Hayward Perflex EC50C Series Owner's Manual page 6

While Perflex filters are basically resistant to the difficulties often encountered as a result of chemical build-up in swimming pools, it is important to
keep in mind that the mineral content in a pool increases every day as a result of the chemicals and the normal water evaporation process. If the
concentration of minerals is allowed to get too high, the minerals will form deposits on the Flex-Tubes inside the filter, and will eventually result in
shortened filter cycles. To guard against this, a yearly chemical cleaning (soaking) of the Flex-Tube assembly is suggested. Use commercially
available 20% muriatic acid added to water in 1 to 1 ratio; or use other commercial filter element cleaner mixed according to the package
instructions. Use a plastic container.
CAUTION: Chemical Hazard –Chemicals can cause personal or property damage, to avoid use personal protective
gear when handling.
After cleaning, thoroughly flush all affected parts with cold water. Always wear gloves and eye protection when handling cleaning agents.
WINTERIZING
In areas where sub-freezing temperatures can be expected, the filter should be drained and removed from its operating location and stored indoors.
Prior to removal, cycle the filter as described under CLEANING.
REPLACECMENT PARTS (WITH PLASTIC-TYPE CLAMP)
REF. PART NO.
1 ECX5000D Bump Mechanism Cover
2 ECX1322A Vent Valve with O-ring
3 ECX5000BP Filter Head with Vent Valve
4 ECX4000C Clamp Assembly with Hardware
5 ECX100Z9 Pivot Pin (long)
6 ECX4236A Shoulder Screw and Nut set
7 ECX1040 Bump Handle
8 ECX1037B Bump Handle Grip
9 Hardware Kit for Clamp Assembly
ECX4000CHK
10 ECX5000F Bump Shaft, 1/2"
11 SPX1500NYA Tube Sheet Bolt and Nut Set
12 ECX1004A Tube Sheet Top
13 ECX5000G Diaphragm Gasket
14 ECX1004 Tube Sheet Bottom
Bump Shaft Kit
15 ECX1014A
(Includes 2 each O-ring, Retainer, Thrust
Washer)
16 ECX1032PAK10 Flex-Tube Assembly (Set of 10)
17 ECX5000AP Filter Body w/Flow Diffuser
18 ECX27091 Pressure Gauge, back mount
19 ECX12866 Gauge/Inspection Port Adapter
20 ECX1287 O-ring for Gauge Adapter
21 ECX5029 Decal -Operation
22 SPX1055 Flow Controller
23 ECX4077B1 Check Valve
24 ECX1256 Flow Diffuser with Check Valve
25 SP1022C Drain Plug with Gasket
26 ECX1161 Platform Base
27 SP1480 1-1/2" Male Union
28 SPX142576 O-Ring
29 — Hayward Pool Pump
30
SPX1250WA 6 ft. Cord Set
31
ECX1108A Pump Mounting Screw Set (2)
SP0723 Ball-Type Drain Valve with Nipple
PREVENTIVE MAINTENANCE
D E S C R I P T I O N QTY
1
1
1
1
1
1
1
1
1
1
12
1
1
1
1
72
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
