- Page 3 1:Left side panel 2:Right side panel 3:Rear top bar 4:Near bottom bar 5:Bottom panel 6:Front top bar 7:Golden aluminum bar 8:Front inner bar 9:Left door 10:Right door A.Cam bolt B.Cam lock C.Cam patch D.Screw(65mm)&plastic 22mm anchor 65mm E.Screw(14mm) F.Iron sheet G.Door handle H.Gold cabinet feet I.Hinge...
- Page 4 Connect the rear bottom bar (4)to the bottom panel (5) Use 2 cam locks (B) to secure in the place. Connect the aluminum bar (7) to the front top bar (6) use 2 screw (E)to secure in the place Attach the bottom panel and rear boffom bar to the left side panel(1) and secure using 4 cam locks(B) Attach the rear top bar (3)to the left side panel(1) and secure using 4 cam locks(B) Attach the front inner top bar (8)to the left side panel(1) and secure using 2 cam locks(B)
- Page 6 5.Attach Legs Invert the cabinet and assemble the legs (H) to the bottom panel with necessary screws (E) 5.Install Door Handle Install 2 door hand le(G) to the door panel and secure using 4 screw(J) Use 7 screws(E) secure left side panel and rear top bar with iron sheet Repeat for the right side panel...
