Bodine BUA1 Installation Instructions

Firstlink high & low lumen unit equipment
Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

BUA1 & BUA2
Installation Instructions
FirstLink High & Low Lumen Unit Equipment
! IMPORTANT SAFEGUARDS !
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1.
Maximum mounting height is 10 feet. For installations greater than 10 feet, consult factory to
ensure that adequate illumination will be available on the path of egress.
2. All servicing should be performed by qualified personnel only.
3. Equipment should be mounted in locations and at heights where it will not readily be subjected to
tampering by unauthorized personnel.
4. The use of accessory equipment not recommended by the manufacturer may cause an unsafe
condition.
5. Do not let power supply cords touch hot surfaces.
6. Do not mount near gas or electric heaters.
7.
Do not use this equipment for other than intended use.
8. Make sure all connections are in accordance with the National Electrical Code and any local
regulations. Turn off AC power to branch circuits to which units will be connected.
9. This product is for use in indoor or damp locations where the ambient temperature is 10°C to
40°C. Not suitable for outdoor, wet, or hazardous locations.
10. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference that may cause undesired operation.
11. This product must be grounded.
THIS PRODUCT CONTAINS A RECHARGEABLE LITHIUM-ION BATTERY.
Collierville, TN USA 38017 • Tech Support 888-263-4638 • www.bodine.com
SAVE THESE INSTRUCTIONS
THE BATTERY MUST BE RECYCLED OR DISPOSED OF PROPERLY.
Bodine © 2024 Signify Holding. All rights reserved.
WHEN USING ELECTRICAL EQUIPMENT, BASIC
SAFETY PRECAUTIONS SHOULD ALWAYS BE
FOLLOWED, INCLUDING THE FOLLOWING:
Li - ion
2/1/24
442296086571

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BUA1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bodine BUA1

Summary of Contents for Bodine BUA1

  • Page 1 SAVE THESE INSTRUCTIONS Li - ion THIS PRODUCT CONTAINS A RECHARGEABLE LITHIUM-ION BATTERY. THE BATTERY MUST BE RECYCLED OR DISPOSED OF PROPERLY. 2/1/24 Bodine © 2024 Signify Holding. All rights reserved. Collierville, TN USA 38017 • Tech Support 888-263-4638 • www.bodine.com 442296086571...

  • Page 2: Installation

    INSTALLATION Caution: Turn off AC power to the location where these products will be installed. See wiring diagram for connections to AC power. Make sure all connections are in accordance with the National Electrical Code and any local regulations. Connect white wire to neutral. Connect black wire to 120VAC or 277VAC.

  • Page 3: Wiring Diagram

    WIRING DIAGRAM BUA1 BUA2 NOTE 1: For short-term testing of the emergency function, the battery must be charged for at least one hour. The emergency driver must be charged for at least 24 hours before conducting a long-term test.

  • Page 4: Operation

    COMPLETE INSTALLATION • Snap the housing onto the backplate. • Apply AC power. Press the illuminated test button. The lamp heads should illuminate as long as the test button is depressed. • Adjust lamp heads as required (see adjustment drawing below). •...

  • Page 5: Troubleshooting Guide

    (30 seconds every 30 days) and duration tests (90 minutes every year) will be conducted automatically and the results stored in the unit awaiting download from the app. Written reports in the form of Excel “.csv” files are available through the app as well. See Bodine FirstLink App Guide (FirstLink App...
