INSTALLATION
MANUAL
Bi-directional Wind-sun Sensor Instruction
DD116
Read the manual before you begin the
installation. If these instructions are not
followed, this may lead to defects and
injury in which warranty can't be claimed.
www.brel-home.com
Visit our website for more manuals and information
DD 116
Scan the QR code here for the manual to
download & view instructional videos
M O T O R S
EN
EN NL DE FR
NL DE FR
Advertisement
Related Manuals for BREL DD116
Summary of Contents for BREL DD116
- Page 1 M O T O R S INSTALLATION MANUAL Bi-directional Wind-sun Sensor Instruction DD116 Read the manual before you begin the installation. If these instructions are not followed, this may lead to defects and injury in which warranty can’t be claimed.
- Page 2 Wiring/Matchable Motors and Receivers /Installing the Motor Technical data of the motor Functions Remote Control/Settings Warning Do not operate the motor BREL-Motors declares that this in humid surroundings. motor has been manufactured according to the guidelines of the CE standard 1999/5/EC...
-
Page 3: Installing The Motor
Page 3 Matchable Motors and Receivers Uni-directional mode Image Required DC1600 DC1536 or other uni-directional receivers. DD116H Bi-directional mode Image Required DD1600H DM45EAC/S or other bi-directional receivers. DD116H Installing the Motor Note: If to change the installation position, open the power terminal box, loosen the screw and adjust to the desired position then tighten the fixed screw. - Page 4 Page 4 Technical data of the motor DD116 working voltage AC 230V Radio frequency 433.92MHz ＜20mA Working current ℃ ℃ Working temperature Radio range indoor＞30 meters Safety code 50 million times without repeat, high security WARNING: 1 Stable performance, wireless remote control.
- Page 5 Page 5 Functions Remote Control Wind grade light intensity Setting button Scan the QR code here for the manual to download & view instructional videos BLET15-0.3 Step 1 Sensor Working Principle Wind sensor Image Motor Required When breeze, the awning is open DD116H Image Image...
- Page 6 Page 6 Motor Image Required When the sunlight is lessening, the awning will be closed automatically 4:00-6:00 PM. DD116H Step 4 Sensor Grade Adjusting Reference NOTE 1 When the wind intensity exceeds the set grade, the motor runs upward after 3 seconds. 2 When the sun intensity continues to exceed the set grade, the motor runs downward after 5 minutes.
- Page 7 Page 7 Bi-directional mode switch to uni-directional mode Press and hold UP and P2 button, don't release Flash×2 After 3S, the LED After 10S, the LED After 10S, the LED The mode has indicator will be long indicator will be long indicator will be long been switched bright once, don't...
- Page 8 M O T O R S Brel Nederland b.v. info@brel-home.com...
