OWNER'S MANUAL
INSTALLATION, OPERATION, & PARTS
Models C2020 C3020 C4020 C5020
SWIMCLEAR CARTRIDGE FILTERS
EFFECTIVE FILTRATION
MODEL
2
FT
C2020
225
C3020
325
C4020
425
C5020
525
MAXIMUM WORKING PRESSURE FOR ALL MODELS 50 PSI (3.45 BAR)
SAVE THIS INSTRUCTION MANUAL
HAYWARD POOL PRODUCTS
620 Division Street
RATE
2
M
20.9
30.2
39.5
48.8
Elizabeth, NJ 07207
WWW.HAYARD.COM
DESIGN FLOW RATE
GPM
LPM
77
291
122
462
150
568
150
568
Tel: 908-355-7995
ISC2027 Rev D
Advertisement
Table of Contents
Related Manuals for Hayward C3020
Summary of Contents for Hayward C3020
- Page 1 ISC2027 Rev D OWNER’S MANUAL INSTALLATION, OPERATION, & PARTS Models C2020 C3020 C4020 C5020 SWIMCLEAR CARTRIDGE FILTERS EFFECTIVE FILTRATION MODEL DESIGN FLOW RATE RATE C2020 20.9 C3020 30.2 C4020 39.5 C5020 48.8 MAXIMUM WORKING PRESSURE FOR ALL MODELS 50 PSI (3.45 BAR)
