Summary of Contents for Xylem DREDGEPACK
- Page 1 DREDGEPACK® INSTALLATION MANUAL FOR CUTTER SUCTION DREDGES...
- Page 2 INSTALLATION MANUAL FOR CUTTER SUCTION DREDGES DREDGEPACK ® The purpose of this manual to guide you in the installation of the DREDGEPACK® system for cutter suction dredges. Due to the complexity of the installation, please follow the steps described in this guide and if you have questions please contact HYPACK tech- nical support at help@hypack.com or (860) 635-1500.
-
Page 3: Table Of Contents
DREDGEPACK ® TABLE OF CONTENTS I. Precautions II. Equipment Overview III. Installation Instructions A. GNSS Receiver B. Ladder Inclinometer C. Swing Rotation Sensor (Optional) IV. Maintenance and Care V. FAQ Revision History DATE REVISION NUMBER CHANGE DESCRIPTION March-05-2024 Initial release... -
Page 4: Precautions
DREDGEPACK ® I. Precautions General Safety Precautions: • Conduct a thorough risk assessment before starting the installation. • Ensure that all personnel involved are properly trained in handling equipment and working at heights. • Use appropriate personal protective equipment (PPE) such as helmets, gloves, safety goggles, and harnesses. -
Page 5: Equipment Overview
Each DREDGEPACK® system for cutter suction dredges is individually designed to fit the customer’s needs. The following sensors are required for the correct operation of the Cutter Suction System with DREDGEPACK®. There are some optional sensors presented that are needed only in special cases. When you receive the equipment please verify it is complete, if you have any questions please let us know. -
Page 6: Installation Instructions
III. Installation Instructions A. GNSS Receiver DREDGEPACK® requires dredge position and dredge heading. The best method to obtain this data is to use a dual antenna GNSS receiver. - Dredge position: The main antenna can be used for calculating the position and elevation of the dredge. For better performance, the GNSS receiver can be upgraded to have a low uncertainty using RTK (Real Time Kinematic). - Page 7 DREDGEPACK ® The antennas require a 5/8-11 UNC bolt. They can be installed directly on top of the cabin or at the end of a pipe. DO NOT WELD THE SCREW WITH THE ANTENNAS SCREWED IN, THAT COULD SERIOUSLY DAMAGE THEM.
-
Page 8: Ladder Inclinometer
DREDGEPACK ® B. Ladder Inclinometer There are several options when installing the inclinometer, however, the key factor is the rotation direction, what it is labeled in the case. The inclinometer is fully water and dust proof as long as the cable is properly connected. The life span of the inclinometer and cable can be increased by installing it above water and not submerged all the time. - Page 9 DREDGEPACK ® Once the inclinometer is properly installed, it is necessary to run the cable to where the main interface box is going to be located. It is not necessary to finish the ends in the cabin, that work is performed during the integration and training.
-
Page 10: Maintenance And Care
DREDGEPACK ® The swing rotation sensor used to measure the horizontal movement could require some pieces to transfer the movement to the sensor. It should be installed close to the ladder rotation pin. The pieces used to transfer the movement will need certain dimensions in order to have a rotation ratio 1:1. - Page 11 Unparalleled technical support HYPACK – A Xylem brand has been a world leader in software development for the hydrographic and dredging industry since 1984. Our software is one of the most widely used hydrographic software packages in the world, with more than 10,000 users in over 140 countries.
