- Page 1 W h i t e L E D L i g h t b a r I n s t a l l a t i o n and O p e r a t i o n M anu a l...
- Page 2 White LED Light Bar Installation Recommendations Please read this manual in its entirety prior to installation. The RF Driver and Power Supply may be installed outdoors but must be pro- IMPORTANT tected from rain and snow. RF Driver and Power Supply should be installed in a waterproof electrical enclosure.
-
Page 3: System Components
White LED Light Bar System Components Number Component 2-Pin 4-Way Light Cable RF Driver / Receiver 90 Watt Power Supply Adjustable Mounting Clips RF Dimming Remote 2-Pin Pigtail Cable 2-Pin 30’ Light Cable AC Power Cable Stationary Mounting Clips White Led Light Bar... -
Page 4: Installation
White LED Light Bar Installation Step 1 • Mount RF Driver/Receiver to surface using 2 screws. Note: Do not install within 20” of sauna heater and a maximum of 20” off floor. Step 2 • Locate 2-Pin 4-way cable and connect single end to 2-Pin Pigtail of Driver. Step 3 •... - Page 5 White LED Light Bar Installation Step 4 Adjustable • Determine the location where LED light will be installed. Screw Mounting Clips to sur- face ensuring even coverage of light fixture. • Take LED light bar and carefully snap bar Stationary into each clip.
- Page 6 White LED Light Bar Installation Step 6 • RF Remote includes a wall mount holder for storing. • Take holder and slide back mounting plate from holder. • At mounting location screw mounting plate to surface. • Slide holder from top down onto mounting the plate.
-
Page 7: Startup & Testing
White LED Light Bar Startup & Testing • Verify that all connections are secure and complete before proceeding. • Plug DC-out end of Power Supply into DC-in of the Driver. • Plug the Power Supply line into a 120V AC electrical outlet. •... - Page 8 White LED Light Bar Wi-Fi Setup Continued To set up Wi-Fi operation follow the steps below Note: Wi-Fi Driver supports 802.11 b / g / n 2.4 GHz Wi-Fi standard. The Wi-Fi Driver will not connect with 5 GHz network On IOS or Android download the Tuya Smart App...
-
Page 9: Specifications
PART NUM- Operating Max Watt- Dimensions Lumens (with adjusta- Voltage (VDC) (with flush clips) ble clips) BP031085 3/4W x 9/16H x 3/4W x 1-1/4H x 24V DC 11.32W 1,244 LED White BP031086 3/4W x 9/16H x 3/4W x 1-1/4H x 24V DC 14.27W... -
Page 10: Troubleshooting
Note: Resetting Driver will clear any paired remotes and require repairing. Replacement Parts Description Part Number Driver BP031108 Power Supply/90W BP031137 RF Control Single-Zone BP031111 4-Way IP67 2-PIN Splitter BP031075 2-PIN IP67 Pigtail BP031073 48” White Light Bar BP031085 60” White Light Bar BP031086... - Page 11 White LED Light Bar Notes:...
- Page 12 T e c h n i c a l S u p p o r t ( 2 2 4 ) 2 5 3 - 5 9 0 9 © 2023 Bathing Brands, Inc.
