(9)
(10)
(11)
(12)
(13)
10
Hz
-
100
Hz
100
Hz
-
1
kHz
1
kHz
-
10
kHz
10
kHz
-
100
kHz
100
kHz
-
1.0
MH2
DELAY
Controls.
The
rotary
switch
selects
one
of
five
ranges
and
the
vernier
provides
continuously
variable
control
of
each
range.
The
instrument
is
set
to
the
delay
indicated
on
the
front
panel
when
the
vernier
is
in
the
"MAX"
position.
100
ns
-
1
ous
lus
-
10
us
10
us
-
100
us
100
us
-
1
ms
1
ms
-
10
ms
ADVANCE,
DELAY,
DOUBLE
PULSE.
With
this
three
position
switch
in
the
ADVANCE
position,
the
leading
edge
of
the
output
pulse
precedes
the
leading
edge
of
the
SYNC
output.
When
in
the
DELAY
position,
the
leading
edge
of
the
SYNC
output
precedes
the
leading
edge
of
the
main
output.
When
in
the
DOUBLE
PULSE
position,
the
main
output
provides
two
successive
output
pulses
having
a
separation
determined
by
the
DELAY
(9)
controls.
PULSE
WIDTH
Controls.
The
rotary
switch
selects
one
of
five
ranges
and
the
vernier
provides
continuously
variable
control
of
each
range.
The
instrument
is
set
to
the
pulse
width
indicated
on
the
front
panel
when
the
vernier
is
in
the
"MAX"
position.
50
ns
-
l
us
1
us
-
10
us
10
us
-
100
us
100
us
-
1
ms
1
ms
-
10
ms
POLARITY
Switch.
If
the
polarity
switch
is
in
the
"+"
position,
the
main
output
pulse
will
pulse
upwards
(i.e.
to
a
more
positive
level).
If
it
is
in
the
"-"
position,
the
output
will
pulse
downwards
to
a
more
negative
level.
AMPLITUDE
RANGE
Switch.
The
rotary
switch
selects
one
of
five
ranges
and
the
vernier
(14)
provides
continuously
variable
control
of
each
range.
The
instrument
is
set
to
the
amplitude
indicated
on
the
front
panel
when
the
vernier
is
in
the
"MAX"
position.
0
to
1
Volt
(Zour
=
50
Ohm)
0
to
3
Volts
(Zout
=
50
Ohm)
0 to
10
Volts
(Zour
= 50
Ohm)
0 to
30
Volts
(Zoyrt
= 50
Ohm)
0
to
100
Volts
(Zour
=
2
Ohm)
