- Page 1 ProjectorShield™ Installation Guide Ceiling Mount SkyRailPlus™ instruction begins instruction begins Page 3 Page 20 11/22/2023...
-
Page 2: Important Warning
IMPORTANT WARNING USE THIS PRODUCT AT YOUR OWN RISK. NO CLAIM IS MADE AS TO ITS SAFETY, FITNESS, OR RELIABILITY FOR ANY PURPOSE. HITTING GOLF BALLS IN AN INDOOR ENVIRONMENT IS EXTREMELY DANGEROUS! ALWAYS EXERCISE CAUTION WHEN USING YOUR SYSTEM. WE RECOMMEND HITTING 'ALMOST... - Page 3 ProjectorShield™ Ceiling Mount Parts List Parts: Bottom Top Plate ● Bottom Plate ● Left & Right Side Plates ● Back Plate ● Clear Faceplate ● Left Right Hardware: 4 x Bolts ¼”-20 x 4” Long ● 4 x Butterfly Nuts ●...
- Page 4 ProjectorShield™ Ceiling Mount Hole Spacing ● Slots are 10” off center of ProjectorShield™, 20” apart total. Slots are 9” apart ● on each side 10” 10” Slots allow 3” of ● front to back adjustment 9” 3”...
- Page 5 Pre-Drill Mounting Holes and Insert Bolts ● Place Ceiling Bracket on ceiling, positioned center to the projector ● Mark your mounting holes using the slots on either side ● Lower ceiling bracket and verify marked points to Ceiling Mount 9” Hole Spacing diagram (see also previous page) ●...
- Page 6 Moving to prepare ProjectorShield™ Bolts can be left hanging for now. Next steps will prepare the ProjectorShield™ for mounting.
- Page 7 Attach Side Plates to Top Plate 1. Press Side Plate onto Top Plate 2. Push Side Plate backwards until hooks hooks facing forward. Smooth lock into place. Some light force may surface of side plate faces inside. be needed to lock plates into place. *click*...
- Page 8 Attach Side Plates to Top Plate Repeat the previous step and attach Side Plates to both sides...
- Page 9 Secure safety straps to Top and Side Plates Zipping safety straps are used as an extra level of protection to keep the ProjectorShield™ held together in case of a catastrophic damaging event. 3. Add 4 x safety straps to left and right side plates.
- Page 10 Attach Bottom Plate 4. Flip unit over and push bottom plate 5. Push bottom plate forward and lock onto hooks facing up into place with hooks. Some light force may be needed to lock plates into place.
- Page 11 Secure safety straps to Bottom and Side Plates 6. Add 4 x safety straps to left and right side plates and bottom plate. Trim off tails.
- Page 12 Attach Faceplate 8. Push faceplate down and lock into 7. Turn unit over and carefully attach place with hooks. Some light force may clear faceplate onto hooks on the be needed to lock plates into place. front of your ProjectorShield™. *click* *click*...
- Page 13 Secure Safety Straps to Faceplate and Side Plates 9. Add 4 x safety straps to Faceplate and Sides. Trim off tails. Safety strap holes...
- Page 14 Hang ProjectorShield™ 10. Lift partially built ProjectorShield™ 11. Slide ProjectorShield™ backwards, up around projector and feed the bringing faceplate close to lens of pre-hung bolts through passthrough projector. Tighten bolts and secure holes in Ceiling Bracket. ProjectorShield™ to ceiling.
- Page 15 Adjust Projector inside Projector Shield 12. Through the open back of the ProjectorShield™, plug in power and video cables and adjust your projector image to fit to your screen. Be sure to thoroughly secure your projector in place.
- Page 16 Attach Back Plate 13. Press back plate onto back hooks. 14. Push back plate up and lock into place with hooks. Some light force may be needed to lock plates into place. *click* *click*...
- Page 17 Secure safety straps to Back Plate and Side Plates 15. Add 4 x safety straps to back plate on left and right sides...
- Page 18 Installation Complete!
- Page 19 Ceiling Mount instruction begins Page 3 SkyRailPlus™ instruction begins Page 20...
- Page 20 ProjectorShield™ for SkyRailPlus™ Parts List Parts: Bottom Top Plate ● Bottom Plate ● Left & Right Side Plates ● Back Plate ● Clear Faceplate ● Left Right Hardware: 2 x ¼-20 Hex Nuts ● 2 x 2” long ¼-20 Knobs ●...
- Page 21 Prepare SkyRailPlus™ (for previous SkyRailPlus™ owners ONLY) 1. Remove previously installed knobs from 2. Remove top plate. This will not be sliding plate assembly needed with the ProjectorShield™.
- Page 22 Attach Side Plates to Top Plate 4. Push Side Plate backwards until hooks 3. Insert hooks into Side Plate with lock into place. Some light force may be hooks facing forward. needed to lock plates into place. *click* Repeat and attach Side Plates to both sides...
- Page 23 Secure safety straps to Top and Side Plates Zipping safety straps are used as an extra level of protection to keep the ProjectorShield™ held together in case of a catastrophic damaging event. 5. Add 4 x safety straps to left and right side plates.
- Page 24 Attach Bottom Plate 6. Attach Bottom Plate to hooks on 7. Push Bottom Plate backwards until hooks bottom of Side Plates. lock into place. Some light force may be needed to lock plate into place. *click* *click*...
- Page 25 Secure safety straps to Bottom and Side Plates 8. Add 4 x safety straps to left and right side plates and bottom plate. Trim off tails. Safety strap holes...
- Page 26 Mount Partial ProjectorShield™ Enclosure to SkyRailPlus™ 9. Before attaching clear faceplate or backplate, bring the partially built ProjectorShield™ Enclosure over and around the projector. Center the ProjectorShield™ Enclosure on projector using the different slots in Top Plate. ✅...
- Page 27 Mount Partial ProjectorShield™ Enclosure to SkyRailPlus™ 10. After centering the ProjectorShield™ on the projector, insert the 2x included ¼-20 Hex Nuts into the closest slots in Top Plate. 11. Thread knobs through the projector sliding tray into the ¼-20 Hex Nuts. DO NOT OVER TIGHTEN.
- Page 28 Attach Clear Faceplate 12. Carefully attach the clear faceplate onto hooks on the front of your ProjectorShield™. *click* *click* Push faceplate down and lock into place with hooks. Some light force may be needed to lock plates into place. 13. Add 4 x safety straps to Faceplate and Sides.
- Page 29 Adjust Projector 14. Adjust projector position for the best image fit for your enclosure. Next using the slots in the Top Plate, side the ProjectorShield™ as close as possible to the lens of the projector. ✅...
- Page 30 Attach Back Plate 15. Press back plate onto back hooks, push up and lock into place. Some light force may be needed to lock plates into hooks. *click* *click* 16. Add 4 x safety straps to back plate and Sides. Trim off tails. Safety strap holes...
- Page 31 Installation Complete!
