396 (18*22) detection zones; sensitivity level ranges from 0 to 100; area
threshold ranges from 0 to 100.
Motion Detect
Activation event: video storage, image snapshot, log, email function and
etc.
Activation event: video storage, image snapshot, log, email function and
Video Loss
etc.
Record
Manual> Video detect>Schedule
Priority
Local Storage Support Micro SD card storage
Wire Network
1-channel wire Ethernet port, 10/100 Base-T Ethernet
Standard HTTP, TCP/IP, IPv4/IPv6, ARP, IGMP, ICMP, RTSP, RTP,
Network
UDP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, Bonjour,
Protocol
SNMP.
Platform
interface
ONVIF
Standard
Remote
Monitor, system setup, log information, maintenance , upgrade and etc
Operation
Reset
Built-in RESET button
Power Support DC12V and PoE
Power
DC 12V 2.5W MAX
Consumption
Working
-20℃~+60℃
Temperature
Working
≤95%
Humidify
Dimensions(m
¢ 110×54
m)
Weight 0.25Kg
Installation Installed in the places such as wall or the ceiling
DC 12V 3W MAX
5
