Kellys Junior Owner's Manual

JUNIOR
Dear customer,
Thank you for buying KELLYS Junior bicycle. We strongly encourage you to read the owner's manual
first, to enjoy your bicycle and for safety reasons, too. By doing so, you will have a better understanding
for the general operation of your bike.
Your local KELLYS dealer will provide warranty services and repairs of your new bike.
TYPE OF BICYCLE USE
The bicycle is designed for a ride on public cityroads and a good quality asphalt roads. If you will use
bicycle on roads and it is not equipped with lights and reflectors, you have to equip it by yourself
according the law in your country.
SET UP OF SADDLE AND HANDLEBAR POSITION
All function parts of the bicycle are adjusted by manufacturer and checked by your local dealer, so
you can safely use your bike immediately. The only thing you need to do is to set up the saddle,
handlebar and stem position, to provide yourself with maximum comfort and safe operation of
brakes and control systems of the bike.
SADDLE
SADDLE LEVEL SETTING-UP
Take a seat on bicycle. Put your foot on pedal which is in the position nearest to the ground. Heel
must be on pedal. Leg must be stretched and slightly bent in the knee for reaching right level of
saddle. If you have saddle too high you will overcharge legs and back muscles. Knee and hips muscle
overcharge will be caused be too low levelled saddle.
SETTING UP OF SADDLE POSITION AND ANGLE
Most recommended position of saddle is when saddle is parallel with ground. Try some positions of
saddle and finally choose the one which is best for you. It is possible to move saddle in front or back
towards the handlebar. Angle setting-up and moving of saddle is possible by screw on lock of seat
tube. Release the screw, move the saddle and set up the angle and then tighten screw to keep saddle
safely in requested position. Make sure that the screw is tightened properly.
IMPORTANT WARNING
Make sure the minimum insertion mark on the seatpost is not visible above the bike frame after the seatpost
is inserted into the frame! The seatpost quick-release lever must be securely tightened, so the seatpost is
not turnable inside the frame. Move the lever of the quick-release to the sides only, to positions OPEN or
CLOSE. Do not turn locked quick-release lever, it could get damaged!
Torque tightening values:
Screw M8 for seat tube lock
Screw M5 for seat tube lock
Screw M8 for seat tube fastening in the bicycle frame
Screw M5 for seat tube fastening in the bicycle frame
*Recommended values must be kept if instruction on product does not vary.
STEM AND HANDLEBARS
Check what type of stem is used on your bicycle.
STEM WITHOUT THREAD (A-HEAD TYPE STEM)
This type of stem is fastened on fork neck and is fixed by 2 Allen screws. Height of stem and handlebars
is setting-up by rings which are placed between stem and headset or by stem change for another
with different angle. Allowance of headset is setting-up by stem.
Release 2 Allen screws on stem sleeve which lock stem to the fork and release screw on headset
as well. You can set up allowance of headset by this screw to provide fork rotation easy. Do not let
headset to have its own allowance. At first tighten headset screw. Now set up stem direction and
tighten stem by 2 Allen screws on stem sleeve.
Torque tightening values:
Screw M5 for stem sleeve 6 - 8 Nm*
Screw M6 for stem sleeve
Screw M5 for handlebars sleeve 6 - 8 Nm*
*Recommended values must be kept if instruction on product does not vary.
STEM WITH THREAD
This kind of stem is plugged-in fork neck. It is secured by long screw and nut inside fork. Long screw
has shape of oblique frustum. Release long screw and slew the stem for stem level and direction
OWNER'S MANUAL
20 - 25 Nm*
10 - 12 Nm*
25 Nm*
6 - 8 Nm*
15 Nm*
GB
1
