MikroTik L11UG-5HaxD Manual

L11UG-5HaxD
L11UG-5HaxD

Safety Warnings

Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for
preventing accidents. The installer should be familiar with network structures, terms, and concepts.
Ultimate disposal of this product should be handled according to all national laws and regulations.
The product comes without enclosure and is meant to be installed into the enclosure by trained and qualified personnel. The installer is responsible for
making sure, that the Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair or modify the
device.
Please read the mounting instructions carefully before beginning installation. Failure to use the correct hardware and configuration or to follow the correct
procedures could result in a hazardous situation for people and damage to the system.
Keep this device away from water, fire, humidity, or hot environments.
Use a wrist grounding strap when unpacking and working with electrical components to avoid electrical discharge (ESD) damage. After unpacking, please
place the router on the anti-static mat. When mounting the unit, make sure there are no objects that can damage or touch the PCB plate.
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your
own risk!
To avoid contamination of the environment, separate the device from household waste and dispose of it in a safe manner, for example, in designated
areas. Become familiar with procedures for properly transporting the equipment to designated collection points in your area.
This is a Class A product. In a domestic environment, this product might cause radio interference in which case the user might be required to take
adequate measures.
Exposure to Radio Frequency Radiation: This MikroTik equipment complies with the European Union radiation exposure limits set forth for an uncontrolled
environment. This MikroTik device should be installed and operated no closer than 20 centimeters from your body, occupational user, or the general public.

Quickstart

Please follow these quick steps to set up your device:
This product comes without enclosure and is designed to be installed into the users' end products or enclosures. Compatible with the
and CA433U MikroTik enclosures.
The device comes in ESD protective packaging. When handling electrical equipment, please observe the following safety precautions:
Use a wrist grounding strap when unpacking and working with electrical components to avoid electrical discharge (ESD) damage;
After unpacking, please place the router on the anti-static mat;
When mounting the unit, make sure there are no objects that can damage or touch the PCB plate;
The device can be mounted in your desired location using the factory-provided holes in a PCB plate, located on each side of the device;
Connect the device to the included PoE injector with an Ethernet cable to the data+power end;
Connect the data end of the PoE injector to the computer;
Connect the power adapter to the PoE injector;
Configuration should be made using the WinBox configuration tool https://mt.lv/winbox ;
CA411-711
