What are Add-On Effects?
Add-On Effects are software packages that install additional high-quality effects programs on
digital consoles.
What is Open Deck?
Open Deck is an Add-On Effects package.
It emulates the tape compression created by two open reel tape recorders (a recording deck and a reproduction
deck). You can change the sound quality by adjusting various elements, such as the deck type, tape quality,
playback speed, etc.
What is VCM (Virtual Circuitry Modeling)?
VCM is a technology that enables the creation of models of element levels in analog circuits (such as resistors
and capacitors).
This technology was developed by an engineering group led by Mr. Kunimoto, an engineer who developed the
first physical modeling synthesizers, VL1 and VP1. Open Deck utilizes VCM technology.
Special Notices
• Copying of the commercially available music sequence data and/or digital audio files is strictly prohibited except for your personal use.
• The software and this Owner's Manual are exclusive copyrights of Yamaha Corporation.
• Copying of the software or reproduction of this manual in whole or in part by any means is expressly forbidden without the written
consent of the manufacturer.
• Yamaha makes no representations or warranties with regard to the use of the software and documentation and cannot be held
responsible for the results of the use of this manual and the software.
• The screen displays as illustrated in this Owner's Manual are for instructional purposes, and may appear somewhat different from
the screens which appear on your computer.
• The company names and product names in this Owner's Manual are the trademarks or registered trademarks of their respective
companies.
Studio Manager Open Deck Window
© 2003 Yamaha Corporation. All rights reserved.
1

Advertisement

   Related Manuals for Yamaha AE021

   Summary of Contents for Yamaha AE021

  • Page 1

    • Copying of the software or reproduction of this manual in whole or in part by any means is expressly forbidden without the written consent of the manufacturer. • Yamaha makes no representations or warranties with regard to the use of the software and documentation and cannot be held responsible for the results of the use of this manual and the software.

  • Page 2

    Installing Open Deck See the Add-On Effects Installation Guide for more information on installing Open Deck. Using Open Deck As with other effects, you can recall and edit the Open Deck program on the console or in Studio Manager. The basic operation is as follows: Select one of the internal effects processors.

  • Page 3

    Part Names and Functions Open Deck consists of the following main sections: • Recording deck section (page 4) • Reproduction deck section (page 5) • Open reel tape section (page 6) • Meter section (page 7) Studio Manager Open Deck Window Console screen (This is a DM2000 screen.)

  • Page 4

    In the following section: Functions marked with Studio Manager Functions marked with are available on the console. Console Recording deck section [REC DEC] Studio Manager Selects the recording deck type. You can select from four deck types: Swiss70, Swiss78, Swiss85, and America70. [RECORD]/[REC LVL] control Adjusts the input level of the recording deck.

  • Page 5

    [BIAS]/[REC BIAS] control Adjusts the bias of the recording deck. The range is from –1.00 through +1.00. [AUTO MAKE UP] switch/[MAKE UP] control If you turn on this switch or control, when you adjust the level of the recording deck (by using the [RECORD]/[REC LVL] control ), the level of the reproduction deck (the [REPRODUCE]/[REPR LVL] control ) reflects the change, maintaining the relative output level.

  • Page 6

    REPRODUCE:[-ADJUST- LOW]/[REPR LO] control Adjusts the low range gain of the reproduction deck. The range is from –6.0 through +6.0 dB. Open reel tape section [VU ADJUST] button When you turn this button on, the [VU ADJUST] control , instead of the VU meter for Channel 2, appears in the meter section.

  • Page 7

    Meter section [RECORD/REPRO] switch Enables you to select RECORD (input to the recording deck) or REPRO (output from the reproduction deck) as the signals to be monitored via the level and VU meters. Level meters Studio Manager Studio Manager displays the Effects output level. On the console, you can select the input level or output level to be displayed using the METER: [IN][OUT] switch.

  • Page 8
