AMG Systems AMG350-14GAT-2S-P300 Installation Manual

Industrial unmanaged switch
Hide thumbs
1
2

Advertisement

Table of Contents

INTERFACE CONNECTIONS

AMG Systems Ltd. 4 Pioneer Way, Castleford, WF10 5QU, UK T: +44 (0) 1767 600 777 E: technical@amgsystems.com
AMG Systems Inc. 62 Spring Hill Road, Trumbull, CT 06611, USA T: +1-855-AMGPOE1 (855-264-7631)
D33752-00
① Insert the Cat5/6 cable into the
RJ45 port.
② Ports 1-14 support IEEE802.3at PoE
output (max 30W per port). 300W
max total PoE budget.
③ If a PD device is connected the
respective PoE LED will turn on.
④ Insert the fiber patch cable into the
SFP module.
Note: SFP ports support 1Gb speed
only. 100Mb SFP's are not supported.
www.amgsystems.com
AMG350-14GAT-2S-P300
AMG350-14GAT-2S-P300
Industrial Unmanaged Switch
Industrial Unmanaged Switch
amgsystems.com
Installation Manual - Hardware
Installation Manual - Hardware
