- Page 1 USER MANUAL USER MANUAL USER MANUAL LivePremier™ unit (V4.0) References: AQL-RS-ALPHA, AQL-RS1, AQL-RS2, AQL-RS3, AQL-RS4, AQL-RS5, AQL-RS6, AQL-C, AQL-C+, AQL-Cmax www.analogway.com...
- Page 2 USER MANUAL USER MANUAL Information contained in this document, in particular data, pictures, information, trademarks and logos are exclusive property of Analog Way and are protected by copyrights and other intellectual property rights. 2024, Analog Way, all rights reserved – 03/2024 Consequently, any representation and/or reproduction, in part or in full, is prohibited and would be considered a violation of Analog Way’s copyright and other intellectual property rights.
-
Page 3: Table Of Contents
USER MANUAL USER MANUAL Contents Disclaimer ....................... 10 Copyrights ........................... 10 Warranty ............................. 10 Liability ............................10 Force Majeure ..........................10 Terms and Definition ..................11 Hardware Specifications ................12 General safety instructions ......................12 3.1.1 English ..............................12 3.1.2 French .............................. - Page 4 USER MANUAL USER MANUAL Using the Web RCS ..................30 Run the Web RCS ........................30 5.1.1 Web RCS requirements........................30 5.1.2 Default network settings ........................31 5.1.3 Connection ............................31 5.1.4 Login page ............................31 5.1.5 LivePremier Simulator ......................... 31 General tips ..........................
- Page 5 USER MANUAL USER MANUAL 6.5.3 A VPU can support both capacities at the same time ................. 49 6.5.4 Scaling engine boundary........................49 6.5.5 Combined VPUs ........................... 50 6.5.6 Optimized mode ..........................50 6.5.7 Cut & Fill resources ..........................51 6.5.8 How many VPUs per model? .......................
- Page 6 USER MANUAL USER MANUAL 7.7.2 Background set for a Screen with one output group ................73 7.7.3 Background set for a Screen with multiple output groups ..............73 7.7.4 Reset a background set ........................73 7.7.5 Remove a source from all background sets ..................73 Preconfig >...
- Page 7 USER MANUAL USER MANUAL 11.2.4 Assign an imported image to an image slot ..................91 11.2.5 Assign a timer to an image slot ......................91 11.2.6 Image signal ............................91 11.2.7 Image aspect ............................92 Formats and EDID ..................93 12.1 Formats ............................
- Page 8 USER MANUAL USER MANUAL 15.1.6 PGM and PRW buttons – Screen controls ..................107 15.1.7 Bottom bar buttons ........................... 108 15.1.8 Transitions - Right panel ........................109 15.2 Layer properties ........................109 15.2.1 Layer selection and tools ........................110 15.2.2 Layer position and size ........................
- Page 9 USER MANUAL USER MANUAL 17.2 Multiviewers menu interface ....................124 17.2.1 Sources - Left panel ........................... 125 17.2.2 Widget selection ..........................126 17.2.3 Multiviewer layout editor ........................127 17.2.4 Bottom bar buttons ........................... 127 17.3 Widget properties ........................128 17.3.1 Widget position and size ........................
-
Page 10: Disclaimer
1.3 Liability Analog Way shall not be liable for any loss or damage, be it direct or indirect in regard to the utility or contents of the software or hardware, except to the extent provided by law. Notwithstanding the above, liability for indirect, special, incidental or consequential loss or damage that may arise in respect of the software or hardware, is expressly excluded. -
Page 11: Terms And Definition
RCS: User interface to setup and operate the LivePremier. It is a web browser based Remote Control Software designed by Analog Way. Widget: Multiviewer item displaying one content (Input, Image, Timer, Preview or Program Screen). A widget is similar to a Layer but without visual priority, widgets are displayed on same level and cannot overlap. -
Page 12: Hardware Specifications
USER MANUAL USER MANUAL 3 Hardware Specifications 3.1 General safety instructions 3.1.1 English All of the safety and operating instructions should be read before the product is operated and should be maintained for further reference. Please follow all of the warnings on this product and its operating instructions. -
Page 13: French
The internal Lithium cell battery is not replaceable. In case of a problem, contact your supplier or Analog Way. • OPENINGS: Never push objects of any kind into this product through the openings. If liquids have been spilled or objects have fallen into the device, unplug it immediately and have it checked by a qualified technician. -
Page 14: Italian
USER MANUAL USER MANUAL - Ne laissez pas tomber le cordon d’alimentation et ne posez pas d’objets lourds dessus. Si un des cordons d’alimentation est endommagé, débranchez-le immédiatement de la prise murale. Il est dangereux de faire fonctionner un appareil avec un cordon endommagé ; un câble abîmé peut provoquer un risque d’incendie ou un choc électrique. -
Page 15: German
La batteria al litio all’interno dell’apparato non e’ sostituibile. In caso di problemi contattare il fornitore o Analog Way. • APERTURE DI VENTILAZIONE: Le apparecchiature possono comportare delle aperture di ventilazione, si prega di non introdurre mai oggetti o ostruire le sue fessure. - Page 16 Schrauben zu Stromschlägen oder anderen Gefahren für den Benutzer führen kann. Die im Gerät eingebaute Lithium Batterie ist nicht austauschbar. Im Falle eines Problems nehmen Sie Kontakt mit Ihrem Lieferanten auf oden au Analog Way. • ÖFFNUNGEN UND MUNDUNGEN: Die Geräte können über Öffnungen verfügen (Belüftung, Schlitze, usw.).
-
Page 17: Spanish
USER MANUAL USER MANUAL 3.1.5 Spanish Para comprender mejor el funcionamiento de este aparato, le recomendamos que le acuidadosamente todas las consignas de seguridad y de funcionamiento del aparato antes de usarlo. Conserve las instrucciones de seguridad y de funcionamiento para que pueda consultarlas posteriormente. Respete todas las consignas indicadas en la documentación, relacionadas con el producto y este documento. -
Page 18: Symbols On Product Identification And Warning Labels
La batería interna de litio no es reemplazable. En caso de problema, contacte con su proveedor o Analog Way. • ABERTURAS Y ORIFICIOS: Los aparatos pueden contener aberturas (aireación, ranuras, etc.). Nointroduzca allí... -
Page 19: Environmental Specifications For All Livepremier Models
USER MANUAL USER MANUAL 3.1.7 Environmental specifications for all LivePremier models RS alpha, RS1, RS2 and C: • Dimensions without rack mount and handles: W 439.8 x H 177 x D 700 mm • Dimensions with rack mount and handles: W 482.4 x H 177 x D 701 mm •... -
Page 20: Ups Compatibility
USER MANUAL USER MANUAL General: • Cooling air flows from front side to rear • Operating temperature: 0 to +40°C / +32°F to +104°F • Storage temperature: -10 to +60°C / +14°F to +140°F • Operating humidity: 10 to 80% (non-condensing) •... -
Page 21: Introducing Livepremier
USER MANUAL USER MANUAL 4 Introducing LivePremier™ LivePremier can process up to 160 Megapixels throughput at 10 bits 4:4:4 @60Hz without any limitation of pixel canvas size. 4.1 LivePremier – Modular architecture LivePremier is designed to be modular. Input and Output cards can be configured to match source and display requirements. -
Page 22: Front Panel
USER MANUAL USER MANUAL 4.3 Front panel It is composed of one OLED display, two USB ports, three buttons (Power, Enter and Exit) and a coder. The front panel can be used for admin features or information (Firmware update, Network settings, Import/Export configuration, Factory Reset and Status check). -
Page 23: Input / Output Cards
12G-SFP input and output cards can receive SFP modules either for SDI over Fiber or for SDI over IP / SMPTE. Compatible with 1GbE. Supports SDR input signals only (convertible internally to HDR10 or HLG). Works with DAC cables. For more information, visit www.analogway.com or contact Analog Way support. www.analogway.com... -
Page 24: Change An Input / Output Card
USER MANUAL USER MANUAL 4.5.2 Change an input / output card Tools required: one cross-head screwdriver. Installation rules: - Cards must be installed from top to bottom. (Inputs and outputs are numbered in rows from left to right and from top to bottom (see Fig. 2 - page 22)). - LivePremier units must have 2, 4 or 6 input cards (no odd numbers). -
Page 25: Optional Control Card With Displayport Multiviewer Outputs
USER MANUAL USER MANUAL 4.6.1 Optional control card with DisplayPort Multiviewer outputs Warning: - Changing the control card also changes the device configuration. If needed, export a configuration to recover it after the update (see 5.5 Save / Reset / Load Configuration page 39). - The control card is NOT hot swappable. -
Page 26: Power Supply Units (Psu)
Power supply compatibility Caution: - Use only power supplies provided or recommended by Analog Way. - Ensure that all power supplies present on the unit are of the same type (type 1 or type 2). Contact technical support in case of a doubt. -
Page 27: Livepremier Accessories
USER MANUAL 4.7 LivePremier accessories For more information on LivePremier accessories, visit www.analogway.com or contact Analog Way support. 4.7.1 HDMI 2.0 over fiber extenders – Transmitter and Receiver Fig. 4 - HDMI 2.0 over fiber extender The extenders are designed to transfer HDMI 2.0 signal with embedded audio over one multimode fiber cable. - Page 28 USER MANUAL USER MANUAL When mounting the LivePremier unit, ensure proper air flow and consider the following points on safe use: Always use the handles built on the sides of the chassis for easy mounting into any standard rack or flight case.
-
Page 29: Power On And Off
USER MANUAL USER MANUAL 4.9 Power on and off 4.9.1 Start the LivePremier To safely start the LivePremier unit: 1. Connect all inputs and outputs. 2. Connect the power cables to the unit and then plug them into a mains socket. 3. -
Page 30: Using The Web Rcs
USER MANUAL USER MANUAL 5 Using the Web RCS Fig. 6 - Web RCS Interface Web RCS is the main controller for the LivePremier. It is embedded in all units and compatible with all operating systems. LivePremier can be operated from any computer via wired network connection without installing any software. -
Page 31: Default Network Settings
USER MANUAL USER MANUAL 5.1.2 Default network settings Tip: All connections should be done before starting the LivePremier unit. Default network settings: IP Address: 192.168.2.140 Subnet Mask: 255.255.255.0 Port: 80 Note: Make sure that ports 80, 443, 10591, 10606, 10691, 10692 and 10693 are available on your network and/or not blocked by firewall. To connect to this address, a computer needs to be configured to use a unique IP address on the same network. -
Page 32: General Tips
USER MANUAL USER MANUAL 5.2 General tips 5.2.1 Web browser features The Web RCS is fully browser integrated and behaves like any web site. It manages browser features such as: Previous page / Next page Multi-selection of items using the Ctrl or Shift keys Open in new tab / Open in new page Enter direct URL Bookmark any page... -
Page 33: Search Bar
USER MANUAL USER MANUAL 5.2.5 Search bar In the top bar, use the search bar to simply access a feature or setting. 1. Click the search bar. 2. Enter a keyword to search (ex: Input, Pattern, Keying). The search results are displayed. 3. -
Page 34: Device Overview
USER MANUAL USER MANUAL 5.3 Device overview Check a device status and modify network settings directly from the main page. 5.3.1 Back panel In the top bar, click to show the virtual Back panel. Click the connectors to access their settings directly. 5.3.2 Device status In the top bar, click then a device name for a quick overview. - Page 35 USER MANUAL USER MANUAL 5.3.2.2 Network 1. Go to the Device Overview > Network. 2. In Adapter, set Host name. 3. In IPv4, manage DHCP, set IP address, Netmask, Gateway and DNS. 4. Click Apply. 5. If needed, enable and set IPv6 and click Apply. 5.3.2.3 Power Caution: always use same model of power supply units.
-
Page 36: Dashboard
USER MANUAL USER MANUAL 5.4 Dashboard In the top bar, click then Dashboard to access System Overview and settings. Click on any System Overview item to open the corresponding settings on the right panel. Fig. 10 - System Overview 5.4.1 Firmware 5.4.1.1 Update Prerequisite:... -
Page 37: Remote Access
USER MANUAL USER MANUAL 5.4.1.2 Reinstall current Firmware When a firmware is installed, the LivePremier unit saves the installer of the current firmware in its memory. It is possible to reinstall the current firmware if needed (ex: update an input / output connector card). 1. - Page 38 USER MANUAL USER MANUAL 5.4.2.5 Reset Web RCS password from the front panel If the password is lost or forgotten, it can be reset from the front panel of the LivePremier unit. Note: The password can only be reset from the front panel. 1.
-
Page 39: Remote Control
- For more information about RC400T, see Appendix A RC400T page 132. - AWJ is a JSON based protocol developed by Analog Way for LivePremier. AWJ is a bidirectional TCP API, it grants full control on a LivePremier device and receives real-time status updates from the LivePremier device. For more information, visit www.analogway.com. -
Page 40: Save The Current Configuration
USER MANUAL USER MANUAL 5.5.1 Save the current Configuration 1. In the top bar, click , then Save. 2. Enter a label for the Configuration to save. 3. In the filters, select the settings to save. 4. Select the destination and click Download or Save. The configuration is downloaded on the local computer or saved in the selected memory slot. -
Page 41: Device Control Synchronization
USER MANUAL USER MANUAL 5.6 Device control synchronization A LivePremier device can be connected to up to 5 control instances (multiple Web RCS pages, RC400T, etc.). It is possible to enable / disable the synchronization of each control instance with the server from the Web RCS. -
Page 42: Livepremier Concepts
USER MANUAL USER MANUAL 6 LivePremier concepts 6.1 What is “Capacity”? A capacity is the maximum bandwidth allocated to an item. Allocating a max capacity for every item ensures the interoperability between all the internal elements of a LivePremier unit. Capacities are automatically assigned when setting a format. -
Page 43: Content And Layer Compatibility
USER MANUAL USER MANUAL 6.1.3 Content and layer compatibility An input or image with capacity can be used in a layer with capacity or 2: Layer with capacity Content with capacity Layer with capacity The content is displayed correctly but the resources are not optimized. An input or image with capacity can only be used in a layer with capacity 2: The content cannot be... -
Page 44: Screen Layers
Tip: It is possible to use an NDI stream as an input. For more information on how to set up an NDI input see 7.8.1 IP/SDI page 74. 6.2.2 Mixing layers This is the default layer mode for LivePremier units as well as most Analog Way products. Mixing layers support cross transitions with both contents visible at the same time during the transition (seamless transition). -
Page 45: Aux Screens And Aux Layers
USER MANUAL USER MANUAL 6.3 Aux Screens and Aux layers Aux Screens do not consume processing resources. They are a great help to display more content when the LivePremier unit has available outputs while processing resources are fully used by Screens. 6.3.1 Aux layers quantity and capacity Outputs used in Aux Screens can display up to 8 layers with capacity 1. -
Page 46: Screen / Aux Screen Comparison
USER MANUAL USER MANUAL 6.4 Screen / Aux Screen comparison Feature supported Screen with layers Screen without layers Aux Screen Multiple outputs DPH104 output Multiple layers Consume zero processing resources Background layer (with No. Monochrome color eight Background Sets only. using inputs or images) Display a Screen Program Layer border settings... -
Page 47: Livepremier Processing
USER MANUAL USER MANUAL 6.5 LivePremier Processing 6.5.1 VPUs and Scaling engines The main processing components of LivePremier are the Video Processing Units (VPU). VPUs create the layers and allocate them to one or multiple outputs. Understanding VPU concept is the key for optimized performance. -
Page 48: Self-Rearrangement
USER MANUAL USER MANUAL 6.5.2 Self-rearrangement A VPU has a modular architecture and rearranges its links depending on the Screen configuration: - Number of outputs in the Screen - Number of layers in the Screen - Capacity of the links between layers and outputs VPU configuration examples One VPU can manage up to 8 Screens, each Screen using 1 output and 1 mixing layer. -
Page 49: A Vpu Can Support Both Capacities At The Same Time
USER MANUAL USER MANUAL 6.5.3 A VPU can support both capacities at the same time One Screen cannot support mixing and split layers at the same time. However, VPUs and Screens can support layers of capacity at the same time, in any order. Screen 1 (1 output and 1 mixing layer capacity 1) Screen 2 (1 output and 1 mixing layer capacity 1) Screen 3 (2 outputs and 2 mixing layers capacity... -
Page 50: Combined Vpus
USER MANUAL USER MANUAL 6.5.5 Combined VPUs A Screen using more than 8 outputs uses another VPU. In the following example, each mixing layer of Screen 1 uses 3 layer links: Screen 1 (12 outputs and 4 mixing layers) Screen 2 (4 outputs and 4 mixing layers 6.5.6 Optimized mode An Optimized mode is enabled for the whole VPU when one Screen uses at least 5 outputs links and at least one layer of capacity 2. -
Page 51: Cut & Fill Resources
USER MANUAL USER MANUAL 6.5.7 Cut & Fill resources The Cut & Fill effect enabled for a layer doubles the resources needed for that layer. Screen 1 (4 outputs and 2 mixing layer capacity 1; 1 mixing layer capacity with Cut & Fill; 1 mixing layer capacity with Cut &... -
Page 52: Hdr Conversion
USER MANUAL USER MANUAL Aquilon Simult. 4K image channels Models RS alpha 0 or 1 0 or 12 Up to 2 Up to 24 Up to 2 Up to 24 C max 6.6 HDR conversion Tip: HDR conversion adds no latency. LivePremier can manage inputs and outputs with different frame rates. -
Page 53: Preconfig Menu
USER MANUAL USER MANUAL 7 Preconfig Menu Fig. 14 - Preconfig Menu Preconfig is composed of the following submenus: System Multiviewers Outputs Screens Aux Screens Canvas Inputs Images Backgrounds AVoIP Click Preconfig to display the submenus. 7.1 Preconfig > System Preconfig >... -
Page 54: Framelock Input Settings
USER MANUAL USER MANUAL 7.1.1.1 Set defined rate 1. Go to Preconfig > System. 2. In Vertical Rate > Source, click Internal. 3. In Rate, select the refresh rate. 7.1.1.2 Set relative rate Caution: Make sure the reference input is a reliable source. Any disruptions in the reference signal may cause visible glitches on the output, even if the selected framelock reference input is not being displayed. -
Page 55: Quick Hdcp
USER MANUAL USER MANUAL 7.1.5 Quick HDCP From Preconfig > System, quickly enable / disable HDCP for all inputs and outputs. Note: Disabling HDCP reduces potential problems when the content is not fully HDCP compliant. When output HDCP is disabled, HDCP inputs will not be displayed anymore. -
Page 56: Preconfig > Outputs
USER MANUAL USER MANUAL 7.3 Preconfig > Outputs Fig. 15 - Preconfig – Outputs Preconfig > Outputs: - Set output groups, output rotation and output group format - Set a DisplayPort output as using a DPH104 - Set output clone and aux duplication Note: - Output rotation is enabled in Preconfig >... -
Page 57: Output Capacity - The 4-4 Rule
USER MANUAL USER MANUAL Note: - By default, all outputs are set in a 1x1 group. - Rotation is possible for the output group but not for independent outputs inside groups. - Individual output settings are still available in the Output menu (color space, patterns, HDCP, audio channels, etc.). - Using a group of two or more outputs adds a one frame latency. -
Page 58: Set An Output Group For A Screen
USER MANUAL USER MANUAL 7.3.3 Set an output group for a Screen 1. In Preconfig > Outputs, click an output. 2. In Configuration, select Screen mode and Group type. 3. Select the output group layout (1x1 by default). Selecting a higher group layout automatically groups the following output(s). 4. -
Page 59: Output Cloning And Aux Output Duplicate
USER MANUAL USER MANUAL 7.3.6 Output cloning and Aux output duplicate All outputs can reuse the content from other outputs to send an identical signal while saving processing resources. 7.3.6.1 Output cloning An output clone will send the same signal as another output without consuming processing resources. Note: An output clone is limited to these following conditions: - It cannot be affected to any Screen or Aux Screen. -
Page 60: Creating Screens
USER MANUAL USER MANUAL 7.3.6.2 Aux output duplication When an output is set to Aux mode with 4 or more layers, the following output(s) are preempted. These outputs become disabled by default, but they can be set to duplicate the content of the preempting Aux output. -
Page 61: Create An Aux Screen
USER MANUAL USER MANUAL 7.3.7.2 Create a Screen Preconfig > Screens, click a Screen to show more options: Note: An output group must be set to Screen mode to be assigned in a Screen. Enable / disable the Screen Select the Layer mode (Mixing layers or Split layers) If needed, in Regions, click Add Region Click Add Outputs and select the output(s) to assign to a Screen region Click Add Outputs to confirm the selection or drag and drop them individually to each region... -
Page 62: Rename A Screen
USER MANUAL USER MANUAL 7.3.9 Rename a Screen By default, all Screens are named S1, S2, or A1, A2 and so on. To rename a Screen: 1. In Preconfig > Screens or Aux Screens, click a Screen or Aux Screen on Enter Label… 2. -
Page 63: Tree View
USER MANUAL USER MANUAL 7.4.1 Tree view Preconfig > Canvas, select a Screen to display the tree view of the Screen. Select one element to change the corresponding settings in the right panel. X and Y (Only displayed if the Screen is in Grid type) Create covering or gap between the grid cells areas Set blending and black areas for covering areas Groups... - Page 64 USER MANUAL USER MANUAL Output rotation Display result No rotation or 180° rotation 90° rotation CCW or 270° rotation CCW Fig. 21 - Display result using output rotation - 2x2 Screen Output Display result rotation rotation or 180° 90° or 270° Fig.
-
Page 65: Patterns
USER MANUAL USER MANUAL 7.4.3 Patterns Display patterns are used during the Screen configuration phase to test and control how outputs are displayed in Screens. Use patterns to identify and test that the displays are set correctly (color, position, resolution, etc.). Enabling a pattern overrides any content displayed in the output. It is possible to use Screen patterns and Output patterns. -
Page 66: Grid Canvas
USER MANUAL USER MANUAL 7.4.4 Grid canvas 7.4.4.1 Create a Grid canvas Grid type, create a grid and assign output groups to corresponding cells to create the Screen canvas. 1. In Preconfig > Canvas, select a Screen. Grid 2. Select the canvas type. -
Page 67: Free Canvas
USER MANUAL USER MANUAL 7.4.5 Free canvas Free type is separated in two modes: Auto mode Set the position of each output or group freely. The canvas size is automatically computed and optimized for the created Screen. Custom mode Set the Screen size then position each output or group inside the created Screen 7.4.5.1 Bottom bar buttons –... - Page 68 USER MANUAL USER MANUAL 7.4.5.3 Create a canvas in Custom mode Custom mode, enter a H and V size to create the custom Screen canvas. Then enter position or use drag and drop to position each output inside the canvas. Custom mode is recommended for complex shows where the canvas size is known.
-
Page 69: Advanced Output Settings (In Preconfig > Canvas)
USER MANUAL USER MANUAL 7.4.6 Advanced output settings (in Preconfig > Canvas) Note: Output settings are applied to the selected output. These following settings are specific to outputs and can be used in all canvas types. 7.4.6.1 Canvas settings for DPH104 Preconfig All DPH104 outputs are limited to a grid created according to the Layout selected in >... -
Page 70: Preconfig > Inputs
USER MANUAL USER MANUAL 7.5 Preconfig > Inputs Preconfig > Inputs, set input group and input format. 7.5.1 Input group All inputs, except for NDI and 8-plug HDMI card, can be grouped together to be used as one source content. Using input group saves time and frees layers for processing optimization more. -
Page 71: Set Four 3G-Sdi Inputs For 2Si Format
USER MANUAL USER MANUAL 7.5.3 Set four 3G-SDI inputs for 2SI format Tip: It is possible to connect the four 3G-SDI inputs in any order as long as they are connected to the same input card and the SDI signal is encoded in 2SI format. 1. -
Page 72: Preconfig > Images
USER MANUAL USER MANUAL 7.6 Preconfig Images > Preconfig > Images, set the expected image resolution for image slots. 7.6.1 Image slots The number of available image slots displayed at the same time depends on the number of IPU of the unit and the image slots capacity. -
Page 73: Background Set For A Screen With One Output Group
USER MANUAL USER MANUAL 7.7.2 Background set for a Screen with one output group Note: The content and output capacities must match. Otherwise, it is not possible to assign it to the background set. The procedure is the same if using one output or one output group with multiple outputs. For example: Screen 1 is a single output screen using Output 1. -
Page 74: Preconfig > Avoip
USER MANUAL USER MANUAL 7.8 Preconfig > AVoIP Preconfig > AVoIP, click on an input / output connector to display status information of a corresponding AV over IP device (IP/SDI, SDVoE or Dante) and modify selected settings. 7.8.1 IP/SDI IP/SDI input card can accommodate up to four NDI full bandwidth streams. Tip: Any unused NDI input may be changed to an SDI input by modifying a plug type in Preconfig >... -
Page 75: Sdvoe
Tip: The update of the Dante card is integrated in the firmware update of the LivePremier unit. A pre-requisite is to install AW Dante Firmware v3.7.0.X (available on Analog Way’s website) using the Dante Firmware Update Manager tool before updating the LivePremier firmware. -
Page 76: Multiviewers
USER MANUAL USER MANUAL 8 Multiviewers A Multiviewer is a dedicated output displaying a user customizable selection of Widgets as display resources. A Widget is a Multiviewer layer containing a program, preview, input, image or timer. One Multiviewer can display up to 64 Widgets. Note: Orange FX (Effect) sign at the bottom of a widget indicates Take in progress. -
Page 77: Multiviewers Adjustment (Image Correction)
USER MANUAL USER MANUAL Recommendation: Always use high quality cables to prevent connection and bandwidth errors when using HDCP. Note: - The actual Pixel encoding and Color space used can be different from the one set in the output format. It is indicated in the details of the signal status in the table. -
Page 78: Outputs
USER MANUAL USER MANUAL 9 Outputs Outputs, set the Label, Format, Signal parameters, Image correction and Patterns for each output group. Note: - Go to Preconfig > Outputs to set output resources. - The thumbnail preview is only possible for Outputs used in Screens. Outputs used in Aux. Screens have a black thumbnail. 9.1 Outputs main screen Go to Outputs, the outputs main screen displays all outputs in a Grid view. -
Page 79: Output Format
USER MANUAL USER MANUAL 9.2.1 Output format Outputs, select an output. In Format, the following settings are available: Note: Output format settings are identical for all outputs of the same group. Setting name Description / Setting selection Format Mode Set to follow internal rate or select a custom rate in the list Format Set the format for each output of the group OSD ON/Off toggle: Display / hide On Screen Display DPH104 information... -
Page 80: Output Adjustment (Manual Image Correction)
USER MANUAL USER MANUAL Setting name Description / Setting selection Conversion Mode Mode Auto or LUT Conversion LUT In LUT Conversion mode, select a LUT from the Conversion LUT library (only for HLG with SDR as internal profile) Inverse Tone Mapping or Direct Mapping Mapping - Use Inverse Tone Mapping if internal processing and main output are using Limited Range color space... -
Page 81: Output Pattern
USER MANUAL USER MANUAL 9.2.5 Output pattern Outputs, select an output. In Group Pattern, the following settings are available: Note: Output pattern settings are identical for all outputs of the same group. Setting name Description / Setting selection Patterns Enable On/Off toggle. -
Page 82: 0 Inputs
USER MANUAL USER MANUAL Inputs Inputs, set the Label, Signal parameters, Aspect, Keying, Image correction, Pattern and NDI source (for NDI plugs only). Note: - Go to Preconfig > Inputs to set input resources. - Input settings are identical for all inputs of the same group. 10.1 Inputs main screen Inputs, the inputs main screen displays all inputs in a Grid view. -
Page 83: Input Signal
USER MANUAL USER MANUAL 10.2.1 Input signal Inputs, select an input. In Signal, the following settings are available, depending on Internal Profile: Setting name Description / Setting selection Settings Auto, YUV, RGB Full (0-255) or RGB Limited (16-235) Signal Type Auto, SDR, HDR10 or HLG Dynamic Range Luminance... -
Page 84: Input Aspect
USER MANUAL USER MANUAL 10.2.2 Input aspect Inputs, select an input. In Aspect, set the Aspect ratio or set input crop. Note: Aspect ratio and Crop replaces the input content and affects every layer using it. If needed, use crop at layer level in Live or duplicate the input with a splitter. - Page 85 USER MANUAL USER MANUAL 10.2.3.1 Set Chroma Keying Inputs, select one input and click Keying and Chroma mode. 1. In 2. Enable Freeze on the content. 3. In Value, select the Hue to Key (color). 4. Or use the assistant to pick directly from the content: a.
- Page 86 USER MANUAL USER MANUAL 10.2.3.3 Keying using a CremaTTe 3D LUT from the Library Inputs, select one input and click Keying and CremaTTe 3D mode. 1. In 2. Enable Freeze on the content. 3. In CremaTTe 3D LUT, select a LUT from the CremaTTe 3D LUT library. The LUT is used for the keying of the input group.
-
Page 87: Input Adjustment (Manual Image Correction)
USER MANUAL USER MANUAL 10.2.4 Input adjustment (manual image correction) Inputs, select an input. In Adjustments, in Manual mode, the following settings are available: Setting name Description / Setting selection Brightness Adjust Global, Red, Green and Blue for Brightness (Global and RGB are cumulative) Contrast Adjust Global, Red, Green and Blue for Contrast (Global and RGB are cumulative) Colorimetry... -
Page 88: Images And Library
USER MANUAL USER MANUAL Images and Library LivePremier units can store up to 200 images. Image management is separated in two menus: Image Library: transfer images to the LivePremier unit. Images: assign uploaded images to image slots to be used in layers. 11.1 Library Image Library, all imported images are displayed in a Grid view. -
Page 89: Transfer Images From The Computer To The Unit
USER MANUAL USER MANUAL 11.1.3 Transfer images from the computer to the unit Note: It is possible to import only one folder at a time. 1. In Image Library, select one or multiple image files (or a folder) on the computer file browser. 2. -
Page 90: Manage Image Library From The Front Panel
USER MANUAL USER MANUAL 11.1.7 Manage Image Library from the front panel It is also possible to manage Library images from the front panel in the Export menu: - Download images from a USB drive to the Library (one at a time). - Download images from the Library to a USB drive (one at a time). -
Page 91: Assign An Imported Image To An Image Slot
USER MANUAL USER MANUAL 11.2.4 Assign an imported image to an image slot Tip: Click an image slot in the slot grid or use the arrows to browse through the image slots. 1. In Images, click an image slot. The image slot settings are displayed. 2. -
Page 92: Image Aspect
USER MANUAL USER MANUAL 11.2.7 Image aspect Images, select an image slot. In Aspect, set the Aspect ratio or set image crop. Note: - Aspect ratio and Crop replaces the image slot content and affects every layer using it. If needed, use crop at layer level in Live. - Aspect ratio and Crop set for an image slot remain when changing the image source. -
Page 93: 2 Formats And Edid
USER MANUAL USER MANUAL Formats and EDID 12.1 Formats Formats, create and manage up to 16 custom formats. Custom formats are particularly useful for LED wall applications and non-standard display applications (ex: pixel frequency over 165MHz or Dual-link outputs with single link formats 2400x700@60Hz). Custom formats can also be used to create custom EDIDs and then reset or request the preferred EDID of connected outputs and inputs. -
Page 94: Edid
USER MANUAL USER MANUAL 12.2 EDID Fig. 29 - EDID menu EDID is a metadata format used by displays to indicate their preferred format. A LivePremier unit receives EDIDs from connected inputs and outputs. It is possible to store these EDIDs in a memory called EDID bank. It is then possible to overwrite the preferred format of inputs and outputs. -
Page 95: Set A Custom Format For An Edid
Tip: The AW EDID Editor is a free software available on www.analogway.com. AW EDID Editor is a software developed by Analog Way to create, edit and import/export EDID files. Import the EDID file in the Web RCS to change the preferred format of any input and solve compatibility issues. AW EDID Editor supports EDID, DisplayID and CEA-861-G extension. -
Page 96: 3 Lut Libraries
USER MANUAL USER MANUAL LUT Libraries Libraries, manage Lookup Tables (LUTs). LivePremier uses 33x33x33 3D LUTs to instantly transform the colors of an Input or Output according to a mapping table. The LUTs are separated in three types: Conversion LUTs Used to convert the signal of an input (ex: SDR to HDR) Correction LUTs Used to change the color tone of an input or output (ex: cooler or warmer colors,... -
Page 97: Using A Lut
USER MANUAL USER MANUAL 13.3 Using a LUT Conversion and Correction LUTs can be used in the Inputs Outputs menus. A CremaTTe 3D LUT can be used in the Inputs > Group Keying menu. 13.4 Export a LUT to computer Libraries, hover over an LUT slot and click to download the LUT to the computer. -
Page 98: 4 Audio, Timers And Gpio
USER MANUAL USER MANUAL Audio, Timers and GPIO 14.1 Audio LivePremier units can manage audio routing with and without Dante audio network. Using the Dante audio, LivePremier can manage up to 64 input channels and 64 output channels at 48 kHz. Audio, assign audio channels from inputs and Dante receivers to outputs, multiviewers and Dante transmitters. -
Page 99: Default Audio Routing
USER MANUAL USER MANUAL - Click to delete the audio routing. - Set the number of channels to send (outputs only) - Enter (or reset) channel labels (Dante only) In the top bar: - Use the filter buttons to show/hide audio channels. - Enable Advanced Routing Mode for single channel routing. -
Page 100: Timers
USER MANUAL USER MANUAL 14.2 Timers Timers are time-based contents to be displayed in Screens, Aux Screens and Multiviewers. LivePremier units can generate up to four timers in three different modes: - Current time - Count down - Count up (Stopwatch) 14.2.1 Create a timer 1. -
Page 101: Use Timers In Screens And Aux. Screens
USER MANUAL USER MANUAL 14.2.3 Use timers in Screens and Aux. Screens Note: Timers can be displayed in Multiviewers without being assigned as image slots. Timers can be assigned to image slots. They can then be used in layers just like regular images. Images, click an image slot. -
Page 102: On/Off Switch Pins
USER MANUAL USER MANUAL Fig. 35 - GPIO Phoenix connection example 14.3.2 On/Off switch pins A switch can be placed between the On/Off pins to turn the LivePremier unit on and off. It will work as the front panel switch: when the device is on, closing the switch will request the device to power down. If the switch remains closed for more than four seconds, a forced power down is performed. -
Page 103: Set Gpio In The Web Rcs
USER MANUAL USER MANUAL 14.3.3 Set GPIO in the Web RCS GPIO, set the GPI and GPO actions. Fig. 36 - Setting name Description / Setting selection Polarity Set when the GPI connector is active (when powered or when unpowered) Select No action to disable triggers from this GPI Mode Select Take and associate a Screen to trigger the transition when using the GPI... -
Page 104: Screens / Aux
USER MANUAL USER MANUAL Screens / Aux. Screens / Aux. is the main page for controlling a show after all pre-configurations are set: - Display content in layers in Screens and Aux Screens - Create dynamic layer transitions - Transition Preview to Program - Save and Load Screen memories and Master memories Fig. - Page 105 USER MANUAL USER MANUAL Setting name Description / Setting selection Toggle to lock all the Screens and Aux Screens Prevent edits during Live, or lock Program to only edit in Preview PGM / PRW Layers cannot be modified; Memories cannot be loaded but transition can be triggered Toggle to show/hide all Program, Preview, Screens and/or Aux.
-
Page 106: Sources - Left Panel
USER MANUAL USER MANUAL 15.1.3 Sources - Left panel The Sources are in the left panel. Click the icons to show the corresponding sources: Screen sources Backgrounds Inputs Images Program Screens Note: - Program Screens can only be used as content for Aux Screens and Split layers. - Backgrounds can only be used in Background layers. -
Page 107: Screen Layout Editor
USER MANUAL USER MANUAL Tip: - Hold Ctrl or Shift to select multiple layers. - Scroll the slide bar under the Layer letters to access the layers that are not displayed. 15.1.5 Screen layout editor Click to open the layout editor, a smart tool to place layers in the Screen easily. Note: The layout editor is only available for Screens with layers. -
Page 108: Bottom Bar Buttons
USER MANUAL USER MANUAL 15.1.7 Bottom bar buttons In addition to the layout editor, use the buttons in the bottom bar to help setting the layers in Screens. Button Button description Action buttons Screen selection for transition (same as the Screen transition filter in the right panel) Select all layers in the Screens selected for transition (indicated on the left side) Deselect all layers Empty the layers content and keep other properties for the selected layers... -
Page 109: Transitions - Right Panel
USER MANUAL USER MANUAL 15.1.8 Transitions - Right panel Setting name Description / Setting selection Copy Program to Preview after the transition If Preset Toggle is enabled for a Screen, the layers in PGM replace the Preset Toggle layers in PRW during a Take or Take Cut (“swap” effect). If Preset Toggle is disabled, the layers in PRW are copied to PGM and remain in PRW Screens during a Take or Take Cut. -
Page 110: Layer Selection And Tools
USER MANUAL USER MANUAL 15.2.1 Layer selection and tools Setting name Description / Setting selection Keep the layer selection and toggle to Program or Preview Current layer selection. The layer indicated is the Reference layer. The following layers will have the same settings applied if possible. Click to open the selection menu. -
Page 111: Layer Source
USER MANUAL USER MANUAL Tip: In the Size property, click to keep the aspect ratio when changing the size values. - Use bottom bar buttons (Keep aspect ratio, snap to items) to have layers of equal size or alignment. When enabling snap to item, layer borders are automatically attracted to other objects (Screen border, layer border, grid snap point) to match their position or size. -
Page 112: Cut & Fill Effect
USER MANUAL USER MANUAL 15.2.3.5 Set a colored background In addition to the eight background sets, each Screen can display a color in the background layer. Screens / Aux., select a background layer (BKG). 1. In 2. In Properties, click Source to show the corresponding settings. 3. -
Page 113: Set Layer Opacity
USER MANUAL USER MANUAL 15.2.4.2 Set Cut & Fill in layer 1. In Screens / Aux., select a layer with Cut & Fill 2. Assign a content in the layer. 3. In Properties, click Cut&Fill to show the corresponding settings. 4. -
Page 114: Set Layer Border
USER MANUAL USER MANUAL 15.2.8 Set layer border 1. In Screens / Aux., select a layer. 2. In Properties, click Border to show the corresponding settings. 3. Toggle Edge to apply layer border settings. 4. Toggle Smooth to create a fading effect on the borders. 5. -
Page 115: Layer Transition
USER MANUAL USER MANUAL 15.3 Layer transition The transition is the animations of the layers during Take. Each layer can be defined by an opening and a closing transition. The opening effect is triggered when the layer switches from one source to another or when the layer appears on Screen. -
Page 116: Aux Screens
USER MANUAL USER MANUAL 15.4 Aux Screens Outputs used in Aux Screens can display up to 8 layers with capacity 1. Aux layers are dynamic, assigning a content with a capacity higher than will preempt the next Aux layer(s). One capacity needed = one layer preempted. For example: an Aux Screen is set with 6 layers. -
Page 117: 6 Memories
USER MANUAL USER MANUAL Memories Memories are used to save layers settings. Master memory Saves / loads multiple Screen memories at once (one per screen) Screen memory Saves / loads the layers settings for one Screen or Aux Screen Layer memory Saves / loads the settings for one layer The LivePremier can save up to 500 Master memories, 1000 Screen memories and 50 Layer memories. -
Page 118: Master Memories
USER MANUAL USER MANUAL 16.2 Master Memories 16.2.1 Save a Master memory from current Screens Master memory is the default saving mode and can be used alone as it loads settings on all Screens. A Master memory saves the selected Screens in the current settings. Using Filters, select which Screens, Aux, Layers and Layer settings to save in the Master memory. -
Page 119: Save A Master Memory From Existing Screen Memories
USER MANUAL USER MANUAL 16.2.2 Save a Master memory from existing Screen memories Because a Master memory is made from Screen memories. It is also possible to create a Master memory by using existing Screen memories. Screens / Aux., click the Memories tab in the right panel. -
Page 120: Edit A Master Memory
USER MANUAL USER MANUAL 16.2.5 Edit a Master memory 1. Load a Master memory. 2. Click Save to open the Master memory saving window. 3. Select the settings to save. 4. Select the existing Master memory slot to edit. 5. Click Save to overwrite the previous Master memory. 16.3 Screen Memories 16.3.1 Save a Screen memory A Screen memory saves the selected Screen in the current settings. -
Page 121: Load A Screen Memory
USER MANUAL USER MANUAL 16.3.2 Load a Screen memory 1. In Screens / Aux., click the Memories tab in the right panel. 2. Select Screen mode and click Load. 3. If needed, enable Auto Scale to adapt the loaded memory to fit the Screen. 4. -
Page 122: Layer Memories
USER MANUAL USER MANUAL 16.4 Layer Memories 16.4.1 Save a Layer memory A Layer memory saves the selected Layer in the current settings. Using Filters, select which Layer settings to save in the Layer memory. By default, all Layer settings are selected. -
Page 123: Rename A Memory
USER MANUAL USER MANUAL 16.5 Rename a Memory 1. In Screens / Aux., click the Memories tab in the right panel. 2. Select Master, Screen or Layer mode. 3. Click Edit. 4. Click in the top right corner of the memory slot to open the Label and Color fields. 5. -
Page 124: 7 Multiviewers
USER MANUAL USER MANUAL Multiviewers Tip: Go to Multiviewers after all pre-configurations are set. A Multiviewer is an output displaying a user customizable selection of Widgets as display resources. A Widget works like a layer and can display a program, preview, input, image or timer. One Multiviewer can display up to 64 Widgets. -
Page 125: Sources - Left Panel
USER MANUAL USER MANUAL 17.2.1 Sources - Left panel The Sources are located in the left panel. Click the icons to show the corresponding sources: Multiviewers sources Inputs Images Timers Screens Note: Widgets can display Program and Preview for Screens and Program only for Aux Screens. The following information are displayed per source content: - Source number - Source label... -
Page 126: Widget Selection
USER MANUAL USER MANUAL 17.2.1.2 Set Preview mode for Preview Screen widgets 1. In Multiviewers, click Screens in the source panel. 2. Hover a Preview Screen and click to show preview options: Setting Description / Setting selection name Select what is displayed in the Preview widget: - Display Program during transitions Preview - Display Nothing during transitions... -
Page 127: Multiviewer Layout Editor
USER MANUAL USER MANUAL 17.2.3 Multiviewer layout editor Click to open the layout editor, a smart tool to place widget in the Multiviewers easily. Setting name Description / Setting selection Columns & Create a custom grid Rows Reduce the area of this layout (ex: Top: 50% Margin will ignore the top half of the Multiviewer) Spacing... -
Page 128: Widget Properties
USER MANUAL USER MANUAL 17.3 Widget properties When a widget is selected, the following widget settings are available in the Properties tab: Setting name Description / Setting selection Enable: Toggle to show/hide the widget OSD (On Screen Display): View - Off: Hide OSD information - Basic: Only show the title of the source in widget OSD - Detailed: Show full OSD information on the widget Source... -
Page 129: Widget Source - Assign Content To A Widget
USER MANUAL USER MANUAL 17.3.1.3 2x2 Slicer mode with DPH104 When using a Multiviewer output in 2x2 Slicer mode with a DPH104, the signal is automatically divided in 2x2 following the selected format. Tip: Use the layout editor to make sure the widgets are placed in their corresponding ¼ of the Screen. 17.3.2 Widget source - Assign content to a widget Multiviewers, click a source icon in the left panel. -
Page 130: Load A Multiviewer Memory At Startup
USER MANUAL USER MANUAL 17.4.3 Load a Multiviewer memory at startup Load a user defined Multiviewer memory when turning the LivePremier device on. 1. In Multiviewers, click the Memories tab in the right panel and click . 2. Enable Load At Startup and select a Multiviewer memory slot to load at startup for each Multiviewer output. -
Page 131: 8 User Maintenance And Troubleshooting
USER MANUAL USER MANUAL User Maintenance and Troubleshooting 18.1 User Maintenance – Air filter The LivePremier unit is equipped with a removable air filter at the front of the unit. Tip: For optimal performance, this air filter must be cleaned by the user regularly (once a year). Tools: Torx T20 screwdriver, duster or vacuum. -
Page 132: Appendices
USER MANUAL USER MANUAL APPENDICES Appendix A. RC400T The RC400T event controller has been designed to instantly access the crucial functionalities of the LivePremier image processor such as screens, layers, sources and memories. The RC400T offers 56 user programmable buttons, a high-resolution T-bar and a three-axis joystick for easy and fast programming (assign source in layers, load memories, etc.). - Page 133 To turn the lamp on, go to front panel settings and enable Power on light. Note: For more information on the XLR lamp for RC400T, visit www.analogway.com or contact Analog Way support. A.b.c. Program/Preview key Press the Program/Preview key to toggle between Program and Preview modes.
- Page 134 USER MANUAL USER MANUAL A.b.g. RC400T rear panel Fig. 43 - RC400T - rear panel The rear panel is composed of: - One power plug with a switch button - One Ethernet plug for network connection - One HDMI plug - One USB plug Note: The HDMI plug will be fully functional in a future version.
- Page 135 USER MANUAL USER MANUAL A.c.d. Control multiple units with the RC400T When multiple LivePremier units are enabled for remote control, the RC400T displays a new home page to select the device to use (by default, the active unit is the one configured in the first device slot). - Press the Exit/Menu button on the Setting page to display the device selection page.
- Page 136 USER MANUAL USER MANUAL A.d.b. Layer selection The RC400T has two modes for selecting layers. Layers Shows all available live layers in the selected Screens as BKG Layer, Layer 1, Layer 2, etc. This mode allows quick selection of the same layer in multiple screens. It is recommended when programming shows with lots of Screens and Layers.
- Page 137 USER MANUAL USER MANUAL A.d.e. Set a layer position and size Note: This is only applicable to one layer. If multiple layers are selected, changes will only be applied to the layer leader (first selected). 1. Select the Program or Preview mode. 2.
- Page 138 USER MANUAL USER MANUAL A.d.h. Load a Layer memory 1. Select the Program or Preview mode. 2. Select one or multiple layers. 3. On another row, press the LCD key and select a Layer Memories. 4. Select a memory. Use the rotary encoder to change the page if needed. The Layer memory is now loaded to the selected Screen.
- Page 139 USER MANUAL USER MANUAL A.d.m. Save a Master Memory Note: Saving Master Memories from the RC400T will always include all Screens, all layers and all layer properties. 1. Select the Program or Preview mode to save the corresponding Screens. 2. On the User keys area, press the Memories key. 3.
- Page 140 USER MANUAL USER MANUAL A.d.q. Button color guide Button color Description - Element, Source or Function is available and not selected Solid green - T-bar is disabled - Screen, Aux or Multiviewer element is selected for edition and for transition - Master Memory is currently loaded - Screen Memory is loaded in all selected Screens - Layer Memory is loaded in all selected Layers...
- Page 141 USER MANUAL USER MANUAL Appendix B. Other LivePremier control options LivePremier units are also compatible with the Analog Way Shot Box² and Control Box and also with Companion or Universe installed on a Stream deck. Stream deck + Shot Box²...
- Page 142 Caution: - Do not use the synch or QSFP connectors with equipment other than Analog Way’s. - The device sync and QSFP connections do not require the device to be powered down, but disconnecting them when the device is running will result in disruption to the show and is to be avoided.
- Page 143 USER MANUAL USER MANUAL When properly connected, an orange LED (indicating connection speed) should be on and a green LED (indicating network activity) should be blinking. Fig. 2 - Ethernet cable connection The Link connector cards of all devices must be daisy-chained to create a closed ring via the DAC link cables. Note: The first and the last device must be within 3 meters maximum of each other (max length of DAC cables).
- Page 144 USER MANUAL USER MANUAL C.b. Share setup The Link feature offers two types of sources: - Global: shared between the devices and available for all layers o Up to 16 x 2K / Dual resolution or 8 x 4K inputs can be used as global sources o Up to 48 image slots can be defined as global - Local: processed only on a device receiving the source Note: All devices must be on the same Link network to exchange data in real time and to synchronize the sources on a global level.
- Page 145 USER MANUAL USER MANUAL Tip: Use regions for an easier visibility of global / local setups and to optimize the use of sources. Fig. 5 - Example of a Global Screen setup with Global Region 1 and Local Region 2 C.b.d.
- Page 146 USER MANUAL USER MANUAL C.c.b. Firmware update The updater file extracted on the Leader machine is automatically sent to all the Followers and runs on each device in parallel. The Leader machine restarts when the entire system is updated. Note: The Default reset can be launched from a Leader device for the entire system, breaking the link configuration. C.c.c.
- Page 147 Tip: Use the search bar at the bottom of the Sources panel to find a source or to display a batch of sources with the same char in the label. C.e. Controllers Analog Way controllers using USB port must be connected to the Leader device and activated on the WebRCS. Note: - Presets are available for the first two Multiviewers.
-
Page 148: Contact Information
USER MANUAL USER MANUAL CONTACT INFORMATION Analog Way Inc. Analog Way SAS - Headquarters Analog Way Ltd Tel.: +1 212 269 1902 Tel.: +33 (0)1 81 89 08 60 Tel.: +852 2967 0428 3047 Summer Oak Place 2/4 rue Georges Besse... - Page 149 USER MANUAL USER MANUAL www.analogway.com...
Need help?
Do you have a question about the LivePremier AQL-RS-ALPHA and is the answer not in the manual?
Questions and answers
