- Page 1 The Professional Presenter Wireless Presenter User Manual Be sure to read this user manual carefully before using the wireless presenter and keep it for future reference. - 1 -...
- Page 2 The Professional Presenter WARNING This product can generate laser beam. DO NOT STARE INTO BEAM OR EXPOSE USERS OF TELESCOPIC OPTICS. Do not shine the laser beam on people's or animal’s eyes to avoid eye damage! Do not give this product to children as a toy! Warning label for red laser product: Warning label for green laser product:...
- Page 3 The Professional Presenter I. Features 1. Support previous page, next page. Click the page up key to go backward to previous page, long press to play slides from the current page. Click the down page key to go forward to the next page, long press to go into the black screen.
- Page 4 8. Supports USB 2.0 version, use operation system universal USB driver, plug and play. 9. The page up/down keys can be customized by Norwii Presenter software. The firmware of the USB receiver is updatable. II. Operation system Windows 7 / 8 / 10 / 11 or later, macOS/ Linux/ Android system.
- Page 5 The Professional Presenter IV. Specifications Transmitter Technology: Radio frequency Frequency: 2.4GHz Control Distance: 50 meters Laser Power: <1mW (Class 2) Laser Distance: >200m Wavelength: Red 640-660nm Wavelength: Green 495-545nm Battery capacity: 300mAh battery: AAAx2pcs Working Voltage: Dimension: 143.7*41.7*27mm Weight: 46.5g USB Receiver Working Voltage: 4.5-5.5V...
- Page 6 The Professional Presenter V. Function map Attention: When using this product, please change your Input Method Editors (IME) to English input mode. - 6 -...
- Page 7 The Professional Presenter VI. Function Description 1. Power switch: push up to “ON” to turn on the presenter, push down to “OFF” to turn off the presenter. 2. Page up key ： click to page up, long press to play slides from the current page.
- Page 8 The Professional Presenter Press the air mouse key again to stop the cursor movement. 7. Left mouse key ：Equivalent to the function of a computer's left mouse key. 8. Right mouse key ： Equivalent to the function of a computer's right mouse key.
- Page 9 The Professional Presenter software. It supports page up and page down keys’ function switching. The page up and page down keys correspond to the function of the up and down arrows on the computer keyboard by default and it supports page up and page down for PowerPoint and Keynote.
- Page 10 The Professional Presenter default up and down arrows on the computer keyboard. 12. The page up/down keys can be customized by Norwii Presenter software. VII. Installation 1. Install the battery The product is powered by two No. 7 AAA batteries. After opening the battery cover, put in two No.
- Page 11 The Professional Presenter "Discovered New Hardware", and the system will automatically install the driver. When Windows displays "New hardware installed and ready to use", it indicates that the USB receiver installation is complete. The attached image is as follows: (Take out the USB receiver.) (The USB receiver into the computer USB port) 3.
- Page 12 The attached image is as follows: VIII. Frequently Asked Questions 1. How download Norwii Presenter software and how to pair the presenter and the USB receiver? For products that support key function customization or highlight...
- Page 13 The Professional Presenter "Downloads" under "Support" menu of Norwii official website www.norwii.com in English version. 2. How to know if the battery is out of power? When the power is turned on, if the wireless presenter key is pressed and the LED indicator light does not indicate, it indicates that the battery is low.
- Page 14 The Professional Presenter aging. Please contact us for after- sales repair. 4. Why does the computer do not detect the device when the USB receiver plugs into the PC? Please check whether the USB works or not. You can use a USB mouse or keyboard to test the USB port.
- Page 15 The Professional Presenter but the mouse cursor keeps moving in one direction until it stops at the edge screen. Another situation when moving product horizontally or vertically, the mouse on the computer does not move horizontally or vertically, and there is an angle between the movement direction horizontal...
- Page 16 The reason is the USB receiver doesn’t save presenter’s address properly. You can use Norwii Presenter software to let the receiver save presenter’s address again. We also call this operation is to PAIR the wireless presenter and the USB receiver.
- Page 17 The Professional Presenter Preferences] - [Security & Privacy] - [Privacy] - 17 -...
- Page 18 21 CFR 1040.10 and 1040.11, except for deviations pursuant to Laser Notice No.50, dated June 24, 2007. X. Product Support Shanghai Norwii Technology Co., Ltd. Add: 2F, Building 3, No 277, Jinfeng Road, Pudong New Area, Shanghai 201201, P. R. China Tel: 86-21-51872080 Email: support@norwii.com...
