CURVE
ARCHITECTURAL INDOOR LED EMERGENCY LIGHT
INSTALLATION AND OPERATING INSTRUCTIONS
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be
followed including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1. Install in accordance with all national and local electrical codes.
2. Disconnect power at circuit breaker or fuse before installing or servicing the unit.
3. DO NOT mount in hazardous locations, near gas or near electric heaters.
4. DO NOT let power cords contact hot surfaces.
5. Equipment should be mounted in locations and at heights where it will not be readily subject to
tampering by unauthorized personnel.
6. DO NOT use accessory equipment not recommended by the manufacturer. The use of such
equipment may cause unsafe conditions and will void the unit's warranty.
7. DO NOT use this equipment for other than its intended purpose.
8. All servicing should be performed by qualified personnel only.
9. Allow battery to charge for 24 hours before first use.
10. For indoor use only.
SAVE THESE INSTRUCTIONS
2575 Metropolitan Drive • Trevose, PA • 19053 U.S.A
Telephone: (215) 244-4204 • Fax: (215) 244-4208
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Evenlite CURVE
Summary of Contents for Evenlite CURVE
- Page 1 CURVE ARCHITECTURAL INDOOR LED EMERGENCY LIGHT INSTALLATION AND OPERATING INSTRUCTIONS IMPORTANT SAFEGUARDS When using electrical equipment, basic safety precautions should always be followed including the following: READ AND FOLLOW ALL SAFETY INSTRUCTIONS 1. Install in accordance with all national and local electrical codes.
- Page 2 LEDs, Arms, Test Button, Front Housing, Cover, Buttons to Press Prior to removing knockouts, support rear panel on a base to prevent panel deflection and/or damage to the cover’s flatness. REAR VIEW 2 ISOLITE WWW.ISOLITE.COM EVENLITE WWW.EVENLITE.COM REV-1 20230724 Z410201...
-
Page 3: Installation Instructions
7. Plug battery male connector into battery female connector on PCBA. 8. Snap the front cover on the back plate. 9. Restore power and press test button. LED heads will turn on. 10. Adjust the lamp heads direction as needed. EVENLITE WWW.EVENLITE.COM ISOLITE WWW.ISOLITE.COM REV-1 20230724... -
Page 4: Wiring Instructions
MAXIMUM MOUNTING HEIGHT (9W UNIT ONLY) = 21 FEET MAXIMUM MOUNTING HEIGHT (16W UNIT ONLY) = 28 FEET WIRING INSTRUCTIONS AC Only Operation Wiring Instructions (9W Wiring) ORANGE 277VAC WHITE NEUTRAL BLACK 120VAC MOUNTING KNOCKOUTS BATTERY CONNECTION EVENLITE WWW.EVENLITE.COM 4 ISOLITE WWW.ISOLITE.COM REV-1 20230724 Z410201... - Page 5 If the battery charge is insufficient, the 30 second functional test will be performed instead. NOTE: The lamp current will be calculated upon the running of the first self-diagnostic test. Subsequent self-diagnostics checks will verify the lamp current against the initial measurement. EVENLITE WWW.EVENLITE.COM ISOLITE WWW.ISOLITE.COM REV-1 20230724...
-
Page 6: Lamp Adjustment
LAMP ADJUSTMENT This Emergency Light has Two Adjustable LED lampheads. Each lamphead can be tilted down up to 20° and rotated up to 90° away from the wall. TILT HEAD ASSEMBLY LAMPHEAD ROTATION EVENLITE WWW.EVENLITE.COM 6 ISOLITE WWW.ISOLITE.COM REV-1 20230724 Z410201... -
Page 7: Status Indications
Failure indications can be cleared by correcting the indicated fault and pushing and holding the “TEST” Switch for 1 second. STATUS INDICATIONS Status indications for the self-testing / self-diagnostic system are shown on the following page. ISOLITE WWW.ISOLITE.COM EVENLITE WWW.EVENLITE.COM REV-1 20230724 Z410201... -
Page 8: Maintenance
SELF-TESTING / SELF-DIAGNOSTIC system according to the requirements of NFPA 101. If battery replacement is required, replace using the BATTERY INSTALLATION procedure. For the 9W Curve, the unit will be supplied with a Nickel Metal Hydride (Ni-MH) battery, replace with part number B350007 only. -
Page 9: Setup And Operation
The lamp current calculation will be performed on the next function test. CCEA APPROVAL- Approval for CCEA City of Chicago Environmental Airspace is available as a factory option. EVENLITE WWW.EVENLITE.COM Z410201 ISOLITE WWW.ISOLITE.COM... - Page 10 SAVE THESE INSTRUCTIONS 2575 Metropolitan Drive • Trevose, PA • 19053 U.S.A Telephone: (215) 244-4204 • Fax: (215) 244-4208 Z410201...
