8. Tightening torque

M8 Cylinder head nuts
M5 Crankcase screws
Spark-plug
M6 and M8 reduction screws
M5 reed valve body screws
Optional automatic decompressor
M10 Crankshaft pulley nut (engines without clutch)
M5 Ignition coil screws
M5 Starter sprocket screws
M6 electric starter screws
M5 x 16 mm electric starter bracket screws
M5 x 20 mm electric starter bracket screws
M5 Carburetor/Airbox (plastic) connector screws
M6 Electravia carbon propeller screws
03/03/2024 V6
23 Nm
10 Nm
26 Nm
15 Nm
4 Nm
10 Nm
40 Nm
10 Nm
10 Nm
13 Nm
5 Nm
2 Nm
3 Nm
8 Nm
1 kg/m = 9.81 Nm
