PARTS LIST
F O U R S T A T I O N W O R K I S L A N D
Part
Qty
A
1
Base Cabinet with Doors
B
2
Long Attaching Angle (38")
C
8
1/4-20 X .50 Hex Whiz-Lock Screw
D
8
1/4-20 Keps Nut
E
1
Table Top
F
8
#14 X 1" Mod Truss Wood Screw
O P T I O N A L A C C E S S O R I E S
Part
Qty
G
8
Mobile Base Weldment (36"D x 42"W)
H
16
1/4-20 X 1.75" Button Head Cap Screw
I
16
1/4-20 Keps Nut
J
4
4" Caster Assembly with Brake
K
4
Mobile Base Channel Cover
L
16
5/16-18 X .75" Serrated Flange Bolt
TOOLS NEEDED
#2 Phillips
3/8", 1/2",
& 7/16"
Screw
Wrench
Driver
Description
Description
5/32"
Hand
Allen
Drill
Wrench
FOUR STATION WORK ISLAND
5/32"
Drill Bit
REV 1 2.28.24
