TT-DR-CV67-030
Transformers dimmable to the
primary 120vAC.
24 watts maximum load.
Triac dimmable from 5% to 100%
Class 2
294
TITANIUM TECHNOLOGY - 2022
Voltage in
120vAC
12vDC
Voltage out
Amperage in
0,27A
Amperage out
2000mA
Power
30w
140mm x 44mm x 33mm
Size
5 1/2" x 13/4" x 11/4"
Yes
Dimmable
5% ~100% Triac
IP
67
PRODUCT CODE
TT
TT
TT
24vDC
0,35A
1250mA
-
TYPE
-
GROUP
-
DR
CV67
-
-
-
DR
CV67
-
-
-
VOLTAGE
MODEL
-
OUT
030
-
12V
030
-

Advertisement

loading
Need help?

Need help?

Do you have a question about the TT-DR-CV67-030 and is the answer not in the manual?

Questions and answers

Summary of Contents for Titanium TT-DR-CV67-030

  • Page 1 • Class 2 Amperage in 0,27A 0,35A Amperage out 2000mA 1250mA Power 140mm x 44mm x 33mm Size 5 1/2" x 13/4" x 11/4" Dimmable 5% ~100% Triac PRODUCT CODE VOLTAGE TYPE GROUP MODEL CV67 CV67 TITANIUM TECHNOLOGY - 2022...
  • Page 2 Brancher le cordon d’alimentation du transformateur à la prise électrique. Ce document peut être modifié à tout moment et sans préavis de la part de Titanium Technologie. / This document can be modified at any time and without notice from Titanium Technology.
  • Page 3 TT-U-01 / TT-U-13 / TT-U-14 / TT-U-06 TT-U-M4 Ce document peut être modifié à tout moment et sans préavis de la part de Titanium Technologie. / This document can be modified at any time and without notice from Titanium Technology. TITANIUM TECHNOLOGY - 2022...
  • Page 4 LIMITED THREE (3) YEARS WARRANTY Titanium Technology offers this limited warranty for three (3) years from the date of purchase of this Titanium Technology product (hereafter : the «Product»). A list of all the Titanium Technology YEARS products covered by this limited warranty is given at the end of this document.
