INSTALLATION
MANUAL
Manual Brel Bi-Directional silent motor
BEQ35-10DD
Read the manual before you begin the
installation. If these instructions are not
followed, this may lead to defects and
injury in which warranty can't be claimed.
www.brel-home.com
Visit our website for more manuals and information
BEQ35-10DD
Scan the QR code here for the manual to
download & view instructional videos
M O T O R S
EN NL DE FR
Advertisement
Table of Contents
Related Manuals for BREL BEQ35-10DD
Summary of Contents for BREL BEQ35-10DD
- Page 1 EN NL DE FR M O T O R S INSTALLATION MANUAL Manual Brel Bi-Directional silent motor BEQ35-10DD Read the manual before you begin the installation. If these instructions are not followed, this may lead to defects and injury in which warranty can’t be claimed.
- Page 2 Technical data of the motor/Reach/Charging the motor Functions remote control Settings Warning Do not operate the motor BREL-Motors declares that this in humid surroundings. motor has been manufactured according to the guidelines of the CE standard 1999/5/EC The motor must be protected from direct moisture influences.
- Page 3 Place the motor in the tube of the roller/shutter. Works with BREL HOME USB Brel-Home-USB With the Brel-Home-USB you can control your motor with your Phone. You can make a time schedule and make scenario's. The Brel-Home-USB can be connected to Siri, Google Home and Alexa.
- Page 4 Page 4 Technical data of the motor BEQ35-10 Voltage AC 230V Power 144W Torque 10 Nm Maximum motor runtime 4 min Speed 17 rpm Amperage 0.63 A Moisture and dust protection IP44 Normal Use: Heavy Use: -20°C tot +70°C -10°C tot +40°C NOTE If the motor has been running continuously for 4 minutes, it may become too hot and then stop.
- Page 5 There are 2x P2 buttons, no matter which one you press. Scan the QR code here for the manual to download & view instructional videos BEQ35-10DD Step 1 Setting up the first remote/channel The remote control can transmit 15 channels and therefore control multiple blinds.
- Page 6 Page 6 Step 3 Adjusting the direction of rotation Only possible if no end positions are set. until Press UP and DOWN button The direction of rotation of simultaneously, until the product moves. the motor is OK. Step 4 Setting the End Limits To move the motor one step: briefly press the UP or DOWN button To move the motor continuously: press the UP or DOWN button for 3 seconds (ATTENTION! Press STOP in time) 1.
- Page 7 Page 7 Additional settings Adjusting the top position Option A If adjustment is not possible, go to Resetting factory settings. until 2x STOP until STOP Press at the same time STOP Go to the new Press at the same time top position.
- Page 8 4th time and beeps 4x. To apply new settings: go to step 1 Changing Batteries Brel Netherlands B.V. is registered according to the transposition of Directive 2012/19EU (the WEEE Directive) and to the transposition of Directive 2006/66EC (the...
