6. DMX 512 CONTROL
CHANNELS VALUE
CH 1
0-255
CH 2 0-255
CH 3
0-255
CH 4 0-255
0-50
CH 5
51-100
101-150
151-255
CH 6
0-255
NOTICE!
• Be sure to follow figures 2 & 3 when making your
own cables.
• Do not connect the cable's shield conductor to
the ground lug or allow the shield conductor to
come in contact with the XLR' s outer casing.
DMX-512 OUT
3-PIN XLR
XLR FEMALE SOCKET
1 GROUND
SPECIAL NOTE: LINE TERMINATION
When longer runs of cable are used, you may need
to use a terminator on the last unit to avoid erratic
behaviour.
Dimmer
UV Dimmer
W Dimmer
STROBE
- Macro Function
No Function
Macro 1
Macro 2
Sound Mode
SPEED
XLR MALE SOCKET
2 COLD 2 COLD
3 HOT
DESCRIPTION
• Grounding the shield could cause a short circuit
and erratic behaviour.
COMMON
1 GROUND
OUT
3 HOT
Termination reduces signal transmission
problems and interferance. It is always advisable
to connect a DMX terminal ,(resistance 120 Ohm
1/4 W) between pin 2 (DMX-) and pin 3 (DMX+) of
the last fixture.
DMX-512 IN
3-PIN XLR
XLR CONFIGURATION
PIN 1 = GROUND
PIN 2 = NEGATIVE
PIN 3 = POSITIVE
