- Page 1 Kramer Electronics, Ltd. USER MANUAL Model: UTBUS-1 Under the Table Connection Bus...
-
Page 2: Table Of Contents
Figure 1: UTBUS-1 Under a Table Figure 2: UTBUS-1 Under the Table Connection Bus Figure 3: Installing a Kramer TOOL Figure 4: Securing the UTBUS-1 to the Underneath of the Table Tables Table 1: UTBUS-1 Under the Table Connection Bus Features... -
Page 3: Introduction
Rack Adapters; GROUP 11: Sierra Products 2 We recommend that you use only the power cord supplied with this device 3 Download up-to-date Kramer user manuals from our Web site: http://www.kramerelectronics.com 4 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com... - Page 4 Getting Started KRAMER: SIMPLE CREATIVE TECHNOLOGY...
-
Page 5: Overview
Germany-EU, Belgium-France, South Africa, Australia, and “Universal” (for use anywhere) • Lets you install a Kramer TOOL or Pico TOOL inside the body of the unit To achieve the best performance: • Connect only good quality connection cables, thus avoiding interference,... -
Page 6: Your Utbus-1 Connection Bus
Outer Rim For mounting under the table TOOL Mounting Holes (8) Screw in the appropriate holes to install a Kramer TOOL or Pico TOOL Tie Holes (12) Insert the self-locking tie, through the holes to fix the pass-through cables to the inside walls of the unit... -
Page 7: Installing The Utbus-1
Replace Screw Reinsert the two screws to affix the wall plate insert in position, and tighten them. Replace Screw 1 The complete list of Kramer wall plates and module connectors is on our Web site at http://www.kramerelectronics.com... -
Page 8: Installing The Cables
2. Insert the self-locking ties through the tie holes to secure the cables to the inside walls of the enclosure. 5.3 Connect the Kramer TOOL or Pico TOOL (Optional) You can install a Kramer TOOL or Pico TOOL, as illustrated in the example in Figure To connect the Kramer TOOL to the UTBUS-1: 1. -
Page 9: Securing The Utbus-1 Enclosure To The Table
1. Place the unit to the underside of the table and mark the correct location. 2. Insert the four M4.2X16 wood screws into the four rim screw holes and fix the UTBUS-1 to the table. Figure 4: Securing the UTBUS-1 to the Underneath of the Table The UTBUS-1 is ready for use. -
Page 10: Technical Specifications
Power cord, self locking ties, wood screws OPTIONS: Passive wall plate inserts and interfaces 1 Specifications are subject to change without notice 2 The complete list of Kramer wall plates and module connectors is on our Web site at http://www.kramerelectronics.com KRAMER: SIMPLE CREATIVE TECHNOLOGY... - Page 11 EXCLUSION OF DAMAGES The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall not be liable for: 1. Damage to other property caused by defects in this product, damages based upon inconvenience, loss of use of the product, loss of time, commercial loss;...
- Page 12 For the latest information on our products and a list of Kramer distributors, visit our Web site: www.kramerelectronics.com, where updates to this user manual may be found. We welcome your questions, comments and feedback. Safety Warning: Disconnect the unit from the power supply before opening/servicing.
