MG RZUS-U9 Instruction Manual

INSTRUCTION MANUAL
(universal input, 12 points; isolated; bus-powered USB)
BEFORE USE ....
Thank you for choosing us. Before use, please check con-
tents of the package you received as outlined below.
If you have any problems or questions with the product,
please contact our sales office or representatives.
This product is for use in general industrial environments,
therefore may not be suitable for applications which require
higher level of safety (e.g. safety or accident prevention sys-
tems) or of reliability (e.g. vehicle control or combustion con-
trol systems).
For safety, installation and maintenance of this product
must be conducted by qualified personnel.
■ PACKAGE INCLUDES:
PC Recorder .........................................................................(1)
USB cable ............................................................................(1)
CD (software and users manual) ........................................(1)
■ MODEL NO.
Confirm Model No. marking on the product to be exactly
what you ordered.
■ INSTRUCTION MANUAL
This manual describes necessary points of caution when
you use this product, including installation, connection and
basic maintenance procedures. Read also the Users Manual
for the software included in the CD for maximum use of the
PC Recorder.
The RZUS is programmable using the PC configurator soft-
ware. For detailed information on the PC configuration, re-
fer to the RZMSCFG instruction manual. The RZMSCFG
PC Configurator Software is downloadable at our web site.
POINTS OF CAUTION
■ POWER INPUT
• The RZUS is a high power device supplied with 0.2A (ap-
prox.) through the USB port. The USB high power port
must be capable of 300mA power consumption. When
connecting the RZUS to a USB hub, choose the self-pow-
ered configuration.
Laptop PC's supply current may be limited by its battery
power. Confirm the USB port's current capacity in ad-
vance.
■ GENERAL PRECAUTIONS
• Before you remove the module, turn off the input signal
for safety.
■ PC RECORDER SOFTWARE
• Use the latest version of PC Recorder Software included
in the product package.
• Be sure to install the driver for the RZUS from the CD.
• Refer to the instruction manual for the MSR128 for more
information on handling the software programs.
MG CO., LTD. www.mgco.jp
5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
PC RECORDER
MODEL
■ PC
• Certain PCs are designed not to start proper services to
USB devices such as the RZUS or may cause other incon-
veniences if such devices are connected to the PC before
start-up. Be sure to disconnect such devices when start-
ing up the PC and to connect them only after that.
• The PC Recorder Software is not applicable to various
power saving features provided by the PC (suspend,
stand-by, sleep, etc.). Do not go to the power saving mode
while the software program is running.
• If the PC goes to a low-power-consumption mode (stand-
by mode), the connected RZUS also goes to suspend mode.
The RZUS will then need warm-up for 10 minutes in or-
der to re-start.
• Do not connect/disconnect the RZUS while the PC Re-
corder software program is running (when the screen is
not in pause). When connecting the RZUS, wait that all
LEDs turns on and then the RUN LED starts blinking
before starting recording.
■ COM PORT
• There are PCs which have some of their serial ports re-
served for specific devices. If such a reserved port is as-
signed as virtual COM port for the RZUS, the PC Record-
er may not operate adequately. Assign a new port other
than reserved for the PC Recorder.
• PC's plug-and-play function may automatically assign a
COM port reserved for other devices to the PC Recorder if
such port is not actually used.
• Device reservation status can be confirmed on the Win-
dows desktop at: Start > Program > Accessories > System
Tool > System Information > Components.
■ USB HUB
• In certain system configurations using a USB hub/switch,
there are possibilities of missing sampling due to delays
at the hub. We recommend not to use a hub if possible,
and to limit the number of connected devices to the mini-
mum if a hub must be used.
■ ENVIRONMENT
• Indoor use.
• When heavy dust or metal particles are present in the air,
install the module inside proper housing with sufficient
ventilation.
• Do not install the module where it is subjected to continu-
ous vibration. Do not subject the unit to physical impact.
• Environmental temperature must be within 0 to 60°C (32
to 140°F) with relative humidity within 30 to 90% RH in
order to ensure adequate life span and operation.
• Be sure that the ventilation slits are not covered with ca-
bles, etc.
RZUS-U9
EM-7622 Rev.10 P. 1 / 8
