite illustration.
Page 277 Since special procedure are required for replacement of LED tail / brake light bulb, we recommend you take your vehicle to a (3) / (4) Maruti Suzuki authorised workshop. 61MM0B084 61MM0B089 (5) Removal (6) Install...
Page 278 INSPECTION AND MAINTENANCE 2) Disconnect the coupler (3) by pushing License Plate Light High-mount Stop Light the lock release. Turn the bulb holder of EXAMPLE the reversing light (4) counterclockwise EXAMPLE and remove it. EXAMPLE 61MM0B086 1) Turn the cover (1) counterclockwise to remove it.
Page 279 INSPECTION AND MAINTENANCE Interior Light Center EXAMPLE Remove the lens by using a flat blade EXAMPLE screwdriver covered with a soft cloth as shown. To install it, simply push it back in. Front (without overhead console) EXAMPLE 68KS063 3) Remove the bulb holder as shown in the illustration.
Page 280: Wiper Blades
2) Push the damper (1) (if equipped) right- Wiper Blades ward to remove the grove box. Since special procedures are required, we recommend you take your vehicle to a EXAMPLE Maruti Suzuki authorised workshop for EXAMPLE bulb replacement. EXAMPLE 64MM07019 64MS096...
Page 281 INSPECTION AND MAINTENANCE For windshield wipers: Removal EXAMPLE EXAMPLE EXAMPLE 68PH00751 64MM07020 Installation 1) Hold the wiper arm away from the wind- shield. EXAMPLE NOTE: When raising both of the front wiper arms, pull the driver’s side wiper arm up first. When returning the wiper arms, lower the passenger’s side wiper arm first.
Page 282 INSPECTION AND MAINTENANCE NOTE: For rear wipers: EXAMPLE When you install the metal retainers (4), EXAMPLE make sure the direction of metal retainers as shown in the above illustrations. 5) Install the new blade in the reverse order of removal, with the locked end positioned toward the wiper arm.
Page 283: Windshield Washer Fluid
INSPECTION AND MAINTENANCE 4) If the new blade is provided without the Windshield Washer Fluid two metal retainers, move them from the old blade to the new one. EXAMPLE 5) Install the new blade in the reverse order of removal. Make sure the blade is properly retained by all the hooks.
Page 284: Air Conditioning System
INSPECTION AND MAINTENANCE Air Conditioning System Replacement of the Air Conditioner Filter (if equipped) If you do not use the air conditioner for a long period, such as during winter, it may 1) To access the air conditioner filter, not give the best performance when you remove the glove box.
Page 285 64MS0-74E...
Page 286: Emergency Service
EMERGENCY SERVICE EMERGENCY SERVICE Tire Changing Tool ............. 8-1 Jacking Instructions ............8-2 Changing Wheels ..............8-4 Jump Starting Instructions ..........8-6 Towing .................. 8-7 Engine trouble: Starter does not operate ......8-8 Engine trouble: Flooded engine ........8-8 Engine trouble: Overheating ..........8-8 Warning Triangle..............
Page 287: Tire Changing Tool
EMERGENCY SERVICE Tire Changing Tool EXAMPLE EXAMPLE 64MM08002 To remove the jack, hold the tire changing tool storage with one hand while pulling (3) (4) the jack from the centre as shown in the above illustration. WARNING After using the tire changing tools, be sure to stow them securely or they can cause injury if an accident occurs.
Page 288: Jacking Instructions
EMERGENCY SERVICE Jacking Instructions 3) Turn on the hazard warning flasher if EXAMPLE your vehicle is near traffic. 4) Block the front and rear of the wheel EXAMPLE diagonally opposite of the wheel being lifted. 5) Place the spare wheel near the wheel being lifted as shown in the illustration in case the jack slips.
Page 289 EMERGENCY SERVICE To Raise the Vehicle with a Garage EXAMPLE WARNING Jack • Apply the garage jack to one of the points • Use the jack only to change wheels indicated below. on level, hard ground. • Always support the raised vehicle with •...
Page 290: Changing Wheels
For any fur- For more details, please contact a Maruti ther assistance contact your nearest Suzuki authorised workshop. Maruti Suzuki authorised workshop. To change a wheel, use the following pro- cedure: 1) Remove the jack, tools and spare 64MS140 wheel from the vehicle.
Page 291 If you do not have a torque wrench, have the wheel nut torque checked by a Maruti Suzuki autho- rised workshop. EXAMPLE 81A057 65J4033...
Page 292: Jump Starting Instructions
EMERGENCY SERVICE Jump starting instructions Return the spare tire back into the luggage compartment in the reverse order of NOTICE removal and tighten its bolt (5) clockwise WARNING Your vehicle should not be started by as shown in the above illustration. pushing or towing.
Page 293: Towing
EMERGENCY SERVICE 3) Make jump lead connections as follows: 6) Remove the jump leads in the exact reverse order in which you connected NOTICE 1. Connect one end of the first jump them. lead to the positive (+) terminal of the Towing your vehicle with the front discharged lead-acid battery (1).
Page 294: Engine Trouble: Starter Does Not Operate
Have the vehi- mal in the engine starting system, the stop the vehicle in a safe place and cle inspected by a Maruti Suzuki autho- starter motor runs only while the engine immediately turn off the engine to let rised workshop.
Page 295: Warning Triangle
• To help prevent personal injury, If your engine overheats and you are MHO-07-001 keep hands, tools and clothing unsure what to do, contact a Maruti Suzuki away from the engine cooling fan In case of vehicle break-down or during authorised workshop.
Page 296 EMERGENCY SERVICE • Remove the warning triangle carefully from the cover as shown by arrow 1. • Open both the reflector arms as shown by arrow and lock the arms with each other with the clip provided in the right arm.
Page 297 64MS0-74E...
Page 298: Appearance Care
APPEARANCE CARE APPEARANCE CARE Corrosion prevention ............9-1 Vehicle cleaning ..............9-2 64MM09000 56RH0-74E...
Page 299 APPEARANCE CARE Corrosion prevention mote corrosion even though other body your vehicle if it is left on painted surfaces. sections may be completely dry. Remove these types of deposits as quickly It is important to take good care of your 4) High temperatures will cause an accel- as possible.
Page 300 APPEARANCE CARE Park your vehicle in a dry, well-venti- Vehicle cleaning Cleaning interior lated area Vinyl upholstery Park your vehicle to save it from continu- EXAMPLE Prepare a solution of soap or mild deter- ous exposure to direct sunlight. gent dissolved in warm water. Apply the Do not park your vehicle in a damp, poorly- solution to the vinyl with a sponge or soft ventilated area.
Page 301 APPEARANCE CARE NOTE: Seat belts CAUTION • In order to keep leather upholstery look- Clean seat belts with a mild soap and ing good, it should be cleaned at least water. Do not use bleach or dye on the • Do not spill liquid or semi-solid on twice a year.
Page 302 APPEARANCE CARE • Do not use a bristle brush and soap con- NOTICE NOTICE taining an abrasive material. These will damage finished surfaces. Do not use chemical products that • Liquid such as liquid aromatics, Washing contain silicon to wipe electrical soft drinks or juice may cause dis- components such as the air condi- coloration, wrinkles, and cracking...
Page 303 APPEARANCE CARE When washing the vehicle, park it in the hard materials which can scratch the 1. Clean all damaged spots and allow place where direct sunlight does not fall on paint or plastic. Remember that the them to dry. it and follow the instructions below: headlight covers or lenses are made of 2.
Page 304 APPEARANCE CARE Waxing EXAMPLE 64MM09002 After washing the vehicle, waxing and pol- ishing are recommended to further protect and beautify the paint. • Only use waxes and polishes of good quality. • When using waxes polishes, observe the precautions specified by the manufacturers.
Page 305 56RH0-74E...
Page 306: General Information
GENERAL INFORMATION GENERAL INFORMATION Vehicle Identification ............10-1 FASTag (if equipped) ............10-1 High Security Registration Plate (HSRP) ......10-3 84MM01001 64MS0-74E...
Page 307 Chassis Serial Number information. Whenever you have occasion As per Ministry of Road Transport and to consult your Maruti Suzuki authorised Highways, the FASTag (1) is mandatory for EXAMPLE workshop, remember to identify your vehi- each vehicle for the purpose of electronic cle with this number.
Page 308 GENERAL INFORMATION As seen from inside of the vehicle As seen from outside of the vehicle EXAMPLE EXAMPLE Easy to Cruise Please do not peel off the tag, as it Please do not peel off the tag, as it would permanently damage the tag would permanently damage the tag xxxx xxxx xxxx xxxx xxxx xxxx 64MM01002...
Page 309 GENERAL INFORMATION High Security Registration Third license plate - As seen from out- • In the event of any replacement of the side of the vehicle third license plate, may please contact Plate (HSRP) the approved authority. EXAMPLE As per Ministry of Road Transport and Third license plate - As seen from Highways, every new vehicle must have inside of the vehicle...
Page 310: Specifications
SPECIFICATIONS SPECIFICATIONS NOTE: Specifications are subject to change without notice. MT: Manual Transaxle AT: Automatic Transaxle ITEM: Dimensions UNIT: mm Overall length 4300 Overall width 1785 Overall height 1595 Wheelbase 2600 Front 1535 Track Rear 1505 ITEM: Mass (weight) UNIT: kg 1130 ~ 1160 Curb mass (weight) 1160 ~ 1170...
Page 311 *1 When battery replacement is necessary, use only N55 (Exide Conservo) battery. Else it may deteriorate performance of Smart Hybrid system. *2 If the lithium-ion battery is completely discharged, the battery cannot be recharged. When replacing or disposing the lithium-ion battery, consult your Maruti Suzuki authorised workshop. 11-2 64MS0-74E...
Page 312 SPECIFICATIONS ITEM: Lights WATTAGE BULB No. High beam 12V 55W Halogen Headlight Low beam 12V 55W – Front fog light (if equipped) 12V 19W Position light (vehicle with halogen headlights) 12V 5W Position light & Daytime running light (vehicle with LED headlights) –...
Page 313 SPECIFICATIONS ITEM: Wheels and Tires Tire size, front and rear 215/60R16 95V *2 *3 For vehicle equipped with 215/60R16 95 V tire 215/60R16 95V (Steel wheel) Tire size, spare Rim size 215/60R16 95V tire: 16X6 1/2J Tire pressures For the specified tire pressure, see the Tire Information Label located on the driver’s door lock pillar. *1: When tire replacement is necessary and if the specified load index and speed rated tire is not available, then use a tire of higher load index and speed rating.
Page 314 Service Division MARUTI SUZUKI INDIA LIMITED Palam Gurgaon Road, Gurgaon - 122 015 (Haryana) 99011M64M14-74E www.marutisuzuki.com...

MARUTI SUZUKI Nexa S-Cross 2021 Owner Manual And Service Booklet

Table of Contents

Before Driving

Operating Your Vehicle

Driving Tips

Other Controls and Equipment

Inspection and Maintenance

Quick Links

Chapters

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MARUTI SUZUKI Nexa S-Cross 2021

Summary of Contents for MARUTI SUZUKI Nexa S-Cross 2021

Table of Contents
