CURVE
ARCHITECTURAL INDOOR LED EMERGENCY LIGHT
INSTALLATION AND OPERATING INSTRUCTIONS
IMPORTANT SAFEGUARDS
Equipment is intended for connection to FLEXIBLE CONDUIT ONLY
When using electrical equipment, basic safety precautions should always be
followed including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1. Install in accordance with all national and local electrical codes.
2. Disconnect power at circuit breaker or fuse before installing or servicing the unit.
3. DO NOT mount in hazardous locations, near gas or near electric heaters.
4. DO NOT let power cords contact hot surfaces.
5. Equipment should be mounted in locations and at heights where it will not be readily subject to
tampering by unauthorized personnel.
6. DO NOT use accessory equipment not recommended by the manufacturer. The use of such
equipment may cause unsafe conditions and will void the unit's warranty.
7. DO NOT use this equipment for other than its intended purpose.
8. All servicing should be performed by qualified personnel only.
9. Allow battery to charge for 24 hours before first use.
10. For indoor use only.
SAVE THESE INSTRUCTIONS
2575 Metropolitan Drive • Trevose, PA • 19053 U.S.A
Telephone: (215) 244-4204 • Fax: (215) 244-4208

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Curve and is the answer not in the manual?

Questions and answers

Related Manuals for Evenlite Curve

Summary of Contents for Evenlite Curve

  • Page 1 CURVE ARCHITECTURAL INDOOR LED EMERGENCY LIGHT INSTALLATION AND OPERATING INSTRUCTIONS IMPORTANT SAFEGUARDS Equipment is intended for connection to FLEXIBLE CONDUIT ONLY When using electrical equipment, basic safety precautions should always be followed including the following: READ AND FOLLOW ALL SAFETY INSTRUCTIONS 1.
  • Page 2 TEST SWITCH/STATUS INDICATOR RELEASE TABS REAR PANEL FIGURE A Prior to removing knockouts, support rear panel on a base to prevent panel deflection and/or damage to the cover’s flatness. REAR VIEW FIGURE B 2 ISOLITE    WWW.ISOLITE.COM EVENLITE WWW.EVENLITE.COM REV-1  20230726 Z410201...

  • Page 3: Installation Instructions

    When snapping the unit together, ensure that the plug and mating connector are aligned so that the unit receives power. 7. Adjust the lamp heads down and outward for the designed emergency illumination. EVENLITE WWW.EVENLITE.COM ISOLITE    WWW.ISOLITE.COM REV-1  20230726...
  • Page 4 NOTE: Secure wire connectors near the upper latches. AVOID grouping wires and wire nuts in the area of thse PCB and the battery as this may limit engagement of connector to PCB. 4 ISOLITE    WWW.ISOLITE.COM REV-1  20230726 EVENLITE WWW.EVENLITE.COM Z410201...

  • Page 5: Wiring Instructions

    BLUE REMOTE LAMP NEGATIVE (OPTIONAL) BLACK 120-277 VAC YELLOW REMOTE LAMP POSITIVE (9.6 VDC) (OPTIONAL) WIRING INSTRUCTIONS AC Only Operation Wiring Instructions (9W Wiring) FIGURE E ORANGE 277VAC MOUNTING KNOCKOUTS BLACK 120VAC BATTERY CONNECTION ISOLITE    WWW.ISOLITE.COM EVENLITE WWW.EVENLITE.COM REV-1  20230726 Z410201...
  • Page 6 When installing remote lamps, ensure that adequate space is provided between the line voltage wires and the remote lamp wires [FIGURE F]. Always wire the devices in accordance with local and national electrical codes. 6 ISOLITE    WWW.ISOLITE.COM REV-1  20230726 EVENLITE WWW.EVENLITE.COM Z410201...

  • Page 7: Mounting Instructions

    If the battery charge is insufficient, the 30 second functional test will be performed instead. NOTE: The lamp current will be calculated upon the running of the first self-diagnostic test. Subsequent self-diagnostics checks will verify the lamp current against the initial measurement. EVENLITE WWW.EVENLITE.COM ISOLITE    WWW.ISOLITE.COM REV-1  20230726...

  • Page 8: Lamp Adjustment

    This Emergency Light has Two Adjustable LED lampheads. Each lamphead can be tilted down up to 20° and rotated up to 90° away from the wall. FIGURE H TILT HEAD ASSEMBLY LAMPHEAD ROTATION EVENLITE WWW.EVENLITE.COM 8 ISOLITE    WWW.ISOLITE.COM REV-1  20230726 Z410201...

  • Page 9: Status Indications

    Failure indications can be cleared by correcting the indicated fault and pushing and holding the “TEST” Switch for 1 second. STATUS INDICATIONS Status indications for the self-testing / self-diagnostic system are shown on the following page. ISOLITE    WWW.ISOLITE.COM EVENLITE WWW.EVENLITE.COM REV-1  20230726 Z410201...
  • Page 10 The USER-TEST can be performed up to 20 feet away using the standard “INFRARED REMOTE TESTING TRANSMITTER”. By aiming the TRANSMITTER [FIGURE I] at the Curve, and pushing the "TEST SWITCH" [FIGURE A] at the unit for 1 second, the lamps will illuminate for 30 seconds. If the “STATUS”...

  • Page 11: Maintenance

    SELF-TESTING / SELF-DIAGNOSTIC system according to the requirements of NFPA 101. If battery replacement is required, replace using the BATTERY INSTALLATION procedure. For the 9W Curve, the unit will be supplied with a Nickel Metal Hydride (Ni-MH) battery, replace with part number B350007 only.
  • Page 12 SAVE THESE INSTRUCTIONS 2575 Metropolitan Drive • Trevose, PA • 19053 U.S.A Telephone: (215) 244-4204 • Fax: (215) 244-4208 Z410201...
