- Page 1 BUILT-IN GAS ON GLASS COOKING HOBS INSTALLATION ADVICES - INSTRUCTIONS FOR THE USE • CVG6PX LPG • CVG938WPB LPG CANDY HOOVER GROUP S.R.L. • Via Comolli 16 • 20861 Brugherio (MB) Italy...
-
Page 2: Declaration Of Ce Conformity
Dear Customer, Thank you for having purchased and given your preference to our product. The safety precautions and recommendations reported below are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance. -
Page 3: Important Safety Precautions And Recommendations
IMPORTANT SAFETY PRECAUTIONS AND RECOMMENDATIONS IMPORTANT: This appliance is designed and manufactured solely for the cooking of domestic (household) food and is not suitable for any non domestic application and therefore should not be used in a commercial environment. The appliance guarantee will be void if the appliance is used within a non domestic environment i.e. - Page 4 • CAUTION: this appIiance must only be installed in a permanently ventilated room in compliance with the applicable regulations. • Do not operate your appliance by means of an external timer or separate remote-control system. • Do not carry out cleaning or maintenance operations on the appliance without having previously disconnected it from the electric power supply.
- Page 5 • The manufacturer declines all liability for injury to persons or damage to property caused by incorrect or improper use of the appliance. • WARNING: During use the appliance and its accessible parts become hot; they remain hot for some time after use. Care should be taken to avoid touching heating elements on –...
- Page 6 • If the power supply cable is damaged, it must be replaced only by an authorized service agent in order to avoid a hazard. • If the appliance is not fitted with a supply cord and a plug, or with other means for disconnection from the supply mains having a contact separation in all poles that provide full disconnection under overvoltage category III conditions, means for disconnection...
- Page 7 ADVICE ADVICE for the for the INSTALLER INSTALLER...
- Page 8 IMPORTANT: • The appliance is designed and approved for domestic use only and should not be installed in a commercial, semi commercial or communal environment. Your product will not be guaranteed if installed in any of the above environments and could affect any third party or public liability insurances you may have. •...
-
Page 9: Installation
INSTALLATION TECHNICAL INFORMATION FOR THE INSTALLER In order to install the cooker top into the kitchen fixture, a hole with the dimensions shown in fig. 1.1a or 1.1b has to be made, bearing in mind the following: ■ 30cm wide models: •... -
Page 10: Standard Installation
STANDARD INSTALLATION X=8 mm X=4 mm Fig. 1.1a FLUSH INSTALLATION (MODELS WITHOUT METAL TRIM/S AND X=4 ONLY) If you wish to install the hob flush with the work surface, it is neccessary to execute/carry out a miling in the hole of the cut-out as indicated in figs. 1.1b. X=4 mm Fig. - Page 11 Measures (mm) Description A (*) B (*) C (**) D1 (***) E1 (***) E1A (***) E1B (***) 30cm wide models 50 ( 1 ) 60cm wide models 54 ( 2 ) or 60 ( 2 ) for 75cm wide models flush installation 90cm wide models...
-
Page 12: Fastening The Cooktop
FASTENING THE COOKTOP Fig. 1.2a Each cooktop is provided with an installation kit including brackets and screws for fastening the cooktop to benches from 30 to 40mm thick. 30, 60 and 75cm wide models (fig. 1.2a, 1.2b): The kit includes two “F” type brackets (for the front of the cooktop), two “R”... - Page 13 Fig. 1.2f Fig. 1.2g Rear Fixing Brackets Front Fixing Brackets Fig. 1.2h Fig. 1.2i G (G1) G (G2)
-
Page 14: Ventilation Requirements
VENTILATION REQUIREMENTS The appliance must be installed in compliance with applicable local regulations concerning ventilation and the evacuation of exhaust gases. Intensive and prolonged use may require extra ventilation, e.g. opening a window, or more efficient ventilation increasing the mechanical suction power if this is fitted. CHOOSING SUITABLE SURROUNDINGS The room where the gas appliance is to be installed must have a natural flow of air so that the gas can burn (in compliance with applicable local regulations). -
Page 15: Gas Section
GAS SECTION GAS INSTALLATION REQUIREMENTS Important ! This appliance must be installed and serviced only by a suitably qualified, • registered installer. The installer shall refer to the local standards in force. • Failure to install the appliance correctly could invalidate any manufacturer’s warranty. - Page 16 CONNECTING THE COOKTOP TO THE GAS SUPPLY The gas connection fitting (fig. 2.1) is made up of: • the floating nut; • the elbow; • the gaskets; The gas connection must be carried out by an authorised person according to the relevant local standards.
- Page 17 ADDITIONAL GAS CONNECTION REQUIREMENTS When connecting the cooktop to the gas supply with rigid pipes or a flexible hose, make sure that: • You use rigid pipes or a flexible hose compliant with applicable local regulations. The flexible hose shall be of the correct construction for the type of gas being used and of the correct size to maintain the heat output of the appliance.
-
Page 18: Lubrication Of The Gas Taps
Some models - for the gas category check the data label attached on the appliance TABLE FOR THE CHOICE OF THE INJECTORS Cat: II 2H 3+ G30/G31 (Countries IT-ES-PT-IE-GB-CH) 28-30/37 mbar 20 mbar Cat: II 2E+3+ G30/G31 G20/G25 (Countries FR-BE) 28-30/37 mbar 20/25 mbar Nominal... - Page 19 REPLACEMENT OF THE INJECTORS Auxiliary, If the injectors are not supplied they can semi-rapid be obtained from the “Service Centre”. and rapid burner Select the injectors to be replaced according to the “TABLE FOR THE CHOICE OF THE INJECTORS”. nozzle diameters, expressed hundredths of a millimetre, are marked on...
- Page 20 SETTING THE MINIMUM OF THE COOKTOP BURNERS In the minimum position the flame must have a length of about 4 mm and must remain lit even with a quick turn from the maximum position to that of minimum. The flame adjustment is done in the following way: •...
-
Page 21: Electrical Section
ELECTRICAL SECTION – connect the blue wire to the IMPORTANT: The appliance must be terminal marked with the letter “N” installed by a qualified technician or coloured black; according with the current local – connect the brown wire to the regulations and in compliance with terminal marked with the letter “L”... - Page 22 SECTION OF THE SUPPLY CABLE TYPE “H05V2V2-F” resistant to temperatures of 90°C 220-240 V 50-60 Hz 3 x 0,75 mm (*) (**) 220V ac 18/3 (*) (**) Connection possible with plug and outlet (**) Connection with wall box connection. REPLACING THER POWER SUPPLY CABLE WARNING: If the power supply cable is damaged, it must be replaced only by an authorised service agent in order to avoid a hazard.
- Page 24 ADVICE ADVICE for the for the USERS USERS...
-
Page 25: Features And Technical Data
FEATURES AND TECHNICAL DATA Fig. 1.1 Fig. 1.2 Fig. 1.3 Fig. 1.4 Fig. 1.5 Fig. 1.6 11 10 9 8 15 8... - Page 26 Fig. 1.7 Fig. 1.8 13 8 9 11 10 Fig. 1.9 Fig. 1.10 Fig. 1.11 13 8 9 10 11 15 14 8 9 10 11...
-
Page 27: Gas Burners
GAS BURNERS Auxiliary (A) 1,00 kW Semirapid (SR) 1,75 kW Semirapid (SR) 1,75 kW Rapid (R) 2,50 kW Double-ring compact (DRC) 3,50 kW Double-ring (DR) 3,50 kW Dual (DB) (*) 4,20 kW IMPORTANT: The Dual burner is controlled by two separate knobs; one knob for the inner crown only and one knob for the outer crown only. -
Page 28: How To Use The Cooktop
HOW TO USE THE COOKTOP BRUCIATORI A GAS Gas flow to the burners is adjusted by turning the knobs (illustrated in fig. 2.1a or 2.1b) which control the safety valves. Turning the knob, so that the indicator line points to the symbols printed on the panel, achieves the following functions: –... -
Page 29: Lighting The Burners
LIGHTING THE BURNERS DUAL BURNER - SOME MODELS ONLY ignite burner, following instructions are to be followed: The Dual Burner is a very flexible burner which allows different regulations and Press in the corresponding knob and optimal cooking. turn counter-clockwise (fig. 2.2a or It is composed by one inner and one outer 2.2b) to the full flame position marked crown: the inner and outer crown can be... -
Page 30: Choice Of The Burner
CHOICE OF THE BURNER On the control panel, near every knob there is a diagram that indicates which burner is controlled by that knob. The suitable burner must be chosen according to the diameter and the capacity used. The burners and pans must be used in accordance with the following instructions: DIAMETERS OF PANS WHICH MAY BE USED ON THE BURNERS BURNERS MINIMUM... - Page 31 SMALL PAN ADAPTER - SOME MODELS ONLY (OPTIONAL) This adapter is to be placed: • on top of the (smaller) auxiliary burner when using small diameter pans, in order to prevent them from tipping over; • on top of the Dual burner (used with the inner crown only) when using small diameter pans, in order to prevent them from tipping over.
- Page 32 WOK STAND (OPTIONAL) (fig. 2.5a - 2.5b, 2.6a - 2.6b, 2.7a - 2.7b) This special grille for woks should be placed over the pan-rest for the double-ring compact, double ring or Dual burner (depending on models). Warning: • Do not use woks without this special wok stand correctly in place. •...
- Page 33 MODELS WITH DOUBLE-RING BURNER WRONG CORRECT Fig. 2.6a Fig. 2.6b MODELS WITH DUAL BURNER WRONG CORRECT Fig. 2.7a Fig. 2.7b...
- Page 34 Fig. 2.8...
-
Page 35: Important Warnings
RESTRICTIONS ON GRIDDLE PAN USAGE X=8 mm Cod. 0422497 - ß0 IMPORTANT! Do not use cast iron pans and plates, or pots in terracotta, stoneware or refractory material for grilling or toasting: RISK of glass breaking due to extreme heat transmission by irradiation. INSTRUCTIONS FOR CORRECT GRILLING •... -
Page 36: Cleaning And Maintenance
CLEANING AND MAINTENANCE GENERAL ADVICE Before you begin cleaning, you must ensure that the appliance is switched off • and disconnected from the electrical power supply. Important: The use of suitable protective clothing/gloves is recommended when • handling or cleaning of this appliance. Under no circumstances should any external covers be removed for servicing or •... -
Page 37: Important Warning
ENAMELLED SURFACES All the enamelled parts must be cleaned with a sponge and soapy water only or other non- abrasive products. Dry preferably with a microfibre or soft cloth. If acid substances such as lemon juice, tomato conserve, vinegar etc. are left on the enamel for a long time they will etch it, making it opaque. - Page 38 BURNERS These parts must be cleaned using a sponge and soapy water or other suitable non- abrasive products. Dry with a soft cloth. Warning! Not dishwasher safe. If left on the surface for a length of time, acidic substances such as lemon juice, tomato sauces and passata, vinegar and other similar products will damage the surface and dull its shine.
- Page 39 Fig. 3.2 Fig. 3.3 MODELS WITH DOUBLE-RING MODELS WITH COMPACT BURNER DOUBLE-RING BURNER Fig. 3.4 Fig. 3.5...
- Page 40 MODELS WITH DUAL BURNER Fig. 3.6 Fig. 3.7 Fig. 3.8...
-
Page 41: Pan Supports
PAN SUPPORTS These parts must be cleaned using a sponge and soapy water or other suitable non- abrasive products. Dry with a soft cloth. Warning! Not dishwasher safe. After cleaning, they must be repositioned properly (fig. 3.9). It is very important to check that the pan supports have been correctly positioned. Failure to do so can cause serious problems. - Page 44 The manufacturer will not be responsible for any inaccuracy resulting from printing or transcript errors contained in this brochure. We reserve the right to carry out modifications to products as required, including the interests of consumption, without prejudice to the characteristics relating to safety or function.
