  • Page 1 User manual Dishwasher HV642E60UK...

  • Page 2: Table Of Contents

    Contents Your dishwasher ........................Safety instructions ........................Installation ..........................Declaration of conformity ......................Overflow guard ......................... Packaging ..........................Disposal ............................ Symbols on the appliance ......................Before washing for the first time ................... 1. Water hardness ........................2. Basic settings ........................Top up with rinse aid ........................
  • Page 3 Troubleshooting ........................Installation ..........................Safety instructions ........................Setup ............................Drainage connection ......................... Connection to water supply ...................... Electrical connection ......................... Service ............................. Number of program cycles ....................... Technical data and energy labelling ..................Technical data ........................... Information for consumers ......................Information for test institute ......................

  • Page 4: Your Dishwasher

    Your dishwasher Install the dishwasher, see the chapter Installation. Then open the door and press The first time the dishwasher is switched on, it is important that you choose the right settings to ensure good dishwashing results. See the chapter Before washing for the first time. On/Off Start/Stop Select program...

  • Page 5: Safety Instructions

    Safety instructions Read the user manual and keep it in a safe place! Number of standard place settings: 13 Never use the dishwasher for any purpose other than that specified in these operating instructions. Do not load the dishwasher door or dishwasher baskets with anything other than dishes.

  • Page 6: Installation

    WARNING! Children must be supervised – dishwasher detergent is corrosive! Installation See the chapter Installation. Declaration of conformity We hereby declare that this appliance is in conformity with the relevant European directives and the requirements of the relevant standards. Overflow guard The overflow guard starts pumping out the water and turns off the water supply if the water level in the dishwasher exceeds the normal level.

  • Page 7: Before Washing For The First Time

    Before washing for the first time 1. Water hardness In order to achieve good dishwashing results, the dishwasher needs soft water (water with low mineral content). Hard water leaves a white coating on dishes and the dishwasher. Checking water hardness Water hardness is specified using German degrees of water hardness (°dH), French degrees of water hardness (°fH), English degrees of water hardness (°eH) or millimoles per litre (mmol/l).

  • Page 8: Basic Settings

    2. Basic settings The first time the dishwasher is switched on, it is important that you choose the right settings to ensure good dishwashing results. See page 19. Set up: Rinse aid Water hardness TAB (All-in-one detergent) Top up with rinse aid Drying is faster and a better result is achieved Lift up to open if you use rinse aid.
  • Page 9 WARNING! In order to avoid rust stains a dishwashing program must be started immediately after adding salt.

  • Page 10: Greener Dishwashing

    Greener dishwashing Save energy and water When using a dishwasher in a residential setting, less energy and water are generally used compared to washing the dishes by hand. Do not rinse under running water Do not rinse the dishes under running water as this will lead to increased energy and water consumption. Simply scrape off large food particles before loading the dishwasher.

  • Page 11: Loading The Dishwasher

    Loading the dishwasher Fragile dishes Some cookware is not dishwasher safe. This can be for several reasons. Some materials cannot withstand high heat, others can be damaged by dishwasher detergent. Exercise caution with, for example, handmade items, fragile decoration, crystal/glassware, silver, copper, tin, aluminium, wood and plastic.

  • Page 12: Lower Basket

    3 positions Knife stand Raising and lowering the upper basket 1. Pull out the upper basket. 2. Grab the sides of the upper basket with both hands and lift it up. 3. If the upper basket is raised while in the top position, it will drop to the bottom position. Note that both sides of the basket must always be set to the same height.

  • Page 13: Cutlery Basket

    Adjustable plate supports The adjustable plate supports can be folded down to make it easier to load pots and bowls. Cutlery basket Place cutlery with the handles facing down, except for knives, and spread them out as much as possible. Ensure that spoons do not stack inside each other. Place the cutlery basket in the lower basket.

  • Page 14: Using The Dishwasher

    Using the dishwasher Add detergent Follow the instructions on the detergent packaging. This dishwasher is fitted with a water softener, so use detergent and rinse aid doses suitable for soft water. Too much detergent can result in less effective dishwashing and also entails greater environmental impact.

  • Page 15: On/Off

    On/Off Start/Stop Select program Display NOTE! The control panel only reacts to use when the door is open. On/Off Open the door and press . Also turn on the water tap if it is turned off. Select program Select a program to suit the type of dishes and how dirty they are. Eco 55° is always pre-selected. Press one or more times until the desired program is activated, which is indicated by an indicator light.

  • Page 16: Select Option

    Hygiene 70° This program is ideal to use where demands on hygiene are extra high, e.g. for baby bottles and cutting boards. The temperature is high both in the main wash and in the final rinse. Self-clean Self-cleaning program for hygienic cleaning of the dishwasher tub, spray arms and spray pipes. This program should be run (with no dishes in the machine) using normal dishwasher detergent or citric acid.

  • Page 17: If You Want To Load More Dishes

    If you want to load more dishes Open the door. The dishwasher stops automatically. Add the dishes and close the door. After a while, the dishwasher continues the program. Power failure If the dishwasher is turned off due to a power failure when a dishwashing program is running, the program continues when power is restored.

  • Page 19: Settings

    Settings 1. Open the door and press 2. To open the dishwasher's settings menu, press and hold until SEt is shown on the display. 3. Press to step through the settings menu. 4. Press to step through the alternatives. 5. Confirm the selected setting by pressing 6.
  • Page 20 Settings Alternatives 5:00 (Off) Activate this setting when using an all-in-one detergent that (All-in-one detergent) 5:01 (On) contains rinse aid. This setting reduces the rinse aid dosage and affects how often the dishwasher's built-in softener is regenerated. Pre-selected at factory: 5:00 Error readout Any error messages.

  • Page 21: Care And Cleaning

    Care and cleaning Top up with rinse aid When the rinse aid needs topping up, the above symbol lights on the display. Lift up to open Press to close 1. Open the rinse aid compartment lid. 2. Carefully top up with rinse aid to the level marked MAX. 3.

  • Page 22: Clean The Filter

    Clean the filter The filter traps larger food particles, which cannot get past the drainage pump. Empty the filter when necessary. It should be cleaned at regular intervals depending on how often the dishwasher is used. 1. Turn the locking ring anticlockwise and lift the filter straight up. 2.

  • Page 23: Clean The Outside Of The Dishwasher

    Lower spray arm Pull the lower spray arm straight up to release it. Clean the outside of the dishwasher Door and door seal Open the door. Clean the sides of the door and the door seal regularly with a slightly damp cloth. Clean the door seal at the lower front edge of the dishwasher with a washing-up brush.

  • Page 24: Winter Storage/Transport

    7. Plug the machine in again. Drainage pump stop NOTE! Do not forget to refit the drainage pump stop. Unblocking the inlet hose filter If the water supply contains small particles, the outer filter on the inlet hose may become blocked, which results in the Water inlet fault error message.

  • Page 25: Troubleshooting

    Troubleshooting Error messages Action Overfilling water Unblocking the drainage pump. See the chapter Care and cleaning. If the problem persists, contact your nearest service centre. Water outlet fault See "Water remains in the dishwasher" under "Problem" in the table below. If the problem persists, contact your nearest service centre.
  • Page 26 Problem Possible causes Action Check whether the Delayed Press and hold for three start option has been selected. seconds if you want to cancel the Delayed start option. The plug is not plugged into the Check. wall socket. A fuse/circuit breaker has been Check.
  • Page 27 Problem Possible causes Action All stainless steel can cause In order to avoid marks and tar- spots on silver if they come into nishing, separate dishes made contact during dishwashing. from different metals, such as Aluminium can also cause spots silver, stainless steel and alu- on dishes.
  • Page 28 Problem Possible causes Action Debris in the drainage pump. Clean the drainage pump. See the chapter Care and cleaning. Drainage pump stop missing. Check that the yellow drainage pump stop (on the right in the bottom drain) is in place. See the chapter Care and cleaning.

  • Page 29: Installation

    Installation It is important that you read through and follow the instructions and directions below. Conduct installation and connection in accordance with the separate installation instructions. [mm] Remove the plastic strips if the recess dimension is 596-598 mm. Exercise caution! The edges may be sharp. Wear protective gloves! Cover door length.

  • Page 30: Drainage Connection

    Mount the protective film beneath the worktop and up around the edge. The function of the protective film is to protect the worktop from moisture. (The protective film is in the enclosed plastic bag.) Note that the door springs may need adjusting after a cover door has been fitted. Adjust the left and right door springs equally until the door is evenly balanced.

  • Page 31: Service

    Read the chapter Troubleshooting before contacting the service centre. If you have encountered a problem that you cannot resolve, please contact your nearest service centre for professional help, see global.hisense.com. Our website also has information about spare part availability and what you can repair yourself.

  • Page 32: Technical Data And Energy Labelling

    2) In accordance with the EN 60436 standard. Information for consumers Information about your appliance can be found at global.hisense.com. You can also find information in the EU Product Registration database for Energy Labelling, EPREL. Scan the QR code on the energy label supplied with the dishwasher (or go to https://eprel.ec.europa.eu and search for the model name).
  • Page 33 Your notes...
  • Page 34 Your notes...
  • Page 35 Your notes...
  • Page 36 871908-a4 We reserve the right to make changes.
