Technical data

Dimensions
Weight
Supply Voltage
Load
Power consumption
Terminal Capacity
Temperature
Humidity
Material (casing)
Type
Safety

Microwave frequency compatibility

The allowable frequency of operation of this product is different depending on region. Please select the correct order
code using the table below.
Suffix
blank UK, China, India, Middle East, Malaysia, Hong Kong, Singapore
-R2 Australia and all of Europe except: UK, France, Portugal, Germany, Switzerland, Austria, Slovak Republic, Republic of Ireland
-R3 France, Portugal, Switzerland
-R4 Germany, Austria, Slovak Republic
-R5 Republic of Ireland

Part numbers

Part number
Detector MWS3A-PRM-LV
MWS3A-PRM-LV-GOLD Ceiling Microwave presence/absence detector 12-24V AC/DC for low current
MWS3A-PRM-LV-OC
Accessories DBB
UHS5
UNLCDHS
IMPORTANT NOTICE!
This device should be installed by a qualified electrician in
accordance with the latest edition of the IEE Wiring
Regulations and any applicable Building Regulations.
FM 45789 EMS 534520
Due to our policy of continual product improvement CP Electronics reserves the right to alter the specification of this product without prior notice.
8
See diagrams opposite
0.15kg
Min 11.5VDC max 36VDC, min
10VAC max 26.5VAC
MWS3A-PRM-LV
Low voltage supply with relay output
rating 16A resistive 10A inductive
MWS3A-PRM-LV-GOLD
Low voltage with relay contact for low
on resistance suitable for control wire
applications 3A resistive load. Not
suitable for inductive loads
MWS3A-PRM-LV-OC
Low voltage supply with open collector
output, rating 50mA, 30VDC max
On 1100mW, Off 767mW
2
2.5mm
-10ºC to 35ºC
5 to 95% non-condensing
Flame retardant ABS and PC/ABS
Class 2
The microwave radiation emitted by
these units is extremely low power
and complies with ANSI standard
"IEEEC95.1-1999 Standard for Safety
Levels with Respect to Human
Exposure to Radio Frequency
Electromagnetic Fields 3kHz
300GHz."
Description
Ceiling Microwave presence/absence detector 12-24V AC/DC
Ceiling Microwave presence/absence detector 12-24V AC/DC + open collector
output
Surface mounting box
Programming IR handset
Universal LCD IR handset
OHS 642036
IP rating
Compliance
MWS3A-PRM-LV
MWS3A-DBB
Region
IP40
EMC-2004/108/EC
LVD-2006/95/EC
C.P. Electronics Ltd
Brent Crescent
London
NW10 7XR
United Kingdom
Tel: + 44 (0) 333 900 0671
Fax: + 44 (0) 333 900 0674
www.cpelectronics.co.uk
enquiry@cpelectronics.co.uk
Ref: #WD615 Issue 3.1
Frequency
10.587GHz
10.525GHz
9.900GHz
9.350GHz
10.41GHz
