Street Wrap
Installation Guide
Cutting and Sealing
Insert
Installation tools & components
1. Cut on designated cut mark.
3. Install silicone insert after cut.
Flex Side-Bend
™
End
Silicone
cap
glue
2. Clean cut end before next steps.
4. Coat end cap with silicone glue
and install.
Pipe
cutter
CAUTION
Do NOT twist and
STOP
bend this product
abruptly or severely.
This action may
cause copper trace or solder
connections to crack, resulting in
section outages along the strand.
TAKE EXTREME CAUTION WHEN
UNBOXING AND INSTALLING.
Normal flex
Unnatural bend
Section outage
Result of twist & bend
Outages caused by these actions
may void your warranty.
Unwind Flex strip from coil or reel
carefully and without twisting.
PAGE 1 OF 2
Advertisement
Table of Contents
Related Manuals for Principal LED SloanLED Street Wrap Flex Side-Bend
Summary of Contents for Principal LED SloanLED Street Wrap Flex Side-Bend
- Page 1 Street Wrap Flex Side-Bend ™ Installation Guide Cutting and Sealing CAUTION Do NOT twist and STOP bend this product abruptly or severely. This action may Insert Silicone Pipe cause copper trace or solder glue cutter connections to crack, resulting in section outages along the strand.
- Page 2 Street Wrap Flex Side-Bend ™ Installation Guide Installation NOTE: There are no pre-drilled holes in the aluminum extrusion, please drill holes accordingly to meet field requirements, using the appropriate screw. Finish Aluminum clips extrusion Mounting clips Steel chain for curve installations 1.
