Street Wrap
Installation Guide
Cutting and Sealing
Silicone
Silicone
insert
end cap
Installation tools & components
1. Cut on designated cut mark.
3. Install silicone insert after cut.
Flex Pod
™
Silicone
Pipe
glue
cutter
2. Clean cut end before next steps.
4. Apply silicone glue to silicone end
cap, making sure that cut section is
completely sealed.
CAUTION
Do NOT twist and
STOP
bend this product
abruptly or severely.
This action may
cause copper trace or solder
connections to crack, resulting in
section outages along the strand.
TAKE EXTREME CAUTION WHEN
UNBOXING AND INSTALLING.
Normal flex
Unnatural bend
Section outage
Result of twist & bend
Outages caused by these actions
may void your warranty.
Unwind Flex strip from coil or reel
carefully and without twisting.
PAGE 1 OF 2
