Agriframes 30144-TBK Assembly Instructions

In the unlikely event you are missing any components please call 0117 934 1790 and state the name of the
product, size and description of the item. i.e. Classic Round Arch Matt Black 1.2m, End Plug.
ROUND ARCH
CURVES
2 X REDUCED
AT ONE END
4 X END PLUGS
10 X MOISTURE
SEALS
1 X ALLEN KEY
16 X GRUB
SCREWS IN RING
CLAMPS &
SPARES IN A BAG
AGRIFRAMES, Journal House, Hartcliffe Way, Bristol, BS3 5RJ
ORDERS 0117 934 1790 FAX + (0)117 934 1791 ORDER ONLINE www.agriframes.co.uk
PARTS LIST
2 X WITH
PLAIN ENDS
8 X SPACER BARS WITH
RING CLAMPS
8 X UPRIGHTS
1 X HOLE MAKER
* Optional Lattice & Ties
Arch Cells Quantity
1.2m 4 x 3 4
1.5m 4 x 3 4
Assembly Instructions for Classic Round Arch
Product Code: 30144-TBK & 30145-TBK
Please read the assembly instructions
carefully prior to construction.
Tips:
Positioning of the Spacer Bars
In many cases the position of the Spacer
Bars is down to personal preference.
However, if you have the lattice option you
will need to leave the correct distance
between bars.
On the bottom section the Spacer Bars need
to be at least 3 inches above the base of the
tube.
Issues:
If you are experiencing any issues with your Agriframes product please contact our customer services team on
0117 934 1790 and quote your order reference.
WARNING, Contains small parts, tools and plastic bags. Keep children away until the unit is assembled and
everything is cleared away.
NOTE the card, paper sack, and polythene bags are recyclable - please dispose of carefully.
MISSING PARTS PROCEDURE, please call our customer service team on 0117 934 1790 and quote your order
reference and quote the missing part. E.g. ASO-----, 2 uprights missing.
Matt Black
Tips:
Spacer Bars
Before positioning the Spacer Bars on the
uprights, half screw in the grub screws to
the ring clamps on the spacer bars, to
reduce the risk of losing the screws.
Once correctly positioned tighten the
grub screw to secure the spacer bar to
the uprights.
Lattice Panel Option
For illustrative purposes we have only
shown one side fixed with the lattice
panels. Attach panels to both sides as you
proceed.
