To adjust the headlight on a BMW Motorrad R 1300 GS:

1. Switch on the ignition.
2. Start the engine.
3. Use the tool from the onboard toolkit to turn the adjusting screw.
4. Adjust the headlight beam throw as needed.
5. If the motorcycle is later ridden with a lower load, return the headlight to its basic setting.
6. If unsure about the correct headlight beam throw, have it checked by a specialist workshop, preferably an authorized BMW Motorrad retailer.

This answer is automatically generated

Summary of Contents for BMW Motorrad R 1300 GS

Page 1 MOTORRAD RIDER'S MANUAL R 1300 GS MAKE LIFE A RIDE...
Page 2 Vehicle data Model Vehicle Identification Number Colour code Date of first registration Registration number Dealership details Person to contact in Service department Ms/Mr Phone number Dealership address/phone number (company stamp)
Page 3 YOUR BMW. We congratulate you on your choice of a vehicle from BMW Motorrad and welcome you to the community of BMW riders. Familiarise yourself with your new vehicle so that you can ride it safely and confidently in all traffic situations.
Page 4 GENERAL STATUS INSTRUCTIONS INDICATORS Quick & easy reference Indicator and warning Abbreviations and sym- lights bols Menu view Equipment Pure Ride view Technical data Sport view Currency My Vehicle view Additional sources of Warning indicators information Certificates and operat- INSTRUMENT ing licences CLUSTER Data memory...
Page 5 Dynamic Traction Handlebars Spring preload Control (DTC) Dynamic Suspension Adjustment (DSA) RIDING Riding mode Riding mode Pro Safety information Cruise control Regular check Radar-based rider as- Starting sistance systems Running in Distance control (Act- Off-road use Shifting gear ive Cruise Control Brakes ACC) Parking your motor-...
Page 6 Lane change warning ACCESSORIES (SWW) General notes Dynamic Suspension Power sockets Adjustment (DSA) USB charging sockets Riding mode Cases Dynamic Brake Con- Topcase trol Navigation system Tyre pressure control (RDC) CARE Gear Shift Assistant Hill Start Control Care products (HSC) Washing the vehicle ShiftCam Cleaning easily dam-...
Page 7 SERVICE call Reporting safety-rel- evant defects INDEX Recycling BMW Motorrad Service BMW Motorrad service history BMW Motorrad mo- bility services Maintenance work Maintenance sched- BMW Motorrad run- ning-in check Maintenance confirm- ations Service confirmations APPENDIX Declaration of Con-...
Page 8 GENERAL INSTRUCTIONS...
Page 9 QUICK & EASY REFERENCE ABBREVIATIONS AND SYMBOLS EQUIPMENT TECHNICAL DATA CURRENCY ADDITIONAL SOURCES OF INFORMATION CERTIFICATES AND OPERATING LICENCES DATA MEMORY BLUETOOTH CONNECTIVITY FUNCTIONS INTELLIGENT EMERGENCY CALL SYSTEM...
Page 10 GENERAL INSTRUCTIONS ATTENTION Special notes QUICK & EASY REFERENCE and precautionary meas- An important aspect of this ures. Non-compliance can lead rider's manual is that it can be to damage to the vehicle or ac- used for quick and easy refer- cessory and, consequently, to ence.
Page 11 Lane change warning. plete with all the BMW Motorrad EQUIPMENT optional equipment When you ordered your originally ordered. BMW Motorrad, you chose Optional accessories. various items of custom You can obtain equipment. This rider's manual BMW Motorrad describes optional equipment...
Page 12 Your authorised tration documents, or can be BMW Motorrad retailer obtained from your authorised will be happy to answer any BMW Motorrad retailer or an- questions you may have. other qualified service partner or specialist workshop. The Internet specifications in the vehicle...
Page 13 Data protection rights DATA MEMORY In accordance with applicable General data protection laws, vehicle Control units are installed in users have certain rights in re- the vehicle. Control units pro- lation to the manufacturer of cess data that they receive, for the vehicle or in relation to example, from vehicle sensors, companies which collect or...
Page 14 Status reports of the vehicle website. and its individual components, The vehicle owner can also re- for example wheel speed, quest that a BMW Motorrad wheel circumferential velo- retailer or another qualified city, deceleration Environmental conditions, for service partner or specialist...
Page 15 BMW Motorrad retailer or an- this technical information can other qualified service partner be read out of the vehicle to- or specialist workshop.
Page 16 GENERAL INSTRUCTIONS vehicle and can be changed or Incorporation of mobile reset at any time. devices If required, data can be entered Depending on the equipment, in the entertainment and mobile devices connected to communication system of the the vehicle, for example smart- vehicle, for example using a phones, can be controlled using smartphone.
Page 17 is enabled by the vehicle's utory functions are excluded own transceiver unit or from this. using personally integrated Services from other providers mobile devices, for example When using online services smartphones. Online functions from other providers, these can be accessed through this services are subject to the re- wireless connection.
Page 18 BMW Motorrad operate in a Bluetooth network, Connected app with wireless technology of this The BMW Motorrad Connec- nature it is not possible to en- ted app enables the user to sure fault-free communications call up usage data and vehicle in every situation.
Page 19 centre that is commissioned by gency call system satisfies the the vehicle manufacturer. European directives for the For information on operating protection of personal data. the intelligent emergency call The intelligent emergency call system and its functions see system processes personal data 97).
Page 20 GENERAL INSTRUCTIONS Location determination Automatic emergency call The position of the vehicle can The system is designed so that, be determined exclusively by following a sufficiently serious the mobile phone network accident, which is detected by provider based on the mobile sensors in the vehicle, an emer- phone site locations.
Page 21 contact with those involved in the accident if required. Data storage The data for an activated emergency call is stored in the vehicle. The data contains information on the emergency call, for example the location and time of the emergency call. The voice recordings of the emergency call are stored at the emergency call centre.
Page 22 GENERAL VIEWS...
Page 23: Table Of Contents
GENERAL VIEW, LEFT SIDE GENERAL VIEW, RIGHT SIDE UNDERNEATH THE SEAT MULTIFUNCTION SWITCH, LEFT MULTIFUNCTION SWITCH, RIGHT MULTIFUNCTION SWITCH, RIGHT INSTRUMENT CLUSTER...
Page 24: General View, Left Side
GENERAL VIEWS GENERAL VIEW, LEFT SIDE Table of tyre pressures Payload table USB charging interface (underneath the stor- age compartment lid) 238) Fuel filler neck ( 164) Air filter (underneath side panel, left) ( 220) Passenger grab handle Seat lock ( 133) Rear footrest Rider footrest...
Page 25: General View, Right Side
GENERAL VIEW, RIGHT SIDE Air filter (underneath side Oil filler opening panel, right) ( 220) 204) Brake-fluid reservoir, front Brake-fluid reservoir, rear 207) 208) Power socket ( 236) Spring preload at rear wheel ( 145) Vehicle identification number (on steering head) Type plate (on the frame, front right)
Page 26: Underneath The Seat
GENERAL VIEWS UNDERNEATH THE SEAT Fuses ( 231) Diagnostic connector 233) Toolkit ( 201)
Page 27: Multifunction Switch, Left
MULTIFUNCTION SWITCH, LEFT High-beam headlight and headlight flasher 100) Cruise control ( 109) Hazard warning lights 102) Multi-function rocker switch ( Turn indicators ( 102) Horn MENU rocker button Multi-Controller ( Functions list (...
Page 28: Multifunction Switch, Right
GENERAL VIEWS MULTIFUNCTION SWITCH, RIGHT without intelligent emergency call Steering lock Central locking system Ignition ( Riding mode ( 105) Emergency-off switch (kill switch) ( Starting engine ( 152)
Page 29: Multifunction Switch, Right
MULTIFUNCTION SWITCH, RIGHT with intelligent emergency call Steering lock Central locking system Ignition ( Riding mode ( 105) Emergency-off switch (kill switch) ( Starter button ( 152) SOS button Intelligent emergency call 152)
Page 30: Instrument Cluster
GENERAL VIEWS INSTRUMENT CLUSTER Indicator and warning lights ( Instrument cluster Indicator light DWA ( 125) Keyless Ride ( Photosensor (for auto- matic measurement of ambient brightness)
Page 32 STATUS INDICATORS...
Page 33 INDICATOR AND WARNING LIGHTS MENU VIEW PURE RIDE VIEW SPORT VIEW MY VEHICLE VIEW WARNING INDICATORS...
Page 34: Indicator And Warning Lights
STATUS INDICATORS INDICATOR AND WARNING LIGHTS Turn indicators, left 102) High-beam headlight 100) General warning light Turn indicators, right 102) Warning light, drive mal- function ( DTC ( ABS ( Automatic daytime riding light ( 101) Auxiliary headlights 101)
Page 35: Menu View
MENU VIEW Hill Start Control ( 12 Ambient temperature Speedometer 13 Menu section Cruise control ( 109) Speed Limit Info ( Distance control ( 117) Front collision warning 119) Rider info. status line Recommendation to up- shift ( Gear indicator Clock ( 10 Connection status 11 Muting (...
Page 36: Pure Ride View
STATUS INDICATORS PURE RIDE VIEW START SCREEN Hill Start Control ( 13 Heated grips ( 128) Change of operating fo- 14 Outside temperature cus ( warning ( Rev. counter ( Rider info. status line Speedometer Riding mode ( 105) Recommendation to up- shift ( Gear indicator Speed Limit Info (...
Page 37 REV. COUNTER Scale The warmer the engine, the Engine speed range higher the speed at which the Upper/red engine speed red engine speed range starts. range When operating temperature is reached, the display of the red Needle engine speed range no longer Secondary indicator changes.
Page 38 STATUS INDICATORS Range Recommendation to upshift Range readout 1 indicates how The recommendation to upshift far you can ride with the fuel in the status line 1 or in the remaining in the tank. This dis- Pure Ride view 2 indicates the tance is calculated on the basis best time to upshift economic- of average consumption and...
Page 39: Sport View
SPORT VIEW Maximum DTC torque re- duction Actual DTC torque reduc- tion Rev. counter Maximum heel angle, left Actual heel angle in corners for left and right Maximum heel angle, right Current retardation rate during braking Maximum retardation rate...
Page 40: My Vehicle View
STATUS INDICATORS MY VEHICLE VIEW START SCREEN Check Control display Mode of presentation Coolant temperature Range ( Odometer Service display ( Tyre pressure, rear On-board voltage 226) Engine oil level ( Tyre pressure, front...
Page 41 between them are displayed On-board computer and trip for each wheel. computer Immediately after the ignition is switched on, only dashes are displayed. The sensors do not start transmitting tyre pressure signals until the first time the vehicle accelerates to more than the minimum speed stated below: RDC sensor is not active...
Page 42 For further information about BMW Motorrad RDC, see the section entitled "Engineering details" ( 190). Service requirements When the next service is due...
Page 43: Warning Indicators
Green CHECK OK 1: no mes- WARNING INDICATORS sage, optimum values. Mode of presentation White circle with small "i" 2: Warnings are indicated by the information. corresponding warning lights. Yellow warning triangle 3: Warnings are indicated by the warning, value not ideal. 'General' warning light showing Red warning triangle 3: warn- in combination with a dialogue...
Page 44 STATUS INDICATORS their occurrence until they are White: (---) No valid value acknowledged. available. Dashes 5 are dis- If symbol 2 is actively dis- played instead of a numerical played, it can be acknow- value. ledged by tilting the Multi- To some extent, indi- Controller to the left.
Page 45 Warnings, overview Indicator and Display text Meaning warning lights is displayed. Outside tempe- rature warning lights up Radio-operated Remote key not yellow. key out of range in range. lights up Keyless Ride Keyless Ride yellow. failed ( failure lights up Replacing battery Remote key bat- yellow.
Page 46 STATUS INDICATORS Indicator and Display text Meaning warning lights flashes red. Serious fault in Serious fault the power supply in the power supply! lights up The faulty bulb is Bulb faulty yellow. displayed. flashes yel- The faulty bulb is low. displayed.
Page 47 Indicator and Display text Meaning warning lights flashes. Serious drive mal- function ( lights up Engine control No communica- yellow. failed ( tion with en- gine control. shows. lights up Engine in emer- Fault in the en- yellow. gency-operation gine control. mode ( flashes red.
Page 48 STATUS INDICATORS Indicator and Display text Meaning warning lights lights up Tyre pressure Tyre pressure yellow. monitoring (RDC) check failure! failed ( lights up Battery for tyre RDC sensor bat- yellow. pressure sensor tery weak. weak ( Malfunction, drop Drop sensor sensor ( faulty.
Page 49 Indicator and Display text Meaning warning lights lights up ABS Pro failed ABS Pro fail- yellow. ure! shows. flashes ir- ABS control at regularly. front wheel only quick- DTC intervention flashes. slow- DTC self-dia- flashes. gnosis not com- pleted ( shows.
Page 50 STATUS INDICATORS Indicator and Display text Meaning warning lights lights up DSA fault, Suspension ad- yellow. suspension justment lim- adjustment ited. limited ( lights up DSA fault, Suspension yellow. suspension adjustment adjustment failed. unavailable lights up DSA fault, lower- Ride height. yellow.
Page 51 Indicator and Display text Meaning warning lights Hill Start Control HSC not avail- cannot be activ- able. Engine ated ( not running. lights up Cruise control Cruise control yellow. failed ( has no func- tion. lights up Distance control ACC temporarily yellow.
Page 52 STATUS INDICATORS Indicator and Display text Meaning warning lights Hazard warning flashes lights system green. is switched on flashes green. is displayed in Service due white. Service due! lights up is displayed in yel- Service-due yellow. low. date has passed Service over- due!
Page 53 Ambient temperature The ambient temperature is WARNING displayed in the status line of Risk of black ice forming the instrument cluster. even when temperature is When the vehicle is at a stand- above approx. 3 °C still, the heat of the electrical Risk of accident machine can falsify the ambi- Always take extra care when...
Page 54 The integral battery in the ra- Have the faulty radio-operated dio-operated key has lost a key replaced by an authorised significant proportion of its BMW Motorrad retailer. original capacity. There is no Keyless Ride failed assurance of how long the ra- lights up yellow.
Page 55 Consumers with high power quickly as possible by a spe- consumption are in operation cialist workshop, preferably an (such as heated body warm- authorised BMW Motorrad re- ers), too many consumers are tailer. in operation at one time, or battery faulty.
Page 56 Have the fault rectified as On-board battery quickly as possible by a spe- overheated. Switch cialist workshop, preferably an off the engine or con- authorised BMW Motorrad re- tinue riding with re- tailer. striction to allow cool- Fault in the vehicle battery ing.
Page 57 Rear left turn in- Stop the vehicle immediately. dicator faulty! Have the fault rectified as Rear right turn indic- quickly as possible by a spe- ator faulty! cialist workshop, preferably an Number plate light authorised BMW Motorrad re- faulty! tailer.
Page 58 Have LED light sources re- cialist workshop, preferably an placed as complete units; authorised BMW Motorrad re- consult a specialist work- tailer. shop, preferably an authorised Anti-theft alarm battery weak BMW Motorrad retailer.
Page 59 Consult a specialist work- appointment at a spe- shop, preferably an authorised cialist workshop. BMW Motorrad retailer. This error message is dis- played briefly only after DWA failed the Pre-Ride-Check completes. with anti-theft alarm (DWA) Possible cause: Alarm system failure...
Page 60 Consult a specialist work- met, the oil level cannot be shop, preferably an authorised judged by the system. Dashes BMW Motorrad retailer. ) appear on the display in- Engine temperature high stead of a reading. lights up yellow.
Page 61 Possible cause: workshop, preferably an authorised BMW Motorrad The coolant level is too low. retailer. Check the coolant level. 209) Possible cause: If the coolant level is too low: The temperature sensor has Allow the motor to cool detected a high temperature in down.
Page 62 Have the fault rectified as flashes. quickly as possible by a spe- cialist workshop, preferably an authorised BMW Motorrad re- Serious fault in the tailer. engine control! Rid- ing at mod. speed pos. Engine in emergency- Damage possible.
Page 63 It is possible to continue to cialist workshop, preferably an ride but not recommended. Avoid high load and rpm authorised BMW Motorrad re- ranges if possible. tailer. Have the fault rectified as Serious fault in engine control quickly as possible by a spe- flashes red.
Page 64 STATUS INDICATORS is displayed in yellow. Stop immediately! Check tyre pressure. Tyre press. control. Tyre pressure does Loss of pressure. not match setpoint Stop immediately! Check Check tyre pressure. tyre pressure. Possible cause: Measured tyre pressure is close WARNING to the limit of permitted toler- ance.
Page 65 Instrument cluster in the TYRE preferably an authorised view PRESSURE BMW Motorrad retailer. Tyre pressures table Possible cause: Have the tyre checked for Wireless communication with damage by a specialist work- the RDC sensors has been dis- shop, preferably an authorised rupted.
Page 66 The integral battery in the tyre- by a specialist workshop, pressure sensor has lost a sig- preferably an authorised nificant proportion of its ori- BMW Motorrad retailer. ginal capacity. There is no as- surance of how long the tyre Tyre pressure monitoring pressure monitoring system (RDC) failed can remain operational.
Page 67 Motorcycle dropped Consult a specialist work- shop, preferably an authorised Cannot start engine. BMW Motorrad retailer. Stand motorcycle up- right. Switch ignition Emergency call function failed on/off. Start the en- with intelligent emergency gine. call Possible cause: lights up yellow.
Page 68 (The motorcycle has to reach cialist workshop, preferably an a defined minimum speed authorised BMW Motorrad re- with the engine running for tailer. the wheel sensors to be ABS failed checked: min 5 km/h) lights up yellow.
Page 69 You can continue to ride. quickly as possible by a spe- Bear in mind the more cialist workshop, preferably an detailed information on authorised BMW Motorrad re- certain situations that can tailer. lead to an ABS fault message 174). ABS control at front wheel...
Page 70 STATUS INDICATORS Possible cause: DTC switched off The DTC has detected a de- shows. gree of instability at the rear wheel and has intervened to re- Off! duce torque. The indicator and warning light Traction control de- flashes longer than the duration activated.
Page 71 Have the fault rectified as DSA fault, damping quickly as possible by a spe- adjustment cialist workshop, preferably an with Dynamic Suspension Ad- authorised BMW Motorrad re- justment tailer. lights up yellow. DTC fault lights up yellow. Damping adjustment failed. Limited shows.
Page 72 Bear in mind that damping authorised BMW Motorrad re- adjustment and ride height tailer. adjustment are not available DSA fault, lowering or availability is restricted.
Page 73 BMW Motorrad re- ted. tailer. Bear in mind that ride height cannot be lowered. Lift assistance temporarily You can continue to ride.
Page 74 Have the fault rectified as Operate Hill Start Control. quickly as possible by a spe- 122) cialist workshop, preferably an Hill Start Control authorised BMW Motorrad re- automatically deactivated tailer. flashes yellow. Fuel down to reserve Tank reserve level Possible cause: reached.
Page 75 Operate Hill Start Control. cialist workshop, preferably 122) an authorised BMW Motorrad Hill Start Control cannot be retailer. activated Distance control (Active is displayed. Cruise Control ACC) temporarily failed HSC not available. En- with Riding Assistant gine not running.
Page 76 Have the fault rectified as Have it checked by a quickly as possible by a spe- specialist workshop. Possible cause: cialist workshop, preferably an authorised BMW Motorrad The control unit has detected a retailer. fault. Bear in mind that the front Front collision warning...
Page 77 BMW Motorrad Check radar sensor for retailer. damage. Possible cause: Gear not taught The function of the rear radar with shift assistant Pro sensor is impaired. The gear indicator flashes. Bear in mind that the lane change warning function is Possible cause: temporarily not available.
Page 78 102) regularly by a specialist work- Service display shop, preferably an authorised If service is overdue, the BMW Motorrad retailer. due date or the odometer The vehicle remains oper- reading at which service was ationally reliable and road- due is accompanied by the worthy.
Page 79 The vehicle remains oper- ationally reliable and road- worthy. The vehicle retains its value.
Page 80 INSTRUMENT CLUSTER...
Page 81 WARNINGS CONTROLS MULTI-FUNCTION ROCKER SWITCH MENUS MY VEHICLE SETTINGS BLUETOOTH PAIRING OPERATING FOCUS NAVIGATION MEDIA TELEPHONE SOFTWARE VERSION LICENCE INFORMATION...
Page 82: Warnings
INSTRUMENT CLUSTER WARNINGS CONTROLS Multi-Controller WARNING Operation of a smartphone while riding the vehicle Risk of accident Always comply with the road traffic regulations in force where you are riding. Do not use a smartphone while riding. This applies Multi-Controller with the exception of ap- Move the cursor up in lists plications without opera-...
Page 83: Multi-Function Rocker Switch
MENU rocker button top section of the rocker but- ton. Instructions given by the navigation system are displayed as a dialogue if the menu has not Navigation been called up. Operation of the MENU rocker button is temporarily restricted. Short-press the top section of MULTI-FUNCTION ROCKER MENU rocker button 1: SWITCH...
Page 84 INSTRUMENT CLUSTER Assigning function Operating feedback shows the Press button 1. symbol of the corresponding function 1 and the status of MULTI-ROCKER SWITCH menu opens. the function 2. The arrows 3 Use Multi-Controller 3 to se- show the corresponding setting lect the desired function.
Page 85: Menus
Use Multi-Controller 2 to se- The operating feedback for lect the desired function. the priority-select function is Long-push Multi-Controller 2 shown. to the right. While the operating feedback is visible, press multi-function rocker switch 2 to change the value for the priority-select function.
Page 86: My Vehicle
INSTRUMENT CLUSTER Short-press the bottom sec- Break tion of MENU rocker button 2 to open the corresponding Journey menu. MY VEHICLE Current Call up the on-board computer Speed Call up the My vehicle menu. Consump. Scroll to the right until the menu ON-BOARD COMPUTER Call up the trip computer...
Page 87: Settings
SETTINGS Select the content of the top status line Requirement The vehicle is at a standstill. Change to Pure Ride view. The instrument cluster shows all the information necessary Change to Pure Ride view. for riding on public roads Repeatedly short-press but- from the on-board computer ton 1 to select the value in (e.g.
Page 88: Bluetooth Pairing
Reduce volume: Turn the The pairing of the Multi-Controller down. vehicle to the current Mute: Turn the Multi-Control- BMW Motorrad Connected- ler all the way down. Ride account is reset. Changing system settings BLUETOOTH PAIRING Navigate to...
Page 89 BMW Motorrad Connected app Connect mobile device has to be opened prior to use. Perform pairing. ( Activate the mobile device's During the pairing process, the Bluetooth function (see mo- instrument cluster searches bile device's operating in- for other Bluetooth-compat- structions).
Page 90: Operating Focus
INSTRUMENT CLUSTER Select Rider's helmet OPERATING FOCUS and con- Passenger helm. with preparation for naviga- firm. tion system Make the helmet's communic- Change of operating focus ation system visible. Select If the Navigator is connected, Pair new rider's you can toggle between opera- helmet Pair new pas- and confirm.
Page 91: Navigation
Navigate to Navigation Enter the destination address Favourites Connect a mobile device. Select and confirm destina- tion. Call up the BMW Motorrad Select Start guidance Connected app and start the Enter special destinations route guidance. Navigate to Call up the...
Page 92 INSTRUMENT CLUSTER Select and confirm the special Select a destination from one destination. of the three destination cat- Select egories. Start route guid- and confirm. Select ance Change route guid- in the destination entry. ance Set route criteria Select Add as waypoint Navigate to Navigation add the selected destination...
Page 93: Media
Vehicle is connected to a before riding off. compatible mobile device. The BMW Motorrad Connected app Adjust volume. ( is installed on the mobile Next track: Short-tilt Multi- device.
Page 94: Telephone
INSTRUMENT CLUSTER sible to switch between two TELEPHONE phone calls. Precondition Telephone data The vehicle is connected to a Depending on the mobile compatible mobile device and device, when pairing ( helmet. completes telephone data Telephone calls are automatically sent to the vehicle.
Page 96 OPERATION...
Page 97 IGNITION EMERGENCY-OFF SWITCH (KILL SWITCH) INTELLIGENT EMERGENCY CALL LIGHTING DYNAMIC TRACTION CONTROL (DTC) DYNAMIC SUSPENSION ADJUSTMENT (DSA) RIDING MODE RIDING MODE PRO CRUISE CONTROL RADAR-BASED RIDER ASSISTANCE SYSTEMS DISTANCE CONTROL (ACTIVE CRUISE CONTROL ACC) FRONT COLLISION WARNING (FCW) LANE CHANGE WARNING (SWW) HILL START CONTROL (HSC) ANTI-THEFT ALARM (DWA) TYRE PRESSURE MONITORING (RDC)
Page 98: Ignition
OPERATION IGNITION Radio-operated key The motorcycle is supplied with one radio-operated key and one spare key. If a key is lost or mislaid, consult the in- formation on the electronic im- mobiliser (EWS) ( 94). Indicator light 1 flashes: Loc- The vehicle cannot be ating radio-operated key.
Page 99 The steering lock is disen- gaged: Short-press button 1. Lights and all function circuits are switched on. Engine can be started. Steering lock is engaged: Press and hold down but- ton 1. Press and hold down but- The steering lock disengages. ton 1.
Page 100 You can obtain spare keys lock: only through an authorised Short-press button 1. BMW Motorrad retailer. The Light is switched off. keys are part of an integrated The steering lock does not security system, so the retailer engage.
Page 101 simply inserting the folded Checking battery voltage of radio-operated key into the radio-operated key ring aerial under the seat. Remove the rider's seat. 134) Insert the spare key or folded- in radio-operated key with the empty battery 2 into ring aerial 1.
Page 102 OPERATION Remote key battery weak. Function lim- ited. Change battery. DANGER Swallowing a battery Risk of injury or death An ignition key contains a button cell as its battery. Press button 1. Batteries or button cells, if Key bit flips out. Push battery cover 2 up.
Page 103: Emergency-Off Switch (Kill Switch)
Battery type CR 2032 Install battery cover 2. Indicator light in the instru- ment cluster flashes. The radio-operated key is again ready for use. Engine switched off EMERGENCY-OFF SWITCH Normal operating position (KILL SWITCH) (run) INTELLIGENT EMERGENCY CALL with intelligent emergency call Emergency call via BMW Press the SOS button in an...
Page 104 The BMW Call Center answers in this language. The language for the emergency call can be changed only by the authorised BMW Motorrad retailer. The time until transmission The language assigned to of the emergency call is dis- the vehicle varies from the played.
Page 105 The connection was estab- The time until transmission lished. of the emergency call is dis- played. During that time, it is possible to cancel the emer- gency call. To cancel an emergency call: Press the SOS button and hold it down for two seconds, or switch the ignition off.
Page 106: Lighting
OPERATION The low-beam headlight switches on automatically when the engine is started. In daytime the daytime riding light can be switched on as an alternative to the low-beam headlight. High-beam headlight and Open cover 1. headlight flasher Provide information to the Switch on the ignition.
Page 107 in that position until the park- ing lights come on. Switch the ignition on and off again to switch off the park- ing lights. Auxiliary headlights with additional headlight Requirement The auxiliary headlights are act- Immediately after switching ive only when the low-beam off the ignition, pull switch 1 headlight is active.
Page 108 OPERATION WARNING The automatic daytime rid- ing light is not a substitute for the rider's personal judgement of the light conditions Risk of accident Switch off the automatic Press button 1 to switch on daytime riding light in poor the hazard warning flashers. light conditions.
Page 109: Dynamic Traction Control (Dtc)
If the comfort turn indicators The indicator in the display function is switched on, the flashes in sync with the indic- turn indicators are cancelled ator light in the instrument automatically when the cluster. speed-dependent distance is flashes yellow. covered. Alternatively: Press button 1 Press the top section of the to cancel the turn indicators.
Page 110 OPERATION Select the setting to increase damping. Adjusting ride height with Adaptive Ride Height Switch on the ignition. Assign the Ride height function to the multi-function rocker switch ( 77). The damping settings 1 can be Select the appropriate setting. changed for a different setup, depending on the riding mode.
Page 111: Riding Mode
The chassis and suspension ad- RIDING MODE justment can also be adjusted Using riding modes in the scenario selected. BMW Motorrad offers you pre- For more information on the configured modes to suit the riding modes, see the section various purposes: entitled "Engineering details"...
Page 112 OPERATION Preselect a riding mode with riding modes Pro Switch on the ignition. Navigate to Settings Vehicle settings Rid- ing mode preselection Activate or deactivate rid- ing modes for riding mode Press button 1. preselection. The activated riding modes are available for subsequent selection.
Page 113 The ABS indicator light flashes ATTENTION irregularly. See the section entitled "En- Activation of the off- gineering details" for more in- road mode (ENDURO and formation on riding dynamics ENDURO PRO) for on-road control systems such as ABS. riding The availability of the riding Risk of crash due to lack of modes depends on the cus- stability when the vehicle...
Page 114: Riding Mode Pro
OPERATION Select system and confirm. RIDING MODE PRO with riding modes Pro Adjustment option The Pro riding modes can be set up to suit individual rider needs and preferences. Selecting Pro riding mode Switch on the ignition. Navigate to You can browse through the Settings available settings 3 and the Vehicle settings...
Page 115: Cruise Control
The following factory settings Display when adjusting apply for settings (Speed Limit Info DYNAMIC PRO RID- active) ING MODE ENGINE Dynamic Road Dynamic CRUISE CONTROL Display when adjusting settings (Speed Limit Info not active) Symbol 1 for cruise control is displayed in the Pure Ride view and in the top status line.
Page 116 OPERATION Setting road speed Push button 1 forward and hold it in this position. Speed is increased in steps of 10 km/h. The current speed is main- tained and saved if button 1 is not pushed again. Decelerating Short-push button 1 forward. Adjustment range for cruise control (gear-de- pendent)
Page 117 Resuming former cruising Cruise control is deactiv- speed ated if the clutch is pulled for longer than 1.5 seconds. For safety reasons, cruise control is automatically deactivated whenever ABS or DTC intervention occurs. If DTC is deactivated by the rider, cruise control is deactivated as well.
Page 118: Radar-Based Rider Assistance Systems
OPERATION The system is deactivated. Safety information disappears. Distance control (ACC), Front Collision Warning (FCW) and lane change warning (SWW) Button 1 is disabled. are radar-based rider assist- Configure the character of ance systems. Functional re- cruise control strictions and the limits of the with Riding Assistant systems must be taken into consideration.
Page 119 Object detection can be WARNING restricted, for example on twisting or hilly roads and Radar is not functional in when you ride offset from certain situations the vehicle ahead in your Risk of accident due to non- lane or if you weave from application of the brakes or side to side in the lane.
Page 120: Distance Control (Active Cruise Control Acc)
OPERATION ATTENTION WARNING Radar might incorrectly ACC cannot compensate for detect certain objects and excessive speed differences traffic situations Risk of accident ACC cannot perform emer- Risk of accident Radar-based rider assist- gency braking. Retardation ance systems might respond and the rate at which retard- without justification in reac- ation increases are limited.
Page 121 It is back up to the road speed best to consult an authorised set beforehand. This can BMW Motorrad retailer. be the case in bends, for Toggling between cruise example. control and ACC...
Page 122 OPERATION section entitled "Engineering Navigate to Settings details" ( 180). , select sist Cruise con- trol Operating ACC Activate or deactivate Requirement Alternatively: Assign the is activated. function to the multi-function rocker switch ( 77). ACC is not available ACC is inactive: in ENDURO and Short-press the bottom ENDURO Pro riding modes.
Page 123 Status indicators showing in If a warning light shows in the the instrument cluster instrument cluster: Intervene actively to avert po- When ACC is in operation, the tential danger. following symbols can appear in the instrument cluster: Setting approach distance Assign the function to Indicator lights...
Page 124: Front Collision Warning (Fcw)
OPERATION The following settings are available: WARNING Short approach distance FCW can lose sight of an object detected beforehand Medium approach dis- Risk of accident tance If FCW loses sight of an ob- ject detected beforehand Long approach distance a warning might not be is- sued or its application of When the ACC detects a the brakes might be can-...
Page 125 Behaviour of front collision If a warning light shows in the warning instrument cluster: Intervene actively to avert po- FCW is available only in tential danger. the ECO, RAIN, ROAD and DYNAMIC riding modes. Setting timing for issue of warning See the "Engineering details"...
Page 126: Lane Change Warning (Sww)
OPERATION Navigate to See the "Engineering details" Settings , select section for more information sist Front-colli- on FCW ( 182). sion warning Select Braking assist- LANE CHANGE WARNING ance (SWW) The following settings are available: with Riding Assistant Activated: In addition to issue Behaviour of lane change of the acute warning, a brak- warning...
Page 127: Hill Start Control (Hsc)
Acute warning : SWW is deactivated, neither notifications nor acute If actuation of the turn indicators on the side warnings are issued. : SWW is active, both noti- corresponding to the lit-up fications and acute warnings warning triangle indicates are issued. an imminent lane change, : SWW is act- warning triangle 1 flashes...
Page 128 OPERATION Operating Hill Start Control lever 1 or the footbrake lever again. Requirement disappears. Vehicle stationary and upright, engine running. Alternatively, ride off in 1st or 2nd gear. ATTENTION In order for the motor- cycle to pull away from Non-availability of Hill Start rest with Hill Start Control, the Control throttle grip has to be turned to...
Page 129 Hill Start Control Pro is If Hill Start Control Pro purely a comfort system has been deactivated by that facilitates hill starts and means of the handbrake lever, consequently, is not to be con- automatic Hill Start Control is fused with a parking brake. deactivated for the next 4 m.
Page 130: Anti-Theft Alarm (Dwa)
OPERATION when you switch the ignition To switch on manual Hill Start off. Control Pro, select Manual Activation takes approximately Hill Start Control Pro can be 30 seconds to complete. activated by forcefully oper- Turn indicators flash twice. ating the handbrake or foot- Confirmation tone sounds brake lever.
Page 131 29 seconds. While from the motorcycle's battery an alarm is in progress an Flashes 5x: Tilt sensor 3 alarm tone sounds and the turn indicators flash. The type of acoustic alarm tone can be set by an authorised BMW Motorrad retailer.
Page 132 OPERATION Deactivation The following settings are available: Kill switch in operating posi- Adapting tion (run). Warning signal Switch on or Switch on the ignition. Tilt sensor Switch on or Arming tone Switch Arm automatically on or off Possibilities for adjustment 126) Possibilities for adjustment : Set the...
Page 133: Tyre Pressure Monitoring (Rdc)
function after the ignition is Pull lever 2 down to raise switched off. windscreen 1. Push lever 2 up to lower TYRE PRESSURE MONITOR- windscreen 1. ING (RDC) Electrically adjusting Switch the target-pressure windscreen warning on or off with windscreen, electrically The system can be set to is- adjustable sue a target-pressure warning...
Page 134: Heating
Select the appropriate setting. There is no guarantee that the anti-trap system will function correctly if a windscreen that does not have BMW Motorrad approval is installed. Under these circumstances: Before switching off the igni- tion, make sure that nothing obstructs the windscreen's freedom of movement.
Page 135 Operate the heating Operating passenger-seat heating with seat heating with seat heating The heating in the heated with two-up riding package handlebar grips and the Start the engine. ( 152) seat heating can be activated only when the engine is run- Seat heating can be activ- ning.
Page 136: Central Locking System
OPERATION 3 Switch pressed at one dot: Unlocking low heating power. with central locking system 4 Switch pressed at two dots: The central locking un- high heating power. locks automatically when you switch on the ignition. Selected heating stage 1 and seat-heating symbol 2 are dis- Press button 1.
Page 137 Cases and topcase are auto- with central locking system with topcase matically locked after the igni- tion has been switched off. Emergency unlocking with central locking system with case with central locking system with topcase Requirement If the central locking system Turn the key to the RELEASE refuses to unlock or if cases position in the topcase lock.
Page 138: Storage Compartment
OPERATION STORAGE COMPARTMENT Opening and closing storage compartment ATTENTION High temperatures in the storage compartments, par- ticularly in summer To open, press slide 2 and flip Damage to objects stowed storage compartment flap 1 away, particularly electronic open. devices, such as mobile To close, press storage com- phones partment flap 1 closed.
Page 139: Front And Rear Seats
Installing passenger seat FRONT AND REAR SEATS with seat heating Removing passenger seat Make sure the ground is level and firm and place the motor- cycle on its stand. Connect plug connection 1 of the seat heating. Turn vehicle key 1 clockwise and hold it in this position.
Page 140 OPERATION Removing rider's seat Remove the rear seat. 133) Slightly lift passenger seat 1. Lift the rear of the rider's seat. Slide passenger seat 1 in dir- ection A or B. Remove rider's seat 1 from mount 3. with seat heating Disconnect plug connection 2 of the seat heating.
Page 141 Installing rider's seat with seat heating Connect plug connection 1 of the seat heating. Engage the rider's seat in mounts 2 on left and right and lower it on to the motor- cycle. Applying pressure to the rear of the seat, push the front seat slightly forward and then press the seat firmly down.
Page 142 ADJUSTMENT...
Page 143 MIRRORS HEADLIGHT CLUTCH GEARSHIFT LEVER BRAKES FOOTRESTS HANDLEBARS SPRING PRELOAD...
Page 144: Mirrors
ADJUSTMENT MIRRORS Mirror (lock nut) to ad- apter Adjusting mirrors M10 x 1.25 22 Nm (Left-hand thread) Push protective cap 1 over the threaded fastener. with Riding Assistant Turn the mirror to the correct position. Adjusting mirror arm Push protective cap 1 over the threaded fastener of the mirror arm up to expose the threaded fastener.
Page 145: Headlight
When the motorcycle is again motorcycle. ridden with a lower load: If there are doubts about Return the headlight to its ba- the correct headlight sic setting. beam throw, have the setting checked by a specialist work- shop, preferably an authorised BMW Motorrad retailer.
Page 146: Clutch
ADJUSTMENT Position C: Widest span CLUTCH between handlebar grip and Adjusting clutch lever clutch lever Check the and protector. WARNING 143) Adjusting the clutch lever GEARSHIFT LEVER while riding Adjusting gearshift lever peg Risk of accident Adjust the clutch lever only ATTENTION when the motorcycle is at a standstill.
Page 147: Brakes
Tighten screw 2. BRAKES Screw to gearshift lever Adjusting handbrake lever and gearshift lever ad- juster WARNING M6 x 20 Adjusting the handbrake 8 Nm lever while riding with Option 719 Billet Pack Risk of accident Do not attempt to adjust the Shadow handbrake lever unless the motorcycle is at a standstill.
Page 148: Footrests
ADJUSTMENT Position C: Widest span Pull peg 1 out and turn it to between handlebar grip and the desired position. handbrake lever FOOTRESTS Check the and protector. 143) with enduro package Pro Adjust the footbrake lever with sport suspension Adjusting footrests with Option 719 Billet Pack The footrest is adjusted on Shadow...
Page 149: Handlebars
140) the handlebars. Have the Adjust the footbrake lever handlebars replaced by a peg. ( 142) specialist workshop, preferably an authorised BMW Motorrad HANDLEBARS retailer. Adjustable handlebars Checking hand protector Have the handlebars adjusted If the hand protector is twis-...
Page 150: Spring Preload
Have the hand protector posi- tioned correctly by a specialist workshop, preferably an au- thorised BMW Motorrad re- tailer. The turn indicators are integrated into the hand Check the clearance between protectors.
Page 151 preload accordingly when the Basic setting of spring vehicle is lightly loaded. preload, rear Adjusting spring preload for Turn the hexagon head rear wheel counter-clockwise as far as it will go (with full load of fuel, WARNING with rider weighing approx. 85 kg) Adjusting spring preload Turn the hexagon head as...
Page 152 RIDING...
Page 153 SAFETY INFORMATION REGULAR CHECK STARTING RUNNING IN OFF-ROAD USE SHIFTING GEAR BRAKES PARKING YOUR MOTORCYCLE LIFT ASSISTANCE REFUELLING SECURING MOTORCYCLE FOR TRANSPORTATION...
Page 154: Safety Information
This applies even to short sure to comply with the journeys, and to every season instructions on loading. of the year. Your authorised BMW Motorrad retailer will be happy to advise you on WARNING the correct clothing for every purpose.
Page 155 Pack heavy items at the bot- Setup of the suspension Imbalanced load tom and toward the inboard Loose clothing side. Insufficient tyre pressure Note the maximum permiss- Poor tyre tread ible payload and maximum permissible speed, see Maximum speed with knobbly also the section entitled tyres or winter tyres "Accessories"...
Page 156 RIDING WARNING WARNING Exhaust gases adversely af- Opening radiator cap fecting health Risk of burning Do not open the radiator Risk of asphyxiation Do not inhale exhaust cap when the system is hot. Check and, if necessary, top fumes. Do not run the engine in an up the coolant in the expan- enclosed space.
Page 157: Regular Check
Risk of overheating REGULAR CHECK Comply with checklist ATTENTION At regular intervals, use the checklist below to check your Engine running for pro- motorcycle. longed period with vehicle at standstill Always before riding off Overheating due to insuf- Check operation of the brake ficient cooling;...
Page 158: Starting
RIDING STARTING Starting engine Switch on the ignition. Pre-Ride-Check is performed. 152) ABS self-diagnosis is per- formed. ( 153) DTC self-diagnosis is per- Press starter button 1 and formed. ( 154) hold it down until the engine Select neutral or, if a gear is fires.
Page 159 Have the fault rectified as Phase 2 quickly as possible by a spe- Test of the wheel-speed cialist workshop, preferably an sensors as the vehicle pulls authorised BMW Motorrad re- away from rest. tailer. flashes. with riding modes Pro The intervention of riding...
Page 160 (The motorcycle has to reach cialist workshop, preferably an a defined minimum speed authorised BMW Motorrad re- with the engine running for tailer. the wheel sensors to be checked: min 5 km/h)
Page 161: Running In
BMW Motorrad re- Brake pads tailer. New brake pads have to be run in before they can achieve their RUNNING IN optimum friction levels. You Engine can compensate for this initial Until the first running-in reduction in braking efficiency...
Page 162: Off-Road Use
Always check that the tyre available as optional extras. pressures are correct. BMW Motorrad recommends Brakes checking the rims for damage after off-roading. WARNING with off-road tyres Driving on unpaved or dirt...
Page 163: Shifting Gear
BMW Motorrad recommends SHIFTING GEAR disengaging the clutch for with shift assistant Pro shifts in these circumstances. Gear Shift Assistant Pro...
Page 164: Brakes
RIDING BMW Motorrad Integral BRAKES ABS Pro prevents the front How can stopping distance be wheel from locking up. minimised? Emergency braking Each time the brakes are ap- If you brake sharply from a plied, a load distribution shift speed in excess of >50 km/h,...
Page 165 Wet and dirty brakes ABS Pro Physical limits applicable to motorcycling WARNING Wetness and dirt result in WARNING diminished braking effi- ciency Braking when cornering Risk of accident Risk of crash despite ABS Pro Apply the brakes lightly Invariably, it remains the while riding to remove rider's responsibility to ad- wetness and dirt, or...
Page 166: Parking Your Motorcycle
RIDING Use on public roads ABS Pro and Dynamic Brake ATTENTION Control help make the motor- Poor ground underneath the cycle even safer for riding on stand public roads. When the brakes Risk of damage to parts if are applied because of an un- vehicle topples foreseen hazard when the mo- Always check that the...
Page 167: Lift Assistance
lift the motorcycle on to the stand. ATTENTION with Adaptive Ride Height Poor ground underneath the Lift assistance helps you to stand lift the motorcycle on to its Risk of damage to parts if centre stand ( 161). vehicle topples Always check that the ground under the stand is WARNING...
Page 168 RIDING needed to lift the motorcycle on to the stand. ATTENTION A sensor detects exten- Centre stand retracts due to sion of the centre stand as severe movements a request to prepare for lifting Risk of damage to parts if the vehicle on to its stand and vehicle topples readies the suspension accord-...
Page 169: Refuelling
More After removing the motor- information is available from cycle from the stand, first your authorised BMW Motorrad retract the centre stand, then retailer. flip the peg of the centre Recommended fuel stand 1 closed.
Page 170 RIDING ATTENTION After refuelling with fuels of Wetting of plastic surfaces poor-quality, sporadic knock- by fuel ing noises may be perceptible. Damage to the surfaces (sur- faces become unsightly or Refuelling dull) Requirement Clean plastic surfaces im- The steering lock is disen- mediately after contact with gaged.
Page 171 After the waiting time has ex- pired. Variant 1 Requirement Within the waiting time Refuel with fuel of the grade stated above; do not fill the tank past the bottom edge of the filler neck. When refuelling after run- ning on reserve, make Slowly pull tab 1 on the fuel sure that you top up the tank filler cap up.
Page 172: Securing Motorcycle For Transportation
Hold emergency release 2 in Have the fault rectified as position. quickly as possible by a spe- Install screws 1. cialist workshop, preferably an SECURING MOTORCYCLE authorised BMW Motorrad re- FOR TRANSPORTATION tailer. ATTENTION Incorrect lashing Component damage Never lash anything to add- on parts such as the engine protection bars, for example.
Page 173 equately protected against scratching. Use adhesive tape or soft cloths, for example, for this purpose. ATTENTION Trapping of components Component damage Do not trap components ATTENTION such as brake lines or cable legs. Vehicle topples to side when Pass the straps on left and being lifted on to stand right through the fork bridge Risk of damage to parts if...
Page 174 RIDING Tension all the straps uni- formly to hold the vehicle se- curely.
Page 176 ENGINEERING DETAILS...
Page 177 GENERAL NOTES ANTILOCK BRAKE SYSTEM (ABS) DYNAMIC TRACTION CONTROL (DTC) DYNAMIC ENGINE BRAKE CONTROL (MSR) BATTERY GUARD SHUTDOWN CONCEPT DISTANCE CONTROL (ACTIVE CRUISE CONTROL ACC) FRONT COLLISION WARNING (FCW) LANE CHANGE WARNING (SWW) DYNAMIC SUSPENSION ADJUSTMENT (DSA) RIDING MODE DYNAMIC BRAKE CONTROL TYRE PRESSURE CONTROL (RDC) GEAR SHIFT ASSISTANT HILL START CONTROL (HSC)
Page 178: General Notes
If the rider increases braking rear brakes are applied. pressure to the extent that The BMW Motorrad fully in- braking force exceeds the tegral ABS adapts brake force maximum transferable limit, the distribution between front and...
Page 179 BMW Motorrad reacts instantly and adjusts Integral ABS Pro will be un- braking force accordingly to able to prevent the rear wheel achieve optimum braking.
Page 180 Risk of falling In addition to problems with When you brake sharply, the BMW Motorrad ABS, ex- bear in mind that ABS con- ceptional riding conditions can trol cannot always be re- lead to a fault message being...
Page 181 Evolution of ABS to ABS Pro Safety reserves Until now, BMW Motorrad ABS The potentially shorter has helped ensure a very high braking distances which degree of safety for braking BMW Motorrad Integral...
Page 182: Dynamic Traction Control (Dtc)
ABS intervention. and more comfortable for the Advantages for the rider rider. BMW Motorrad DTC is de- The advantages of ABS Pro for signed as an assistant system the rider are sensitive response for the rider and for use on and high braking and direc- public roads.
Page 183 DTC fault shows. Self- conditions off-road or on the track. The BMW Motorrad DTC diagnosis has to complete can be deactivated in these before fault messages can be cases.
Page 184: Dynamic Engine Brake Control (Msr)
ENGINEERING DETAILS Sharp braking during sporty BMW Motorrad recommends riding. turning the throttle grip back slightly when lifting the front In the same way as DTC trac- wheel in order to reach a stable tion control, dynamic engine driving condition again as soon brake control compares the as possible.
Page 185: Shutdown Concept
Comfort functions transmitted by electronic noti- are either downgraded or fication. More detailed inform- switched off in line with ation about the BMW Motorrad demand to ensure that vehicle Teleservices is available from operation can be maintained. your authorised BMW Motorrad In the event of a shutdown, a retailer.
Page 186: Distance Control (Active Cruise Control Acc)
The front-mounted radar CRUISE CONTROL ACC) sensor detects vehicles What is ACC? travelling ahead. At the same BMW Motorrad ACC is a cruise time, the radar sensor analyses control system with approach yaw rate and vehicle speed to distance control. The function...
Page 187 comfortable bank angle (e.g. would apply, for example, 20°). As bank angle increases, to a vehicle that is on the moreover, braking and accel- left in right-hand traffic or a eration dynamism is limited vehicle on the right in left- so that no sudden braking or hand traffic.
Page 188: Front Collision Warning (Fcw)
(FCW) the brakes ( 119). What is FCW? Timing of warning threshold BMW Motorrad FCW is an To determine when the rider collision warning system that should be warned, the system warns of critical situations calculates how long the rider...
Page 189: Lane Change Warning (Sww)
(SWW) Early Medium Late What is lane change warning? Speed range of FCW BMW Motorrad lane change The FCW can monitor traffic warning monitors following ahead and intervene in the fol- traffic and notifies the rider of lowing speed ranges: critical riding situations before 30...160 km/h...
Page 190: Dynamic Suspension Adjustment (Dsa)
ENGINEERING DETAILS tects movements in the chassis Range of rear radar: The and suspension and responds radar sensor has a maximum by adjusting the damper valves. viewing range of approx. Additionally, the suspension 80 m. Timely issue of a characteristic can be set up to collision warning is possible suit the desired riding experi- up to a speed differential...
Page 191: Riding Mode
ride height, making it easier for RIDING MODE the rider to put their feet on Selection the ground. To adjust the motorcycle to the Ride height can also be adjus- road condition and the desired ted manually, depending on the driving experience, the follow- riding mode.
Page 192 ENGINEERING DETAILS In DYNAMIC PRO riding DTC can be switched off in mode, the ABS setting each riding mode. The ex- corresponds to the DYNAMIC planations below always refer riding mode. to the dynamic safety systems In DYNAMIC PRO and that are switched on.
Page 193 ABS Pro Actuation of the rear brake In ECO, RAIN and ROAD rid- In ECO, RAIN and ROAD rid- ing modes, ABS Pro is fully ing modes, maximum possible available. brake force is distributed to In DYNAMIC, DYNAMIC the front wheel. PRO and ENDURO riding In DYNAMIC and DYNAMIC modes, ABS Pro assistance is...
Page 194 ENGINEERING DETAILS Riding stability vehicle is being ridden off- road and is fitted with cleated In RAIN riding mode, DTC in- tyres. DTC intervenes later tervenes early to maximise riding stability. than in ENDURO riding mode. In ECO, ROAD and In the ENDURO PRO and DYNAMIC PRO riding modes, DYNAMIC PRO riding modes,...
Page 195 engine characteristic (paramet- The following steps must be risation of the electromotive taken to change the riding throttle controller) to keep the mode: Close the throttle twistgrip. engine in the operating range Release the brake levers. of the consumption-oriented Deactivate cruise control. part-load cam, so as to maxim- ise the distance travelled with a The desired riding mode is ini-...
Page 196: Dynamic Brake Control
ENGINEERING DETAILS Behaviour during accidental DYNAMIC BRAKE CONTROL actuation of the throttle grip How Dynamic Brake Control If the throttle is accidentally works opened (throttle grip posi- The Dynamic Brake tion > 5 %) during emergency Control function is active braking, Dynamic Brake Con- in all riding modes.
Page 197 measured values until the mo- Filling pressure outside per- torcycle has accelerated to a mitted tolerance defined minimum speed for the Temperature compensation first time. Tyre pressure is a temperature- Minimum speed for sensitive variable: pressure in- transmission of the RDC creases as tyre-air temperature measured values: rises and decreases as tyre-...
Page 198: Gear Shift Assistant
ENGINEERING DETAILS Pressure adaptation GEAR SHIFT ASSISTANT Compare the RDC value in the with shift assistant Pro instrument cluster with the Gear Shift Assistant Pro value in the table on the back Your vehicle is equipped with cover of the rider's manual. Gear Shift Assistant Pro, a Then use the air-line gauge at a system originally developed for...
Page 199: Hill Start Control (Hsc)
It is not necessary to close Downshifting the throttle twistgrip when Downshifting is assisted until shifting under acceleration. maximum rpm for the tar- When downshifting (throttle get gear to be selected is twistgrip closed), engine reached. This prevents over- speed is adjusted by blipping revving.
Page 200 ENGINEERING DETAILS pressure is built up in the rear If the rear wheel slips, the brake system to keep the ma- brake is released again after chine at a standstill on a gradi- approx. 1 m. This prevents ent. the vehicle slipping with a The brake pressure in the locked rear wheel, for ex- brake system is dependent on...
Page 201: Shiftcam
swirled more thoroughly and The holding pressure combusted effectively - so all is released immediately in all the fuel is utilised more without a brake warning jolt as efficiently and engine operation soon as the ignition is switched is perceptibly smoother. The off.
Page 202 ENGINEERING DETAILS the motorcycle banks for cor- nering.
Page 204 MAINTENANCE...
Page 205 GENERAL NOTES TOOLKIT FRONT-WHEEL STAND REAR-WHEEL STAND ENGINE OIL BRAKE SYSTEM CLUTCH COOLANT TYRES WHEEL RIMS WHEELS AIR FILTER SIDE PANEL LIGHTING JUMP-STARTING BATTERY FUSES DIAGNOSTIC CONNECTOR...
Page 206: General Notes
If in doubt consult a Non-reusable cable ties specialist workshop, preferably Non-reusable cable ties are an authorised BMW Motorrad used at some points to secure retailer. cables and lines. To prevent damage to cables and lines...
Page 207: Toolkit
FRONT-WHEEL STAND Install the front-wheel stand Screwdriver handle Use with screwdriver insert ATTENTION Reversible screwdriver Use of the BMW Motorrad blade front-wheel stand without With star-head and plain- accompanying use of centre tip ends stand or auxiliary stand Disconnect the battery Risk of damage to parts if from the motorcycle.
Page 208: Rear-Wheel Stand
BMW Motorrad offers an aux- procedure for installation. iliary stand suitable for every BMW Motorrad offers an aux- vehicle. Your BMW Motorrad...
Page 209 ATTENTION Misinterpretation of oil level reading, because oil level is temperature-dependent (the higher the temperature, the higher the oil level) Engine damage due to incor- rect oil filling Check the oil level only after ATTENTION a lengthy ride or when the Vehicle toppling sideways engine is at operating tem- Risk of damage to parts if...
Page 210: Brake System
If the oil level is below the BMW Motorrad retailer. MIN mark max 0.5 l top up Topping up engine oil the engine oil. Make sure the ground is level...
Page 211 Have the brakes checked front by a specialist workshop, 1.0 mm (Friction pad only, preferably an authorised without backing plate. The BMW Motorrad retailer. wear indicators (grooves) Checking brake pad thickness, must be clearly visible.) front brakes If the wear indicating marks are...
Page 212 MAINTENANCE preferably an authorised BMW Motorrad retailer. Checking brake pad thickness, rear brakes Make sure the ground is level and firm and place the motor- cycle on its stand. Brake-pad wear limit, rear 1.0 mm (Friction pad only, without backing plate. The wear indicators (grooves) must be clearly visible.)
Page 213 Checking brake-fluid level, front brakes WARNING Not enough brake fluid in brake fluid reservoir, or con- taminants in brake fluid Considerably reduced braking power due to presence of air, Check the brake fluid level in contaminants or water in the brake fluid reservoir for front brake system wheel brake 1.
Page 214 Have the fault rectified as cycle on its centre stand. quickly as possible by a spe- cialist workshop, preferably an authorised BMW Motorrad re- tailer. Checking brake-fluid level, rear brakes WARNING Not enough brake fluid in...
Page 215: Clutch
If the brake fluid level drops below the permitted level: Have the fault rectified as quickly as possible by a spe- cialist workshop, preferably an authorised BMW Motorrad re- Check the coolant level in ex- tailer. pansion tank 1. CLUTCH...
Page 216: Tyres
MAINTENANCE Open cap of expansion Specified coolant level tank 1. Top up coolant to the spe- Between MIN and MAX cified level using a suitable marks on the expansion tank funnel. (Engine cold) Check the coolant level. If the coolant drops below the 209) Close cap of expansion permitted level:...
Page 217 perature. Consequently, the values they show do not usually WARNING tally with the pressure read- Tendency of valve inserts ings shown by the instrument installed vertically to open cluster. by themselves at high riding Check the tyre tread depth speeds Sudden loss of tyre pressure WARNING Install valve caps fitted with...
Page 218: Wheel Rims
In cessary, replaced by a special- particular, the diameter and ist workshop, preferably an the width of a vehicle's wheels authorised BMW Motorrad re- are programmed into the con- tailer. trol unit and are fundamental to all calculations. Any change...
Page 219 BMW Motorrad recommends have to be forced apart the BMW Motorrad rear- Do not operate the brakes wheel stand. with a brake caliper not cor- Install the rear-wheel stand.
Page 220 MAINTENANCE Lift the front of the motor- cycle until the front wheel is clear of the ground, preferably using a BMW Motorrad front- wheel stand. Install the front-wheel stand. 201) Withdraw quick-release axle 1, support the front wheel when doing this.
Page 221 Damage, or threaded fasten- ers work loose Always have the security of the fasteners checked by a specialist workshop, preferably an authorised BMW Motorrad dealer. Lubricate quick-release axle 1. Lubricant Unirex N3 Lift the front wheel slightly and install quick-release Lubricate the friction face of axle 1.
Page 222 MAINTENANCE Remove front-wheel stand and firmly compress front forks several times. Do not operate the brake in this pro- cess. Install the front-wheel stand. 201) Tighten right axle clamping screws 1 to the specified torque. Clamping screws for quick-release axle Tightening sequence: Tighten screws six times in alternate Install screw 1 and tighten to...
Page 223 Operate the brake several on an auxiliary stand; times until the brake pads are BMW Motorrad recommends bedded. the BMW Motorrad rear- Insert the cable for the wheel wheel stand. speed sensor into holding Install the rear-wheel stand. clips 1 and 2.
Page 224 Always have the security the silencer is installed. of the fasteners checked by a specialist workshop, preferably an authorised BMW Motorrad dealer. Remove bolts 1 from the rear wheel, while supporting the wheel. Tilt the rear wheel to the side Clean the contact surfaces to remove.
Page 225 Seat the rear wheel on the Lubricant rear-wheel adapter. Optimoly TA Slide new clamp 3 on to si- lencer 1. Push silencer 1 to the limit position. Install the screw with shaped washer 2. Silencer to bracket Install wheel bolts 1 and tighten to specified torque.
Page 226: Air Filter
MAINTENANCE Remove the right side panel. Clamp to silencer and 221) exhaust manifold 22 Nm with off-road tyres Remove screws 1. Remove air filter cover 2. Clean the threads for screws 1. Hold spray guard 2 in posi- tion. Install screws 1. Spray guard to bevel gears M6 x 20...
Page 227: Side Panel
Installing air filter element SIDE PANEL Removing right side trim panel The procedure described here for the right side panel applies by analogy to the left side as well. Make sure the ground is level and firm and place the motor- Install frame 1 with air filter cycle on its stand.
Page 228 MAINTENANCE Remove screws 1. Snap front trim panel 2 into Disengage side trim panel 2 mounting clips 1 on left and from mounting clips 3 and right. remove. Installing right side panel Install threaded rivet 1. Snap side trim panel 2 into mounting clips 3.
Page 229: Lighting
Consult a special- ist workshop, preferably an ATTENTION authorised BMW Motorrad Retailer. Excessive current flowing when the motorcycle is All light sources of the vehicle jump-started are LED light sources. The...
Page 230 MAINTENANCE ATTENTION Contact between crocodile clips of jump leads and vehicle Risk of short-circuit Use jump leads fitted with fully insulated crocodile clips at both ends. Remove protective cap 1. Use the red jumper cable to connect the positive ter- ATTENTION minal 3 of the discharged bat- tery to the positive terminal of...
Page 231: Battery
Install protective cap 1. BMW Motorrad has de- veloped a float charger Install the rider's seat. specially designed for com- 135) patibility with the electron- BATTERY ics of your motorcycle.
Page 232 Damage to the on-board The suitable charger is avail- electronics Disconnect the battery at able from your authorised the battery terminals before BMW Motorrad dealer. charging. With the battery connected to the vehicle's on-board elec- trical system, charge via the ATTENTION power socket.
Page 233 Recharging disconnected battery Charge the battery using a suitable charger. Comply with the operating instructions of the charger. Once the battery is fully charged, disconnect the charger's terminal clips from Remove protective cap 1. the battery terminals. First disconnect negative bat- The battery has to be tery cable 2.
Page 234 MAINTENANCE Connecting battery to with cold-climate version motorcycle ATTENTION Battery not connected in ac- cordance with correct pro- cedure Risk of short-circuit Always proceed in compli- ance with specified installa- First connect positive battery tion sequence. cable 1. Then connect negative battery cable 2.
Page 235 with cold-climate version Remove cable strap 3. Remove screw 1. Remove cable strap 3. Remove battery holder with Remove screw 1. Remove battery holder with ring aerial 2 from holder 4 ring aerial 2 from holder 4 and lay it on the tail of the and lay it on the tail of the vehicle, noting the cable of vehicle, noting the cable of...
Page 236 Install screw 1. consult a specialist workshop Install cable strap 3. beforehand, preferably an au- with cold-climate version thorised BMW Motorrad re- tailer. Insert battery 1 into the bat- tery compartment, positive Insert battery 2 into the bat- terminal on the left in the for- tery compartment, positive ward direction of travel.
Page 237: Fuses
(DWA) quently have the electric If applicable, switch on the circuits checked by a specialist anti-theft alarm. workshop, preferably an au- thorised BMW Motorrad re- Change the system settings. tailer. Insert connector 1, con- FUSES nector 2 or cap 3.
Page 238 MAINTENANCE Fuse assignment I Fuse assignment II 10 A Instrument cluster Multifunction switch, left Anti-theft alarm (DWA) Auxiliary headlights Socket for onboard dia- gnosis 20 A Seat heating USB socket Central locking, cases and Voltage supply, cases and topcase topcase 15 A Fuse assignment III Keyless Ride...
Page 239: Diagnostic Connector
3. it to be disconnected Securing diagnostic socket except in the course of a Disconnect the interface for BMW Motorrad service by the diagnosis and information a specialist workshop or by system. other authorised persons. Have the work carried out by appropriately trained per- sonnel.
Page 240 ACCESSORIES...
Page 241 GENERAL NOTES POWER SOCKETS USB CHARGING SOCKETS CASES TOPCASE NAVIGATION SYSTEM...
Page 242: General Notes
Use of other-make products tion and use regulations applic- Safety risk able in your country. BMW Motorrad cannot ex- Your authorised amine or test each product BMW Motorrad retailer of outside origin to ensure can offer expert advice on the...
Page 243: Usb Charging Sockets
Automatic shutdown USB CHARGING SOCKETS The sockets will be automat- Notes on use ically switched off during the start procedure. ATTENTION The power supply to the sockets is switched off Vibrations when vehicle is 60 seconds after the ignition moving is switched off, in order to Damage to mobile phones prevent overloading of the...
Page 244 ACCESSORIES 60 seconds after the ignition is switched off, in order to pre- vent overloading of the on- board electrics. While riding in the rain, you should disconnect the device from the interface in order to protect against damage. To prevent dirtying, keep the This is a 5 V USB charging in- protective cover closed when terface 1 that provides a max-...
Page 245: Cases
Topcase with topcase Emergency unlocking. with topcase with central locking system 131) The USB charging socket is inside the topcase ( 244). Slide lock 1 to the right. Carry handle 2 pops up. This is a 5 V USB charging in- terface 1 that provides a max- imum charge current of 3 A (maximum charging power...
Page 246 ACCESSORIES To increase case volume, turn adjustment wheel 1 counter- clockwise in direction B. Adjustment frame 2 is pushed out. with case with central locking system Close the case. ( 239) Locking protective cap Close carry handle 1. Carry handle 1 engages with an audible click.
Page 247 Installing cases Unlock the protective cap. 240) Push release lever 1 up and fully open locking flap 2. Remove protective cap 2 from magnetic plug connec- tion 1. Check magnetic plug connec- tion 3 of case and case holder for dirt and damage. Engage hooks 2 securely in mounts 1.
Page 248 ACCESSORIES The locking flap engages. Removing cases Slide lock 1 to the right. Turn the key in the case lock Carry handle 2 pops up. to position 1 and remove the with case key from the lock. with central locking system Unlock the protective cap.
Page 249 Maximum payload and maximum speed When lashing light items of luggage to the vehicle, take care not to put too much strain on the eyes (max 1 kg). Consequently, tighten straps or ropes by hand, without using any mechanical advantage (e.g. Push release lever 1 up and ratchet).
Page 250: Topcase
ACCESSORIES TOPCASE with topcase with central locking system Opening topcase with central locking system Unlock. ( 130) Central locking system has failed or topcase has been Press release button 1 and locked and removed: open the topcase lid by the with central locking system carry handle.
Page 251 Adjusting topcase volume Locking protective cap with topcase with central locking system Open the topcase. ( 244) Empty the topcase. Turn the protective cap to po- sition 1. The protective cap engages with a perceptible snap. Unlocking protective cap Pull adjustment wheel 1 up to the adjustment position.
Page 252 ACCESSORIES Installing topcase WARNING Luggage on topcase not se- cured in compliance with correct procedure Impairment of handling stabil- Do not lash luggage car- Turn the key to the RELEASE ried on the topcase to the position in the topcase lock. topcase carrier or to other The locking flap pops up.
Page 253 Check magnetic plug connec- Turn the key in the topcase tion 2 of topcase and topcase lock to position 1 and remove holder for dirt and damage. the key from the lock. Engage hooks 3 securely in Removing topcase mounts 1. Slide lock 1 to the right and Push locking flap 2 forward pop carry handle 2 up.
Page 254 ACCESSORIES Turn the key to the RELEASE Check protective cap 1 and position in the topcase lock. magnetic plug connection 2 The locking flap pops up. for dirt and damage. Turn the key in the topcase Install protective cap 1 on lock to position 1 and remove magnetic plug connection 2.
Page 255: Navigation System
16.2 kg NAVIGATION SYSTEM with preparation for naviga- tion system Secure the navigation device Navigation prepara- tion is suitable from BMW Motorrad Navigator IV Insert navigation device 1 at onward. bottom and pivot it toward the rear.
Page 256 BMW Motorrad ConnectedRide Navigator. Only the latest version of Turn ignition key 1 anti-clock- the BMW Motorrad com- wise. munication system is suppor- Pull lock retainer 2 all the way ted. A software update of the to the left.
Page 257 BMW Motorrad re- Turning Multi-Controller 1 up/ tailer. down Select menu If the BMW Motorrad Change volume ConnectedRide Navigator is Zoom map installed and the operating focus is switched to the Short-tilting Multi-Controller 1 Navigator ( 84), some of...
Page 258 CARE...
Page 259 CARE PRODUCTS WASHING THE VEHICLE CLEANING EASILY DAMAGED COMPONENTS CARE OF PAINTWORK PAINT PRESERVATION LAYING UP MOTORCYCLE RESTORING MOTORCYCLE TO USE...
Page 260: Care Products
BMW Motorrad retailer. The BMW Motorrad recommends substances in BMW Care that you use BMW insect re- Products have been tested in mover to soften and wash off laboratories and in practice;...
Page 261: Cleaning Easily Damaged Components
BMW Motorrad re- the vehicle. tailer. To prevent stains, do not wash CLEANING EASILY DAMAGED the vehicle immediately after COMPONENTS it has been exposed to strong Plastics sunlight and do not wash it in the sun.
Page 262: Care Of Paintwork
BMW Care Products range. Treat rubber components with This is particularly important to water or BMW rubber-care counter the effects of salt. products. Use BMW Motorrad high-gloss Radar sensors polish for additional treatment. with Riding Assistant Radiator Clean the radiator regularly to prevent overheating of the en- gine due to inadequate cooling.
Page 263: Paint Preservation
For paint preservation, can be affected or become BMW Motorrad recommends discoloured. Substances of the use of BMW Motorrad this nature include spilt fuel, gloss polish or agents contain- oil, grease, brake fluid and ing carnauba wax or synthetic bird droppings.
Page 264: Restoring Motorcycle To Use
CARE Spray the brake-lever and clutch-lever pivots mounts with suitable lubricant. The pivot mounts of the side stand and the centre stand are maintenance-free and require no lubrication. Coat bright metal and chrome-plated parts with an acid-free grease (e.g. Vaseline). Stand the motorcycle in a dry room in such a way that there is no load on either wheel.
Page 266 TECHNICAL DATA...
Page 267 TROUBLESHOOTING CHART THREADED FASTENERS FUEL ENGINE OIL ENGINE CLUTCH TRANSMISSION FINAL DRIVE FRAME CHASSIS AND SUSPENSION BRAKES WHEELS AND TYRES ELECTRICAL SYSTEM ANTI-THEFT ALARM DIMENSIONS WEIGHTS PERFORMANCE FIGURES...
Page 268: Troubleshooting Chart
TECHNICAL DATA TROUBLESHOOTING CHART The engine does not start. Possible cause Rectification Side stand extended and gear Retract the side stand. engaged Gear engaged and clutch not Select neutral or pull the clutch disengaged lever. No fuel in tank Refuel. ( 164) Battery flat Recharge the battery connec-...
Page 269 Active route guidance is not displayed in the TFT display. Possible cause Rectification Navigation from the Call up the BMW Motorrad BMW Motorrad Connec- Connected app on the paired ted app was not transmitted. mobile device prior to depar- ture.
Page 270: Threaded Fasteners
TECHNICAL DATA THREADED FASTENERS Front wheel Value Valid Screw in quick-re- lease axle M20 x 1.5 50 Nm Clamping screws for quick-release axle M6 x 30 - 10.9 Tightening sequence: Tighten screws six times in alternate se- quence 12 Nm Radial brake caliper on telescopic forks M10 x 60...
Page 271 Mirrors Value Valid Mirror (lock nut) to adapter M10 x 1.25 Left-hand thread, 22 Nm Mirror (bottom lock nut) to adapter M10 x 1.5 22 Nm with Riding Assistant Gearshift lever Value Valid Peg to gearshift lever M6 x 20 10 Nm micro-encapsulated Footbrake lever...
Page 272 TECHNICAL DATA Handlebars Value Valid Clamping block (handlebar clamp) on fork bridge M8 x 30 Tightening sequence: Tighten until seated at front as viewed in forward direction of travel 19 Nm One handlebar riser Tightening sequence: with handle- (15 mm), M8 x 45 Tighten until seated bar exten- at front as viewed in...
Page 273: Fuel
FUEL Recommended fuel grade Premium unleaded (max 15 % ethanol, E10/E15) 95 ROZ/RON 90 AKI Alternative fuel grade Normal unleaded (power- and consumption-related restrictions.) (max 15 % ethanol, E10/E15) 91 ROZ/RON 87 AKI Usable fuel capacity approx. 19 l Reserve fuel approx.
Page 274: Engine Oil
SAE 5W-40, API SL / JASO MA2, Additives (e.g. molybdenum-based) are not permissible because they can attack coated components of the engine, BMW Motorrad recommends BMW Motorrad ADVANTEC Ultimate oil. Engine oil, quantity for topping max 0.75 l, Difference between MIN and MAX...
Page 275: Clutch
Idle speed 1050 ±50 , Engine at reg- ular operating temperature CLUTCH Clutch type Multi-plate oil-bath clutch, anti- hopping TRANSMISSION Type of transmission Claw-shift 6-speed gearbox, integrated into engine block FINAL DRIVE Gear ratio of final drive 2.909 (32/11 teeth) Rear axle differential oil SAE 70W-80 FRAME...
Page 276: Chassis And Suspension
210 mm, at front wheel Rear wheel Type of rear suspension Cast aluminium single swinging arm with BMW Motorrad Paralever Spring travel at rear wheel 200 mm, at rear wheel with sport suspension 220 mm, at rear wheel BRAKES...
Page 277: Wheels And Tyres
Rear wheel Type of rear brake Single-disc brake, diameter 285 mm, 2piston floating cal- iper Brake-pad material, rear Sintered metal Brake disc thickness, rear 5.0 mm, When new min 4.5 mm, Wear limit Blow-by clearance of the foot- 1...1.5 mm, between the frame brake lever and the footbrake lever WHEELS AND TYRES...
Page 278: Electrical System
TECHNICAL DATA Rear wheel Rear-wheel type Aluminium cast wheel with cross-spoked wheels Cross-spoked wheel with cross-spoked wheels with enduro forged wheel Forged aluminium wheels Rear wheel rim size 4.50'' x 17'' Tyre designation, rear 170/60 R 17 Load index, rear tyre min.
Page 279: Anti-Theft Alarm
Fuse 5 5 A, CCP 30G, auxiliary head- lights, left multifunction switch Battery Battery type Lithiumion battery, mainten- ance-free with cold-climate version AGM battery (Absorbent Glass Mat), maintenance-free Battery rated voltage 12 V Battery rated capacity 10 Ah with Option 719 Billet Pack 14 Ah Shadow Spark plugs...
Page 280 TECHNICAL DATA Height of motorcycle 1406 mm, without mirrors, over windscreen, at DIN un- laden weight with Adaptive Ride Height 1376 mm, without mirrors, over windscreen, at DIN un- laden weight with windscreen, electrically 1459 mm, without mirrors, adjustable over windscreen, at DIN un- laden weight with Adaptive Ride Height with sport suspension...
Page 281: Weights
WEIGHTS Vehicle kerb weight 237 kg, DIN unladen weight, ready for road 90 % load of fuel, without OE Permissible gross vehicle 465 kg weight Maximum payload 227.6 kg PERFORMANCE FIGURES Top speed 225 km/h with power reduction 204 km/h with case 180 km/h with topcase...
Page 282 SERVICE...
Page 283 REPORTING SAFETY-RELEVANT DEFECTS RECYCLING BMW MOTORRAD SERVICE BMW MOTORRAD SERVICE HISTORY BMW MOTORRAD MOBILITY SERVICES MAINTENANCE WORK MAINTENANCE SCHEDULE BMW MOTORRAD RUNNING-IN CHECK MAINTENANCE CONFIRMATIONS SERVICE CONFIRMATIONS...
Page 284: Reporting Safety-Relevant Defects
SERVICE REPORTING SAFETY-RELEVANT DEFECTS with Canada export If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately in- form the NHTSA (National Highway Traffic Safety Administration) in addition to notifying the BMW of North America, LLC. If the NHTSA receives other, similar complaints, it may open an investigation.
Page 285: Recycling
In order to help ensure BMW MOTORRAD SERVICE that your BMW is always in optimum condition, BMW Motorrad has an BMW Motorrad recommends extensive network of retailers compliance with the mainten- in place to look after you and...
Page 286: Bmw Motorrad Service History
An authorised BMW Motorrad retailer or a MAINTENANCE WORK specialist workshop can also BMW pre-delivery check view data that is stored in the The BMW pre-delivery check is electronic service booklet.
Page 287 500 km and 1200 km. approaching. BMW Motorrad Service To find out more about service The BMW Motorrad Service go to: is carried out once a year; the bmw-motorrad.com/service extent of servicing can vary,...
Page 288: Maintenance Schedule
MAINTENANCE SCHEDULE BMW running-in check 10 Change brake fluid, entire (including oil change and system oil filter change) annually or every BMW Motorrad Service, 10000 km (whichever standard scope comes first) Engine-oil change, with every two years or every filter...
Page 289: Bmw Motorrad Running-In Check
BMW MOTORRAD RUNNING-IN CHECK BMW Motorrad running-in check The tasks included in the BMW Motorrad running-in check are listed below. The actual scope of work applicable for your vehicle may vary. Setting service-due data and countdown distance Performing vehicle test with BMW Motorrad diagnostic system...
Page 290: Maintenance Confirmations
SERVICE MAINTENANCE CONFIRMATIONS BMW Motorrad Service standard scope The tasks included in the BMW Motorrad Service standard scope are listed below. The actual scope of maintenance work applic- able for your vehicle may vary. Performing vehicle test with BMW Motorrad diagnostic system...
Page 291 BMW Motorrad pre- BMW Motorrad running-in delivery check check carried out carried out odometer reading Next service at the latest or, when reached earlier odometer reading Stamp, signature Stamp, signature...
Page 292 SERVICE BMW Motorrad service carried out odometer reading Next service at the latest or, when reached earlier odometer reading Work performed BMW Motorrad service Engine oil change with filter Oil change in rear angular gearbox Checking valve clearance Renewing all spark plugs...
Page 293 BMW Motorrad service carried out odometer reading Next service at the latest or, when reached earlier odometer reading Work performed BMW Motorrad service Engine oil change with filter Oil change in rear angular gearbox Checking valve clearance Renewing all spark plugs...
Page 294 SERVICE BMW Motorrad service carried out odometer reading Next service at the latest or, when reached earlier odometer reading Work performed BMW Motorrad service Engine oil change with filter Oil change in rear angular gearbox Checking valve clearance Renewing all spark plugs...
Page 295 BMW Motorrad service carried out odometer reading Next service at the latest or, when reached earlier odometer reading Work performed BMW Motorrad service Engine oil change with filter Oil change in rear angular gearbox Checking valve clearance Renewing all spark plugs...
Page 296 SERVICE BMW Motorrad service carried out odometer reading Next service at the latest or, when reached earlier odometer reading Work performed BMW Motorrad service Engine oil change with filter Oil change in rear angular gearbox Checking valve clearance Renewing all spark plugs...
Page 297 BMW Motorrad service carried out odometer reading Next service at the latest or, when reached earlier odometer reading Work performed BMW Motorrad service Engine oil change with filter Oil change in rear angular gearbox Checking valve clearance Renewing all spark plugs...
Page 298 SERVICE BMW Motorrad service carried out odometer reading Next service at the latest or, when reached earlier odometer reading Work performed BMW Motorrad service Engine oil change with filter Oil change in rear angular gearbox Checking valve clearance Renewing all spark plugs...
Page 299 BMW Motorrad service carried out odometer reading Next service at the latest or, when reached earlier odometer reading Work performed BMW Motorrad service Engine oil change with filter Oil change in rear angular gearbox Checking valve clearance Renewing all spark plugs...
Page 300 SERVICE BMW Motorrad service carried out odometer reading Next service at the latest or, when reached earlier odometer reading Work performed BMW Motorrad service Engine oil change with filter Oil change in rear angular gearbox Checking valve clearance Renewing all spark plugs...
Page 301 BMW Motorrad service carried out odometer reading Next service at the latest or, when reached earlier odometer reading Work performed BMW Motorrad service Engine oil change with filter Oil change in rear angular gearbox Checking valve clearance Renewing all spark plugs...
Page 302: Service Confirmations
SERVICE SERVICE CONFIRMATIONS The table is intended as a record of maintenance and repair work, the installation of optional accessories and, if appropriate, technical campaign work. Work performed odometer Date reading...
Page 303 Work performed odometer Date reading...
Page 304 DECLARATION OF CONFORMITY RADIO EQUIPMENT TFT INSTRUMENT CLUSTER KEYLESS RIDE SYSTEM MAIN UNIT KEYLESS RIDE SYSTEM ACTIVE KEY MID RANGE RADAR SHORT RANGE RADAR RADIO EQUIPMENT TYRE PRESSURE CONTROL (RDC) RADIO EQUIPMENT INTELLIGENT EMERGENCY CALL...
Page 305: Declaration Of Conformity
DECLARATION OF CONFORMITY Manufacturer Bayerische Motoren Werke Aktiengesellschaft Petuelring 130, 80809 Munich, Germany Simplified EU Declaration of Conformity according to EU RED (2014/53/EU). Simplified UK Declaration of Conformity according to Radio Equipment Regulations 2017 of the United Kingdom. Hereby, BMW AG declares that the radio equipment components listed below are in compliance with Directive 2014/53/ EU and with Radio Equipment Regulations 2017 of the United Kingdom.
Page 306 APPENDIX Radio Com- Frequency band Output/ equip- ponent Transmis- ment sion Power Keyless allowed ZB001 134.5 kHz Ride 66 dBµA/ m @ 10m max. Keyless ZB002 433.92 MHz 10 dBm Ride e.r.p TXBM- 433.05 MHz - 434.79 MHz 18,8 dBm RDC3 433.92 MHz <...
Page 307 Radio Com- Frequency band Output/ equip- ponent Transmis- ment sion Power Peak max. 76 - 77 GHz Re14FCR 32 dBm Nom max. 27 dBm Front Peak max. ARS513 77 GHz radar 30 dBm Rear Peak max. SRR521 77 GHz radar 30 dBm Intelli- TL1P22...
Page 308 APPENDIX Radio Com- Frequency band Output/ equip- ponent Transmis- ment sion Power Keyless ZB006 134,5 kHz < 10 mW 433,92 MHz Ride Act- e.r.p. ive Key...
Page 309: Radio Equipment Tft Instrument Cluster
RADIO EQUIPMENT TFT Changes or modifications not INSTRUMENT CLUSTER expressly approved by the party responsible for compliance For all countries without EU could void the user's authority to Model name: ICC65V2 operate the equipment. Manufacturer Le présent appareil est conforme Robert Bosch GmbH aux CNR d'Industrie Canada Robert-Bosch-Platz 1, 70839...
Page 310: Keyless Ride System Main Unit
APPENDIX Paraguay Informations concernant l'exposition aux fréquences radio (RF) La puissance de sortie émise par l’appareil de sans fil est inférieure à la limite d'exposition aux fréquences radio d'Industry NR.: 2023-03-I-0156 Canada (IC). Utilisez l’appareil de sans fil de façon à minimiser KEYLESS RIDE SYSTEM les contacts humains lors du MAIN UNIT...
Page 311 Country undesired operation of the device. Argentina This Class B digital device complies with Canadian ICES- 003. Le présent appareil est conforme aux CNR d'Industrie Canada H-28764 applicables aux appareils radio exempts de licence. Australia/New Zealand L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et...
Page 312 APPENDIX 13349 ZB005 Certificado Homologacion Numero: Israel BMBMZB22-28194 ZADI S.P.A ITALY : ‫רתיהה לעב םש‬ Morocco ZB005 : ‫ םגד‬Italy : ‫סמ רושיא ץרא‬ . 5172747 ‫נטנאה תא ףילחהל רוסא‬ AGREE PAR L’ANRT MAROC ‫ 50.334 -97.434 ה‬MHz ‫רשואמ‬ Numéro d’agrément: ‫.01 םירדת...
Page 313: Keyless Ride System Active Key
Philippines Taiwan Type Approved 取得審驗證明之低功率射頻器材，非經核准，公司、商號或使 No.: ESD-RCE-2231813 用者均不得擅自變更頻率、加大 Serbia 功率或變更原設計之特性及功能。低功率射頻器材之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。前述合法通信，指依 И005 22 電信管理法規定作業之 Singapore 無線電通信。低功率射頻器材須忍受合法通信或工業、科學及醫 Complies with 療用電波輻射性電機設備之干擾 IMDA Standards DA105282 Vietnam Sultanate of Oman TRA/TA-R/14769/22 D100428 South Africa...
Page 314 APPENDIX Model name: ZB006 Australia/New Zealand Manufacturer ZADI S.p.A. Via Carlo Marx 138, 41012 Carpi (MO), Italy Technical Information Battery type R-NZ CR2032 Brunei Nominal voltage: Operating voltage: 2,5 - 3,16 V Operating temperature: Ref. Num.: DTA-022594 -20 °C - +60 °C Canada Operating frequency LF: IC: 22239-KLRKZB006...
Page 315 L'exploitation est autorisée aux Jordan deux conditions suivantes : BMW Keyless Ride System is (1) l'appareil ne doit pas produire in conformity with Jordanian de brouillage, et technical requirements. (2) l'appareil doit accepter Malaysia tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Page 316 APPENDIX Nigeria Philippines The equipment has been found to comply with the standards of the Commission and therefore approved for connection to the Nigerian Telecommunication Network, or for use in Nigeria. Type Approved No.: ESD-RCE-2231812 Oman Serbia TRA/TA-R/14770/22 D100428 Pakistan И005 22 Singapore Complies with...
Page 317: Mid Range Radar
Technical information 取得審驗證明之低功率射頻器材，非經核准，公司、商號或使 Frequency band: 76 ‑ 77 GHz 用者均不得擅自變更頻率、加大 Output/Transmission power: 功率或變更原設計之特性及功 2,0 W (33 dBm RMS EIPR) 能。低功率射頻器材之使用 Country 不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立 Argentina 即停用，並改善至無干擾時方得繼續使用。前述合法通信，指依電信管理法規定作業之無線電通信。低功率射頻器材須忍受合法通信或工業、科學及醫 C‑22292 療用電波...
Page 318 APPENDIX undesired operation of the et utilisé avec un minimum de 20 cm de distance entre la device. source de rayonnement et votre Radiofrequency radiation corps. Ce transmetteur ne doit exposure Information: This pas etre place au meme endroit equipment complies with IC ou utilise simultanement avec un radiation exposure limits set forth autre transmetteur ou antenne.
Page 319 Mexico Sultanate of Oman IFT: RCPCOAR18-1800 OMAN - TRA D172249 Philippines TRA/TA-R/6132/18 Taiwan 警語經型式認證合格之低功率射頻電機,非經許可,公司、商號或使用者 Type Approved 均不得擅自變更頻率、加大功率 No. ESD‑1817853C 或變更原設計之特性及功能。低功率射頻電機之使用不得影響 Serbia 飛航安全及干擾合法通信;經發現有干擾現象時,應立即停用 ,並改善至無干擾時方得繼續使用。前項合法通信,指依電信法規定作業之無線電通信。低功率射頻電機須忍受合法通信或工業、科學 И011 18 及醫療用電波輻射性電機設備之 Singapore 干擾。 Complies with Vietnam IMDA Standards DA 101586...
Page 320: Short Range Radar
APPENDIX SHORT RANGE RADAR Canada Model: SRR5-B For all countries without EU IC: 4135A-SRR5B Model name: SRR521/SRR5- This device complies with Industry Canada licence-exempt Manufacturer RSS standard(s). Operation ADC Automotive Distance is subject to the following two Control Systems GmbH conditions: Peter-Dornier-Straße 10, 88131 (1) this device may not cause...
Page 321 ‫הז ללכבו ,רישכמה לש תויטוחלאה‬ (1) l’appareil ne doit pas produire ‫ייוניש‬ de brouillage; ‫וא תירוקמ הנטנא תפלחה ,הנכות‬ (2) l’utilisateur de l'appareil ‫הנטנאל רוביחל תורשפא תפסוה‬ doit acceptor tout brouillage ‫דרשמ רושיא תלבק אלב ,תינוציח‬ radioélectrique subi, même si ‫,תרושקתה‬...
Page 322: Radio Equipment Tyre Pressure Control (Rdc)
APPENDIX Singapore Vietnam Complies with IMDA Standards DA 101586 South Africa SUNTECH VN C00082015 RADIO EQUIPMENT TYRE PRESSURE CONTROL (RDC) For all countries without EU TA-2019/5066 APPROVED Model name: Wus moto gen 3 Sultanate of Oman Manufacturer OMAN - TRA LDL Technology S.A.S.
Page 323: Radio Equipment Intelligent Emergency Call
Australia South Africa TA-2019/1178 Malaysia APPROVED Taiwan 第十二條經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設計之特 RBEF/29A/0919/S(19-3776) 性及功能。第十四條低功率射頻電機之使用不得影響飛航安全 Mexico 及干擾合法通信；經發現有干擾 IFETEL: IFT/223/UCS/DG-AUSE/ 現象時，應立即停用，並改善至 2418/2019 無干擾時方得繼續使用。前項合 Morocco 法通信，指依電信法規定作業之 AGREE PAR L'ANRT MAROC 無線電通信。低功率射頻電機 Numéro d'agrément : 須忍受合法通信或工業、科學及...
Page 324 APPENDIX Model name: TL1M23NE Avis d’Industrie Canada sur Manufacturer l’exposition aux rayonnements LG ELECTRONICS INC. Cet appareil est conforme aux limites d’exposition aux 10, Magokjungang 10-ro, rayonnements d’Industrie Gangseo-gu Seoul, Republic of Canada pour un environment Korea non contrôlé. Il doit être installé Country de façon à...
Page 326 INDEX recharging disconnected Abbreviations and symbols, 4 battery, 227 removing, 228 Engineering details, 172 Technical data, 273 Self-diagnosis, 153 Warning indicators, 48, 49, Status indicators, 62 50, 51 Warning indicators, 62, 63 Bluetooth, 82 Brake fluid activating, 115 Checking fluid level, deactivating, 115 front, 207 Engineering details, 180...
Page 327 Radar sensors, 256 DTC, 33 Engineering details, 176 Washing the vehicle, 254 operating, 103 Cases, 239 Self-diagnosis, 154 Central locking operating, 130 Warning indicators, 63, 64, Chassis and suspension Technical data, 270 Warning indicator lights, 53 Check control Warning indicators, 52, 53 Dialogue, 37 Dynamic Brake Control, 190 Display, 37...
Page 328 INDEX Filler neck, 19 Left multifunction switch, 21 Fill-level indicator, 19 left side of vehicle, 18 Indicator light for engine oil My vehicle, 34 Right multifunction switch, 22, level, 54 Technical data, 268 right side of vehicle, 19 topping up, 204 Underneath the seat, 20 Engine temperature, 54, 55 operating, 103...
Page 329 Indicator lights, 24 Headlight courtesy delay Overview, 28 feature, 100 Instrument cluster Headlight flasher, opera- Overview, 24 ting, 100 Instrument panel, 24 High-beam headlight, Ambient-light brightness operating, 100 sensor, 24 Low-beam headlight, 100 operating, 74, 79, 81 Operating auxiliary head- Overview, 29, 30 lights, 101 Parking lights, 101...
Page 330 INDEX Multifunction switch Refuelling Overview, left side, 21 Fuel filler cap, unlocking, 164, Overview, right side, 22, 23 Fuel grade, 163 Remote control Navigation Replacing battery, 95 operating, 85 Rev. counter, 24 Rev. counter, 31 Riding height Off-roading, 156 adjusting, 104 On-board computer, 80 Riding mode On-board voltage, 48, 49...
Page 331 Shift assistant Transmission, 269 Engineering details, 192 Weights, 275 Gear not taught, 71 Wheels and tyres, 271 Riding, 157 Toolkit Shift lever Position on the vehicle, 20 Adjusting peg, 140 Topcase ShiftCam, 195 operating, 244 Engineering details, 195 Torques, 264 Shifting gear Traction control, 176 Recommendation to...
Page 332 INDEX Warning light, drive Warning indicator lights, 50, 51 malfunction, 55 ABS, 62, 63 Warning light, drive malfunc- Anti-theft alarm, 53 tion, 55 Bulb faulty, 51 Warning lights, 24 Cruise control, 69 Overview, 28 Distance control (Active Warnings, overview, 39 Cruise Control ACC), 69 Weights Drop sensor, 61...
Page 333 Errors and omissions excepted. © 2023 Bayerische Motoren Werke Aktiengesellschaft 80788 Munich, Germany Not to be reproduced by any means whatsoever, wholly or in part, without the written per- mission of BMW Motorrad, After Sales. Original rider’s manual, printed in Germany.
Page 334 Important data for refuelling: Fuel Premium unleaded (max Recommended fuel grade 15 % ethanol, E10/E15) 95 ROZ/RON 90 AKI Normal unleaded (power- Alternative fuel grade and consumption-related re- strictions.) (max 15 % eth- anol, E10/E15) 91 ROZ/RON 87 AKI Usable fuel capacity approx.

This manual is also suitable for:

R 1300 rt 2024

BMW Motorrad R 1300 GS Rider's Manual

General Views

Status Indicators

Instrument Cluster

Operation

Adjustment

Riding

Engineering Details

Maintenance

Accessories

Table of Contents

Technical Data

Service

Quick Links

Chapters

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BMW Motorrad R 1300 GS

Summary of Contents for BMW Motorrad R 1300 GS

This manual is also suitable for:

Table of Contents
