- Page 1 Fan Coil Unit Installation and Operation Manual...
-
Page 2: Packing List
Fan Coil Unit Packing List TCR/TCRQ/TFM Name Qty. Fan Coil Unit Installation and Operation Manual Name Qty. Fan Coil Unit Installation and Operation Manual Remote control Name Qty. Fan Coil Unit Installation and Operation Manual Remote control... - Page 3 Fan Coil Unit Note: Installation and maintenance require qualified personnel who are familiar with local standards and rules of installation and maintenance and are experienced with these types of machines. Caution: Mind the sharp edges and surfaces to avoid scratch. ...
- Page 4 Fan Coil Unit the position of suspender bolts are right. (4) If the size of air-return pipe or air-out pipe are installed for high static pressure units, and if resistance is in accordance with the scope of operating pressures. Unit Installation (1) Installation of water pipes All the pipes including water inlet pipes and water outlet pipes must be installed according to engineering drawings and products drawings in the process of...
- Page 5 Fan Coil Unit All wiring of electricity must be in accord with regulation of national standards and local standards. Before connection, please read wiring diagram of electricity offered with unit. Ceiling Concealed FCUs: TCR (AC Motor) On top of the TCR there are waist-shape apertures for suspender. Customers are advised to use full threaded screws flat washer, lock washer and nut to make the unit sturdy when in operation.
- Page 6 Fan Coil Unit Ceiling Concealed FCUs: TCR (DC Motor) Caution:...
- Page 7 Fan Coil Unit (1) In order to fix unit, besides nut, lock washer and flat washer on the bottom, a nut and washer is recommended on the top, to make the unit steadier when operating. (2) Due to the drain pans designed incline, fan coil casing should be installed level, to ensure proper drainage.
- Page 8 Fan Coil Unit Ceiling Concealed –High Pressure FCUs: TFM On top of the TFM there are waist-shape apertures for suspender. Customers are advised to use full threaded screws flat washer, lock washer and nut to make the unit sturdy when in operation.
- Page 9 Fan Coil Unit Condensal Inlet/Outlet Motor e Water Pipe Quantity Quantity Pipe 800B 1000B 1200B 1600B 1110 1800B 1260 1083 2000B 1560 1403 1250 1373 3000B 2010 1853 1700 1823 Caution: (1) In order to fix unit, besides nut, lock washer and flat washer on the bottom, a nut and washer is recommended on the top, to make the unit steadier when operating.
- Page 10 Fan Coil Unit Ceiling Expose/Vertical Expose FCUs: TC (1) Decide the open size of the ceiling according to the units. (2) The choice of hanging base: Hanging base should be the wooden frame and reinforced concrete frame that are firm, dependable and can bear 200kg or more weight. The hanging base should bear a certain weight for a long term.
- Page 11 Fan Coil Unit Air discharge port Cassette FCUs: TKM Connection of the pipe (1) Cut the opening in the suspended ceiling to allow the fan coil to be inserted. (2) Position the tie rods and fix them to the load bearing structures. (3) Adjust the height of the unit and keep it horizontal using a leveling.
- Page 12 Fan Coil Unit Drain pipe installation The drain must be installed with a downward slope. The drain line should be insulated. If the units share the common flexible hose, large diameter is needed in order to drain out condensate water. Exhaust and pressure test of water pipes If no water is present in the coil, before filling, open air valve, then begin filling to release any air inside the coil.
- Page 13 Fan Coil Unit Before the units running, inspection procedures hereinafter must be completed: (1) All operating personnel read the handbook carefully. (2) Horizontal installation to ensure normal drainage. (3) The drain pan, coil and body are all cleaned properly. (4) Power supply of unit and controlled line of unit are all connected properly; wire of power supply connected properly;...
-
Page 14: Wiring Diagram
Fan Coil Unit Wiring diagram Model for TCR /TFM (AC Motor) - Page 15 Fan Coil Unit Model for TCR (DC Motor) 2 pipes...
- Page 16 Fan Coil Unit 4 pipes...
- Page 17 Fan Coil Unit Model for TCRQ (DC motor)
- Page 18 Fan Coil Unit Model for TC Model for TKM 300~500...
- Page 19 Fan Coil Unit Model for TKM 600~1200...
- Page 20 TIСA PRO LLC 141014, Russia, Moscow oblast, Mytishchi, Very Voloshinoy Ulitsa, office 705 and 805 Tel.: +7(495)822-29-00 E-mail: info@tica.ru www.tica.ru...
