HAMPTON BAY CREATALIGHT 7741 Series Installation Instructions

LIMITED LIFETIME WARRANTY

This product is warranted to be free from defects in material and workmanship for the life of the product. If a defect in material or
workmanship occurs, call 1-800-562-5625 for instructions on how to have the defective product repaired or replaced free of charge.
LIMITATIONS
• This warranty only covers the assembled lighting fixture and is not extended to other components or equipment that is
used in conjunction with the product.
• This warranty is extended to the original purchaser of the product. A purchase receipt or other approved proof of purchase is
required before warranty service will be rendered.
• Unauthorized service or modification to this product or any furnished component will void the warranty in its entirety.
• THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING ANY
WARRANTY, REPRESENTATION OR CONDITION OF MERCHANTABILITY OR THAT THE PRODUCTS ARE FIT FOR ANY
PARTICULAR PURPOSE OR USE, AND SPECIFICALLY IN LIEU OF ALL SPECIAL, INDIRECT, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES (INCLUDING BUT NOT LIMITED TO ANY LOSS OF BUSINESS OR PROFITS, WHETHER
OR NOT FORESEEABLE) RESULTING FROM THE USE OF THE PRODUCT OR ARISING OUT OF ANY BREACH
OF THIS WARRANTY.
Some states or provinces do not allow the exclusion of incidental or consequential damages, so the above limitation
or exclusion may not apply.
• This warranty gives you specific rights, and you may also have other rights that vary from state to state.
NOT COVERED
• Lamp Bulb(s)
• Failure of the product as a result of an accident, abuse, negligence, alteration, or faulty installation,
or any other failure not relating to faulty material or workmanship.
• Damaged caused by separately purchased replacement bulbs.
• Corrosion and discoloration of brass components.
• Reimbursement for inconvenience, installation, setup time, loss of use, or unauthorized service.
All components UL listed
Hampton Products International Corp.
50 Icon
Foothill Ranch, CA 92610-3000
www.hamptonproducts.com
Made in China
© 2005 Hampton Products International Corp.
REVA 05/05
999-60010
Patent Pending
PAGE 4
Installation INSTRUCTIONS FOR
OUTDOOR SECURITY FLOODLIGHTS
SERIES 7741

IMPORTANT SAFETY INFORMATION

• TURN POWER OFF AT THE MAIN POWER PANEL OR FUSE BOX BEFORE INSTALLING OR
REPLACING THE FIXTURE AND/OR WHEN REPLACING THE BULBS.
• THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH ALL APPLICABLE INSTALLATION CODES BY A PERSON
FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED.
• If you are not familiar with electrical wiring, it is recommended that you secure the services of a qualified electrician who can
assure that this installation meets local, state, and national codes.
• Before installing this fixture, be sure to check with local ordinances regarding approved outdoor lighting.
• The electrical system and the method of connecting this fixture to the system must be in accordance with local, state,
and national electrical codes.
• This fixture is to be connected to a 120-Volt, 60 Hz power source.
Connecting to a different power source may create a hazard and will void the warranty.
• This fixture should be mounted to a grounded junction box marked for use in wet locations.
• This fixture is for outdoor use only.
• Do not use near or around flammable/combustible materials or liquids.
• The bulb and unit can get hot during use.
Turn off the power and allow the unit to cool down for at least 20 minutes before working on the unit.
• When replacing the bulb(s), use only a T3 Halogen bulb (150 Watt max) of the same size.
Never use a bulb with a higher wattage than the stated maximum wattage allowed for the fixture.
Using a higher wattage bulb may cause a fire hazard and/or cause damage to the unit.
• Always handle halogen bulbs with gloves or a soft cloth. NEVER touch the bulb with your bare hands.
Oil from your hand may cause the bulb to fracture when illuminated.
• If it becomes necessary to replace the lens, only use a tempered safety glass of equal thickness.
• Do not attempt to open the fixture housing. There are no serviceable parts inside.
WHAT'S INCLUDED
A – CREATaLIGHT™ Outdoor Lighting Fixture
B – EZ-N-STALL™ Connector
C – Mounting Bar
D – Mounting Bar Screws (2)
E – Ground Screw
F – Fixture Mounting Screw
G – Wire Connectors (3)
H – Fixture Mounting Screw Cover
I – Gasket
J – T3-150 Watt Halogen Bulb(s) (One bulb per head)
K – CREATaLIGHT™ Accessory Socket Cover

TOOLS YOU WILL NEED

• #2 Phillips Screwdriver
• Silicone Sealant or Caulk
SERIES 7742
H
A
K
G
D
F
I
C
E
B
PAGE 1
SERIES 7743
J
