Sony VAIO VGF-WA1 Setup Manual

Wireless Digital Audio
VGF-WA1
Setup Guide
* This Setup Guide explains how to connect and set up the Wireless Digital Audio (hereinafter referred to as "this
device"). For more detailed instructions, refer to the supplied "Operating Instructions".
3-094-117-11(1) © 2007 Sony Corporation Printed in China
STEP 1 Check the contents of the carton
 Wireless Digital Audio  Remote control
 AC adapter  Power cord
 Wireless Adapter connection  Setup CD-ROM
support cable
 Operating Instructions
 Setup Guide (this leaflet)
 Warranty card
 Wireless Adapter
 USB cable
STEP 2 Plug into a power outlet
1
Connect the supplied AC adapter to this device, and then plug into a wall outlet.
The POWER lamp lights up in red.
Note
Do not disconnect the AC adapter during the setup of this device. It may cause a malfunction.

STEP 3 Install and set up the software
Q1: Do you already have a wireless LAN environment that contains an access point?
No
Q2: Do you intend to connect the Wireless Digital
Audio to a Sony VAIO computer installed with
Windows Vista?
Yes
Proceed to .


Using the supplied Wireless Adapter
1
Turn the AUTO INSTALL switch of the Wireless Adapter to ON.
AUTO INSTALL switch
2
Insert the Wireless Adapter into the USB port of the computer.
The Setup automatically starts.

Tip
If you cannot insert the Wireless Adapter directly into the USB port of your computer, connect via the supplied
Wireless Adapter connection support cable.
3
Perform the setup following the instructions on the screen of your computer.
Be sure to read the precautions on the screen thoroughly.
If you have set up the VAIO Media Integrated Server in the Setup,
the preparation is complete.
To listen to the music files that are stored on your computer (PC Streaming Function), select the desired
server from the server selection screen. This device begins to connect to the server. Select the desired
music files to start playback. Refer to the supplied "Operating Instructions" for more detailed
information on how to use this device.
If your Internet service provider instructs you to use their proxy server, use the access
point connection tool to set up the proxy server settings. For more details, refer to
"Setting up the proxy server settings for the Wireless Adapter connection" in the
"Operating Instructions" (page 54).
To use this device with Windows Media Connect or Windows Media Player, proceed to
"Preparing the computer" on the back side of this guide to set up.
Yes
No
Proceed to .

(Other side)
