- Page 3 1 : L eft side panel 2: R ight side panel 3: R ear top bar 4: N ear bottom bar 5: B ottom panel 6: F ront top bar 7 : G olden aluminum bar 8: F ront inner bar 9: L eft door 10: R ight door A .
- Page 4 Connect the rear bottom bar (4)to the bottom panel (5) Use 2 cam locks (B ) to secure in the place. Connect the aluminum bar (7 ) to the front top bar (6) use 2 s crew (E )to secure in the place A ttach the bottom panel and rear boffom bar to the left side panel(1 ) and secure using 4 cam locks(B ) A ttach the rear top bar (3)to the left side panel(1 ) and secure using 4 cam locks(B )
-
Page 6: A Ttach L Egs
5. A ttach L egs Invert the cabinet and assemble the legs (H ) to the bottom panel with necessary screws (E ) 6. Install D oor H andle Install 2 door hand le(G ) to the door panel and secure using 4 screw(J) U se 7 s crews(E ) secure left side panel and rear top bar with iron sheet R epeat for the right side panel...
