Page 7
コネクターパネルの名称と働き HD-DEC SDTI IN (HDCAM) SDTI IN (HDCAM)(SDTI信号入力)端子(BNC型) SDTI上のHDCAMストリームを入力します。 ACTIVE THROUGH OUT(SDTI信号出力)端子 SDTI IN (HDCAM)端子に入力された信号をスルー出力します。 REF IN 75Ω終端切り換えスイッチ 75Ω REF IN端子から入力されたSYNC信号の終端ON/OFFを切り換えます。 REF IN(外部同期信号入力)端子(BNC型) 1125または525 SYNC信号を入力します。 LOOP OUT(外部同期信号出力)端子(BNC型) REF IN端子に入力されたSYNC信号を出力します。 DIGITAL OUT DIGITAL OUT(デジタル信号出力)1〜3端子(BNC型) SDTI IN (HDCAM) 端子に入力された信号が、 HD SDI信号に変換されて出力されます。 HKPF-D270 5 (JP)
Page 9
The model and serial numbers are located on the top of the unit. Record the serial number in the space provided below. Refer to them whenever you call upon your Sony dealer regarding this product. Model No. HKPF-D270 Serial No.
Page 10
Table of Contents Table of Contents Overview ..................... 3 Features of the HKPF-D270 ..............3 Connector Panel..................4 Specifications ....................5 2(GB)
The HKPF-D270 comprises the following items: Board (1) External synchronization Connector panel (1) Operation Manual (1) The HKPF-D270 can output the HD SDI signal with Maintenance Manual (1) synchronized to the external SYNC signal (1125 or Slot number labels (1 set) 525 SYNC signal).
LOOP OUT(external SYNC signal output) connector (BNC-type) Outputs the external SYNC signal input to REF IN connector. DIGITAL OUT DIGITAL OUT 1/2/3 connectors (BNC-type) Outputs the HD SDI signal converted from the input signal of SDTI IN (HDCAM) connector. HKPF-D270 4(GB)
Specifications General Output Power requirements Digital signal output +5 V DC: 1.9 A, –5 V DC: DIGITAL OUT connectors: BNC- 1.6 A type (3) Power consumption HD SDI signal conforming to the Approx. 17.5 W SMPTE-291M/292M/299M Operating temperature Output signal amplitude 800 mVp-p ±10% (at 75 Ω) 5°C to 40°C (41°F to 104°F) Storage temperature...
Page 15
(操作、保守等)と異なる目的で本マニュアルを使用す ることを禁止します。 The material contained in this manual consists of information that is the property of Sony Corporation and is intended solely for use by the purchasers of the equipment described in this manual. Sony Corporation expressly prohibits the duplication of...
