CSL10T3
Installation Instructions
Self-Testing Emergency LED Driver
! IMPORTANT SAFEGUARDS !
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1.
This product is for use with an emergency LED lighting load and supplies nominally 10.0 W of power,
with a voltage of 15-54 VDC in emergency mode for a minimum of 90 minutes, in compliance with
NFPA 101 and NEC 700.12.
2. Make sure all connections are in accordance with the National Electrical Code or Canadian Electrical
Code and any local regulations.
3. To reduce the risk of electric shock, disconnect both normal and emergency power supplies before
servicing. Follow the instructions in the OPERATION section to disable the output of this LED driver.
4. This emergency driver is suitable for both factory or field installation.
5. This product is suitable for use in damp locations where the ambient temperature is 0ºC minimum,
+55ºC maximum. Product is also suitable for installation in sealed and gasketed fixtures. Product is
not suitable for heated air outlets and wet or hazardous locations. Maximum allowable case temp is
65ºC. See unit label for Tc measurement location.
6. An unswitched AC power source is required (120-277 VAC, 50/60 Hz).
7.
Do not install near gas or electric heaters.
8. Do not attempt to service the battery. A sealed, no-maintenance battery is used that is not field
replaceable. Contact the manufacturer for information on service.
9. The use of accessory equipment not recommended by the manufacturer may cause an unsafe
condition.
10. Do not use this product for other than intended use.
11. Servicing should be performed by qualified service personnel.
12. Equipment should be mounted in locations and at heights where it will not be subjected to tampering
by unauthorized personnel.
13. For Canadian application the output terminals should be in compliance with the accessibility
requirement of the Canadian Electric Code.
14. This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
15. This product must be grounded. See the wiring diagrams for details.
THIS PRODUCT CONTAINS A RECHARGEABLE LITHIUM-ION BATTERY.
THE BATTERY MUST BE RECYCLED OR DISPOSED OF PROPERLY.
Collierville, TN USA 38017 • Tech Support 888-263-4638 • www.bodine.com
SAVE THESE INSTRUCTIONS
Li - ion
8/5/22
Bodine © 2022 Signify Holding. All rights reserved.
442295716652
WHEN USING ELECTRICAL EQUIPMENT, BASIC
SAFETY PRECAUTIONS SHOULD ALWAYS BE
FOLLOWED, INCLUDING THE FOLLOWING:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CertaPath CSL10T3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bodine CertaPath CSL10T3

Summary of Contents for Bodine CertaPath CSL10T3

  • Page 1 SAVE THESE INSTRUCTIONS Li - ion THIS PRODUCT CONTAINS A RECHARGEABLE LITHIUM-ION BATTERY. THE BATTERY MUST BE RECYCLED OR DISPOSED OF PROPERLY. 8/5/22 Bodine © 2022 Signify Holding. All rights reserved. Collierville, TN USA 38017 • Tech Support 888-263-4638 • www.bodine.com 442295716652...

  • Page 2: Installation

    INSTALLATION Make sure the necessary branch circuit wiring is available. An unswitched source of power is required. The emergency driver must be fed from the same branch circuit as the AC driver. Installation of this emergency LED driver will vary based on the luminaire type, however, generally follow these steps: STEP 1 - DETERMINE SUITABILITY...

  • Page 3: Operation

    STEP 3 - INSTALLING THE ILLUMINATED TEST SWITCH Fixture or Test/Monitor Plate > Mount the Illuminated test switch in a location that is visible and accessible by maintenance personnel. The test switch 2 Wire mounts through a ½” hole which may need to be made in the Illuminated Test Switch luminaire or could come pre-punched by the luminaire supplier.

  • Page 4: Maintenance

    MAINTENANCE This self testing emergency driver automatically performs required routine testing. Results are reported to maintenance personnel via the indicator light. Note: Maintenance personnel should periodically check the indicator light. If the indicator light is flashing, follow steps in the Troubleshooting Guide. TROUBLESHOOTING GUIDE If the unit has encountered a problem after installation, then the Illuminated Test Switch will flash the error code with the indicator light.
  • Page 5 WIRING DIAGRAMS EMERGENCY DRIVER AND AC DRIVER MUST BE FED FROM THE SAME BRANCH CIRCUIT TYPICAL SCHEMATICS ONLY. MAY BE USED WITH OTHER DRIVERS. CONSULT THE FACTORY FOR OTHER WIRING DIAGRAMS. UL Class 2 Circuits G round LED - AC Dri ver Neutral Li ne LED +...
