RAZOR-3 SERIES
RZR3 DIE CAST ALUMINUM EXIT SIGN / FIXTURE
INSTALLA TION AND OPERATING INSTRUCTIONS
When using electrical equipment, basic safety precautions should always be followed including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS:
1.
DO NOT use outdoors.
2.
DO NOT mount near gas or electric heaters.
3.
Equipment should be mounted in locations and at heights where it will not be
readily subject to tampering by unauthorized personnel.
4.
The use of accessory equipment is not recommended by the manufacturer.
Use of such equipment may cause an unsafe condition.
5.
DO NOT use this equipment for other than intended use.
6.
Conduct periodic visibility tests in accordance with the applicable installation
code (such as NFPA 101).
7.
Supply connections MUST be made inside the junction box.
8.
Install using recommended junction box ONLY.
9.
Servicing of this equipment should be performed by a qualified service
personnel.
10. Install sign indoors only where not exposed to direct unfiltered sunlight, liquid
spray or temperatures outside of the range of 10
11. Before installing unit, disconnect power at breaker panel.
CONSERVER LA FICHE D'INSTRUCTION
Z410139 Rev F
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS
2575 Metropolitan Drive • Trevose • PA 19053 U•S•A
Telephone: (215) 244-4204 • Fax: (215) 244-4208
C to 40
C.
o
o
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Evenlite RAZOR-3 Series
Summary of Contents for Evenlite RAZOR-3 Series
- Page 1 RAZOR-3 SERIES RZR3 DIE CAST ALUMINUM EXIT SIGN / FIXTURE INSTALLA TION AND OPERATING INSTRUCTIONS IMPORTANT SAFEGUARDS When using electrical equipment, basic safety precautions should always be followed including the following: READ AND FOLLOW ALL SAFETY INSTRUCTIONS: DO NOT use outdoors.
-
Page 2: Table Of Contents
RAZOR-3 SERIES RZR3 DIE CAST ALUMINUM EXIT SIGN / FIXTURE TABLE OF CONTENTS Section 1.0 Installation Preparation Page 3 1.1 Knockouts and Chevrons Page 3 1.2 Transformer Wiring Page 4 Section 2.0 Installation Options Page 5 2.1 Back Mount Installation Page 5 2.2 Canopy &... -
Page 3: Installation Preparation
SECTION 1.0: Installation Preparation This Exit Sign is designed to be mounted to a junction box (supplied by others). It can be either back, top or side mounted. The single face unit back mounts to a standard 4” Square (4S) junction box. Dual circuit options will require a deep junction box. -
Page 4: Transformer Wiring
3. To remove directional indicators, remove light guide assembly and diffusers and set aside. Support front cover and knock out desired indicator(s). Knock out desired directional indicators (chevrons) supporting Figure 4: Removing the the front panel as shown. directional indicators (chevrons) SECTION 1.2: Transformer Wiring ***Before installing unit, disconnect power at breaker panel*** AC Single Circuit Input: The transformer plate assembly will be provided assembled as shown... -
Page 5: Installation Options
SECTION 2.0: INSTALLATION OPTIONS The Razer 3 Series has several different Mounting options available to fit a wide variety of applications. Those options are: 1. Back Mount Installation (See Section 2.1) 2. Canopy/Top Mount Installation (See Section 2.2) 3. End Mount Installation (See Section 2.3) SECTION 2.1: BACK MOUNT INSTALLATION (SINGLE FACE SIGN) 1. -
Page 6: Canopy & Top Mount Installation
SECTION 2.2: CANOPY & TOP MOUNT INSTALLATION (SINGLE OR DOUBLE FACE SIGNS) 1. Secure transformer plate to junction box. Guide transformer secondary leads through canopy and connect to sign. 2. Secure canopy to sign and then fasten to spider plate. If an optional security cover will be utilized, it must be assembled to sign prior to securing the canopy to the sign. -
Page 7: End Mount Installation
SECTION 2.3: END MOUNT INSTALLATION (2) PPH #6-32 x 3/8” long Screws Canopy to Exit Sign Transformer supplied with Exit sign Standard 4 inch J Box Plate Not supplied with sign. SCREW LENGTH IS CRITICAL. DO NOT SUBSTITUTE. Canopy Terminate Transformer secondary wires to Sign. -
Page 8: Master-Remote Sign Configuration
SECTION 3.0: MASTER-REMOTE SIGN CONFIGURATION The Master - Remote product (RZMR3) is supplied with 2 signs. The master sign (Figure 13) is provided with a system battery, spider plate assembly (for power) and an option connector used to connect the two signs. The remote sign (Figure 14) is assembled in the same manner as the master sign, without a spider plate assembly. - Page 9 Route remote wire from master sign to remote sign via the knock out in the rear panel. The remote sign can be mounted to a junction box (as shown) or secured safely to the wall using anchors. The remote option printed circuit assembly should be installed into the sign as shown below.
-
Page 10: Diagnostics
SECTION 4.0: DIAGNOSTICS For units with Self-Testing/ Self Diagnostics option, refer to the section on next page for operating instructions. Battery back-up units without Self-Testing/ Self Diagnostic option Include a battery diagnostics system which indicates, via flashing of the indicator light, that the battery needs replacement. If flashing occurs after a new installation, check that the battery plug is properly inserted into the circuit board connector (For reference, see Figure 15). -
Page 11: Options
SECTION 5.0: OPTIONS SECTION 5.1: FLASHER/ FIRE ALARM Battery Backup Emergency signs that are equipped with the FLASH in EMERGENCY MODE OPTION will automatically flash in the emergency mode but not flash on AC operation. AC Only exit signs that are equipped with the flash option will flash continuously while power is supplied. - Page 12 THIS PAGE INTENTIONALLY LEFT BLANK...
