780 nm Fiber Isolator
Chapter 6 Specifications
Item #
Polarization
Fiber Type
Center Wavelength
Operating Range
Weight
Optical Specifications
Isolation @ 780 nm
a
Max Power
Insertion Loss (Without Connectors)
Polarization Extinction Ratio (PER)
Return Loss
a) The maximum power specification represents the maximum power for the combined forward and
reverse directions. Therefore, the sum of the powers in the forward and reverse directions cannot
exceed the maximum power specification.
Page 6
IO-J-780APC
Dependent
Polarization Maintaining (PM), PM780-HP
780 nm
770 - 790 nm
0.150 kg
33 dB (Min)
37 dB (Typ.)
3 W (CW)
1.0 dB (Typ.)
1.3 dB (Max)
≥ 18 dB
≥ 50 dB
Chapter 6: Specifications
TTN021776-D02
